Central Machinery 95647 Guía de referencia rápida

Model 43681

Lathe Stand

No portion of this manual or any artwork contained herein may be reproduced in any manner, shape or form

withoutthe expresswritten consentofHarbor FreightTools.

For technical questions and replacement parts, please call 1-800-444-3353.

Assembly & Operating Instructions

www.harborfreight.com

Model 95647

(For Use With Item 43681 - Gap Bed Lathe)

(LatheNotIncluded)

SAVETHIS MANUAL

Youwillneedthemanual forthesafetywarningsandcautions,assembly instructions,operatingprocedures,

maintenanceprocedures,troubleshooting,partslist,anddiagram.Keepyourinvoice withthis manual.

Writetheinvoicenumberonthe insideof thefrontcover.Keepboth thismanual andyourinvoiceina safe,

dryplace forfuturereference.

READALLINSTRUCTIONSBEFORE USINGTHIS STAND!

SPECIFICATIONS

NOTICE

TheWarnings, Cautions, andInstructionsdiscussedinthis instruction manualcannotcoverall

possibleconditionsandsituationsthatmayoccur.Itmustbeunderstoodbytheoperatorthat

commonsenseandcaution are factorswhichcannotbebuiltinto this product,butmustbe

suppliedbytheoperator.

Page 2 SKU # 95647

Material Mild Steel

Frame Metal Thickness .11” Thick Carbon Steel

Left Cabinet Inside

Dimensions 14-/14” L x 13-1/4” W x 21-31/32” H

Right Cabinet Inside

Dimensions 9-1/4” L x 13-1/4” W x 21-31/32” H

Overall Dimensions 66-15/16” L x 22-13/16” W x 27” H

Max Weight Capacity 1,320 lbs.

This Lathe Stand is designed for use ONLY with the 12” x 37” Gap Bed

Lathe (SKU 43681)

SAFETYWARNING&CAUTIONS

READALLINSTRUCTIONSBEFORE USINGTHIS STAND!

1.KEEPWORKAREACLEAN.Cluttered areasinvite injuries.

2. OBSERVEWORKAREACONDITIONS.Do notusetoolsin damp, wet, or poorlylitlocations.

Don’texposeto rain.Keepwork areawelllit. Donotuse electrically poweredequipmentin thepresence

offlammablegasesorliquids.

3.KEEPCHILDRENAWAY.Children mustneverbe allowedinthe workarea.Do not letthem handle

machines,tools,orequipment.

4. STOREIDLEEQUIPMENT. When notinuse, tools mustbelocked up inadrylocation toinhibit

rust.Alwayslockup tools andkeepout ofreachof children.

5. DONOTFORCE OR MODIFTYTHE STAND.It will do the job better and more safely at the rate

forwhich it wasintended. Do notuse inappropriate attachmentsin an attemptto exceed theStand’s

capacities.

6.DESIGNEDEXCLUSIVELYFORUSEWITH ITEM 43681--Gap Bed Lathe. STANDIS

UNSTABLEWITHOUTLATHE.Donotuse withothermachines orloads.

7. DRESSPROPERLY.Donot wear looseclothingor jewelry,asthey canbecaughtin movingparts.

Non-skidfootwear isrecommended.Wearrestrictivehair coveringto containlonghair.Alwayswear

appropriateworkclothing.

8.USEEYE, EARAND BREATHINGPROTECTION. Always wearANSI approved impact safety

gogglesif you areproducing metal filingsor wood chips.WearanANSI approveddust mask orrespirator

whenworkingaround metal,wood,and chemicaldustsand mists.UseANSIapprovedear protection

whenworkingin aloudornoisyenvironment.

9. READMANUAL.Readmanualfor the Stand and for theLathe(SKU43681)before assembly and/or

use.

10. DONOTOVERREACH.Keep proper footing and balance at all times. Donotreachoveror across

runningmachines.

11. ASSEMBLEAND INSTALLONALEVEL,FLATANDCONCRETE SURFACECAPABLE

OFSUPPOERTINGSTAND,LATHEANDALLWORKPIECES.Bolt the Standto the concrete

securelyand ensuretheStandissquare andstable berforeinstallingtheLathe.

12. DONOTEXCEEDTHEMAXIMUMWEIGHTCAPACITYOF1,320POUNDS.Place Lathe

onStand inacareful andcontrolled fashion;droppingthe Latheonthe Standmay brieflycreatean excess

load,resutlinginStandfailureandpossibledamage and/orpersonal injury.

Page 3 SKU # 95647

13.STAYALERT.Watchwhat you aredoing.Do not operate Lathe orassembleor setup this Standwhen

youaretired.

14. DONOTASSEMBLEWHILE UNDER THE INFLUENCE OFALCOHOL,DRUGS,OR

PRESCRIPTIONMEDICINES.

15.CHECK FORDAMAGEDPARTS.Before usinganytool, any part thatappearsdamaged should

becarefully checkedto determinethatitwilloperate properlyand performits intendedfunction.Checkfor

alignmentandbindingofmoving parts,anybrokenpartsor mountingfixtures,andanyother conditionthat

mayaffectproperoperation.Anypart that isdamagedshould be properlyrepairedorreplaced by a

qualifiedtechnician. Donot usethetoolifany switchdoes notturnonandoffproperly.

16.REPLACEMENTPARTSANDACCESSORIES.Whenservicing,use onlyidentical replacement

partsintended forusewith thistool. Replacementpartsare availablefromHarbor FreightTools.Useofany

otherparts willvoid thewarranty.

ASSEMBLYINSTRUCTIONS

PLEASEREFERTOTHEASSEMBLYDIAGRAMANDPARTS LISTON PAGES6AND 7 OF

THISMANUALANDTOTHE MANUALFORTHE43681LATHE

1. Position the HeadstockStand(1)andTailstockStand(11) on the shopfloor.PlacetheHeadstock

Stand(1)onthe left,andTailstock(11)on therightin the positionyouintend tooperatethe

machine.Be sure thedoors face front.

2. Usingtheincluded hardware,fastenthe Headstock ConnectingStrip (2)to theHeadstockStand

(1)andtheTailstockConnecting Strip (12)to theTailstockStand(11).Then fasten the Connect

ingPlate(4) to the twostands.

3. Compare thecenter-to-centerdistance ofthemounting holes inthetops ofthestands to thesame

distanceof themountingholes inthe headstockandtailstockofthe 43681Lathe(notincluded).

Adjustthestandssothese distances are equal. See Figure1

4. Checkto be sure that the standsareleveland stable on the shop floor. If youneedtorepairthe

floor, do itnow to besureyou haveasolid, level surfacetomount themachine.

Page 4 SKU # 95647

Figure 1. Overall dimensions of Lathe’s

oil tray. The mounting holes on the oil

tray should aling with the mounting

holes on Headstock and Tailstock

Stands.

Page 5 SKU # 95647

5. OncetheStandsare positioned properlyona solidlevelfloor,place the Lathe’soilpan on them.

Alignthemountingholesintheoilpanwiththeholes inthe Stands.Ifneeded,placeshims(notin

cludedbetween the oil/chiptrayand theLatheStands. Checkthelevel andpositionof theStands

againto besurethat whentheLathe ispositionedon thestandsand chiptrayit willbe level,solidand

alignedwiththemountingholes intheStandsandtray.

HOISTINGANDLEVELINGLATHE ONTOSTAND

WARNING:DONOTATTEMPTTOLIFTTHELATHEBYYOURSELF.

The 43681 Lathe weighs over 800 Lbs., and cannot be lifted safely by one or several strong men.

Be sure the Lathe is balanced on the hoist or lift you will use to move it before moving the Lathe.

1. Beforehoisting,lifting ormovingtheLathe,movethetailstock andaprontothefarright

endof the bedway(away from theheadstock) andlockthem inplacethere. Thiswillhelp to

balancethe overallmassofthemachine nearthe center.

2. Use pads(notincluded) toprotectthe machinefromdamage bythe equipmentusedto hoistit.

3. Use ahydrauliclift, forklift,or hoisttoposition theLatheonto theStand.Read andadhereto all

safetywarningsandinstructionsprovidedbythemanufactureroftheliftingdevicethat isbeingused.

4. When thelatheispositionedontheoil trayand Stand,align themountingholesanddropinthe

mountingbolts.

5. Check thelevelof themachine.Using aspiritlevel, check tobe sure thatthebed ofthelathe

islevel bothhorizontallyand frontto back.Ifthere isany outoflevel, correctit now.

Dependingonyourinstallation,useangledironlevelers(shims)toadjustthemachine intoexact

levelfrontto back andsideto side. Checkbothends of thetoolbefore being satisfied.

Besurethemachineislevel,positionedsolidly,andisresistanttovibration.

6. Fasten thelatheto theStandandthe Lathe’soiltray byinsertinga bolt througha lock washerfrom the

insideofthe Stand andupwardthrough theoiltray andlathe.Fasten with awasher and nut.

Repeat thisforeachofthefourmountingholesintheheadstock, andboth mountingholesin

thetailstock.Tightensecurely.Recheckandreadjustlevelifrequired.

NOTE: Periodically recheck the level of the machine to assure that it remains level while it is in use.

Page 6 SKU # 95647

Part

No. Description Qty.

1 Headstock Stand 1

2 Headstock Connecting Strip 1

3 Nut M6 6

4 Connecting Plate between

Stands 1

5 Flat Washer 6 12

6 Bolt M6x10 12

7* Tray* 1

8 Flat Washer 6

9 Spring Washer 6

10 Bolt M12x50 6

11 Tailstock Stand 1

12 Tailstock Connecting Strip 1

Stand Parts List

PLEASE READ THE FOLLOWING CAREFULLY

THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS DIAGRAM IN THIS

MANUALAS A REFERENCE TOOL ONLY: NETHER THE MANUFACTURER NOR DISTRIBUTOR

MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE

IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT OR THAT HE OR SHE IS QUALIFIED TO

REPLACE ANY PARTS OF THE PRODUCT: IN FACT THE MANUFACTURER A ND/OR DISTRIBUTOR

EXPRESSLY STATES THATALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN

BY CERTIFIED AND LICENSED TECHNICIANS AND NOT BY THE BUYER. THE BUYER ASSUMES

ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT

OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF RE-

PLACEMENT PARTS THERETO.

*Please Note: Part 7 (Tray) is not included with the Stand, but with the

43681 Gap Bed Lathe.

Page 7 SKU # 95647

Please note: Oil tray is not included

with Stand. It is a part of the 43681

Lathe

12 11

Harbor Freight Tools Co.makes every effort to assure that its products meet high quality and durability standards,

and warrants to the original purchaser for a period of ninety days from date of purchase that the motor/engine, the

belts (if so equipped), and the blades (if so equipped) are free of defects in materials and workmanship. Harbor

Freight Tools also warrants to the original purchaser, for a period of one year from date of purchase, that all other

parts and components of the product are free from defects in materials and workmanship.This warranty does not

apply to damage due directly or indirectly to misuse, abuse, negligence or accidents; repairs or alterations outside

our facilities; or to lack of maintenance.We shall in no event be liable for death, injuries to persons or property, or

for incidental, contingent, special or consequential damages arising from the use of our product. Some states do

not allow the exclusion or limitation of incidental or consequential damages, so the above limitation of exclusion

may not apply to you. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESS

OR IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS.

To take advantage of this warranty, the product or part must be returned to us with transportation charges prepaid.

Proof of purchase date and an explanation of the complaint must accompany the merchandise. If our inspection

veriﬁes the defect, we will either repair or replace the product at our election or we may elect to refund the purchase

price if we cannot readily and quickly provide you with a replacement. We will return repaired products at our

expense, but if we determine there is no defect, or that the defect resulted from causes not within the scope of

our warranty, then you must bear the cost of returning the product.

This warranty gives you speciﬁc legal rights and you may also have other rights which vary from state to state.

3491 Mission Oaks Blvd. • PO Box 6009 • Camarillo, CA 93011 • (800) 444-3353

LIMITED 90 DAY/1 YEAR WARRANTY

WARRANTY

Page 8 SKU # 95647
