PERFECTCOUNTRY 2000 EASYMOVE
Electric barbecue
Instruction manual
INDEX
1. Parts and components
2. Before use
3. Product assembly
4. Operation
5. Cleaning and maintenance
6. Technical specications
7. Disposal of old electrical appliances
8. Technical support and warranty
SAFETY INSTRUCTIONS
Read these instructions thoroughly before using the appliance.
Keep this instruction manual for future reference or new users.
Make sure that the mains voltage matches the voltage stated
on the rating label of the appliance and that the wall outlet is
grounded.
This product is designed for household use only. Do not use it
for industrial or commercial purposes.
Place the appliance on a dry, stable, flat, heat-resistant surface.
Avoid placing it close to edges.
Keep a minimum free distance of 30 cm from the device to
walls or other objects.
Make sure the product is properly assembled before operating
it.
The appliance will be very hot during and immediately
after operating. Use gloves or other convenient protection
accessories in order to avoid burns and injuries. Keep it away
from flammable substances and objects.
Do not immerse the cord, plug, or any non-removable part
of the appliance in water or any other liquid, nor expose the
electrical connections to water. Make sure your hands are dry
before handling the plug or switching on the appliance.
Do not twist, bend, strain, or damage the power cord in any
way.
Protect it from sharp edges and heat sources. Do not let it
touch hot surfaces. Do not let the cord hang over the edge of
the working surface or countertop.
Do not cover the plate with aluminium foil, this could damage
the non-stick coating.
Do not leave the appliance unattended when switched on or
still hot.
Charcoal or similar combustible fuels must not be used with
this appliance.
Pull from the plug, not from the cord, to disconnect the device
from the power supply.
Check the power cord regularlyforvisible damage. If the cord is
damaged, it must be replaced by the ofcial Technical Support
Service of Cecotec in order to avoid any type of danger.
Switch off and disconnect the device from the main plug:
In case of faults during use.
Before cleaning or moving the appliance from place to place.
After use.
Turn off all controls before disconnecting it from the power
supply.
Keep the device out of the reach of water. Do not expose it to
rain, snow or other moisture conditions.
Use only parts and components provided with the original
product by Cecotec.
The appliance must not be operated (disconnect the mains
plug immediately) when:
The appliance, casing or power cord is damaged.
The appliance shows visible signs of damage.
A fault is suspected after the appliance has been dropped or
similar.
Pay special attention to the positioning of the cord and avoid it
from touching hot parts.
Allowthe device to cool down completely before assembling or
disassembling any of its parts.
The appliance is not intended to be used by children under the
age of 12. It can be used by children over the age of 12, as long
as they are given continuous supervision.
This appliance can be used by children aged 12 and above, and
persons with reduced physical, sensory or mental capabilities
or lack of experience and knowledge, as long as they have
been given supervision or instruction concerning the use of the
appliance in a safe way and understand the hazards involved.
Do not allow children to play with the appliance.
Supervise children, they shall not play with the appliance. Close
supervision is necessary when the appliance is being used by
or near children.
PERFECTCOUNTRY 2000 EASYMOVE
1. PARTS AND COMPONENTS
Fig. 1.
1. Lid handle
2. Barbecue lid
3. Detachable temperature regulator with power cord
4. Temperature light indicator
5. Power socket
6. Grill plate
7. Fat-drip tray
8. Grill holder
9. Side food tables
10. Hook
11. Support tube A
12. Food tray holder
13. Food tray
14. Support feet
15. Support tube I
16. Support tube J
17. Wheel axis
18. Wheel
19. Wheel cover
Fig. 2.
A. ST4 x 12 screw (x8)
B. Pin (x2)
C. M6 x 70 screw (x4)
D. d20 x 5.2 nut (x2)
E. ST4 x 14 screw (x2)
2. BEFORE USE
Take the product out of the box.
Remove all packaging material.
Clean plates, fat drip tray and the grill cover with a soft, dampened cloth.
Dry them with a cloth or paper towel.
Operate the device at maximum temperature for 3-5 minutes without food.
Note: Smoke might be observed during rst use due to residual wastes from manufacture.
Make sure the grill and the fat-drip tray are clean and dry before operating.
PERFECTCOUNTRY 2000 EASYMOVE
3. PRODUCT ASSEMBLY
The food tables (9) are xed on the grill holder (8) with a ST4*12 screw (A).
Fig. 3.
Introduce the support tubes in the holes on the grill holder. There is a xing pin at the end of
the support tube, align it with the slot on the grill holder’s lower part and push it until tted into
place. A click will indicate it has been properly assembled.
Fig. 4.
Put the axle (17) through the support tube (15)(16).
Install a wheel (18) at each end of the axle (17).
Then x the wheel (18) with the pins (B) inserted into the positioning holes at both ends of the
axle (17).
Install the wheels (18) on both sides with the wheel cover (19).
Fig. 5.
The food plates (13) are respectively buckled on the food tray holder (12) of the support pipe
assembly (11), (15), 16.
Set the grill holder (8) with the oil collecting tray (7) into the hook (10).
Fix the grill holder (8) and the hook (10) with M6*70(C) nuts.
Fig. 6.
Place the grill plate (6) in the grill holder (8).
Insert the power socket (5) of the grill plate into the grill holder of the socket hole. Then, lower
the grill plate onto the grill holder.
Make sure it is cool and disconnected from the power.
Fig. 7.
The grill plate can only be used with this grill holder.
Warning: Do not unscrew these plastic feet under the grill plate. Removing the plastic feet
would reduce the gap between the grill plate and the base, which could cause the base to melt.
Use two m4x14 screws and stainless-steel at washers to screw clockwise the grill handle
and cover.
Fig. 8.
Insert the power plug into the wall socket.
Make sure the product is properly assembled before operating it.
Fig. 9.
If there is no need to use the barbecue feet, just assemble the grill plate to the grill holder and
connect the power cord.
PERFECTCOUNTRY 2000 EASYMOVE
4. OPERATION
Connect the appliance to the power supply.
Set the temperature regulator to the required temperature level. There are 5 temperature
settings, from 1 (low) to 5 (high).
The product reaches a maximum temperature of 215 +/- 25 ºC with the cover in place and of
195 +/- 25 ºC without it.
The BBQ electric grill with the grill plate (6) and grill holder (8) can be used separately and can
be moved indoors.
Recommendation: Do not place the lid to use the barbecue inside the house.
Warning: The grill plate (6) must only be used together with the product’s grill holder (8).
Fig. 10.
Note: It usually takes about 3 minutes to preheat. Preheating is faster with the cover in place.
The temperature indicator light will turn off as soon as the required temperature has been
reached.
Place the food to be grilled on the grill plate.
To turn the device off, turn the temperature regulator to the minimum position and then
disconnect it form the power supply.
Fig. 11.
Cooking time and temperature table
Note: The cooking time will depend on different factors.
Food Temperature Cooking time (minutes)
Steak/beef High 10-15
Lamb High 8-13
Chicken thighs High 15-20
Chops High 20-25
Chicken wings High 9-15
Pork llets Medium-high 7-8
Whole sh High 8-11
Kebab Medium-high 7-9
Sausages Medium-high 8-10
Green bell pepper Medium-high 5-10
Onion Medium-high 10-15
PERFECTCOUNTRY 2000 EASYMOVE
Mushrooms Medium-high 5-10
Potato Medium-high 10-15
Indoor or outdoor use
Do not screw down the plastic feet under the grill plate. This would reduce the reasonable gap
between the grill plate and the grill holder, which would lead to melting of the plastic parts.
This could lead to serious injuries and damage to the appliance.
Warnings:
Place the cord in such way that it is not dangerous and people do not trip over.
Remember to disconnect the device after use.
The barbecue can also be used indoors as a griddle.
If the device is going to be used inside the house, make sure to place at a minimum distance of
30 cm from walls and other objects.
To remove it from the rest of the unit, hold it from the handles and lift it.
Place it on a heatproof surface.
The device can be used indoors as a grill-griddle. Simply hold the product from the handles
and take it inside.
Note: It is not recommended to place the cover when using it indoors.
Outdoors use
Fig. 13.
Grilling tips
Always use tongs to turn grilled food. Using a fork to turn
the food will dry it out and damage the non-stick coating.
Only turn meat and sh once during grilling. There is no need to turn it more than once, as it
dries food out.
Never cook meat for too long. Even pork is better if it is served when it is still a little pink and
juicy.
If cooked food sticks to the grill plate, rub the plate with a piece of kitchen paper soaked in oil
from time to time.
Meat willbe more tenderwhen marinated in the refrigerator overnight before cooking. You can
make your own marinade from oil (to aid moistness), vinegar, fruit juice or wine (to tenderise)
and a mixture of seasonings for avor.
PERFECTCOUNTRY 2000 EASYMOVE
5. CLEANING AND MAINTENANCE
Turn off, unplug the product and allow it to cool down before cleaning.
Remove the temperature regulator and power cord from the device.
Clean the handle with warm water and a damp cloth.
Fat splashes can be removed with a mild cleaning agent.
Do not immerse the product in water or other liquid.
Never use strong detergents, gasoline, abrasive powder or metal brush to clean any part of
the product.
Do not hold or transport the device while it is hot.
Protect the appliance from dust and dirt if it is not to be used for a prolonged period of time.
Dry thoroughly and wrap it in a plastic bag or store it in its original box.
Store it in a cool and dry place.
The plate and fat-drip tray are dishwasher safe.
6. TECHNICAL SPECIFICATIONS
Model: PerfectCountry 2000 EasyMove
Product reference: 03113
1680-2000 W, 220-240 V~ 50/60 Hz
Degree of protection: IPX4
Made in China | Designed in Spain
7. DISPOSAL OF OLD ELECTRICAL APPLIANCES
The European directive 2012/19/EU on Waste Electrical and Electronic
Equipment (WEEE), species that old household electrical appliances must
not be disposed ofwith the normal unsorted municipalwaste. Old appliances
must be collected separately, in order to optimise the recovery and recycling
of the materials they contain and reduce the impact on human health and
the environment.
The crossed out “wheeled bin” symbol on the product reminds you of your obligation to dispose
of the appliance correctly.
Consumers must contact their local authorities or retailer for information concerning the
correct disposal of old appliances and/or their batteries.
Otros manuales para PerfectCountry 2000 EasyMove
1
Este manual sirve para los siguientes modelos
1
Tabla de contenidos
Otros manuales de Parrilla de cecotec
cecotec
cecotec Rock'nGrill Smart Manual de usuario
cecotec
cecotec Horno Manual de usuario
cecotec
cecotec Rock'nGrill Smart Manual de usuario
cecotec
cecotec PerfectSteak 4200 Way Manual de usuario
cecotec
cecotec Rock'nGrill 1500 Take&Clean Manual de usuario
cecotec
cecotec ROCK'NGRILL 2000 Manual de usuario
cecotec
cecotec ROCK'NGRILL 2000 Manual de usuario
cecotec
cecotec Txuletaco The Beast 6850 Manual de usuario
cecotec
cecotec 43400 Manual de usuario
cecotec
cecotec PerfectSteak 4250 Stand Manual de usuario
cecotec
cecotec ROCK'N GRILL 1500 TAKE&CLEAN STONE Manual de usuario
cecotec
cecotec Rock'nGrill 1500 Rapid Manual de usuario
cecotec
cecotec CHEESE&GRILL 16000 INOX BLACK Manual de usuario
cecotec
cecotec Rock'nGrill 1500 W Manual de usuario
cecotec
cecotec Rock'nGrill 700 W Manual de usuario
cecotec
cecotec Txuletaco 8000 Inferno Manual de usuario
cecotec
cecotec Rock'nGrill 1000 W Manual de usuario
cecotec
cecotec 03060 Manual de usuario
cecotec
cecotec Rock'nGrill Pro Manual de usuario
cecotec
cecotec Rock'n Grill Smart Manual de usuario
