CDA vw150 Manual de referencia
Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY
vw150 Warming Drawer
Manual for Installation, Use and Maintenance
2
Important
This appliance must only be used for the purpose for which it is
intended, i.e. domestic cooking, defrosting and reheating foods. Any
other use could be dangerous and may lead to premature failure of
the appliance.
The CDA Group Ltd cannot be held responsible for injuries or losses
caused by incorrect use or installation of this product. Please note
that CDA reserve the right to invalidate the guarantee supplied with
this product following incorrect installation or misuse of the appliance.
Under no circumstances should any external covers be removed for
servicing or maintenance except by suitably qualified
personnel.
User information:
•Warming drawers become hot during and immediately after use.
Ensure you do not touch any of the internal components.
•The drawer can become very hot during operation.
•After use, please ensure that the appliance is switched o.
•Keep children away from the appliance when in use, and
immediately after use.
Appliance information:
Please enter the details on the appliance rating plate below for
reference, to assist CDA Customer Care in the event of a fault with
your appliance and to register your appliance for guarantee purposes.
3
Appliance Model
Serial Number
CE Declarations of Conformity:
This oven has been designed, constructed and marketed in
compliance with safety requirements of EEC Directive 2006/95/EEC
(Low voltage) and requirements of EMC Directive 2004/108/EEC.
This appliance has been manufactured to the strictest standards and
complies with all applicable legislation, including Electrical safety (LVD)
and Electromagnetic interference compatibility (EMC). Parts intended
to come into contact with food conform to EEC/89/109.4
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE
PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC.
At the end of its working life, the product must be taken to a special
local authority waste collection centre or to a dealer providing
appliance recycling services. Disposing of a household appliance
separately avoids possible negative consequences for the
environment and health. It also enables the constituent materials to be
recovered, saving both energy and resources.
As a reminder of the need to dispose of household appliances
separately, the product is marked with a crossed-out wheeled dustbin.
4
Important
• Do not rest or sit on the drawer when open, as this will damage the
telescopic runners.
• The maximum capacity of the drawer is 25 kg.
• Do not cover the bottom of the warming drawer with aluminium foil
or other objects. Use only the supplied mat.
• Never pour water directly into the warming drawer.
• Do not use this appliance for heating liquids.
• To avoid scratching, do not drag dishes on the bottom of the
warming drawer.
• Use suitable containers or crockery.
• Residual condensation could eventually damage the warming
drawer and surrounding cabinets. It is advisable to dry any wet parts
when the warming drawer is cold.
• Do not store plastic or ammable objects in the warming drawer.
• We recommend the use of oven gloves or adequate protection
when removing crockery from the drawer.
• Never insert objects (e.g. screwdrivers, sharp objects, papers, etc.) in
the heating element and ventilation slots.
THE MANUFACTURER DECLINES ALL RESPONSIBILITY FOR
EVENTUAL DAMAGES CAUSED BY FAILURE TO OBSERVE THESE
INSTRUCTIONS.
5
Before First Use
Cleaning
Before using the warming drawer for the first time we recommend
that you clean it with a damp cloth, then dry thoroughly. Preheat the
empty drawer at maximum temperature for at least 2 hours.
A slightly unpleasant smell may be produced, caused by grease
remaining on the oven elements from the production process.
Using Your Warming Drawer
To open the drawer
Press the front of the drawer briey and
it will spring open slightly.
Hold the front panel and pull the drawer
open.
To close the drawer
Gently push the drawer back to its
closed position.
6
Use
• Place the dishes in the drawer.
• Set the required temperature.
• Press the power switch, which will light up to conrm the warming
drawer is switched on.
• Close the drawer gently.
• Switch the appliance o before removing the warmed dishes.
Selecting the Temperature
• The temperature knob enables a temperature adjustment between
approx. 40°C and 80°C.
• Turn the temperature knob to the required position.
• Do not force the temperature knob past the maximum position, to
prevent damage to the thermostat.
• The symbols do not indicate absolute temperature values, but
recommendations for optimum settings for cups and dishes.
Knob Position Approx Temperature Usage Information
Approx. 40°C
To prevent hot drinks from cooling too quickly,
use this temperature setting to warm the cups
to a temperature that is safe to touch.
Approx. 60°C
To prevent hot food from cooling too quickly,
use this temperature setting to warm plates or
serving dishes. The use of oven gloves or pot
holders is recommended for this setting.
Max Approx. 80°C
The thermostat is set to maximum
temperature. The use of oven gloves or pot
holders is necessary for this setting.
7
Warming Times
The time necessary for warming depends on various factors:
• Material and thickness of the dishes.
• Quantity of dishes to be warmed.
• Arrangement of dishes in the drawer.
• Temperature setting.
Therefore exact warming times cannot be provided.
With use, experience will demonstrate optimal warming times and
temperature settings.
Warming drawer capacity
The capacity of the warming drawer is 25kg.
The number of items this includes depends on the size and thickness
of your crockery.
8
Cleaning
IMPORTANT:
• Always disconnect the appliance from the power supply before
undertaking any cleaning.
• You should always allow the warming drawer to cool fully after use
before undertaking any cleaning.
• Never use high pressure water or steam cleaners.
• Do not use: detergents containing soda, acids or chlorides, abrasive
detergents (in powder or lotion), abrasive sponges (e.g. steel wool)
or sponges containing residuals of abrasive detergents, descaling
detergents, dishwasher detergents, oven sprays.
Warming drawer exterior
• Clean with a damp cloth. If it is very dirty, add a few drops of dish
washing detergent to the water. Dry with a dry cloth.
• Do not use corrosive or abrasive detergents, as they can create dull
areas. If any of these products accidentally comes into contact with
the warming drawer, immediately clean the appliance with a damp
cloth.
• Slight colour dierences on the front of the appliance are due to the
use of dierent materials, such as glass, plastic and metal.
Front panel
• Use a mild detergent and a soft window cleaning cloth or a
microfibre cloth that does not leave fibres on the surface. Wipe
horizontally, without pressing.
• Do not use corrosive products, hard sponges or rough cloths for
cleaning. Clean the aluminium surfaces with a dry cloth.
9
Antislip drawer base
• The antislip drawer base can be pulled out to clean the bottom of
the drawer. The base can be washed by hand with hot water and a
mild detergent. Dry thoroughly.
Ret the antislip base in the drawer only when completely dry.
Drawer base
It is advisable to clean the bottom of the drawer after every use,
making sure to allow it to cool. In this way grime will not accumulate
and cleaning is easier.
• Use a clean cloth, absorbent paper and dish hand-wash detergent,
or specific products for cleaning the vitroceramic top.
• Remove stubborn cooking grime with specic products.
• Remove any food residuals left on the vitroceramic top; do not leave
to harden.
• Foods with a high sugar-content (coee, fruit juice, jam, etc.) that
have boiled over or any sugar stains due to cooking must be
immediately removed.
• Do not use abrasive products, bleach, oven cleaning sprays or steel
wool.
• It is advisable to periodically treat the vitroceramic with the special
waxes available on the market.
10
PLEASE NOTE: Steam cleaners must not be used to clean this
appliance.
Do not store ammable material in the warming drawer.
Do not allow grease or food particles to build up around the door.
IMPORTANT:
When correctly installed, your product meets all safety
requirements laid down for this type of product. However, special
care should be taken around the rear or the underneath of the
appliance as these areas are not designed or intended to be
touched and may contain sharp or rough edges that could cause
injury.
Troubleshooting
If the dishes are not warm enough, make sure:
• the appliance is on.
• the right temperature has been set.
• the heat openings are not covered by large dishes or soup-plates.
• the dishes have been warmed for a long enough time.
