1| Instruction Manual

FW224

Integrated under counter larder fridge

Use and maintenance

2| Instruction Manual

Important

The CDA Group Ltd cannot be held responsible for injuries or

losses caused by incorrect use or installation of this product.

Please note that CDA reserve the right to invalidate the guarantee

supplied with this product following incorrect installation or misuse

of the appliance or use in a commercial environment.

This appliance is not designed to be used by people (including

children) with reduced physical, sensorial or mental capacity, or

who lack experience or knowledge about it, unless they have

had supervision or instructions on how to use the appliance by

someone who is responsible for their safety.

Under no circumstances should any external covers be removed

for servicing or maintenance except by suitably qualiﬁed personnel.

Appliance information:

Please enter the details on the appliance rating plate below for

reference, to assist CDA Customer Care in the event of a fault with

your appliance and to register your appliance for guarantee

purposes.

EU Declarations of Conformity

This appliance has been manufactured to the strictest standards

and complies with all applicable legislation, including Electrical

safety (LVD) 2014/35/EU and Electromagnetic interference (EMC)

2014/30/EU. Parts intended to come into contact with food conform

to 1935/2004/EC.

Appliance Model

Serial Number

Instruction Manual | 3

IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE

PRODUCT IN ACCORDANCE WITH EU DIRECTIVE 2012/19/EU.

At the end of its working life, the product must not be disposed of

as urban waste. The refrigeration system contains insulating gases

and refrigerants, which require specialised waste disposal. The

valuable materials contained in this appliance can be recycled.

It must be taken to a special local authority dierentiated waste

collection centre or to a dealer providing this service.

Before disposing of an old appliance, remove the door seals, latch

or bolt lock to avoid the risk of child entrapment.

Disposing of a household appliance separately avoids possible

negative consequences for the environment and health. It also

enables the constituent materials to be recovered, saving both

energy and resources. As a reminder of the need to dispose of

household appliances separately, the product is marked with a

crossed-out wheeled dustbin.

4| Instruction Manual

Important

Never store inﬂammable or explosive items and strong corrosive

acids or alkalis in the appliance.

This is a household appliance, which is produced in accordance

with the national standard. It is intended for food storage only, not

for storage of blood, medicine and biological products.

To prevent risk of ﬁre, keep the appliance away from petrol or any

other inﬂammables.

To prevent risk of electromagnetic interference or other accidents,

do not place a microwave oven on top of the refrigerator or use

any electric appliance inside the refrigerator.

Do not allow children to play with or near the appliance.

The internal surfaces of the fridge compartment may be very cold

when the appliance is running. Avoid touching, if possible, the

surfaces especially when hands are wet.

Do not splash water onto the appliance. Keep it away from places

of high humidity that may have adverse eect on the electric

insulation performance.

This appliance is designed to be used in ambient temperatures

between 10˚C and 32˚C. Use outside of this range may cause the

appliance to fail.

Instruction Manual | 5

Before ﬁrst use

You must allow the fridge to settle for at least twenty four hours

prior to switching the power on.

It is recommended that you clean the interior of the appliance prior

to ﬁrst use, using a solution of bicarbonate of soda and warm water

and then thoroughly drying the interior.

The fridge may have an odour to it at ﬁrst use. This will disappear

as the appliance cools.

When ﬁrst switching the appliance on it is advisable to set the

fridge to setting 3 and leaving the fridge to settle for 24 hours

before adusting the temperature to the preferred setting.

Please note:

The appliance will work continuously until it comes down to the

correct temperature.

If the appliance is switched o, you should allow ﬁve minutes

before switching it on again to prevent unnecessary damage to the

compressor.

Never store inﬂammable or explosive items and strong corrosive

acids or alkalis in the appliance.

This fridge cools your food by making the inside back of the

cavity cold. It is normal for frost to build up on this surface; it then

dissipates and drains through a small drain at the bottom, where it

evaporates harmlessly. The presence of frosting at the back is not

a malfunction of the fridge.

This refrigeration appliance is intended for use as a built-in

appliance

6| Instruction Manual

Use

Fridge

• Never put liquids in the refrigerator uncovered

• Never put hot foods in the refrigerator. Warm food should be

allowed to cool to room temperature before being put into the

refrigerator

• Nothing should rest against the rear wall of the refrigerator, as

this will cause frost and possible condensation problems which

will be dicult to remove

• Make sure food is clean and any extra water is wiped away

before putting into the fridge

• Wrap or cover food before putting into the fridge. This will

help prevent the loss of moisture, keep food fresh and avoid

unpleasant odours

• Sort foods prior to storing. Any foods to be used soon should be

stored at the front of the shelf to prevent deterioration caused by

the door being open for prolonged periods

• Do not overﬁll the fridge. There should be sucient space

between the foods to allow the cool air to circulate

• Thawing frozen foods in the fridge compartment will help to keep

the temperature low and save energy

Note: If the appliance does not have a freezer compartment ( )

it is not suitable for freezing foodstus.

Instruction Manual | 7

Storage and use

The fridge is for short term food storage. Although the

temperature can be maintained between 0-10˚C, extended

periods of food storage is not recommended.

As the cold air circulates within the fridge, the temperature can

vary between the dierent sections. As such, foods should be

stored in dierent sections according to type.

1. Butter and eggs

2. Food in jars and bottles

3. Drinks, e.g. milk

4. Cooked food

5. Yoghurts and cheese

6. Fresh meat and ﬁsh

7. Fruit and vegetables

The fridge shelves can be moved according to the storage

requirements within the fridge section. To move the shelf, lift up

the front section and then pull it outwards. To replace, slide the

shelf back into the slot, and lower the front section.

When storing root vegetables with leaves, such as carrots or

turnips, their leaves should be removed. This prevents the leaves

from absorbing nutrients from within the vegetables.

Fig.1

7 7

8| Instruction Manual

Fig. 2

Controls

Temperature control

The temperature controls for this fridge are simple and easy to

use. To change the temperature simply press the adjust button on

the right hand side of the unit to cycle through settings 1 to 5. The

warmest setting being 1 and the coldest being 5.

After changing the temperature setting, the time taken to achieve

the new temperature will depend on how big the change is from

the previous setting.

Switching on and o

When the fridge is connected to a power supply the lights

below the setting numbers will illuminate, indicating which setting is

currently being used.

To switch the appliance on and o simply press and hold the

power button on the left hand side of the unit for approximatley 5

seconds

Power Adjust

1 2 3 4 5

Instruction Manual | 9

Care and cleaning

Always disconnect the appliance

from the power supply before any

cleaning or maintenance.

The fridge and crisper sections

should be cleaned using a solution

of bicarbonate of soda and lukewarm

water. Do not use abrasive products

or detergents. After washing, rinse and

dry thoroughly.

Clean the shelves, drawers and balconies separately by hand with

a mild solution of washing up liquid and water. Do not put them in

the dishwasher.

The water drain hole at the back of the fridge compartment should

be cleaned periodically to prevent the defrosted water from

collecting inside the fridge compartment. The drain plug can be

used to clean the drain hole.

If the appliance is not to be used for prolonged periods of time,

unplug and clean the appliance. The doors should be left slightly

ajar to prevent the formation of mildew and unpleasant odours.

Fig. 3

Water Outlet

Cleaning Rod

10 | Instruction Manual

Defrosting the fridge

The fridge is self-defrosting. Any water created will run out of the

fridge through the channel at the back of the fridge.

It is important to keep the channel clear at all times using the

cleaning tool supplied.

The defrosted water is collected in the evaporating tray at the back

of the appliance and dissipated by evaporation.

If you notice a heavy build up of ice, refer to the troubleshooting

section on ice on page 11.
