CDA FW482 Guía de seguridad
Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY
FW482 integrated in column
freezer
Manual for Installation, Use and Maintenance
2
Important
The CDA Group Ltd cannot be held responsible for injuries or losses
caused by incorrect use or installation of this product. Please note that
CDA reserve the right to invalidate the guarantee supplied with this
product following incorrect installation or misuse of the appliance.
This appliance is not designed to be used by people (including
children) with reduced physical, sensorial or mental capacity, or
who lack experience or knowledge about it, unless they have had
supervision or instructions on how to use the appliance by someone
who is responsible for their safety.
Under no circumstances should any external covers be removed for
servicing or maintenance except by suitably qualified personnel.
Appliance information:
Please enter the details on the appliance rating plate below for
reference, to assist CDA Customer Care in the event of a fault with
your appliance and to register your appliance for guarantee purposes.
Appliance Model
Serial Number
CE Declarations of Conformity:
This appliance has been designed, constructed and marketed in
compliance with safety requirements of EEC Directive 2006/95/EEC
(Low voltage) and requirements of EMC Directive 2004/108/EEC.
3
This appliance has been manufactured to the strictest standards and
complies with all applicable legislation, including Electrical safety (LVD)
and Electromagnetic interference compatibility (EMC). Parts intended
to come into contact with food conform to EEC/89/109.4
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE
PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC.
At the end of its working life, the product must not be disposed of as
urban waste. It must be taken to a special local authority dierentiated
waste collection centre or to a dealer providing this service.
Disposing of a household appliance separately avoids possible
negative consequences for the environment and health deriving from
inappropriate disposal and enables the constituent materials to be
recovered to obtain significant savings in energy and resources. As a
reminder of the need to dispose of household appliances separately,
the product is marked with a crossed-out wheeled dustbin.
4
Important
Never store inflammable or explosive items and strong corrosive
acids or alkalis in the appliance.
This is a household appliance, which is produced in accordance with
the national standard. It is intended for food storage only, not for
storage of blood, medicine and biological products.
To prevent risk of fire, keep the appliance away from petrol or any
other inflammables.
To prevent risk of electromagnetic interference or other accidents,
do not place a microwave oven on top of the refrigerator or use any
electric appliance inside the refrigerator.
Do not allow children to play with or near the appliance.
The internal surface of freezer compartment is very cold when the
appliance is running. Do not touch the surface especially with wet
hands.
Do not splash water onto the appliance. Keep it away from places of
high humidity that may have adverse eect on the electric insulation
performance.
Please remove the door, door seal and shelves before disposal of the
old appliance and put them away in a safe place to prevent children
from being entrapped.
5
Before first use
You must allow the freezer to settle for at least twenty four hours
prior to switching the power on.
It is recommended that you clean the interior of the appliance prior to
first use, using a solution of bicarbonate of soda and warm water and
then thoroughly drying the interior.
The freezer may have an odour to it at first use. This will disappear as
the appliance cools.
Please note:
The appliance will work continuously until it comes down to the
correct temperature.
If the appliance is switched o, you should allow five minutes before
switching it on again to prevent unnecessary damage
to the compressor.
6
Use
Freezer
• The freezer compartments are designed to store only frozen food.
• Never put hot or warm foods in the freezer, allow them to cool fully
before putting them into the freezer.
• Follow the instructions on the food packaging for storage of frozen
food. If no information is provided, foods should not be stored for
more than three months after the purchase date.
• Store food in small packages (ideally less than 2.5kg). This reduces
the freezing time and improves the quality of the food after thawing.
• Wrap food before putting into the freezer. To stop the wrapping
sticking together, ensure it is dry.
• Label the food before freezing with information including type of
food and dates of storage and expiry.
• Once food is thawed, it must not be refrozen unless it has been
completely cooked. Only defrost as much food as is required
to prevent wastage.
• Bottled or canned drinks should not be stored in the freezer
compartment as they could explode.
• Only open the door for as long as is necessary. Leaving the
door open for long periods will aect the temperature inside the
appliance and waste energy.
• Ensure all compartments are fully closed after use.
7
Control panel
Thermostat dial
The thermostat can be set between 1
(least cold) and 5 (coldest)
When introducing large amounts of
fresh food into the freezer, turn the
thermostat dial to position 5. After 24
hours, return the thermostat dial to its
usual position.
fig. 1
45
3
21
8
Defrosting the freezer
Do not use heaters or defrosting sprays in this appliance.
• Never use any metallic or sharp objects to remove the ice as this
could damage the lining.
• The freezer compartment should be defrosted regularly to ensure
the most ecient running of the freezer.
• Once the ice is more than 5mm thick, the freezer should be
defrosted.
• First remove the freezer drawers.
• To speed up the process, place a bowl of warm water in the base of
the freezer compartment.
Once defrosting is complete, dry the inside of the freezer
compartment with a sponge or clean cloth.
The freezer should be cleaned using a solution of bicarbonate of soda
and lukewarm water. Do not use abrasive products or detergents.
After washing, rinse and dry thoroughly.
Clean the drawers separately by hand with soap and water. Do not put
them in the dishwasher.
Once cleaning is complete, then reconnect the power.
9
Troubleshooting
If you have any problems with your appliance, you should check
the troubleshooting prior to calling CDA Customer Care to prevent
unnecessary service calls and potential cost.
If the appliance is not working
• Check there is power to the appliance:
• The house fuses are intact and the fuse in the plug has not blown.
• The plug socket is functioning fine. To check this, plug another
electrical appliance in to see if the socket is working.
• The temperature of the room is adequate (10°C or above).
The appliance is working, but not very well
• The appliance is not overloaded.
• The thermostat is set to an appropriate temperature.
• The door is closing properly.
• The cooling system at the rear of the appliance is clean and free of
dust, and not touching the rear wall.
• There is enough ventilation at the side and rear walls.
• The temperature of the room is adequate (10°C or above).
The appliance is noisy
• The appliance is level and stable.
• The side and rear walls are clear, and there is nothing resting on the
appliance.
• The cooling gas in the refrigerator will make a slight bubbling noise,
even when the compressor is not running.
10
fig. 2
Installation
Product Dimensions and aperture
required for installation:
Your refrigerator is designed to be
installed into a standard larder unit
of width 560-570mm and depth of
550mm. the diagram below shows
the product dimensions and aperture
required.
Note also the arrows on the diagram
show ventilation requirements. In the
diagram a plinth vent is fitted to allow
free air into the cabinet. This is not
necessary where there is already a free
air supply into the run of units provided
by a vent in another unit (or side of the
run)
90°
