Cata IHD60SV Hoja de especificaciones

60901880_00 IHD60SV

IHD60SV

GB IE

[01] x 1

[03] x 2

[02] x 1

[06] x 1

[04] x 1

TEMPLATE

[05] x 1

x 2

Let's

get started...

Getting started... 04

Before you start 05

Safety 07

In more detail... 11

Product functions

Operation

Care and maintenance

Troubleshooting

Recycling and disposal

Technical and legal information

CE Declaration of conformity

Appendix

GB IE

Installation

Information for EU66 21

Getting

Started...

Getting started...

GB IE

Before you start 05

Safety 07

Before you start

To avoid the risks that are always present when you use

an electrical appliance it is important that this appliance is

installed correctly and that you read the safety instructions

carefully to avoid misuse and hazards. Please keep this

instruction booklet for future reference and pass it on to any

future owners. After unpacking the appliance please check

that it is not damaged. If in doubt, do not use the appliance

but contact Customer Services on 0344 800 1128 (UK),

01 4475261 (Ireland).

Check the package and make sure you have all of the parts

listed.

Decide on the appropriate location for your product.

or handling to prevent personal injury or damage to the

product.

ordering replacement parts.

If you sell the appliance, give it away, or leave it behind

when you move house, make sure you also pass on this

manual so that the new owner can become familiar with the

appliance and its safety warnings.

Getting started...

GB IE

Before you start

Ø6mm

Tools required

Accessories not supplied

Ø125mm or Ø150mm

VENT PACK 2 (UK & IE)

Recirculation Extraction

SELF ADHESIVE

ALUMINIUM TAPE

3.9 x 32 mm

Short Screw for cabinet & door

Wall Plug Ø6mm

CARBFILT1 (UK &IE)

CARBON FILTER ORDERING HOTLINE

0344 800 1128 (UK) 01 4475261 (IE)

x 4

x 8

x 4

Getting started...

GB IE

Safety

Getting started...

GB IE

These instructions are for your safety. Please

read through them thoroughly prior to

installation and retain them for future reference.

•All installation work must be carried

electrician.

•This appliance must be installed correctly

following the manufacturer’s instructions.

ThisappliancecomplieswithallcurrentEuropean

safetylegislation,however,theManufacturermust

emphasise that this compliance does not prevent

the surfaces of the appliance from heating up

duringuse andremaininghotduring itsoperation.

Accessible parts may become hot during use.

Young children should be kept away. Care should

be taken to avoid touching the appliance

The Manufacturer highly recommends that this

appliance be kept out of the reach of babies and

small children.

Thisappliancecanbeusedbychildrenagedfrom

8 years and above and persons with reduced

physical, sensory or mental capabilities or lack

of experience and knowledge if they have been

given supervision or instruction concerning use of

the appliance in a safe way and understand the

hazards involved. Children shall not play with the

appliance. Cleaning and user maintenance shall

not be made by children unless they are older

than 8 and supervised.

Safety

Getting

started...

GB IE

Keep the appliance and its cord out of reach of

children less than 8 years.

Means for disconnection must be incorporated

rules. An all-pole disconnection switch having a

contact separation of at least 3 mm in all poles

Regularly check the power plug and power cord

for damage. If the supply cord is damaged,

it must be replaced by the manufacturer, its

order to avoid a hazard.

Do not allow the electric cables to touch the

hot parts of the appliance.

Make sure that the power cord is not caught

under or in the appliance and avoid damage to

the power cable.

Do not install the appliance outdoors in a

damp place or in an area which may be prone

to water leaks such as under or near a sink

unit. In the event of a water leak allow the

machine to dry naturally.

to the appliance.

Please dispose of the packing material

carefully.

to the appliance.

Safety

Getting started...

GB IE

We also recommend that great care be taken

during use and cleaning. Read the cleaning

and maintenance sections for this appliance

carefully.

A steam cleaner is not to be used.

The appliance is not intended to be operated

by means of external timer or separated

remote-control system.

The appliance is for domestic use only.

Warning: Consult local regulations regarding

fumes outlets. Do not connect the hood to

that room ventilation is appropriate with the

local authorities. Make sure the maximum air

room does not exceed 4 Pa (0.04 mbar). The

room must have adequate ventilation if an

extractor hood is used simultaneously with

appliances that run on gas or other fuels. The

used for exhausting fumes fromappliances

burning gas or other fuels. Regulations

regarding air extraction must be complied with.

Warning: Before connecting the hood: switch

off the electricity supply and check that the

supplied voltage and frequency coincide with

that indicated on the appliance nameplate.

Safety

Getting

started...

GB IE

Warning: The hood may stop working during

an electrostatic discharge (e.g. lightning). This

involves no risk of damage. Switch off the

electricity supply to the hood and reconnect

after one minute.

regularly and closely watch and regulate pans

containing hot oil.

Do not use the hood if it shows signs of

damage or imperfection. Contact customer

services.

Flambe cooking must not be carried out

underneath this appliance.

When installing the appliance, make sure

that the following distances between the top

of cooker or hob and the lowest part of the

cooker hood must be observed:

> Gas hobs: 750mm.

> Electric hobs: 650mm.

The Manufacturer declines all liability for

personal or material damage as a result of

misuse or incorrect installation of this appliance.

Warning

cleaning is not carried out in accordance with

the instructions.
