WSD-F21HR

User’s Guide

Thank you for purchasing this watch.

Before trying to use this watch, be sure to read the Safety Precautions in

the Quick Start Guide that comes with it. Make sure you use the watch

correctly.

Contents

Introduction ....................................................................................... EN-3

Watch Features ............................................................................ EN-4

Measurement Functions ............................................................... EN-6

Overview ...................................................................................... EN-8

About This Manual ....................................................................... EN-9

Getting Ready ................................................................................. EN-10

Initial Default Settings for Heart Rate Measurement ................... EN-15

Basic Operations You Should Remember ................................... EN-18

Using Outdoor Watch Functions -

Using CASIO Watch Faces and Apps ........................................... EN-23

Using CASIO Watch Faces ........................................................ EN-24

Using the “Heart Rate” Watch Face ............................................ EN-27

Using the Location Memory App ................................................ EN-34

Using Point Navigation ............................................................... EN-43

Using the TOOL App .................................................................. EN-46

Using the Activity App ................................................................ EN-61

Using the MOMENT SETTER App ............................................. EN-74

Using the Multi Timepiece App ................................................... EN-78

Common Outdoor Function Settings .......................................... EN-82

Troubleshooting ........................................................................... EN-103

EN-1

Important! ...................................................................................... EN-105

Precautions During Use ............................................................ EN-105

User Maintenance .................................................................... EN-117

Chargeable Battery Handling (Please recycle!) ........................ EN-118

Personal Information Protection Precautions ............................ EN-118

Wearing the Watch ................................................................... EN-119

Main Specifications ...................................................................... EN-121

Supplementary Information ......................................................... EN-127

EN-2

Introduction

Attention iPhone Owners!

●When using this watch while it is paired with an iPhone, be sure to have the

Wear OS by GoogleTM app running on the iPhone. If the Wear OS by Google

app is not running, functions that require communication with the iPhone

will not operate.

●Some watch functions are restricted when it is paired with an iPhone. For

details, visit the website below.

https://support.casio.com/wsd/en/

EN-3

Watch Features

Dual-layer Display for Improved Readability

Your watch comes with a dual-layer color and monochrome display. The

monochrome display provides a high level of information readability in

sunlight, along with low-power operation. The monochrome display is

designed to show a greater amount of information (compared with previous

CASIO products).

Heart Rate Monitor

The watch can be used to monitor your approximate heart rate while you are

wearing it. You can view your current heart rate as well as your specified heart

rate zone*1 on the “Heart Rate” watch face, or by using the Activity app.

*1 To display the heart rate zone, you need to use initial settings to specify

a resting heart rate and maximum heart rate.

Powered with Wear OS by Google

Google, Android, Wear OS by Google, Google Play and other related marks

and logos are trademarks of Google LLC.

Wear OS by Google works with phones running AndroidTM 4.4+ (excluding

Go edition) or iOS 10+. Supported features may vary between platforms and

countries.

Five-atmosphere Water Resistance + MIL-STD*2

Even though this watch has a built-in voice recognition microphone, it still is

water resistant up to five atmospheres. This means you can wear your watch

while swimming, fishing, etc. MIL-STD-810G standard environment

resistance allows you to wear your watch while engaged in a variety of

vigorous outdoor activities, including: trail running, mountain climbing, cycle

sports, fishing, and more.

*2 United States Department of Defense Military Standard

EN-4

Built-in GPS

This watch has GPS*3 built in, and you can acquire location information

without connecting with a phone. The watch itself can display a map*4 of your

current location, measure and record data for a variety of activities, and more.

*3 In addition to GPS (U.S.), your watch also supports GLONASS (Russia)

and QZSS (Japan) positioning. This manual uses “GPS” to refer to all of

the above positioning systems.

*4 To display the map when you do not have a smartphone, you need to have

the map data downloaded beforehand.

Three Side Buttons Designed for Sure Operation

The three side buttons are designed for sure operation even when outdoors.

Apps can be freely assigned to the MAP button and the APP button.

EN-5

Measurement Functions

Your watch can take barometric pressure, altitude, bearing, and other

readings. Its built-in watch faces and applications can use readings for display

and other useful functions. Note that this watch is not a special purpose

measuring instrument. Readings produced by measurement functions are

intended as general reference information only.

Compass (Bearing Measurement)

For serious mountain climbing and other activities that require accurate

bearing readings, take along a highly reliable compass to use in combination

with the watch’s compass.

Important!

●Note that accurate compass readings and/or correction will not be possible

in the areas described below.

ーIn the vicinity of a permanent magnet (magnetic accessory, etc.), metal

objects, high-voltage wires, aerial wires, or electrical household

appliances (TV, computer, cellphone, etc.)

ーOn trains, on boats, on aircraft, etc.

ーIndoors, especially inside of reinforced concrete structures.

EN-6

Altimeter, Barometer

The watch’s Altimeter uses a pressure sensor to measure barometric

pressure, and then calculates and displays relative altitude based on the

measured value. Because of this, readings taken at different times at the

same location may produce different altitude values due to changes in

temperature, humidity, barometric pressure, and other factors. Also note that

values displayed by the watch may be different from elevations indicated for

areas where you are located. When using the watch’s altimeter while

mountain climbing, it is recommended that you perform regular correction in

accordance with the local altitude (elevation) indications.

Tide Graph (Graphic Display of Tide Information)

The Tide Graph feature of your watch is intended to provide a rough image

of current tide conditions. Do not use its tide information for navigation

purposes. For navigation purposes, be sure to use official tide charts issued

by a reliable agency or authority for the area you are navigating.

EN-7

Overview

Package Contents

Watch, AC adaptor, charger cable, Quick Start Guide, warranty

General Guide

①

②⑤

⑥

⑦

⑧⑨

③

④

ACharge LED

BCharger terminal

CPressure sensor

DMicrophone

EMAP button

FPower button

GAPP button

HTouch screen

IOptical sensor (PPG Heart

Rate)

EN-8

About This Manual

●The contents of this manual are subject to change without notice.

●Copying of this manual, either in part or its entirety, is forbidden. You are

allowed to use this manual for your own personal use. Any other use is

forbidden without the permission of CASIO COMPUTER CO., LTD.

●CASIO COMPUTER CO., LTD. shall not be held liable for any lost profits

or claims from third parties arising out of the use of this product or this

manual.

●CASIO COMPUTER CO., LTD. shall not be held liable for any loss or lost

profits due to loss of data caused by malfunction or maintenance of this

product, or any other reason.

●The watch and sample screens depicted in the illustrations in this manual

may be different from the actual appearance of the watch.

EN-9
