Casio 3069 Manual de usuario

Module No. 3069

Getting Acquainted

Congratulations upon your selection of this CASIO watch. To get the most out

of your purchase, be sure to read this manual carefully.

•Be sure to keep all user documentation handy for future reference.

Applications

The built-in sensors of this watch measure direction, barometric pressure,

temperature and altitude. Measured values are then shown on the display.

Such features make this watch useful when hiking, mountain climbing, or

when engaging in other such outdoor activities.

E-1

Warning!

•The measurement functions built into this watch are not intended for

taking measurements that require professional or industrial precision.

Values produced by this watch should be considered as reasonable

representations only.

•When engaging in mountain climbing or other activities in which losing

your way can create a dangerous or life-threatening situation, always be

sure to use a second compass to confirm direction readings.

•Note that CASIO COMPUTER CO., LTD. assumes no responsibility for

any damage or loss suffered by you or any third party arising through

the use of this product or its malfunction.

E-2

Keep the watch exposed to bright light

The electricity generated by the solar cell of the

watch is stored by a built-in battery. Leaving or

using the watch where it is not exposed to light

causes the battery to run down. Make sure the

watch is exposed to light as much as possible.

•When you are not wearing the watch on your

wrist, position the face so it is pointed at a

source of bright light.

•You should try to keep the watch outside of

your sleeve as much as possible. Charging is

reduced significantly if the face is covered only

partially.

Bright light

Solar cell

E-3

•The watch continues to operate, even when it is not exposed to light.

Leaving the watch in the dark can cause the battery to run down, which will

cause some watch functions to be disabled. If the battery goes dead, you

will have to re-configure watch settings after recharging. To ensure normal

watch operation, be sure to keep it exposed to light as much as possible.

Bright light

Electrical

energy

All

functions

enabled

LEVEL 1

LEVEL 2

LEVEL 3

LEVEL 4

Charge

Solar cell

(Converts light to

electrical power.)

Rechargeable battery

LEVEL 1

LEVEL 2

LEVEL 3

LEVEL 4

Some

functions

disabled

Dis-

charge

Battery charges in the light. Battery discharges in the dark.

E-4

•The actual level at which some functions are disabled depends on the

watch model.

•Frequent display illumination can run down the battery quickly and require

charging. The following guidelines give an idea of the charging time

required to recover from a single illumination operation.

Approximately five minutes exposure to bright sunlight coming in through

a window

Approximately 50 minutes exposure to indoor fluorescent lighting

•Be sure to read “Power Supply” (page E-108) for important information

you need to know when exposing the watch to bright light.

If the display of the watch is blank...

If the display of the watch is blank, it means that the watch’s Power Saving

function has turned off the display to conserve power.

•See “Power Saving” (page E-126) for more information.

E-5

About This Manual

•Depending on the model of your watch, display

text appears either as dark figures on a light

background, or light figures on a dark

background. All sample displays in this manual

are shown using dark figures on a light

background.

•Button operations are indicated using the

letters shown in the illustration.

•Each section of this manual provides you with

the information you need to perform operations

in each mode. Further details and technical

information can be found in the “Reference”

section.

•To ensure that this watch provides you with the

years of service for which it is designed, be

sure to carefully read and follow the

instructions under “Operating Precautions”and

“User Maintenance”.

(Light)

E-6

Contents

General Guide ................................................................................. E-10

Radio-controlled Atomic Timekeeping ........................................... E-12

Digital Compass ............................................................................... E-32

Barometer/

Thermometer .................................................................E-54

Altimeter .......................................................................................... E-61

Altitude Data Recall ........................................................................ E-83

World Time ........................................................................................ E-89

Stopwatch ........................................................................................ E-91

Countdown Timer ............................................................................. E-93

Alarms .............................................................................................. E-95

Illumination ...................................................................................... E-98

Questions & Answers ....................................................................E-102

Power Supply ................................................................................. E-108

Timekeeping ...................................................................................E-116

Reference ........................................................................................E-122

Specifications .................................................................................E-140

E-7

Procedure Lookup

The following is a handy reference list of all the operational procedures

contained in this manual.

To specify your Home City ............................................................. E-13

To perform manual receive .............................................................E-25

To turn auto receive on and off ....................................................... E-27

To check the latest signal reception results ................................. E-28

To enter and exit the Digital Compass Mode ................................. E-33

To take a direction reading ............................................................. E-34

To perform magnetic declination correction .................................E-41

To perform bidirectional calibration .............................................. E-43

To perform northerly calibration ..................................................... E-44

To store a compass reading in Bearing Memory .......................... E-46

To set a map and find your current location .................................E-49

To find the bearing to an objective ................................................ E-50

E-8

To determine the direction angle to an objective on a map

and head in that direction ......................................................... E-51

To take barometric pressure and temperature readings ............. E-54

To display your current altitude ...................................................... E-65

To select the altitude measurement type ....................................... E-67

To select an Altimeter Mode display format ................................. E-68

To start a new save session ........................................................... E-70

To set a reference altitude ............................................................... E-77

To reset the altitude differential value to zero .............................. E-80

To use altitude differential measurement ..................................... E-81

To view periodic records and current session record contents .. E-86

To view historical record contents ................................................ E-87

To clear the historical record ......................................................... E-88

To view the time in another city ...................................................... E-89

To toggle a city code time between Standard Time and

Daylight Saving Time ................................................................. E-90
