Casio SE-S10 Instrucciones de funcionamiento

Load Memory Protection Batteries and Paper Roll

A) Remove the printer cover

B) Open Battery compart

ment cover

C) Insert 2 new “AA”type batteries

into the compartment

D) Install the supplied 58mm thermal paper roll by lifting up

the platen arm (Push open button) and placing the paper

roll into the printer well. Close the cover firmly.

Initialize Your Cash Register

Insert the supplied key and turn

to the “OFF”position. B)

Plug the power cord into the AC outlet and wait for

the instructional messages to print.

IMPORTANT Be sure that the plus (+) and minus (-) ends of the batteries

are facing in the directions indicated in the illustration inside the

battery compartment.

To prevent losing all of your settings and sales

data, we recommend you install the two memory

protection batteries.

Choosing the Language

A) For English select the following:

Please also refer to printout instructions from the cash register

To set for

journal

printing

To set for receipt printing

Turn key to the PGM position

Perform steps below.

Setting Date and Time

Input date and time as indicated on the printout chit on the cash

A) Turn key to the

Z position

B) Perform the following sequence

Note: This operation automatically sets correct tax

rates, rounding, and receipt formats to Australian

standards.

Setting for Australian Standards

A) Turn key to the PGM position

position

B) Press

To enable

C) Press Press departments as required

D) Press

If using shift departments

otherwise skip this step

To disable use same sequence except use in place of

Australian Quick Programming Guide

Casio SE-S10 (please refer to the supplied “User Manual”for further information)

“

Flash Report

A flash report

is a useful tool

to monitor how much money has been taken throughout the trading day

A) Turn Key to the Xposition

B) Press

Electronic Journal Report

The electronic journal records most operations that are performed at the cash register. Data can be printed out

if a hard copy is required and it is also possible to designate a read range by date and or consecutive number.

(Please refer to the user manual for additional information on this feature)

Note: This operation will print and reset the Electronic Journal print only is performed from X mode please refer User Manual for more

details

The following operation will print the end of day financial report.

Note: Using XMode will print only while ZMode will print and reset the figures ready for the next trading day.

Daily End of Day Report

A) Turn Key to the Zposition

B) Enter 58

Turn key to the PGM position

Perform steps below.

Setting GST to Departments

Printer switch for receipt or Journal

ó Receipt message 1st line

YOUR RECEIPT

ó Receipt message 2nd line

THANK YOU

ó Receipt message 3rd line

CALL AGAIN

ó Receipt message 4th line

ó Receipt message 5th line

Australian Quick Programming Guide

Casio SE-S10 (please refer to the supplied “User Manual”for further information)

Setting descriptors to PLU’s

A) Turn Key to PGM mode

B) Press

C) Press

D) Enter

E) Press

The following sequence will program the descriptor “DAIRY”to PLU

number 1.

Linking PLU’s to Departments

Linking PLU’s to departments is only required if you are using PLU’s.

This process aids end of day reporting by grouping products (PLU’s)

with departments

A) Turn Key to PGM mode

B) Press

C) Enter

D) Press

The SE-S10 contains 20 departments, 5 are located on the keyboard and

an additional 15 are accessible using the department shift function.

Prices can be set to departments if required or entered manually from

with

in the sale.

B) Press

D) Key price then press department key

A) Turn Key to PGM mode

Note: Press dept shift once to access departments 6~10 or twice

for 11~15 e

tc.

IMPORTANT: Never

use decimal point key when imputing

price.

C) Press Dept Shift if programming shift departments

otherwise skip to step D

A) Turn Key to PGM mode

B) Press

C) Press

D) Enter

E) Press

The SE-S10 does have the option of 500 PLU’s. A PLU lookup function is

provided should you decide to use PLU’s on this register.

E) Press

Setting Descriptors to Departments

A) Turn Key to PGM mode

B) Press

D) Enter

E) Press

C) Press

The following procedure will program the descriptor “DAIRY”to Department number 1.

Programming Receipt Message

You can program receipt message text at

the top of the receipt. Up to 5 lines of text

can be programmed.

Receipt message sample

Links PLU1 to

Department 4

This procedure sets $1.00 to PLU1.

Note: button is used to add a space or to lock a character if more than one character is used from a single key in

succession. An example of how this button is used is shown in section 13 - “Receipt Text Programming”.

Setting prices to Departments

Setting prices to PLU’s
