Casio RE-700 Guía de solución de problemas

RE-700(ZX-735)

(without price)

AUG. 1995

INDEX

OUTLINE ....................................................................................................................... 1

SPECIFICATIONS ......................................................................................................... 1

GENERAL GUIDE ......................................................................................................... 3

BATTERY REPLACEMENT.......................................................................................... 6

RESET OPERATION..................................................................................................... 7

TO SAVE THE DATA TO ANOTHER MACHINE.......................................................... 8

LSI PIN FUNCTION..................................................................................................... 10

DIAGNOSTIC PROGRAM........................................................................................... 12

ERROR MESSAGES................................................................................................... 13

SCHEMATIC DIAGRAM.............................................................................................. 14

EXPLODED VIEW ....................................................................................................... 15

PARTS LIST ............................................................................................................... .16

CONTENTS

— 1 —

OUTLINE

The unit checks spelling for you, and tells you the correct hyphenation of a word using a dictionary of

approximately 115,000 words. You can even use wild card characters to look up words. The unit has also the

digital diary functions such as Telephone Directory, Schedule, Memo, Secret, Timekeeping, Alarm and

Calculator mode.

SPECIFICATIONS

Spell Check/Hyphenation Mode

Automatic spell checking and hyphenation advice based on dictionary of approximately 115,000 words.

Telephone Directory Mode

Storage and recall of telephone directory data (name, telephone number, address, etc.). Each item can contain

up to 380 characters. Includes secret memory area and auto sort function.

Schedule Mode

Storage and recall of appointments for any date in the range of January 1901 through December 2099. Each

item can contain up to 372 characters. Includes secret memory area and auto sort function.

Data Memo Mode

Storage and recall of memos. Each item can contain up to 381 characters. Includes secret memory area and

auto sort function.

Timekeeping Mode

Average of accuracy ±3 seconds per day under normal temperatures; year/month/date, hour/minute/seconds,

AM/PM, day of the week, daylight saving/standard time; full automatic calendar; 12/24 hour timekeeping

format

Alarm Mode

Daily Alarm (20-second electronic buzzer); Schedule Alarm (20-second electronic buzzer); Hourly Time Signal

(beeps every hour on the hour)

Calculator Mode

10-digit arithmetic calculations; constant calculations; memory calculations; 20-digit approximations; percent-

age calculations; square roots; sigh changes; function command signs.

Other functions

Contrast adjustment

— 2 —

General

Display: Liquid crystal display

Memory Capacity: 27,014 bytes

Power Supply: Two lithium batteries (CR2032) ... Main and Back-up

Power Consumption: 0.05 W

Battery Life*: Main battery - approximately 200 hours (continuous display of main menu

screen)

approximately 1 year (1 hour use per day)

Back-up battery - approximately 2 years after the low main battery warning

appears on the display

* The batteries that come installed in this unit when you purchase it are for factory

test purposes, so they will probably not provide normal service life.

Auto Power Off: Approximately 6 minutes after last key operation

Ambient Temperature

Range: 0°C ~ 40°C (32°F ~ 104°F)

Dimensions: Folded: 12.4 (H) ×141 (W) ×82 (D) mm

(1/2" (H) ×5 1/2" (W) ×3 1/4" (D))

Unfolded: 10.6 (H) ×141 (W) ×159.5 (D) mm

(3/8" (H) ×5 1/2" (W) ×6 1/4" (D))

Weight: 105.7 g (3.7 oz) including batteries

Current Consumption:

TYP [µA] Max [µA]

ON (MENU) 205.00 244.25

OFF — 8.25

— 3 —

Display

MENU Key

TIME/ALARM Key

Cursor Keys

FUNCTION Key

ALPHA/NUMBER Key

EXE Key

SHIFT Key

AC/ON Key

C/CLR Key

CODE Key

SPELL/HYPHEN Key

SEARCH Keys

OFF Key

SPACE/Return Key

GENERAL GUIDE

Displaying the Main Menu Screen

Press MENU to display the main menu screen.

Main Menu Screen

Menu Icons

1Telephone Directory Business Mode

2Telephone Directory Personal Mode

3Schedule Mode

4Data Memo Mode

5Calculator Mode

6Secret Memory Area

To change modes

1. Display the main menu screen.

2. The icon of the currently selected mode is highlighted on the display.

Use and to change the selected menu icon.

3. When the icon for the mode you want is selected (highlighted), press EXE.

• Press the TIME/ALARM key to enter the Timekeeping Mode and Alarm Mode. Each press of this key

switches between the two modes.

• Press the SPELL/HYPHEN key to enter the Spell Check Mode and Hyphenation Mode. Each press of

this key switches between the two modes.

123456

— 4 —

Using FUNCTION key

Use this key to access special functions and to perform other functions not marked on the keys. Use the

following sequence to access such functions.

1.Press FUNCTION.

2.Use and to move the highlighting to the function you want.

3.Press EXE to execute the function.

4.If another function menu appears, repeat step 2 and 3.

•To return to the previous display, press FUNCTION.

•To clear a displayed function menu, press AC.

To adjust the display contrast

1.Display the main menu screen.

2.To make the figures on the display darker, press . To make them lighter, press .

To switch the key input tone on and off

1.Press TIME/ALARMto enter the Alarm Mode.

2.Press FUNCTION.

3.Use to select “Sound”, and then press EXE.

4.Use to select “Key Tone”, and then use and to switch it on and off.

5.Press EXE to complete the setting operation.

About the “Check time!” display

When the message “Check time!” appears on the display, pressing any key displays the current time setting.

Check to make sure that the setting is correct before performing any other operation.

Low Battery Warning

A low battery warning protects against loss and corruption of data stored in memory due to weak battery power.

Replace the main battery immediately if the following display appears.

Main Battery

Getting Weak!

Replace it!

•Whenever the above display appears, only the OFF key is operational. Power switches off automatically

approximately 30 seconds after the low battery warning message appears.

Memory Capacity Screen

To display the memory capacity

1.While the main menu is displayed, or any time you are in the Telephone Directory, Schedule, Data Memo

or Spell Check/Hyphenation Mode, press FUNCTION.

2.Use and to select “Memory Capacity” and then press EXE.

Memory Capacity

Free 25526

Used 1488 %

Remaining memory

(Unit: bytes)

Memory used

(Unit: bytes)

— 5 —

•The memory values shown on the previous page are the total for both the open memory area and the

secret memory area.

•Press AC to clear the memory capacity screen.

To display the number of items in each mode

1.While the main menu is displayed, press FUNCTION.

2.Use and to select "Number of Items" and press EXE.

Open Memory Area

Secret Memory Area

•If you perform the above procedure while in the open memory area, the number of items stored in the

open memory area only are displayed. To see the number of items in the secret memory area, you must

perform the above operation while accessing the secret memory area.

Tel (Busi): 27

Tel (Pers): 50

Schedule : 1

Tel (Busi) : 3

Tel (Pers): 4

Schedule : 2

How memory capacity is calculated

You can store up to 27,014 bytes of data in memory. There is no limit on the amount of memory you can use

in each mode, but the total amount of data stored is 27,014 bytes. The following shows how many bytes the

data in each mode takes up. One character (each newline operation counts as a character also) takes up one

byte.

Mode Bytes per Data Item

Telephone Directory (name) + (telephone number) + (address, etc.) + 4

Schedule (description) + 12

Data Memo (memo name) + (memo contents) + 3

Examples:

Telephone Directory

When all items use 8 characters for the name, 10 characters for the phone number, and 20 characters

for the address, you can store approximately 640 items.

Schedule

When all items use 20 characters, you can store approximately 840 items.

Data Memo

When all items use 10 characters for the memo name and 10 characters for the memo content, you can

store approximately 1,170 items.

— 6 —

BATTERY REPLACEMENT

Note that the main battery and the back-up battery should be replaced separately. If you remove both batteries

from the unit at the same time, all data stored in memory will be erased. Whenever you remove both batteries

from the unit, be sure to re-install the main battery first.

Important!

• Makesurethat the positive (+) side of thebatteriesisalways facing up (so you can seeit)whenyou install

batteries into the unit.

• Replace the back-up battery at least once every two years.

To replace the main battery

1. Loosen the screw that holds the battery compartment cover of the unit in place and remove the battery

compartment cover.

2. Loosen the screw that secures the main battery holder in place and remove the battery holder.

3. Insert a thin, pointed non-metallic object into (A) and remove the old battery.

4. Wipe off the surfaces of a new battery with a dry, soft cloth and insert it into the unit making sure that its

positive (+) side is facing up (so you can see it).

5. Replace the battery holder and secure it in place with its screw.

6. Replace the battery compartment cover and secure it in place with its screw.

To replace the back-up battery

1. Loosen the screw that holds the battery compartment cover of the unit in place and remove the battery

compartment cover.

2. Remove the back-up battery sticker.

3. Loosen the screw that secures the back-up battery holder in place and remove the battery holder.

4. Insert a thin, pointed non-metallic object into (B) and remove the old battery.

5. Wipe off the surfaces of a new battery with a dry, soft cloth and insert it into the unit making sure that its

positive (+) side is facing up (so you can see it).

6. Replace the back-up battery holder and secure it in place with its screw.

7. Do not forget to replace the sticker.

8. Replace the battery compartment cover and secure it in place with its screw.

RESET

Main battery Back-up battery

(A)

(B)

— 7 —

RESET OPERATION

Two kinds of reset operation can be performed. The all-reset operation deletes all data in memory. The secret

reset operation deletes only your password and the data in the secret memory area.

Important!

Be sure to perform the all-reset operation after purchasing the RE-700.

To perform all-reset

1. Switch power off.

2. Press the RESET button with a thin, pointed object.

3. Use to select “Reset”, and press EXE.

4. Use to select “Yes”, and press EXE.

5. The main menu screen appears and all data is deleted.

To perform secret reset

1. Switch power off.

2. Press the reset button with a thin, pointed object.

3. Use to select “Del Secret Data”, and press EXE.

4. Use to select “Yes”, and press EXE.

5. The message “Check time!” appears and all data in the secret memory area and the password are deleted.

• If you want to cancel the reset operation status immediately after you press the RESET button, select

“Exit”, and press EXE.

The following are the initial settings produced by the all-reset operation.

Built-in Clock: 12:00 AM (midnight), January 1, 1996

12/24-Hour Format: 12-hour

Alarm: OFF

Alarm Time: 12:00 AM

Alarm Time Signal: OFF

Key Input Tone: ON

Date Format: Month/Day/Year

RESET button

RESET

— 8 —

DP1

CP52

CP51

Batteries

CP50

CP51

CP52

CP50

DP1

GND

1K51K

MA713

DTC114YKT

MA713

UNIT-1

CP51

CP52

CP50

DP1

GND

1K51K

MA713

DTC114YKT

MA713

UNIT-2

SB-61 / SB-62

TO SAVE THE DATA TO ANOTHER MACHINE

It is commonly necessary to save all data stored in the customer's unit before repairing it. For this purpose,

you can transfer the data of the RE-700 unit to another unit using the following procedure.

(1)To reset the receiving unit

Please reset the unit used to receive the data from the customer's unit.

(2)To connect transmission unit with receiving unit

Please remove the covers of battery compartments from both the transmission unit and the receiving unit,

and connect one with another as shown in the figures below;

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Calculadora de Casio

Casio

Casio FX-CG20 Manual de usuario

Casio

Casio FX-7700GE Manual de usuario

Casio

Casio fx-9860G AU PLUS Manual de usuario

Casio

Casio V.P.A.M. fx-992S Manual de usuario

Casio

Casio CFX-9970G Manual de uso y cuidado

Casio

Casio My Magic Diary JD-5000 Guía de solución de problemas

Casio

Casio FX-9860GII - SOFTWARE VERSION 2-00 Manual de usuario

Casio

Casio HR-110S Manual de usuario

Casio

Casio fx-7400G PLUS Documento técnico

Casio

Casio Biolator H-801 Manual de usuario

Casio

Casio MS-80VERII Manual de usuario

Casio

Casio CFX-9850G PLUS Manual de usuario

Casio

Casio CFX-9850GB PLUS Guía de inicio rápido

Casio

Casio fx-9860G AU PLUS Guía de inicio rápido

Casio

Casio FX-9700GE Manual de usuario

Casio

Casio fx-100MS Manual de usuario

Casio

Casio FX-500 Manual de usuario

Casio

Casio FX-300ES PLUS Manual de usuario

Casio

Casio OH-300ES Manual de usuario

Casio

Casio FX-CG10 Manual de instalación

Casio

Casio fx-570ES Manual de usuario

Casio

Casio DR-270TM Manual de usuario

Casio

Casio fx-82MS Manual

Casio

Casio COLLEGE fx-80 Manual de usuario

Manuales populares de Calculadora de otras marcas

HP 35s Manual

LEXIBOOK

LEXIBOOK EL350 Manual de usuario

HP HP-97 Manual de usuario

Citizen

Citizen SDC-414N Manual de usuario

Canon

Canon P26-DHIII Manual de usuario

Citizen

Citizen 520DPA Manual de usuario

Sharp

Sharp EL-9900 Manual de usuario

Sharp

Sharp WriteView EL-W506 Manual técnico

HP HP-67 Guía del usuario

Royal

Royal CBC2000 Manual de usuario

Heathkit

Heathkit IC-2009 Manual de usuario

Universal

Universal UNV-15907 Manual de usuario

Sharp

Sharp EL-9650 Manual de usuario

Sharp

Sharp EL2192RII - Printing Calculator Manual de usuario

Ativa

Ativa AT-30i Manual de usuario

HP StreamSmart 400 Manual de usuario

HP 20b Business Consultant Manual de usuario

HP 9g Manual de usuario
