Cashmaster Sigma 105
User Manual
www.cashmaster.com
User Manual
Thank you for choosing the Cashmaster Sigma 105 money counter.
The Sigma 105 is an invaluable, easy to use, and highly accurate money
counting device. The Sigma 105 is designed to manage your cash
intelligently, with accuracy and efciency. With the Sigma 105 you will
speed up cash counting and reconciliation up to six times faster than by
hand.
Cashmaster Sigma 105
10228A
page 1
10228A
Contents
Introduction
Introduction……………………………………………….. 2
Box Items and Guidelines
Maintenance……………………………………………… 3
Warning……………………………………………………. 3
Charging…………………………………………………... 3
Guidelines
Unpacking………………………………………………… 4
Battery......………………………………………………… 4
Keys and Display
Cashmaster Sigma 105...……………………………….. 5
Keypad..........…………………………………………….. 6
Tray..........…………………………………………………. 6
Screen…………………………………………………….. 6
Cashmaster Key Identication
Key Identication…………………………..…………….. 7
Fast Keys......................................................................7
Getting Started
What can you count……………………………………… 8
Switching On……………………………………………… 9
Setting Bank mode..........………………………………..10
Auto Add and Auto Scroll………………………………...11
Counting
Coins………………………………………………………. 13
Learning………………………………………………...… 15
Bills………………………………………………...………. 16
Totalling, Clearing, and Printing………………………...................17
Grams Mode……………………………………....………………....18
Troubleshooting……………………………………………………... 19
FAQ’s…………………………………………………………………. 20
Technical Specication..……………………………………………. 22
Faster, Accurate and Even More Intelligent
Copyright © 2009 Cashmaster International. All rights reserved. This document may not be copied or reproduced
in whole or in part, or transferred to any other media or language, by means without the written prior permission of
Cashmaster International. We reserve the right to make changes to this document and to the product described
herein without obligation to notify any persons of such changes.
page 2
10228A
Introduction
The Cashmaster Sigma 105 is an electronic weighing device which calculates the value
of coins and bills. The Cashmaster Sigma 105 supports your domestic currency: bills
and coins. The intuitive user friendly interface guides you through the cash counting
process. The Cashmaster Sigma 105 is programmed to count the contents of a typical
cash register:
· Bills (loose)
· Coins (loose, rolled)
Using the Cashmaster you will notice some changes in the way you work:
· Reduced paperwork
· Streamlined working methods making the business more competitive
· More time to concentrate on key tasks
Guidelines
1. Place the Sigma 105 on a rm, even surface, away from drafts and vibrations.
2. Insert the Tray, pushing down VERY rmly into position until it “clicks”.
3. Ensure area around the tray is kept clear.
4. The coin scoop should NOT be placed on the device before switching on.
5. Plug in the AC adaptor and switch on at the mains.
6. The device is not a counterfeit detector and hence will not detect counterfeit
money.
7. Weights may vary from the initial factory setting. It may be necessary to carry
out some initial bill ‘learning’ in order to quickly adjust the machine to your
local conditions.
8. Ensure money is sorted by denomination before counting. Mixed denominations
cannot be counted.
9. Do not subject the device to strong impact or shock load by any means.
10. Ensure that money is placed onto the equipment with reasonable care.
Introduction
page 3
10228A
Box Items & Guidelines
Maintenance
Ensure power is switched off during cleaning.
Clean machine with dry cloth only. Do not use cleaning products or damp material.
Do not spill any liquids on device. If liquid is spilled on device, disconnect the power
cable and contact your supplier.
Do not leave any objects on the Cashmaster or tray when not in use.
Warning
Do not use a damaged or wet power adapter.
Do not connect power adapter with wet hands.
Do not place weights over 1.5kg on the device.
Do not disassemble the device, sensitive elements in the scale may be affected and
this will affect your warranty.
Charging
Charging takes approximately 3 hours.
Only use the device with the factory supplied power adapter.
When the LED is red this indicates that the battery is fast-charging.
When the LED is green the battery is fully charged.
When the LED is ashing the battery is very low and the unit is on slow charge.
If the LED continues to ash for more than 3 hours the battery may have a fault
(in event of this, switch off the power at the mains and contact Customer Support).
Cashmaster Sigma 105 Scoop
AC Adapter
If any of the above are missing please contact Customer Support on
1877 - CASHMAS
page 4
10228A
Guidelines
Unpacking
1. Unpack your Cashmaster machine and check that you have a
Cashmaster scale, a tray and a power adapter.
2. Fit the tray into the top of the Cashmaster scale. Push down very
rmly until it “clicks” into place.
(To remove the tray, hold Cashmaster machine rmly and twist the tray
until it “clicks”, then lift the tray from the base)
3. Plug the power adapter into the socket at the back of the Cashmaster
scale.
4. Place the Cashmaster scale on a rm even surface.
5. Ensure the tray is empty (the coin scoop/cup should NOT be placed
on the tray before switching on).
6. Plug the power adapter into the power source.
7. The Cashmaster can now be operated from mains power or from
battery (after charging).
Battery
A fully charged battery will last up to 12 hours. When the battery is low the
display will show “low battery, recharge now”.
To fully charge the battery, plug the Cashmaster machine into the mains. The
LED on the front (located by the On/Off key) will show GREEN (for one second)
then RED.
(A RED LED indicates that the battery is charging. The charging process can
take up to three hours. A GREEN LED indicates that the battery is fully charged
and the unit is connected to the external power supply. If the LED continues to
ash for more than 3 hours the battery may have a fault (in event of this, switch
off the power at the mains and contact Customer Support). No colour indicates
that the unit is running on its internal battery.)
Push down
VERY FIRMLY
until you hear
a “click”
page 5
10228A
Keys and Display
Cashmaster Sigma 105
The Cashmaster Sigma 105 shown above is the device you are going to use.
There are three main component parts:
· the keypad
· the screen
· the tray
The Cashmaster is robust, and will stand up to all normal Cash Ofce activities.
Treat it with sensible care.
Screen
Keypad
Tray
page 6
10228A
Keys and Display
The Keypad
To keep counting as easy as possible, the number and layout of the keys on
the keypad has been kept simple.
The ‘keys’ are ‘full motion’
similar to those on home
computers. They have their
functions printed on them.
They are designed to resist
spills and increase durability.
The Screen
This is where you will see:
- displays of the amounts counted
- messages related to Cashmaster functions
The Tray
The tray is designed to hold scoops, cups, rolled coins, loose bills and banded
bills. To insert, place the tray on the Cashmaster and push down very frmly,
until your hear a “click”.
Total
Scoop
USD
Coins
1c
0
0
19.01.2009 10.15
page 7
10228A
Cashmaster Key Identication
The ON/OFF key. Press once to switch machine on. Press and
hold down to switch machine off.
The COINS/BILLS key. Used for selecting coins, bills or rolls.
The C/+ key. Used for clearing values, and adding to totals.
Fast Keys
Fast key functions are easy access controls that allow you to quickly enter
settings within the Cashmaster. More information is available on further pages.
To perform the fast key functions press both keys simultaneously.
For assistance please contact Customer support (toll free) on:
1 - 877 - CASHMAS
Set Bank Limit
Bank on/off toggle
Auto Scroll on/off toggle
Auto Add on/off toggle
Calibrate Scoop
Switch Currency
Key Idendication
UP and DOWN arrow keys. Used to toggle up or down (through
denominations).
The PRINT key. Press once for a print out of the totals.
The FUNCTION key. In combination with other keys is used to
control various settings.
page 8
10228A
Getting Started
Loose - for counting loose bills.
Loose bills are counted by placing up to 30 bills at any one time.
Continue to add bills of the same denomination in quantities of
up to 30, until all bills from the selected denomination have been
counted.
What You Can Count
BILLS
Rolls - for counting and checking rolls of coins.
Scoop or Cup - for counting loose coins that are on a scoop or
other calibrated container.
COINS
Coin CountingBill Counting Roll Counting
How To Count Cash Items
