Case Eos Guía de instalación
Eos
Platform Lounger
Eos Platform Lounger – designed by Matthew Hilton
To prolong the life of the product and retain its appearance and functionality,
we would like to give you some relevant information and care advice:
Made from aluminium with a Textilene sling, the Eos outdoor range is durable, lightweight,
rustproof and low maintenance. Regular periodic care and cleaning is recommended over
occasional heavy-duty maintenance.
The frame is nished in a hardwearing powder coat, which can be cleaned using a sponge
/ soft bristle brush with a cleaning solution of mild liquid soap and lukewarm water. The
use of abrasive cleaners should be avoided.
Rinse and dry thoroughly for best nish.
Caution: In seaside use, salt can accumulate on the nish which may lead to surface
damage. In indoor pool areas, chlorides can accumulate on the nish which may lead to
surface damage.
In both of the above environments, repeated cycles of condensation followed by evapora-
tion will cause build-up of these aggressive corrosives. Regular cleaning with mild soap
and water will remove the concentrated deposits and protect the furniture nish per the
above instructions.
Although the materials and nished used are selected for their ‘all weather / year-round’
characteristics, we recommend that the product is stored during cold and wet winter
months. The lounger should not be stored upside down.
We thank you for purchasing this product and wish you many years of enjoyable and
functional use.
For more related products please visit: casefurniture.com
Care Instructions
Case Furniture Ltd
London, SW18 2HZ
United Kingdom
casefurniture.com
1
Instructions
Right hand to left hand platform adjustment
A x4 D (5mm)
B x10
2
3
5
D
Re-bolt the back adjustment plates into
the same position on the opposite side
using bolts A.
Two people should turn the lounger
onto its side on a soft at surface.
Remove the back sling and back
adjustment plate.
Required
Provided
Towards centre
of frame.
4
With the frame on its back, remove
and rotate the seat sling 180
degrees.
A x4
B x2
A x4
C x12
B x8 C x8
C x4
D
Place the lounger back onto its side.
Insert the back adjustment bars into
the plates by tilting the backrest
slightly and re-attach the two bolts B
into the correct holes.
C x4
B x2
B x8
C x8
D
180
Re-attach the seat sling at the opposite
end of the frame.
