CASE CONSTRUCTION CX85D SR Manual de usuario

Part number 90332280

1st edition English

April 2020

Crawler Excavator

OPERATOR’S MANUAL

CX85D SR Long Reach

Supplement to 51606329

ORIGINAL INSTRUCTIONS - according to Directive 2006/42/EC, Annex I, 1.7.4.1

Contents

1GENERALINFORMATION

Productidentication.......................................................................1-1

2MAINTENANCE

Every50hours

Greasepoints...........................................................................2-1

Every1000hours

Greasepoints...........................................................................2-4

3SPECIFICATIONS

Machinespecications.....................................................................3-1

Dimensions.................................................................................3-3

Operatingweights..........................................................................3-6

1-GENERALINFORMATION

1-GENERALINFORMATION###_1_###

Productidentication

TheCX85DSRLRisacrawlerhydraulicexcavator.Itconsistsofanundercarriagettedwithtracksandaturntable

bearingwhichsupportstheupperstructureframe.Theupperstructureframesupportstheattachment,atthefrontend

ofthemachine,plustheengine,hydraulicsandcab.Whentheoperatorworksthecontrols,theengine-drivenpump

delivershydraulicuidtothecontrolvalves.Thecontrolvalvesdistributethehydraulicuidtothevariouscylinders

andhydraulicmotorsemployed.Acoolingsystemmaintainsthehydraulicuidatnormaloperatingtemperature.

SMIL19CEX2808EA1

CX85DSRLR(LongReach)

Whenorderingparts,obtaininginformationorassistance,alwayssupplyyourCASECONSTRUCTIONDealerwith

thetypeandserialnumberofyourmachineoraccessories.Writethefollowinginthespacesbelow:thetype,serial

numberandyearofmanufactureofyourmachine,accessoriesandtheserialnumbersofthevarioushydraulicand

mechanicalcomponents.

Machine

(1)Designation/Model

HydraulicExcavatorCX85DSRLR

(2)ProductIdenticationNumber(PIN)

(3)YearofConstruction

(4)ModelYear

(5)Maximumoperatingmass

(theweightshownonthemanufacturer'splateisthevalue

usingtheheaviestcongurationandthatitdoesnotal-

wayscorrespondtothetransportconguration)

(6)EnginepowerISO14396SMIL15CEX3307AA2

1-1

1-GENERALINFORMATION

EngineIDlabel

Manufacturerandmodel:YANMAR4TNV98CT

Serialnumber:

SMIL19CEX0616BA3

Engineemissionlabel

SMIL19CEX0617BA4

1-2

1-GENERALINFORMATION

CabprotectionROPS(RollOverProtectiveStructure)

ComplieswithISO12117-2.

Productidenticationnumber:

SMIL17CEX5115AA5

CabprotectionFOPS(FallingObjectsProtectiveStructure)

ComplieswithISO10262level1(cabroof).

ComplieswithISO10262level2(withoptionalbolt-ontop

guard).

Productidenticationnumber:

SMIL17CEX5116AA6

CabprotectionFGPS(FrontGuardProtectiveStructure)

ComplieswithISO10262level1(withoptionaldouble

framebolt-onfrontgrid).

Productidenticationnumber:

SMIL15CEX3852AA7

1-3

1-GENERALINFORMATION

ComplieswithISO10262level2(withoptionalsingle

framebolt-onfrontgrid).

Productidenticationnumber:

SMIL15CEX3853AA8

Componentserialnumbers

Hydraulicpump:

Swingreductiongear:

Travelreductiongears:

Travelcontrolvalve:

Attachmentcontrolvalve:

Swingcontrolvalve:

1-4

2-MAINTENANCE

2-MAINTENANCE###_7_###

Every50hours

Greasepoints

Lubricant:CASEAKCELA251HEPMULTI-PURPOSEGREASE.

SMIL19CEX2597FA1

Usingagreasegun,injectgreaseofthespeciedtype

inthegreasepointsshowningures:

•Bucketlinkages

NOTICE:thebucketlinkageshouldbelubricatedevery

10hifthemachineisoperatedinwaterormud.

SMIL19CEX2598AA2

2-1

2-MAINTENANCE

•Armlink/connectingrod

SMIL19CEX2599AA3

•Bucketcylinderbottompin

SMIL19CEX2600AA4

•Boomcylindertoppin

SMIL19CEX2803AA5

•Boomcylinderbottompin

SMIL19CEX2804AA6

2-2

2-MAINTENANCE

•Armcylindertoppin

SMIL19CEX2811AA7

•Armcylinderbottompin

SMIL19CEX2811AA8

2-3

2-MAINTENANCE

Every1000hours

Greasepoints

Lubricant:CASEAKCELA251HEPMULTI-PURPOSEGREASE.

SMIL19CEX2597FA1

Usingagreasegun,injectgreaseofthespeciedtype

inthegreasepointsshowningures:

•Boombottompin

SMIL19CEX2806AA2

2-4
