Product information
IP video front door station ARGOS
CAE3000-IP-015x
as of version 5.019
2
3
Table of contents
Scope of delivery............................................................................................................ 5
Introduction.................................................................................................................... 5
Notes on this product information .................................................................................................................................5
Used symbols and warning notices ..............................................................................................................................5
Further used symbols ...................................................................................................................................................5
Safety instructions......................................................................................................... 6
General safety regulations............................................................................................................................................6
Requirements to protect against lightning ....................................................................................................................6
Product description ....................................................................................................... 7
Intended use .................................................................................................................................................................7
Short description............................................................................................................ 7
RFID..............................................................................................................................................................................7
VIDEO...........................................................................................................................................................................7
AUDIO...........................................................................................................................................................................7
Operation / configuration ..............................................................................................................................................8
Event handler................................................................................................................................................................8
Interfaces ......................................................................................................................................................................8
Protocols .......................................................................................................................................................................9
Ambient conditions .......................................................................................................................................................9
Power supply ................................................................................................................................................................9
Housing.........................................................................................................................................................................9
Device overview........................................................................................................... 10
Technical data.............................................................................................................................................................11
Mounting and installation ............................................................................................ 11
Installation...................................................................................................................................................................11
Installation site..............................................................................................................................................................................11
Flush-mount..................................................................................................................................................................................12
Connecting the lines .....................................................................................................................................................................13
Put on the front plate ....................................................................................................................................................................14
Remove the front plate..................................................................................................................................................................14
Connecting the lines.................................................................................................... 15
Connecting lines...........................................................................................................................................................................15
Switch input, with 4 pins .............................................................................................................................................15
Relay output 1 and 2, each with 3 pins.......................................................................................................................15
Local power supply, with 2 pins ..................................................................................................................................16
Initial operation............................................................................................................ 17
Start screen.................................................................................................................................................................17
Configuration via OSD menu........................................................................................ 18
Overview configuration menu .....................................................................................................................................18
Camera .......................................................................................................................................................................18
Audio...........................................................................................................................................................................19
Volume..........................................................................................................................................................................................19
Microphone...................................................................................................................................................................................19
Display ........................................................................................................................................................................20
Automatic control..........................................................................................................................................................................20
Manual control..............................................................................................................................................................................20
Network.......................................................................................................................................................................21
IP address.....................................................................................................................................................................................21
Assigning the IP address manually...............................................................................................................................................21
4
Intercom function for visitor communication ............................................................. 22
Trigger a call.................................................................................................................................................................................22
Cancel a call.................................................................................................................................................................................22
Call accepted................................................................................................................................................................................22
End a call......................................................................................................................................................................................22
Control during a voice connection.................................................................................................................................................23
Set up the access control............................................................................................ 24
Put in employee data ..................................................................................................................................................24
Enrollment...................................................................................................................................................................24
Using the access control............................................................................................. 25
Access via RFID card .................................................................................................................................................25
Overview error messages RFID card............................................................................................................................................25
Access with access code............................................................................................................................................26
Overview error messages access code........................................................................................................................................26
Set up video surveillance ............................................................................................ 27
Extended configuration via web interface.................................................................. 28
Home screen...............................................................................................................................................................28
Login/Logout ...............................................................................................................................................................29
Admin password...........................................................................................................................................................................29
Special cards................................................................................................................................................................................30
System status .............................................................................................................................................................30
Menu Modifications.....................................................................................................................................................30
Telephone mode.........................................................................................................................................................31
Basic settings..............................................................................................................................................................31
User ............................................................................................................................................................................32
Set up access control with RFID UID............................................................................................................................................33
Set up access control with PIN code ............................................................................................................................................33
Access control with RFID UID and PIN code................................................................................................................................33
Network settings .........................................................................................................................................................34
SIP configuration ........................................................................................................................................................35
Audio/Video.................................................................................................................................................................36
Interface configuration ................................................................................................................................................37
Upload/Download .......................................................................................................................................................38
Cleaning........................................................................................................................ 39
Conformity.................................................................................................................... 39
Information on disposal ............................................................................................... 39
Warranty....................................................................................................................... 39
Service.......................................................................................................................... 40
5
Scope of delivery
1 x IP video front door station ARGOS
1 x wall-mount case for surface- and flush-mount
1 x installation kit with screws, dowels and sealing
1 x allen key with SW 2.0
3 x RFID cards: 1 x green, 1 x red and 1 x grey
1 x assembly instruction
1 x product information
Introduction
Notes on this product information
This product information refers exclusively to qualified electricians.
The product information contains important notes on intended use, installation and initial operation.
Please, keep the product information at a suitable place, where it is easily accessible for maintenance
and repair reasons.
You will find all product information in the download area at www.carus-concepts.com .
Used symbols and warning notices
Symbol Signal word Explanation
DANGER! The signal word describes an endangering with a high level of risk. Failure to ob-
serve this warning will result in death or very serious injury.
WARNING! The signal word describes an endangering with a medium level of risk. Failure to
observe this warning could result in death or very serious injury.
CAUTION! The signal word describes an endangering with a low level of risk. Failure to observe
this warning could result in a minor or moderate injury.
ATTENTION! The signal word indicates that damages on equipment, environment and property
can occur.
Further used symbols
Important note or important information
►Step
Cross reference for further information on this topic, see source
List, list entry 1 level
‐ List, list entry 2 level
a) Explanation
6
Safety instructions
General safety regulations
Assembly, installation, commissioning and repair of electronic devices must be carried out by
qualified electricians.
Observe the latest regulations and standards for system installations.
WARNING! Danger to life due to electric shock
When working on main power connections of 230 V, the safety regulations according to DIN
VDE 0100 must be observed.
When installing TCS:BUS systems the general safety regulations for telecommunication sys-
tems according to VDE 0800 must be observed. Inter alia:
separated cable routing of high and low voltage lines
minimum distance of 10 cm in case of a common cable routing
use of separators between high and low voltage lines within shared cable ducts
use of standard telecommunication lines, e.g. J-Y (St) Y with 0.8 mm diameter,
already existing lines (modernisation) with deviating cross-sections can be used in compli-
ance with the loop resistance
Observe the general requirements for network installations according to DIN EN 50173.
Requirements to protect against lightning
ATTENTION! Device damage due to over-voltage
By suitable lightning protection measures it has to be ensured that the electric voltage of 32 V
DC at each connection is not to be exceeded.
7
Product description
Intended use
The IP video front door station ARGOS is a terminal for access control that combines access control and
video door communication. Video door communication can be implemented into a network directly via
SIP phones.
The IP video front door station ARGOS is suitable for flush- and surface-mount in the outdoor area.
For applications, which differ from the intended use or goes beyond it, the manufacturer ac-
cepts no liability.
Short description
RFID
integrated RFID reader
MIFARE®
optionally adaptable for LEGIC® and iCLASS®
identification storage for up to 1000 persons
integrated code lock
identification query can be combined via RFID and code
VIDEO
integrated camera with 2 mega pixel CMOS colour sensor
wide angle objective with 100 degree opening angle
electronic PTZ control
video compression H.264, MJPEG, JPEG
video resolution VGA and CIF
frame rate with up to 30 images per second
anti-flickering
AUDIO
integrated microphone and loudspeaker
full duplex high power echo suppression
frequency range: 200 - 16,000 Hz
audio coding G.711 (A/µ-Law), G.729
8
Operation / configuration
capacitive colour touch screen with 5.7'' LCD (640 x 480 pixel)
brightness depends on the ambient light
configuration via LCD menus and web interface
customisable start screen
integrated data base, up to 1000 call destinations can be stored
Event handler
assigning events to actions
a maximum of 50 links can be configured
events:
– access control (RFID and/or PIN)
– tamper contact (contact, acceleration)
– SIP (INFO/DTMF, INVITE, BYE)
– trigger inputs
– RFID
– PIN
– TIMER
actions:
– video (PTZ, snapshot)
– relay
– SIP (INVITE, BYE, TALK)
– IP (HTTP GET, UDP Broadcast)
– LCD (Switch screen, Display ON/OFF)
Example 1:
An access event switches a relay. A video snapshot is taken and the message Access grant-
ed is displayed.
Example 2:
A relay is switched on in case of a SIP-DTMF signal and switched off after the timer period
has elapsed.
The configuration of the event handler is only approved for trained system integrators.
Interfaces
Ethernet, 10/100BaseT at RJ45 socket
2 x trigger input (door release button, feedback contact)
2 x relay changer (door release, light)
2-wire interface on spring-loaded terminal (with optional 2-wire kit)
integrated register server for peer-to-peer operation
9
Protocols
SIP RFC 3261, compatible to SIP (image) phones or Soft phones
TCP/UDP/IP, RTP, http, DNS, NTP, DHCP (Client), SNMP
Ambient conditions
temperature range: -20 °C to +60 °C
humidity up to 95%, non-condensing
ambient bright up to 50,000 lx
Power supply
Power over Ethernet (PoE) 802.3af and 802.3at
external mains adapter 12 V DC, 1 A (not polarity-free)
alternative power supply via mains adapter AC 20 V~ to 40 V~ or DC 24 V to 56 V (polarity-free)
Housing
housing made of solid aluminium
structured surface refined by hand
for flush- and surface-mount
colour: silver or black
tamper contact and acceleration sensor against vandalism
10
Device overview
1 housing made of aluminium 6 locking screw
2 loudspeaker 7 RFID reader
3 wall-mount case for surface- and flush-mount 8 microphone
4 pressure compensation element 9 display with touch screen
5 cable gland 10 camera
Otros manuales para ARGOS
1
Tabla de contenidos
Otros manuales de Sistema de intercomunicación de Carus
Carus
Carus IRIS CAE100 Series Manual de usuario
Carus
Carus ARGOS Manual de usuario
Carus
Carus Adapto CAI2210 Manual de usuario
Carus
Carus Adapto CAI1200 Manual de usuario
Carus
Carus Adapto CAI1100 Manual de usuario
Carus
Carus ARGOS CAE3 02-IP-015 Series Manual de usuario
Carus
Carus CAI 1100 Manual de usuario
Carus
Carus CAI 1010 Manual de usuario
Carus
Carus CAI2300-015X Manual de usuario
Carus
Carus IRIS Manual de usuario
