USE AND CARE GUIDE
Questions, problems, missing parts? Before returning to the store,
please contact our Customer Service
inually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Captiva Desings!
THANK YOU
This appliance is for Household use only.
This is not a commercial appliance.
Assembly, Care And Use Instructions
Read Carefully Important:Retain These
Instructions For Future Reference.
Enjoy Your
E02GR022
2
Safety Information
Warnings
Preparation
Assembly Instructions
Troubleshooting
First-time Operation
Care and Maintenance
220
21
22-23
8
3-5
6-7
8-16
Operation Instructions
17-19
Warranty
Product Specifications
24
24
ENJOY YOUR CAPTIVA DESIGNS
Package Contents
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, keep away from the
appliance and immediately call your gas
supplier or your fire department.
5. Failure to follow these instructions could
result in explosion, or burn hazard which
could cause property damage, personal
injury or death.
Assembler/Installer
This instruction manual contains important information necessary for the proper assembly and safe
use of this appliance. Read and follow all warnings and instructions before assembling and using this
appliance.
Leave these instructions with the consumer.
Consumer/User
Follow all warnings and instructions when using this appliance. Keep these instructions for future
reference.
1. DO NOT store or use gasoline or other
flammable liquids or vapors in the vicinity of
this or any other appliance.
2. A LP cylinder not connected for use shall
not be stored in the vicinity of this or any other
appliance.
3. This grill is FOR OUTDOOR USE only and shall
not be used in a building, garage, under
overhangs or any other enclosed area.
4. DO NOT leave a lit grill unattended. Keep
children and pets away from the grill at all
times.
Table of Contents
Safety Information
3
Warnings
PROP 65 WARNING:
This product can expose you to chemicals including Chromium (hexavalent compounds), which are known
to the State of California to cause cancer and birth defects or other reproductive harm.For more
information visit www.P65Warnings.ca.gov.
IMPORTANT SAFETY
Please read this manual carefully and before installing or using your Captiva Designs gas grill to ensure
proper operation, installation, and servicing, and to reduce the risk of fire, burn hazard, and/or other injury.
This manual should be retained for your information.
LOCATION OF GRILL
Remember that your Captiva Designs grill is an outdoor appliance. Ensure your grill is positioned safely away
from anything that can catch fire. Under no circumstance is this grill to be used indoors, this includes
garages or any other enclosed area. This outdoor cooking gas appliance is not approved to be installed in or
on any recreational grills are intended for single-family/residential use only.
Minimum clearance from sides and back of unit to combustible construction, 36 inches from sides and 36
inches from back(see below).
36 in 36 in
When determining a suitable location, take into account concerns such as exposure to wind, proximity to
traffic paths, and keeping any gas supply lines as short as possible.
Proper location and use is also essential to ensure safe and continued trouble-free operation. Any
non-approved alterations made to the grill will void its warranty.
INSTALLATION WARNINGS
Please read all installation, operating, and maintenance instructions thoroughly before installing or servicing
this equipment.
Safe operation of Captiva Designs gas grill depends upon proper installation. All gas installations and gas
conversions must be performed by a qualified technician or authorized service agent. Improper installation,
adjustment, alternation, service, or maintenance may cause property damage, injury or death.
Always check the Rating Plate on the grill to make sure the gas supply you are connecting to is
the gas type the appliance is manufactured for. Do not kink the gas line when installing.
ENJOY YOUR CAPTIVA DESIGNS
Warnings
4
This gas grill must be installed in accordance with all local codes. If installation is planned in an area with no
local codes, your gas grill must be installed in accord with the National Fuel Gas Code with the National Fuel
Gas Code ANSI Z223.1, and storage and handling of CSA B149. 2 propane installation code.
This grill is for outdoor use only. The manufacturer cannot be held responsible for damage or injury caused
by improper use of this appliance.
The installation must conform with local codes or in the absence of local codes, with CAN/ CGA-B149.2,
Propane Installation Code.This grill CANNOT be converted to natural gas. DO NOT attempt to convert this
grill with a different gas type.
FUEL CONCERNS & EXPLOSION HAZARDS
Do not store or use gasoline or other flammable vapors and liquids(that are not connected for use) in the
vicinity of this or any other appliance. Keep the area clear and free from combustible materials, gasoline,
and other flammable vapors and liquids, Failure to do so can result in death, explosion or fire.
Keep an ABC fire extinguisher accessible at all times, and never attempt to extinguish a grease fire with
water or other liquids. Do not attempt to heat unopened containers on the grill. Pressure may build up and
cause the container to explode. Never use charcoal or any other solid fuel in the grill.
PROPER USE
This Captiva Designs grill in NOT intended for commercial use. Do not operate the grill in a building, garage,
or any other enclosed areas. This could result in carbon monoxide buildup, which may cause injury or death.
Grills are not designed or intended for installtion near a window or vent that feeds into the house.
Never test the grill for gas leaks using a lit match or any other open flame; see leak test procedures using
soap-and-water solutions in the “Checking for Gas Leaks” section on Page 17.
For proper operation, burners must be aligned with the valve orifice and seated in the bracket slot. This is
accomplished by first placing the burner tube’s shutter hole securely over the valve orifice, and ensuring the
male post on the rear of the burner rests in the opening in the grill chassis. Failure to do so could result in a
fire and/or injury.
Consult the AHJ (Authority Having Jurisdiction) or a contractor in your area if you have any uncertainty
regarding local codes.
LP CYLINDER CARE & STORAGE
Before each use, visually inspect the gas supply hose for cracks, cuts, or excessive wear. Replace the hose if
necessary. Check for gas leaks as outlined on Page 17 before each use.
Ensure the gas supply hose does not come in contact with hot surfaces or sharp or rough edges of the grill or
outdoor kitchen construction.
Do not twist the gas supply hose.
Never store an LP cylinder or tank indoors, or within the reach of children.
ENJOY YOUR CAPTIVA DESIGNS
5
Warnings
The self-contained LP system appliance is design-certified to be used with a standard 20-lb., 12 1/4”-diameter,
18”-tall cylinder with right-handed connection threads. This is the maximum size LP tank to be used with this
grill. The cylinder must be marked in accordance with the latest U.S. Department of Transportation
specifications for LP gas cylinders. (DOT. CFR49 or National Standards of Canada CAN/ CSA-B359 Cylinders,
Spheres and Tubes for the Transportation of Dangerous Goods).
Use only LP tanks with an OPD (Overfill Prevention Device).
IF YOU SMELL GAS
1. Shut off gas to the grill.
2. Extinguish any open flames.
3. If the odor persists, immediately call your local gas supplier or fire department.
BEWARE OF SPIDERS
BURNER TUBES MUST BE INSPECTED AND CLEANED BEFORE EACH USE.
GENERAL WARNINGS
• All gas grills get hot during use. Use extreme caution when operating.
• Do not touch hot surfaces. Always use the lid handle to open or close the grill.
• Use cooking utensils with wood handles and insulated oven mitts when operating the grill.
• Never lean over the cooking surface when lighting or operating the grill.
• Never light the appliance with the hood closed and without being certain that the burners are positioned and
seated over the gas valves and on the burner support.
• Close supervision is necessary when this or any grill is used near children. Keep children away from the grill
during operation and until it has cooled off.
• Never cook without the grease cup in place.
• Never operate this grill while under the influence of alcohol or drugs.
• Do not store anything in the grill. Make sure food is not forgotten in the grill body; forgotten items could melt
or catch fire when the grill is turned on.
Spiders and small insects occasionally spin webs or make nests in the burner tubes of gas grills. These webs
can lead to a gas flow obstruction, which could result in a fire in and around the burner tubes. This type of fire
is known as “flash-back” and can cause serious damage to your appliance and create an unsafe operating
condition for the user. Although an obstructed burner tube is not the only cause of “flash-back,” it is the most
common cause-making necessary frequent inspection and cleaning of the burner tubes.
Before cleaning the grill, disconnect the rotisserie and trip the circuit breaker if equipped.
Never use the grill in windy conditions. If located in a consistently windy area (oceanfront, mountaintop, etc.),
a wind break will be required. Winds blowing into or across the back hood gap can result in poor performance
and/or cause the control panel and knobs to get dangerously hot.
To prevent injuries, do not use accessories that are not recommended by the manufacturer. The use of
accessories, regulators, or components not recommended by the appliance manufacturer may cause injuries
and will void warranty.
ENJOY YOUR CAPTIVA DESIGNS
6
ENJOY YOUR CAPTIVA DESIGNS
Package Contents
21
25
7
ENJOY YOUR CAPTIVA DESIGNS
Package Contents
No.
1
2
3
4
5
6
7
8
9
10
11
1
2
4
1
1
1
1
2
1
1
1
Name
Warming rack
Cooking grills
Flame tamer
Grease tray
Lid & Body assembly
Left side table
Cart frame
Magnet base
Left leg(back)
Left leg(front)
Cart back panel
12
13
14
1
2
2
Left cart plate (up)
Cart side plate (down)
Door axle
Qty No.
15
16
17
18
19
20
21
22
23
24
25
2
2
1
1
1
1
2
1
1
1
2
Name
Door handle
Door
Bottom plate
Right leg(back)
Right leg(front)
Bottom front panel
Locking caster
Gas cylinder
adjustment bar
Side burner table
Right cart plate (up)
Non-locking caster
26
27
28
29
1
1
1
1
Lid handle
Grease box
Regulator assembly
Cooking plate
Qty
Part No Name
Screw
Part Description Quantity
M6x12mm 50
Screw
Screw & shim
M4x15mm
M4x6mm
4
Door bolt 2
2
4
1
Side burner
nozzle clamp
Lid pad
A
B
C
D
E
Extra spare part
8
Preparation
Before beginning assembly of product, make sure all parts are present. Compare parts with package contents
list on previous page and hardware contents below. If any part is missing or damaged, do not attempt to
assemble the product. Contact customer service for replacement parts.
Tools Required for Assembly and Leak Testing (not included): Phillips screwdriver, Spray bottle,
Pliers, Adjustable Wrench
CAUTION:
THIS UNIT IS HEAVY. Two people required for safe assembly.
Two people required for safe assembly. Some parts may contain sharp edges.Wear protective gloves if
necessary. Read and follow all safety statements, warnings, assembly instructions and use and care
instructions before attempting to assemble and use.
Assembly Instructions
ENJOY YOUR CAPTIVA DESIGNS
1
Magnetic screwdriver
A M6 x 12
8 pcs
17
10 922
19
A
18
Assembly Instructions
9
ENJOY YOUR CAPTIVA DESIGNS
2
3
A M6 x 12
4 pcs
A M6 x 12
12 pcs
A
A
20
11
13
Assembly Instructions
10
ENJOY YOUR CAPTIVA DESIGNS
4
5
A M6 x 12
8 pcs
21
12
25
A
25
