Caple BUCH75 Manual de usuario
Built Under Extractor
Instruction Manual
BUCH75
Contact Caple on 0117 938 7420 for spare parts or www.caple.co.uk
Instruction manual BUCH75
2Please keep this instruction manual for future reference
CONTENTS
Safety Instructions 3
Environmental Protection 9
Product Overview 10
Ducting Options 11
Installation 12
Operation 15
Cleaning and Maintenance 16
Caple Contact Details 20
3
Please keep this instruction manual for future reference Instruction manual BUCH75
IMPORTANT
Please read this instruction manual before installing and
using this cooker hood. Keep this instruction manual in a
safe place for future reference.
-Never pull the power cable as you could damage it.
If the appliance is faulty, do not attempt to repair it.
Isolate it from the mains electric supply and contact
Caple Service either by phone 0117 938 7420 or email
service@caple.co.uk
-Keep all packaging (including plastic bags, polystyrene
foam etc) out of the reach and away from children.
-Do not rest large or unstable objects on any part of the
appliance.
-Caple cannot be held responsible for injuries or losses
caused by incorrect use or installation of this product.
-Please note that Caple reserve the right to invalidate
the guarantee supplied with this product following
incorrect installation or misuse of the appliance. Under
no circumstances should any external covers be removed
for servicing or maintenance except by suitably qualified
personnel.
INSTALLATION WARNINGS:
-Do not operate the appliance before it is fully installed.
-Only a qualified and trained service technician can
undertake the work of installation and servicing.
Instruction manual BUCH75
4Please keep this instruction manual for future reference
-Two or more people are required to install or move this
appliance. Failure to do so can cause physical injuries.
-Caple is not responsible for any damage that may
be caused by defective placement and installation by
unauthorised persons.
-When unpacking the appliance, make sure that it is
not damaged during transportation. In the case of any
defect; do not use the appliance and contact your retailer
or Caple Service immediately.
-Materials used for packaging (nylon, staplers, Styrofoam
etc) may cause harmful effects to children they should be
disposed of immediately.
-Protect your appliance against atmospheric effects. Do
not expose it to effects such as sun, rain, snow etc.
-The surrounding materials of the appliance (i.e. kitchen
cabinet or furniture) must be able to withstand a
minimum temperature of 120°C.
ELECTRICAL SHOCK HAZARD
-Only plug this unit into a properly earthed outlet. If in
doubt seek advice from a suitably qualified engineer.
-Failure to follow these instructions can result in death,
fire, or electrical shock.
-To protect against fire, electrical shock and injury to
persons, do not immerse cords or plugs in water or any
other liquid.
5
Please keep this instruction manual for future reference Instruction manual BUCH75
-Do not use any accessories or attachments not
recommended by Caple as this may result in fire, electric
shock or injury.
-Never touch the appliance with wet or damp hands.
-This appliance must be connected to the mains by a
competent person. We recommend that the appliance is
connected by a qualified electrician who is a member of
the N.I.C.E.I.C who will comply with the I.E.E and local
regulations. Electrical information can be found on the
rating plate.
-Check that the mains voltage corresponds to the one
indicated on the rating plate fixed inside the hood.
-WARNING: Failure to install the screws or fixing device
in accordance with these instructions may result in
electrical hazards.
SAFETY INSTRUCTIONS:
-When using a gas hob, do not leave naked flames under
the extractor.
-Before connecting this appliance check that the power
supply cord is not damaged.
-If the room where the hood is to be used contains a fuel
burning appliance such as a central heating boiler then
its flue must be of the sealed or balanced flue type. If
other types of flue or appliances are fitted ensure that
there is an adequate supply of air to the room.
Instruction manual BUCH75
6Please keep this instruction manual for future reference
-The air must not be discharged into a flue that is used
for exhausting fumes from appliances burning gas or
other fuels.
-Regulations concerning the discharge of air have to be
conformed to.
-Do not flambé under the cooker hood.
-Never leave frying pans unattended during use as
overheated fats and oils may catch fire.
-Do not check the status of the filters while the cooker
hood is operating.
-Do not touch the light bulbs after appliance use.
-To ensure the best performance, we recommend
switching on the extractor 15 minutes before cooking
and leave it running 15 minutes after. This will ensure
that the air in the kitchen is being circulated before
cooking commences and the air is being cleaned after
cooking has finished.
-The performance of your extractor will vary depending
on a number of factors. These include type of extraction,
room volume, length of ducting, ventilation available and
the cleanliness of the filters.
-This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
7
Please keep this instruction manual for future reference Instruction manual BUCH75
-This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not
play with the appliance.
-Never let children operate the machine.
-Children should be supervised to ensure that they do not
play with the appliance.
-Never immerse the appliance in water.
-This appliance is intended to be used in household and
similar applications such as:
› Staff kitchen areas in shops, offices and other
working environments.
› Farm Houses.
› By clients in hotels, motels and other residential type
environments.
› Bed and breakfast type environments.
-To avoid all risk, if the power cable is damaged, it must
only be replaced by a Caple appointed engineer.
-Appliances can be used by persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the
appliance in a safe way and understand the hazards
involved.
Instruction manual BUCH75
8Please keep this instruction manual for future reference
-Children must not play with this appliance.
-When not in use and before cleaning, always isolate the
appliance from the electrical supply.
CLEANING AND MAINTENANCE:
-Disconnect the hood from the main supply before
carrying out any maintenance work.
-Proper maintenance of the cooker hood will ensure
proper performance of the unit.
-The cooker hood and its filter should be cleaned regularly
in order to keep in good working condition.
-Clean the cooker hood according to the instruction
manual to reduce the risk of fire.
-Clean and/or replace aluminium grease filters and
activated charcoal filters after specified period of time.
-Cleaning and user maintenance must not be made by
children without supervision.
-Clean the hood using a damp cloth and a neutral liquid
detergent.
-DISPOSAL: Do not dispose this product as unsorted
municipal waste. Collection of such waste separately for
special treatment is necessary.
-If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
9
Please keep this instruction manual for future reference Instruction manual BUCH75
ENVIRONMENTAL PROTECTION
Waste electrical products should not be disposed of with household waste. Please recycle where
facilities exist. Check with your Local Authority or retailer for recycling advice. This appliance is
marked according to the European directive on Waste Electrical and Electronic Equipment (WEEE).
By ensuring this product is disposed of correctly, you will help prevent potential negative
consequences for the environment and human health, which could otherwise be caused by
inappropriate waste handling of this product. The symbol on the product indicates that this
product may not be treated as household waste. Instead it shall be handed over to the applicable
collection point for the recycling of electrical and electronic equipment. Disposal must be carried
out in accordance with local environmental regulations for waste disposal.
For more detailed information about treatment, recovery and recycling of this product, please
contact your local council, your household waste disposal service or the retailer where you
purchased the product
WARRANTY
Your new appliance is covered by warranty. The warranty card is enclosed - if it is missing, you
must provide the following information to your retailer in order to receive a replacement: date of
purchase, model and serial number. Registration can also be completed online by visiting
www.caple.co.uk.
Ensure you keep your warranty card safe, you may need to show it to Caple Service together with
proof of purchase. If you fail to show your warranty card you will incur all repair charges.
Spare parts are only available from Caple Service and spare parts authorised centres.
CE DECLARATIONS OF CONFORMITY
This appliance has been manufactured to the strictest standards and complies with all applicable
legislation, Low Voltage Directive (LVD) and Electromagnetic Compatibility (EMC).
UKCA DECLARATIONS OF CONFORMITY
This appliance has been manufactured to the strictest standards and complies with all
applicable legislation.
TECHNICAL FICHE
This appliance conforms to all current and applicable energy regulations. To view the Technical
Fiche that supports the energy labelling data, please visit the product page on our
website www.caple.co.uk
Instruction manual BUCH75
10 Please keep this instruction manual for future reference
IMPORTANT:
1. Please read the entire instructions before installing the extractor.
2. Always switch power off prior to installation.
3. Stainless steel is very easily damaged during installation if scratched or knocked by tools.
Protect the extractor with the cardboard box or plastic bag during installation.
4. All electric work must be done in accordance with the local and national electrical codes
as applicable.
5. For safety, this product must be earthed.
6. A power outlet should be within 1500mm of the power cord exit from the extractor.
7. The power socket must be accessible and enable the end user to isolate the extractor from the
power for the purpose of internal cleaning or maintenance.
8. 150mm round ducting adapters are supplied. All other ducting accessories are not supplied.
All ducting must comply with local requirements and building codes.
See Ducting options next page.
PRODUCT OVERVIEW
DIMENSIONS
∅150mm
715mm
750mm
258mm
286mm
750mm
550mm
241mm
9mm
CONTENTS OF PACKAGING:
1 x Hood body
1 x face plate
1 x Pack of installation screws
1 x Ducting spigot
1 x Face plate installation kit
TYPICAL EQUIPMENT REQUIRED:
1. Electric drill
2. Screwdriver
3. Tape measure
4. Spirit level
5. Duct tape (if ducting)
6. Jig saw (if ducting)
7. Ladder (if ducting)
Tabla de contenidos
Otros manuales de Depurador de Caple
Caple
Caple 2MINCHP5 Manual de usuario
Caple
Caple CCH1 Manual de usuario
Caple
Caple D901BK Manual de usuario
Caple
Caple TAU760 Manual de usuario
Caple
Caple CCH7 Manual de usuario
Caple
Caple DD610BK Manual de usuario
Caple
Caple CGI900SS Manual de usuario
Caple
Caple NOV800 Manual de usuario
Caple
Caple PI403 Manual de usuario
Caple
Caple DD940BK Manual de usuario
