Caple RBR6 Manual de usuario

Contact Caple on 0117 938 7420 or for spare parts www.caple.co.uk

Built-under fridge with ice box

instruction manual

RBR6

RBR6 - Instruction Manual.indd 1 18/04/2016 15:55

Instruction manual RBR6

Please keep this instruction manual for future reference

CONTENTS

Warnings 3

Installation warnings 7

Before using your fridge 10

How to operate 10

Cleaning and maintenance 12

Defrosting the fridge 13

Replacing the LED light 14

Food storage 15

Transportation and repositioning 16

Troubleshooting 17

Energy saving tips 19

Parts of the appliance 20

Installation instructions 21

Electrical connection 29

Technical product ﬁche 30

Caple contact details 32

RBR6 - Instruction Manual.indd 2 18/04/2016 15:55

Instruction manual RBR6

Please keep this instruction manual for future reference

WARNING:

-Keep ventilation openings, in the appliance enclosure

or in the built-in structure, clear of obstruction.

-Do not use mechanical devices or other means to

accelerate the defrosting process, other than those

recommended by the manufacturer.

-Do not use electrical appliances inside the food

storage compartments of the appliance, unless they

are of the type recommended by the manufacturer.

-Do not damage the refrigerant circuit.

-To avoid a hazard due to the instability of the

appliance, it must be ﬁxed in accordance with

the instructions.

WARNING:

-This appliance uses R600a as a refrigerant. You

should be careful during shipment and installation to

prevent your appliance’s cooler elements from being

damaged. R600a is an environmentally friendly and

natural gas however it is explosive. In the event of a

leak caused by damage to the cooler elements, move

your fridge from open ﬂames or heat sources and

ventilate the room where the appliance is located for

a few minutes.

-Whilst carrying and positioning the fridge, take care

not to damage the cooler gas circuit.

RBR6 - Instruction Manual.indd 3 18/04/2016 15:55

Instruction manual RBR6

Please keep this instruction manual for future reference

WARNING:

-Do not store explosive substances such as aerosol cans

with a ﬂammable propellant in this appliance.

-This product is not designed for commercial use, it is

a household appliance only. It is not intended to be

used in:

• Staff kitchen areas in shops, ofﬁces and other working

environments.

• Bed and breakfast type environments.

• By clients in hotels, motels and other residential type

environments.

-If the socket does not match the refrigerator plug, it must

be replaced by a Caple approved engineer or similar

qualiﬁed persons in order to avoid a hazard.

-This appliance is not intended for use by persons

(including children) with reduced physical, sensory or

mental capabilities, or lack of experience and knowledge,

unless they have been given supervision or instruction

concerning use of the appliance by a person responsible

for their safety. Children should be supervised to ensure

that they do not play with the appliance.

-A specially grounded plug has been connected to the

power cable of your refrigerator. This plug should be used

with a specially grounded socket of 13 amps. If there is

no such socket in your house, please have it installed by

an authorized electrician.

RBR6 - Instruction Manual.indd 4 18/04/2016 15:55

Instruction manual RBR6

Please keep this instruction manual for future reference

-This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience

and knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe way

and understand the hazard involved.

-Children should not play with the appliance.

-Cleaning and user maintenance should not be made by

children without supervision.

-If the supply cord is damaged, it must be replaced by a

Caple approved engineer or similar qualiﬁed persons in

order to avoid a hazard.

NOTE:

-Please read the instruction manual carefully before

installing and using your appliance. Caple can not be

held responsible for damage incurred due to misuse.

-Follow all instructions on your appliance and instruction

manual, and keep this manual in a safe place to resolve

problems that may occur in the future.

-This appliance is produced for domestic use only. It is

not suitable for commercial use. Such use will cause the

guarantee of the appliance to be invalid and Caple will

not be responsible for losses incurred.

RBR6 - Instruction Manual.indd 5 18/04/2016 15:55

Instruction manual RBR6

Please keep this instruction manual for future reference

SAFETY WARNINGS

-Do not use multiple sockets or extension cords.

-Do not plug in damaged, torn or old plugs.

-Do not pull, bend or damage the cord.

-This appliance is designed for use by adults, do not allow

children to play with the appliance or hang on the door.

-Do not plug-in or un-plug from the socket with wet

hands to prevent electrocution!

-Do not place explosive or ﬂammable material in your

fridge for your safety. Place drinks with higher alcohol

amount vertically and by closing their necks tightly in

the fridge.

-Do not cover the body or top of fridge with lace. This

affects the performance of your fridge.

-Fix the accessories in the fridge during transportation to

prevent damage to accessories.

RBR6 - Instruction Manual.indd 6 18/04/2016 15:55

Instruction manual RBR6

Please keep this instruction manual for future reference

INSTALLATION WARNINGS

Before starting to use your fridge, you should pay

attention to the following points:

-Operating voltage for your fridge is 220-240 V at 50Hz.

-The plug must be accessible after installation.

-There may be an odour when you ﬁrst switch on the

appliance. It will disappear after the appliance starts

to cool.

-Before making the connection to the power supply,

ensure that the voltage on the rating plate corresponds

to the voltage of electrical system in your home.

-Insert the plug into a socket with an efﬁcient ground

connection. If the socket has no ground contact or the

plug does not match, we suggest you call an authorised

electrician for assistance.

-The appliance must be connected with a properly

installed fused socket. Power supply (AC) and voltage at

the operating point must correspond with the details on

the rating plate of the appliance rating.

-We do not take responsibility for damages that occur

due to ungrounded usage.

-Place your fridge in a place where it won’t be exposed to

direct sunlight.

-Your fridge should never be used outdoors or left in

the rain.

RBR6 - Instruction Manual.indd 7 18/04/2016 15:55

Instruction manual RBR6

Please keep this instruction manual for future reference

-Your appliance should be at least 50cm away from hobs,

gas ovens and heater cores, and should be at least 5cm

away from electrical ovens.

-When your fridge is placed next to a deep freezer,

there should be at least 2cm between them to prevent

humidity on the outer surface.

-Do not place heavy items on the appliance.

-Clean the appliance thoroughly, especially in the interior,

before use (See Cleaning and Maintenance).

-Installation procedure is given in the Installation Manual.

This product is intended to be used in proper kitchen

units only.

-The adjustable front legs should be adjusted to an

appropriate height to allow your freezer to operate in a

stable and proper way. You can adjust the legs by turning

them clockwise (or in the opposite direction). This should

be done before placing food in the freezer.

-Before using your fridge, wipe all parts with warm water

added with a tea spoonful of sodium bicarbonate, and

then rinse with clean water and dry.

-Install the distance adjustment plastic (the part with

black vanes at the rear) by turning it 90° as shown in the

ﬁgure to prevent the condenser from touching the wall.

RBR6 - Instruction Manual.indd 8 18/04/2016 15:55

Instruction manual RBR6

Please keep this instruction manual for future reference

ENVIRONMENTAL PROTECTION

Waste electrical products should not be disposed of with household waste. Please

recycle where facilities exist. Check with your Local Authority or retailer for recycling

advice. This appliance is marked according to the European directive 2002/96/EC on

Waste Electrical and Electronic Equipment (WEEE).

By ensuring this product is disposed of correctly, you will help prevent potential

negative consequences for the environment and human health, which could

otherwise be caused by inappropriate waste handling of this product. The symbol

on the product indicates that this product may not be treated as household waste.

Instead it shall be handed over to the applicable collection point for the recycling of

electrical and electronic equipment. Disposal must be carried out in accordance with

local environmental regulations for waste disposal.

For more detailed information about treatment, recovery and recycling of this

product, please contact your local council, your household waste disposal service or

the retailer where you purchased the product.

CE DECLARATIONS OF CONFORMITY

This appliance has been manufactured to the strictest standards and complies

with all applicable legislation, Low Voltage Directive (LVD) and Electromagnetic

Compatibility (EMC).

RBR6 - Instruction Manual.indd 9 18/04/2016 15:55

Instruction manual RBR6

Please keep this instruction manual for future reference

BEFORE USING YOUR FRIDGE

-When the appliance is situated for the ﬁrst time or after

transportation, keep your fridge in the upright position for 12 hours

before connecting to the mains electricity. Otherwise, you may

damage the compressor.

-Your fridge may have a smell when it is operated for the ﬁrst time;

the smell will fade away when your fridge starts to cool.

HOW TO OPERATE THE APPLIANCE

Thermostat setting

IMPORTANT NOTE:

Do not try to rotate knob beyond 1 position it will stop your appliance.

- The thermostat automatically regulates the inside temperature of the refrigerator

compartment and freezer compartment. By rotating the knob from position 1 to

5, colder temperatures can be obtained.

- For short-term storage of food in the freezer compartment, you can set the knob

between minimum and medium position (1-3).

- For long-term storage of food in the freezer compartment, you can set knob

medium position (3-4).

- Note that; the ambient temperature, temperature of the freshly stored food, and

how often the door is opened, affects the temperature in the refrigerator and

freezer compartments. If required, change the temperature setting.

- When you ﬁrst switch on the appliance, you should ideally try to run it without

any food in for 24 hours and not open the door. If you need to use it straight

away, try not to put much food inside.

RBR6 - Instruction Manual.indd 10 18/04/2016 15:55

Tabla de contenidos

Otros manuales de Refrigerador de Caple

Caple

Caple Ri551 Manual de usuario

Caple

Caple CAFF207SS Manual de usuario

Caple

Caple RIL1800 Manual de usuario

Caple

Caple RFL70WH Manual de usuario

Caple

Caple CAFF27 Manual de usuario

Caple

Caple RIL125 Manual de usuario

Caple

Caple RiL892 Manual de usuario

Caple

Caple RIL123 Manual de usuario

Caple

Caple RI7302 Manual de usuario

Caple

Caple Ri552FF Manual de usuario

Caple

Caple RBF1A Manual de usuario

Caple

Caple RIR179 Manual de usuario

Caple

Caple RBR5 Manual de usuario

Caple

Caple C156L Manual de usuario

Caple

Caple RFF731 Manual de usuario

Caple

Caple RI7301 Manual de usuario

Caple

Caple C195/53 Manual de usuario

Caple

Caple C155L Manual de usuario

Caple

Caple RiL892 Manual de usuario

Caple

Caple RBR8 Manual de usuario

Caple

Caple CAFF20 Manual de usuario

Caple

Caple CAFF40SS Manual de usuario

Caple

Caple RIR178 Manual de usuario

Caple

Caple QFF158/91F Manual de usuario

Manuales populares de Refrigerador de otras marcas

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manual de usuario

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manual de usuario

Sharp

Sharp SJ-BA31IEXW2-EU Manual de usuario

CORBERO

CORBERO CC2300MCW Manual de usuario

KitchenAid

KitchenAid 2205264 Manual de usuario

Stengel

Stengel KU 1101 A++ Manual de usuario

NEFF

NEFF KI181 Series Manual de usuario

Hoshizaki

Hoshizaki Reach-In Manual de usuario

Amana

Amana ASD2524VES00 Manual de usuario

BOMANN

BOMANN KGC 213 Manual de usuario

Danby

Danby DAR044A1SLDD Instrucciones de montaje

Samsung

Samsung RF323TE Manual de usuario

Beko

Beko CSA31022 Manual de usuario

IKEA

IKEA FROSTIG C 185 E Manual de usuario

Electrolux

Electrolux ER 6821 D Manual de usuario

True

True TS-28 Manual de usuario

Frigidaire

Frigidaire FSC23R5DW9 Manual de usuario

Beko

Beko LSP4579W Manual de usuario
