Caple C994i Manual de usuario

Instruction manual for induction hob

C994i

Model code:

Contact Caple on 0844 800 3830 or for spare parts www.4caple.co.uk

Congratulations on the purchase of your new Induction Hob.

We recommend that you take some time to read this Instruction / Installation

Manual in order to fully understand how to install and operate it correctly

For installation, please read the installation section.

Read all the safety instructions carefully before use and keep this manual

for future reference.

Product Overview

Top View

Control Panel

1. max. 2000 W zone

2. max. 1500 W zone

3. Glass plate

4. ON/OFF control

5. Control panel

1. ON/OFF control

2. Power / Timer regulating controls

3. Heating zone selection controls

4. Timer control

5. keylock control

A Word on Induction Cooking

Induction cooking is a safe, advanced, efficient, and economical cooking

technology. It works by electromagnetic vibrations generating heat directly in

the pan, rather than indirectly through heating the glass surface. The glass

becomes hot only because the pan eventually warms it up.

Before using your New Induction Hob

• Read this guide, taking special note of the ‘Safety Warnings’ section.

• Remove any protective film that may still be on your Induction hob.

Using the Touch Controls

• The controls respond to touch, so you don’t need to apply any pressure.

• Use the ball of your finger, not its tip.

• You will hear a beep each time a touch is registered.

• Make sure the controls are always clean, dry, and that there is no object (e.g.

a utensil or a cloth) covering them. Even a thin film of water may make the

controls difficult to operate.

iron pot

magnetic circuit

ceramic glass plate

induction coil

induced currents

Choosing the right Cookware

• Only use cookware with a base suitable for induction

cooking. Look for the induction symbol on the

packaging or on the bottom of the pan.

• You can check whether your cookware is suitable by carrying out

a magnet test. Move a magnet towards the base of the pan. If it

is attracted, the pan is suitable for induction.

• If you do not have a magnet:

1. Put some water in the pan you want to check.

2. If does not flash in the display and the water is heating, the pan is suitable.

• Cookware made from the following materials is not suitable: pure stainless steel, aluminium or

copper without a magnetic base, glass, wood, porcelain, ceramic, and earthenware.

Do not use cookware with jagged edges or a curved base.

Make sure that the base of your pan is smooth, sits flat against the glass, and is

the same size as the cooking zone. Use pans whose diameter is as large as the

graphic of the zone selected.Using a pot a slightly wider energy will be used at

its maximum efficiency.If you use smaller pot efficiency could be less than

expected.Pot less than 140 mm could be undetected by the hob. Always centre

your pan on the cooking zone.

Always lift pans off the Induction hob – do not slide, or they may scratch the

glass.

Using your Induction Hob

To start cooking

1. Touch the ON/OFF control.

After power on, the buzzer beeps once, all displays

show “ – “ or “ – – “, indicating that the induction

hob has entered the state of standby mode.

2. Place a suitable pan on the cooking zone that

you wish to use.

• Make sure the bottom of the pan and the surface

Of the cooking zone are clean and dry.

3. Touch the heating zone selection control ,and

the indicator next to the key will flash

4. Select a heat setting by touching the ”-“ or “+”

control.

• If you don’t choose a heat setting within 1

minute, the induction hob will automatically

switch off. You will need to start again at

step 1.

• You can modify the heat setting at any time during cooking.

If the display flashes alternately with the heat

setting

This means that:

• you have not placed a pan on the correct cooking zone or,

• the pan you’re using is not suitable for induction cooking or,

• the pan is too small or not properly centered on the cooking zone.

No heating takes place unless there is a suitable pan on the cooking zone.

The display will automatically turn off after 2 minutes if no suitable pan is

placed on it.

When you have finished cooking

1. Touch the heating zone selection

control that you wish to switch off

2. Turn the cooking zone off by scrolling down to” 0” or touching”-“ and”+”

control together. Make sure the display shows”0”

3. Turn the whole cooktop off by touching the ON/OFF control.

When the hob is in the lock mode,all the controls are disabled except the ON/OFF button,

4. Beware of hot surfaces

H will show which cooking zone is hot to touch. It will disappear when the

surface has cooled down to a safe temperature. It can also be used as an

energy saving function if you want to heat further pans, use the hotplate

that is still hot.

Locking the Controls

• You can lock the controls to prevent unintended use (for example children

accidentally turning the cooking zones on).

• When the controls are locked, all the controls except the ON/OFF control are

disabled.

To lock the controls

Touch the keylock control. The timer indicator will show “ Lo “

To unlock the controls

1. Make sure the induction hob is turned on.

2. Touch and hold the keylock control for a while.

3. You can now start using your induction hob.

you can always turn the induction hob off with the ON/OFF control in an

emergency, but you will need to unlock the hob first before the next operation

Over-Temperature Protection

A temperature sensor equipped can monitor the temperature inside the

induction hob. When an excessive temperature is monitored, the induction hob

will stop operation automatically.

Detection of Small Articles

When an unsuitable size or non-magnetic pan (e.g. aluminium), or some other

small item (e.g. knife, fork, key) has been left on the hob, the hob will automatically

switch to standby after 1 minute. The fan will keep cooling down the induction hob

for a further 1 minute.

Auto Shutdown Protection

Auto shut down is a safety protection function for your induction hob. It shuts

down automatically if ever you forget to turn off your cooking. The default

working times for various power levels are shown in the below table: .

Power level 1 2 3 4 5 6 7 8 9

Default working timer (hour)

8 8 8 4 4 4 2 2 2

When the pot is removed, the induction hob can stop heating immediately and

the hob automatically switches off after 2 minutes.

People with a heart pace maker should consult with their doctor before

using this unit.

Using the Timer

You can use the timer in two different ways:

• You can use it as a minute minder. In this case, the timer will not turn any

cooking zone off when the set time is up.

• You can set it to turn one cooking zone off after the set time is up.

• You can set the timer up to 99 minutes.

Using the Timer as a Minute Minder

If you are not selecting any cooking zone

Make sure the cooktop is turned on.

Note: you can use the minute minder even if you’re not selecting any

cooking zone.

Touch timer control , The minder indicator

will start flashing and “10” will show in the

timer display.

3. Set the time by touching the “-“ or “+” control

of the timer

Hint: Touch the “-“ or “+” control of the timer

once to decrease or increase by 1 minute.

Hold the “-“ or “+” control of the timer to

decrease or increase by 10 minutes.

If the setting time exceeds 99 minutes, the timer

will automatically return to 00 minute.

4. Touching the”-“ and “+” together, the timer is cancelled, and the”00” will

show in the minute display.

5. When the time is set, it will begin to count down

immediately. The display will show the remaining

time and the timer indicator will flash for 5 seconds.

6. Buzzer will sound for 30 seconds and the timer

indicator shows “- - “ when the set time

finished.

Setting the timer to turn one cooking zone off

Cooking zones set for this feature will:

1. Touch the heating zone selection control

that you want to set the timer for.

Touch the timer control , the minder indicator

will start flashing and “10” will show in the

timer display.

3. Set the time by touching the”-“ or”+” control of the

timer

Hint: Touch the “-“ or “+” control of the timer

once will decrease or increase by 1 minute.

Touch and hold the “-“or”+” control of the timer

will decrease or increase by 10 minutes.

If the setting time exceeds 99 minutes, the timer

will automatically return to 00 minute.

4. Touching the”-“ and “+” together, the timer is cancelled, and the ” 00” will

show in the minute display.

5. When the time is set, it will begin to count down

immediately. The display will show the remaining

time and the timer indicator flash for 5 seconds.

NOTE: The red dot next to power level indicator

will illuminate indicating that zone is selected.
