DR-7080C

Colour Production Scanner

Professional-quality colour

scanning at the speed of

black & white

A compact combination of speed and

quality

Speed without compromise

As with most things in business, scanners are often a trade-off. Quality comes at the cost of speed.

Speed at the cost of size. With the Canon DR-7080C production scanner, you get speed without

compromising quality, in a compact package to suit small to medium-sized production environments

and departments with high-end graphics requirements. All this with the flexibility of sheet-fed and

flatbed scanning. So why compromise?

The DR-7080C production scanner

This compact, hard-working A3 colour scanner is a remarkable combination of quality and speed.

Based on the same advanced imaging technology as Canon’s digital multi-function printer/copiers, it

produces true-to-life colour scans at black & white speeds.

Production quality

scanning

The DR-7080C produces the best

image quality in its class. At its

heart is the latest three-line CCD

sensor that delivers optical

resolution of 600dpi. Add to this

24-bit colour depth and 256 shades

of grey for continuous-tone

scanning, the DR-7080C delivers

picture perfect images every time.

Colour at black & white

speeds

With the DR-7080C, high-quality

imaging doesn’t mean reduced

speed. Even at a resolution of

200dpi, it can scan A4, landscape

documents at a speed of 70 pages

per minute, colour or black & white.

Duplex scanning in colour is equally

fast at 36 images per minute.

Fast, reliable document

handling

The DR-7080C’s Automatic

Document Feeder (ADF) is one of

the most advanced of its kind. Its

built-in inclined-plane separation

mechanism makes scanning

documents fast and smooth – even

A3 documents and longer. The pad-

separation mechanism all but

eliminates any risk of double-sheet

feeding. As a flatbed scanner, it

makes light work of scanning

books, bound and fragile

documents.

Advanced automatic

recognition

No manual pre-sorting of

documents is required, even in a

mixed batch. The DR-7080C

automatically detects the length

and width of each document (up to

279 x 432mm), as well as the

orientation of text, rotating the

scanned image to match others in a

multiple-page document.

Time-saving features

The DR-7080C also includes a

number of other valuable time-

saving features, such as:

•90° Auto Rotation. Maximises

the ADF’s high-speed document

handling by scanning A4

documents as landscape for

shorter scanning length, then

displays them as portrait.

•MultiStream. Enables the

output of two images from a

single scan, simultaneously. For

example, colour for archiving

and black & white for optical

character recognition

processing.

Other features include:

• Advanced text enhancement

• User preference

• Colour drop-out

• Pre-scan

• Border removal

• Preset gamma curve

• Book & calendar duplex

scanning

• Skew correction

• Colour emphasis

• Skip blank page

• Batch separation

• Edge emphasis

• Scan area setting

• Two-way duplex selection

• Error diffusion

DR-7080C – fast, reliable document handling

Easy and efficient

operation

A clear, intuitive control panel and

desktop interface make the

DR-7080C exceptionally easy to use.

Routine jobs like scanning to email,

folders and printers can be saved

as automatic processes on the

control panel for one-touch

operation.

Compact, ergonomic

design

This intelligently designed space-

saver leaves the smallest footprint

of any comparable scanner. The

ergonomic design of the DR-7080C

makes it not only easy to operate,

but also to install. Fitting into the

tightest of spaces, it’s well suited to

compact offices.

Low maintenance

durability

The DR-7080C is made for the

heavy-duty demands of production

environments. With a life

expectancy of four-million ADF

scans and 200,000 flatbed scans,

minimum maintenance

requirements, it makes excellent

investment sense.

Powerful software

Optimum throughput is only

possible when everything works in

unison. That’s why the DR-7080C

includes high-speed USB 2.0 and

SCSI-III interfaces for easy

installation, and a wide-ranging

ISIS/TWAIN driver, for high-speed

connectivity. Multi-platform

compatibility gives you access to a

wide variety of scanning

applications and software solutions

to better handle heavy throughput.

DR-7080C

DR-7080C control panel

CapturePerfect

Canon’s scanning application,

CapturePerfect, includes a host of

useful image processing functions

and handy features, including:

•Choice of scan options. Scan-

to-print, scan-to-email, scan-to-

file and scan-to-searchable-PDF

options.

•Split image settings. When

scanning a large document,

such as a two-page spread, it

conveniently splits the image

down the middle and saves the

two images in separate files.

•Variable display options.

Choose from thumbnail images

and split-screen views for quick

and easy visual confirmation of

document images.

DR-7080C

•Scan at 70ppm, colour or

black & white

•Innovative three-line CCD

sensor

• Xenon lamp

•Flatbed and sheet-fed

scanning

•Optical resolution of 600dpi

•100-page Automatic

Document Feeder

•Automatic size and text

orientation detection

•High-speed USB 2.0 and

SCSI-III interfaces

•Wide-ranging ISIS/TWAIN

driver

•Multi-platform compatibility

Sydney

1 Thomas Holt Drive

North Ryde NSW 2113

Ph (02) 9805 2600

Fax (02) 9887 3137

Melbourne

33 Lakeside Drive

Burwood East VIC 3151

Ph (03) 9881 0000

Fax (03) 9881 0316

Brisbane

270 Gladstone Road

Dutton Park QLD 4102

Ph (07) 3214 6000

Fax (07) 3844 1019

Adelaide

1 South Road

Thebarton SA 5031

Ph (08) 8201 9193

Fax (08) 8352 2810

Perth

68 Hasler Road

Osborne Park WA 6017

Ph (08) 9347 2258

Fax (08) 9242 4120

Canberra

98 Barrier Street

Fyshwick ACT 2609

Ph (02) 6206 5999

Fax (02) 6206 5933

Auckland

Akoranga Business Park

Akoranga Drive

Northcote

Ph (09) 489 0300

Fax (09) 489 0399

BRDR-7080C-07_04

AUSTRALIA NEW ZEALAND

DR-7080C COLOUR PRODUCTION SCANNER SPECIFICATIONS

Type Desktop type flatbed

scanner with ADF

Document Feeding Automatic sheet feeding

Document Sizes Width: 139-7mm - 304-8mm

Length:128mm - 432mm.

Up to: 630mm long

document mode

Document thickness 0.06 - 0.15

42 - 128g/m2

Tray capacity 100 pages

Scanning element 3 lines CCD

Light Source Xenon Tube

Scanning Modes Binary (black & white / error

diffusion / advanced text

enhancement)

Greyscale (8 bit)

Colour (24 bit)

Resolutions (dpi) 600 x 600, 400 x 400,

300 x 300, 240 x 240,

200 x 200, 150 x 150,

100x x 100

Black & White Binary, Error Diffusion, Text

Enhanced

Scanning Speeds (black & white, grey, colour)

Simplex:

200dpi: 70ppm, 70ppm, 70ppm

300dpi: 70ppm, 68ppm, 44ppm

400dpi: 50ppm, 40ppm, 28ppm

600dpi: 50ppm, 19ppm, 13ppm

Duplex:

200dpi: 36ipm, 36ipm, 36ipm

300dpi: 36ipm, 36ipm, 36ipm

400dpi: 32ipm, 32ipm, 28ipm

600dpi: 32ipm, 19ipm, 13ipm

Interface SCSI-3 / USB 2.0

Software ISIS/TWAIN driver,

CaputrePerfect 2.0,

Job registration tool

Other Functions Colour Dropout, Deskew,

Automatic Page Size

Detection, Skip Blank Page,

Colour enhance,

Border Removal, Prescan,

Gamma Compensation,

Batch Separation,

User Preferences

Power Requirements AC220 - 240V, 50/60Hz

Power Consumption 240v 0-74A

Operating Environment 15 - 27.5°C, 25 - 75% RH

Dimensions (W x D x H) 575 x 602 x 300mm

Weight 34kg

Options/Consumables Stamp unit

The above scanning speeds apply to PCs with the following

specifications.

• CPU: Intel Celeron 733 MHz or faster

• RAM: 256MB or more

• 400MB or more of free hard disk space

Specifications are subject to change without notice. Product

names appearing in this brochure are the trademarks and/or

registered trademarks of their respective owners.
