Canon FB620U - CanoScan - Flatbed Scanner Instrucciones de instalación
Hardware
Guide
Hardware
Guide
Canon Color Image Scanner
CanoScan FB620U
2
This page intentionally left blank.
3
How to Use the Product Guide
This guide provides in-depth information on individual topics related to the CanoScan FB620U color
image scanner and the accompanying software CD-ROM. If you haven’t already read the Quick Start
Guide, we recommend that you follow its suggestions first before consulting this guide.
Organization of the Product Guide
The guide deals with scanner and software topics that could not be covered in the Quick
Start Guide. Each topic is intended to be read as a separate unit. You need only read the
topics that apply. This guide is divided into 2 sections.
Placement and Connection
How to connect it to the computer and how to position documents for scanning.
Appendices
Troubleshooting tips, care and maintenance.
• References to Windows in this guide refer to Windows 98.
4
Conventions Used in this Guide
Important information in this guide is indicated by the following symbols.
• This symbol indicates precautions that must be taken when operating the equipment.
Ensure that you read all warnings.
• This symbol indicates supplementary operating procedures and other useful information.
Use of a shielded cable is necessary to comply with technical requirements of the EMC Directive.
Disclaimer
1. While every effort has been made to ensure that the information contained in this guide is accurate and complete, no
liability can be accepted for any errors or omissions. We respectfully request that you notify the nearest Canon Customer
Care Center if you have any questions or suggestions about this guide. Canon Inc. reserves the right to change the
specifications of the hardware and software described herein at any time without prior notice.
2. No part of this guide may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any
language in any form, by any means, without the prior written permission of Canon Inc.
3. Canon Inc. makes no warranties for damages resulting from corrupted or lost data due to a mistaken operation or
malfunction of the software or equipment.
• CanoScan is a trademark of Canon Inc.
• Adobe, Adobe Acrobat and Adobe PhotoDeluxe are trademarks of Adobe Systems Incorporated.
• Microsoft and Windows are registered trademarks of Microsoft Corporation in U.S. and other countries.
• Other names and products not mentioned above may be trademarks or registered trademarks of their respective companies.
Copyright © 1998–99 Canon Inc. All rights reserved.
5
Table of Contents
Features of the CanoScan FB620U................................................................................. 7
Safety Precautions ................................................................................................... 9
Setup and Use ............................................................................................................... 13
Components Guide....................................................................................................... 16
Placement and Connection 18
Connecting to the Computer....................................................................................... 19
About the USB Interface .............................................................................................. 21
Positioning the Documents.......................................................................................... 22
How to Use the Start Button ....................................................................................... 24
The Smart Button and ScanGear Toolbox CS ........................................................... 24
Changing the Start Button Functions ...................................................................... 25
Transporting the Scanner............................................................................................. 27
Appendices 29
Troubleshooting ........................................................................................................... 30
Problems with the Initial Connection of the Scanner to a USB Port ...................... 31
Problems with Software Installation ........................................................................ 32
Problems Starting Software Programs ..................................................................... 32
Problems with the Scanner ....................................................................................... 34
Problems with Scanning............................................................................................ 35
Other questions ......................................................................................................... 37
6
Care and Maintenance ................................................................................................. 38
Major Specifications ..................................................................................................... 40
Index.............................................................................................................................. 41
Canon Technical Support ............................................................................................. 42
7
Features of the CanoScan FB620U
This scanner is a flatbed color scanner with 600 dpi optical resolution incorporating the following features.
•Compact Footprint
Ultracompact body [10.1 x 14.7 x 2.5 inches (256 x 372.5 x 63 millimeters)] for an A4/
letter-size scanner. Weighing only 2.0 kilograms (4.4 pounds), this scanner is so light
that it can easily be placed or moved to suit your convenience.
• Standby Power and Energy-Saving Features
Consumes only 2.5 watts at standby and only 5 watts at full operation. The standby
feature means the scanner is always ready to use.
•Fine Color Tones and High Resolution
Employs proprietary Canon LIDE scanning technology in an ultrahigh-sensitivity CIS
(Contact Image Sensor). Reading 12 bits (4096 colors) per red, green and blue (RGB)
channel, the scanner offers 8-bit output that reproduces brilliant tones at high
resolution.
• Convenient Start Button
The one-touch start button on the front of the scanner allows convenient use of the
accompanying software (ScanGear Toolbox CS).
8
• It is illegal to reproduce currency, bills, negotiable securities and other prohibited
documents. Reproduction of such items may be subject to criminal prosecution.
• It is illegal to reproduce legal certificates, licenses, travel tickets, and certain public and
private documents prohibited from reproduction. Reproduction of such items may be
subject to criminal prosecution.
• Please note that intellectual property protected by copyright may not be reproduced
without the express permission of the copyright holder except for personal or household
use under limited circumstances.
9
Safety Precautions
Please read and take the following precautions before using the equipment.
WARNING Indicates a warning concerning operations that may lead to death or injury to persons
if not performed correctly. In order to use the equipment safely, always pay attention
to these warnings.
CAUTION Indicates a caution concerning operations that may lead to injury to persons or
damage to property if not performed correctly. In order to use the equipment safely,
always pay attention to these cautions.
About Locations
WARNING
• Do not place equipment near flammable liquids such as alcohol or thinners. If the
internal electrical parts come in contact with flammable liquids, fire or electric shocks
may result.
• Do not place the following objects on top of the equipment. If the internal electrical
parts come in contact with these objects, fire or electric shocks may result.
- metallic objects, such as necklaces
- containers with liquid, such as cups, vases and flower pots
If any of these objects or liquids enter the equipment, immediately unplug the AC
adapter and contact your retailer or Canon Customer Care Center.
10
CAUTION
• Do not place the equipment in the following areas. Fires or electric shocks may result.
- Areas with high humidity
- Areas subject to direct sunlight
- Areas with high temperatures
- Areas near flame sources
• Do not place on shaky stands, unstable surfaces or surfaces subject to frequent vibrations.
If the equipment falls, it may cause injuries.
• Do not place heavy objects on the equipment. Objects may fall and cause injuries.
About the Power Supply
WARNING
• Do not damage, mutilate or modify the power cord or AC adapter. Do not place heavy
objects on, pull or excessively bend the power cord. Damaged wires may cause fire or
electric shocks.
• Do not plug/unplug the AC adapter with wet hands. You may be electrocuted.
• Do not connect excessive numbers of plugs into one electrical outlet. It could cause fires
or electric shocks.
• Do not twist or tie electrical cords together. It could cause fires or electric shocks.
• Always plug power cords or AC adapters in all the way. If not plugged in completely,
they may cause fires or electric shocks.
• As a rule, do not use electrical extension cords. They could cause fire or electric shocks.
If the use of an extension cord is necessary, do not use one longer than 15 ft. (5 m).
Make sure that the extension cord is not twisted, the connection between the power
