Canon TS3100 Series Manual de usuario

Guía de inicio

Lea primero Información de seguridad

e información importante (apéndice).

Getting Started

Read Safety and Important Information

(addendum) rst.

Instalación de la impresora.............................................página 1

Conexión con el ordenador y con el teléfono

inteligente o la tableta.....................................................página 4

Cómo sujetar

la impresora

Películas explicativas

Installing the Printer...........................................................page 1

Connecting with Computer and Smartphone/Tablet..........page 4

How to Hold Printer Explanatory Movies

ENGLISH

1. Checking Included Items

□ Power cord □ FINE cartridge

□ Safety and Important Information

□ Getting Started (this manual)□ Setup CD-ROM for

Windows PC

2. Removing Packing

Materials / Turning on

Printer

1 Remove the packing materials (such as orange

tape) from outside the printer.

2 Open the cover.

3 Remove the orange tape and the protective

material and discard them both.

4 Close the cover.

5 Connect the power cord.

Do not connect any cables except the power cord

yet.

6 Press the ON button.

If E> 0> 9 appears on the screen, press the ON

button to turn off the printer, and then redo from

step 2 of chapter 2 "Removing Packing Materials /

Turning on Printer".

3. Installing FINE Cartridge

1 Open the cover.

2 aTake out the Color FINE cartridge from the

package.

bRemove the protective tape.

Do not touch.

Be careful of ink on the protective tape.

3 aInsert the Color FINE cartridge into the FINE

cartridge holder on the left at a slight upward

angle.

bPush the FINE cartridge in and up rmly until it

snaps into place.

Make sure that the FINE cartridge is installed

horizontally.

Do not bump it against

the surrounding parts.

Click!

ENGLISH

4 Repeat steps 2 to 3 and install the Black FINE

cartridge as well, on the right.

5 Close the cover.

If E> 0> 4 appears on the screen, return to step 3

of chapter 3 "Installing FINE Cartridge" and conrm

that the Color and Black FINE cartridges are

correctly installed.

4. Loading Paper

1 Open the paper support.

2 Slide the paper guide to the left.

3 aLoad plain LTR or A4 size paper against the

right edge with the print side facing up.

bSlide the paper guide to align it with the side of

the paper stack.

4 Pull out the paper output tray.

5 Open the output tray extension.

6-A. Connecting to Computer

macOSWindows

You need a connection setup for each computer. Proceed with the setup from step 1 for each computer.

1 Start the setup le for either method or method .

Downloading from the Internet

aOpen a web browser ( etc.) on your computer.

bInput the following URL and access the Canon

website.

cSelect Set Up.

dInput the model name of your printer and click OK.

You can select a model name from the list.

eClick Setup.

The procedures for Windows and Mac OS are shown

below. If you are using a computer with an OS other

than Windows or Mac OS, such as a Chrome OS, do

the setup according to the on-screen instructions.

fClick Download and download the setup le.

gExecute the downloaded le.

Proceed to step on the next page to

continue.

5. Preparing for Connection

In the following description, smartphones and tablet

devices are collectively described as smartphone.

1 Conrm that the screen appears as shown below.

Flashing

If the above screen does not appear, press the ON

button to turn off the printer, and then redo from "2.

Removing Packing Materials / Turning on Printer".

From here on, proceed to a step according to how you use

the printer.

• To use the printer by connecting only to a computer

or both to a computer and smartphone

"6-A. Connecting to Computer"

• To use the printer by connecting only to a

smartphone

"6-B. Connecting to Smartphone" on page 6

To use the printer without connecting to

a computer or smartphone

aPress the Stop button on the printer.

bConrm that the screen appears as shown below.

The setup is now complete.

ENGLISH

Using Setup CD-ROM (Windows Only)

aLoad the Setup CD-ROM in your computer.

■ When using Windows 10 or Windows 8.1:

bWhen the following message appears on the right

side of your computer screen, click it.

cIf the following screen appears, click Run

Msetup4.exe.

dIf the User Account Control dialog box appears,

click Yes.

When This Message Does Not Appear (or Has

Disappeared)

1. Click File Explorer on the taskbar.

2. Click This PC on the left side of the opened window.

3. Double-click the CD-ROM icon on the right side of

the window.

If the contents of the CD-ROM appear, double-click

Msetup4.exe.

4. Proceed to step d.

■ When using Windows 7:

b When the AutoPlay screen appears, click Run

Msetup4.exe.

c If the User Account Control dialog box appears,

click Continue.

When AutoPlay Screen Does Not Appear

1. Click Computer from the start menu.

2. Double-click the CD-ROM icon on the right side of

the opened window.

If the contents of the CD-ROM appear, double-click

Msetup4.exe.

Proceed to step to continue.

2 Click Start Setup.

The connection with your computer is now complete. You can print from your

computer.

If the following screen appears, click Exit.

Follow the on-screen

instructions to proceed

with the setup.

6-B. Connecting to Smartphone

AndroidiOS

You need a connection setup for each smartphone. Proceed with the setup from step 1 for each smartphone.

Preparation

• Turn on Wi-Fi on your smartphone.

• If you have a wireless router, connect your smartphone to the wireless router you want to connect to the printer.

* For operations, refer to manuals of your smartphone and the wireless router or contact those manufacturers.

1 Install the application software Canon PRINT Inkjet/SELPHY in your smartphone.

: Search "Canon PRINT" in App Store.

: Search "Canon PRINT" in Google Play.

Or access the Canon website by scanning the QR code.

* You may not connect your smartphone to the Internet wirelessly during connecting the printer to the smartphone directly.

In that case, you may be charged depending on the contract with your service provider.

* Up to 5 devices can be connected to the printer via wireless LAN connection directly.

2 Check the display on the printer.

The screen turns off when no operation is made for about 10 minutes. Press one of the buttons on the operation

panel (except for the ON button) to display the screen.

■ If the following screen appears:

Check the icon on the upper left, and then proceed

to or .

If appears, the printer cannot communicate

by wireless LAN connection. For details, access

"http://ij.start.canon" to see Frequently Asked Questions.

■ If the following screen appears:

Proceed to .

No (Proceed to .)

YES

aTap the installed application software.

bFollow the on-screen instructions to register the

printer.

cMake sure that the following screen appears.

The connection with your smartphone is

now complete. You can print from your

smartphone.

To print photos, load photo paper. Proceed to "Loading

Photo Paper" on page 8.

The following icon appears.

(The printer is connected to a network.)

Flashing

ENGLISH

Procedures below vary depending on iOS or Android. Select your operating system and proceed to its

procedure.

aTap Settings on your smartphone's home screen,

and tap Canon_ij_XXXX in the Wi-Fi settings.

If Canon_ij_XXXX does not appear on the list, see

"Troubleshooting" below to operate the printer, and

then repeat step a.

bTap the installed application software.

cFollow the on-screen instructions to register the

printer.

Follow the on-screen instructions to proceed

with the setup.

If you select Auto Select Conn. Method

(recommended) on the connection method

selecting screen, the appropriate connection

method is selected automatically depending on

your environment.

dMake sure that the following screen appears.

aTap the installed application software.

bFollow the on-screen instructions to register the

printer.

If a message saying "Printer is not registered.

Perform printer setup?" does not appear, see

"Troubleshooting" below to operate the printer, and

then wait for a while until the message appears.

Follow the on-screen instructions to proceed

with the setup.

The appropriate connection method is selected

depending on your environment.

cMake sure that the following screen appears.

The connection with your smartphone is now complete. You can print from your

smartphone.

To print photos, load photo paper. Proceed to "Loading Photo Paper" on page 8.

Troubleshooting

Printer is not found from your smartphone.

aPress and hold the Direct button on the printer for about 2 seconds

until the icon starts to ash on the screen.

bReturn to the operation of your smartphone.

Flashing

1 Open the paper support.

2 Slide the paper guide to the left.

3 aLoad photo paper against the right edge with

the print side facing up.

bSlide the paper guide to align it with the side

of the paper stack.

4 Press the Paper button, select a paper size, and

then press the OK button.

5 Pull out the paper output tray.

6 Open the output tray extension.

Loading Photo Paper

If Print Results Are Unsatisfactory

If the print results are not what you expected, such as if straight lines are crooked or colors are inconsistent, do a

Print Head Alignment.

For details, click the Maintenance on the Online Manual and refer to If Printing Is Faint or Uneven > Aligning

the Print Head.

Refer to the back cover for how to open the Online Manual.

■ Lines Are Misaligned ■ Uneven or Streaked Colors
