TableofContents

TurningthePoweronandoff ................................................. 2

TurningthePoweron ........................................................................................ 2

TurningthePoweroff ........................................................................................ 4

Paper ............................................................................................... 5

Compatiblepaper ................................................................................................ 5

IncompatiblePaper ............................................................................................. 7

PrintableAreas .................................................................................................... 8

LoadingPaper .............................................................................. 9

CautionswhenLoadingPaper ....................................................................... 9

PrintingfromthePaperCassette ..................................... 10

PaperJams ................................................................................ 15

CancelingPrinting ................................................................... 17

CheckingOperations .............................................................. 19

TestPrint ............................................................................................................ 19

StatusPrint ........................................................................................................ 21

ReplacingaTonerCartrige .................................................. 23

TurningthePoweronandoff

Aftertheprinterandoptionsgothroughastatuscheckandcalibration,printingisenabled.

Whenthepoweristurnedoff,alloftheprintingdatainthememoryislost.Alwayscheckthat

theジョブindicatorisoffbeforeturningoffthepowerinordertoavoiddeletingimportant

printingdatabyaccidentordeletingprintingdatafromanothercomputerwhenconnectedtoa

network.

TurningthePoweron

Toturnonthepowerfollowtheinstructionsbelow.

Pressthepowerbuttononthe

printer.

Thepowerbuttonwillnowbeinapressed-

downstate.

Theoperationpanelindicatorsandthe

displaycomesonandthestatusoftheprinter

andoptionaldevice(s)isself-diagnosed.

Iftheresultsoftheself-diagnosisarenormal,

theオンライン indicator,the印刷可

indicatorandtheselectedpaperfeed

indicatorcomeonandprintingisenabled

whenthemessage[00 インサツカノ

ウ]appearsonthedisplay.



印刷可

ジョブ

メッセージ

ユーティリティ

動作モード

セットアップ

ジョブキャンセル

リセット／実行

排出

オンライン

給紙選択

両面

00 ｲﾝｻﾂ ｶﾉｳA4



Thefollowinginformationappearsonthedisplay.

00ｲﾝｻﾂｶﾉｳA4



Printingenabled,no

printingdatabeing

processed

Currentlyselected

outputtray

Powersaving(Sleepmode)

Theprinterwillgointosleepmodetosavepowerifnooperationsarecarriedoutandno

dataissentfromthecomputerforasettime.

Sleepmodeisautomaticallycanceledifdataissentfromthecomputeroranoperation

panelkeyispressed.

● Thefactorysettingforsleepmodeis60minutes.Youcanusethe

menufunctiontochangethisto15,30,60or180minutes.

TurningthePoweroff

Toturnoffthepowerfollowtheinstructionsbelow.

● Iftheprinterisconnectedtoanetwork,checkthatothercomputersarenot

printingbeforeyouturnoffthepower.

●

Ifyouturnoffthepowerwhentheジョブindicatorison,anyprintingdata

remainingintheprinter’smemorywillbelost.Gooff-line,pressthe 排出

keytooutputtheprintingdataandthenturnoffthepower.

● Donotturnofftheprinterwhileprinting.

● Donotturnofftheprinterduringtheself-diagnosiscarriedoutimmediately

afterturningthepoweron.

Checkthattheジョブindicatoris

off.



印刷可

ジョブ

メッセージ

Off

Pressthepowerbuttononthe

printer.

Thepowerbuttonwillpopup.

The message [パワーオフチュウ]

flashesonthedisplayandafterawhile

(approximately10minutes),thepowerwill

turnoff.

● Whenthepoweristurnedoff,theinternalcoolingfanontherearpanelof

theprinterwillcontinuetooperateuntiltheinterioroftheprinterhasbeen

fullycooledoff.Ifyouwanttoremovethepowercable,waituntilthecooling

fanhascompletelystopped(approximately10minutes).

Paper

CompatiblePaper

Usethecorrectpaperinordertogetthebestperformancefromyourprinter.Usingincompatible

papercanleadtoreducedprintingqualityandpaperjamming.

Papersource Papertype Size Weight Max. Papertype/

(g/m

) sheetno. mediasetting

Papercassette Plainpaper A5,B5,A4,Letter,

64-105

approx.250 フツウシ

Executive,Legal (64g/m

)

Paperfeeder Plainpaper A5,B5,A4,Letter,

64-105

approx.500 フツウシ

unit(option) Executive,Legal (64g/m

)

Plainpaper width:76.2-216mm

64-105

approx.100 フツウシ

length:127-356mm (64g/m

)

Thickpaper width:76.2-216mm

106-135

approx.50 アツガミ

length:127-356mm (128g/m

)

Glossypaper A4(CanonColorLaser − approx.50 コウタク

GlossypaperGF-2A4) フィルム

Papertray

Transparencies

A4(CanonColorLaser − approx.50 OHP

OHPpaperTR-1A4)

Labelsheet A4(Canondomestic − approx.50 アツガミ

labelsheet:7.8g)

● Thisprintercannotoutputpaperthatislessthan176mminlengthface

down.Alwaysoutputthistypeofpaperintothesub-outputtray(face-up

output).

● Alwaysusetheoptionalduplexunitwhenyouareduplexprinting.Youcannot

manuallyduplexprintfromthepapertrayorpapercassette.Ifyoudo

manuallyduplexprint(feedinthereversesideofasheetofpaperthatyou

haveprintedon)thiscouldleadtopoorprintingquality.

● IfyouloadExecutive-sizepaperintothepaperfeeder,leaveplentyofspace

betweenthetopofthestackandthepaperlimitguide(→ p.12).(→ p.10)

● PlainPaper

Youcanuseplainpaperof76.2-216mmwidth,127-356mmlengthand64-105g/m2weight

withthisprinter.ThisincludesA5-,B5-,A4-,Letter-,Legal-andExecutive-sizepaper.You

canloadstandard-sizeplainpaperintothepapercassetteand500-sheetpaperfeeder.Paperof

othersizesshouldbeloadedintothepapertray.Attachingtheoptionalduplexunitallowsyou

toautomaticallyduplexprintonplainpaper.

● ThickPaper

Youcanusethickpaperof76.2-216mmwidth,127-356mmlengthand106-135g/m2weight

withthisprinter.ThisincludesA5-,B5-,A4-,Letter-,Legal-andExecutive-sizepaper.Thick

papershouldbeloadedintothepapertray.

● Glossypaper

Touseglossypaper,useonlydedicatedCanonGF-2A4ColorLaserGlossypaper(A4size).

● GF-2A4GlossypaperisdesignedespeciallyforusewiththeLBP-2040

printer.Donotusethispaperinanyothercolorlaserprinterormonochrome

printer.Suchusemayresultinprintermalfunctionordeteriorationinpicture

quality.

● Transparencies

Tousetransparencies,useonlydedicatedCanonTR-1A4ColorLaserOHPpaper(A4size).

● TR-1A4OHPpaperisdesignedespeciallyforusewiththeLBP-2160,LBP-

2040andtheLBP-2260.Donotusethispaperinanyothercolorlaserprinter

ormonochromeprinter.Suchusemayresultinprintermalfunctionor

deteriorationinpicturequality.

● Transparencies,otherthanthosespecifiedsuchasOHPpaperforusewith

CanonLASERSHOTLBP-2030(CanonT-H1A4ColorLaserLBPOHP

paper),OHPforCLC,andOHPformonochromeuse(CanondomesticLBP

transparencies),mustnotbeusedinthisprinter.Suchusemayresultina

malfunctioninthefixingassembly,ordeteriorationofpicturequality.

● Labelsheet

A4-sizelabelsheetcanbeusedinthisprinter.

● Donotusethefollowingtypesoflabelsheet.Ifasheettypethatdoesnot

conformtospecificationsisused,paperjamsthatarehardtoremovemay

occurorprintermalfunctionsmaybecaused.

・ Sheetwithlabelsthatarelikelytopeeloff,orsheetonwhichpartofthe

labelshavebeenused.

・ Coatedsheetthatcaneasilypeelofffromthebackingsheet.

・ Labelsheetwithsomeadhesivesurfacesexposed.

IncompatiblePaper

Inordertoavoidpaperjamsanddamagingtheprinter,donotusethefollowingtypesofpaper.

● Paperthatjamseasily

・ Paperthatistoothickortoothin

・ Non-standardsizepaper

・ Wetordamppaper

・ Tornpaper

・ Coarseorextremelysmoothpaper

・ Paperwithbinderholes,serratedpaper

・ Curledpaper,creasedpaper

・ Paperwithspecialcoatingsonit(suchascoatingsespeciallyforinkjet

printers)

・ Labelsheetwithlabelsthatpeeloffeasily

・ Paperthathasalreadybeenusedforphotocopyingorlaserprinting

(reversesidealsoincompatible)

● Heat-sensitivepaper

・ Paperwithinkthatmelts,burnsorgivesofftoxicvaporsintheheatof

thefixingassembly(approx.180℃)

・ Thermalpaper

・ Colorpaperwithaprocessedsurface

・ Speciallycoatedpaper(suchascoatingsespeciallyforinkjetprinters)

・ Paperwithadhesiveonit

● Paperthatcancauseprintermalfunctionordamage

・ Carbonpaper

・ Paperwithstaples,clips,ribbonsortapeattached

● Paperonwhichtonercannotfixeasily

・ CoarsepapersuchaspulppaperandJapanesewritingpaper,paper

withroughfibers

・ Paperwithspecialcoatingsonit(suchascoatingsespeciallyforinkjet

printers)

PrintableAreas

Theareasthatcanbeprintedonthepaperaregivenbelow.

● Plainpaper,thickpaper,transparencies,glossypaper,labelsheet

Plainpaper,thickpaper,transparencies,glossypaperandlabelsheetcanbeprintedinareas

withaminimummarginof5millimeters.

5mm

LoadingPaper

Whenthepaperinthepapercassetteandthepapertrayrunsout,thedisplaywillshoweitherthe

message[11 XXXヨウシガアリマセン]or[17 カセットヨウシナシ],toshowthat

thepapersourcesareempty.Whenyouseethesemessages,loadpaperintothepapersource.

CautionswhenLoadingPaper

Loadpaperonlyinthefollowingcircumstances.

■ Whentheジョブindicatorisoff



印刷可

ジョブ

メッセージ

Off

■ Whenthemessage[ヨウシガア

リマセン]appearsonthe

display

■Whentheprinterisoff

● Neveropenthecoverorcassettewhileprintingisinprogressandtheジョ

ブindicatorisflashing.Thiscouldcausetheprintertostopandyouwillnot

beabletoprint.

11XXXﾖｳｼｶﾞｱﾘﾏｾﾝ


