Canon SELPHY CP770 Guía de configuración

Printing Guide

Easy Printing

Beautiful Prints

and Fun!

ENGLISH

COPY

BEAUTIFUL

Long lasting

ﬁne prints

FUN

Creating your

original album

SELPHY Has Come to Your Home.

A stylish and powerful printer for preserving precious family moments.

SELPHY enriches your daily life with beautiful photo prints.

Table of Contents

Unpack ..........................................................................................................................p. 4

Getting Started..............................................................................................................p. 5

Printing from Memory Cards .........................................................................................p. 7

What You Can Do with Your SELPHY Printer ................................................................p. 9

Printing from Digital Cameras, Mobile Phones or Computers.....................................p. 15

COPY

EASY

Quick printing

Accessories (Sold Separately)....................................................................................p. 20

Cleaning, Storing or Carrying the Printer....................................................................p. 21

Troubleshooting...........................................................................................................p. 23

Please Read (Safety Precautions and Handling Precautions)....................................p. 27

Speciﬁcations..............................................................................................................p. 30

Scrapbook created by

Art&Craft DUO YOKOHAMA-AOBADAI SHOP

by KURETAKE Co.,Ltd. (m&k)

COPY

Unpack

Package Contents

The package contains the following accessories. If there is anything missing, please contact the store

where you purchased this product.

Components Guide

Controls (p. 9)

Power Lamp

Lights green:

(Power on) Standby

Blinks green: Printing

Lights orange: Charging

battery

Blinks orange: Low battery

Lights/blinks red: Error

Memory Card Slots

Battery Cover Lever

Battery Cover

Air Vents

Paper Ejection Slot

Ink Cassette Compartment

Ink Cassette Lever

Paper Cassette Slot

Ink Cassette Compartment

Cover

Paper Cassette Slot Cover

Infrared Data Receiver

USB Terminal for

Camera Connection

USB Terminal for Computer

Connection

DC IN (Power Input)

Terminal

Printer Unit

Compact Power Adapter

Power Cord

Paper Cassette

(Postcard Size)

Starter Paper Pack

(Postcard Size,

5 sheets)

Storage

arrangement

Cleaner

Starter Ink Cassette

(Postcard Size

for 5 prints)

CD-ROM:

Compact Photo Printer

Solution Disk

Do not use the basket (storage

case) for purposes other

than storing the printer and

accessories.

Printing Guide

(This guide)

•

Warranty Card

•

Paper Cassette

(Card Size)

Basket (Storage case)

Release

the catch.

COPY

Getting Started

Insert the ink and paper cassettes into the printer.

Preparing the Ink Cassette

Conﬁrm that the ink sheet is taut with no slack.

Conﬁrm the size indication.

Push and turn here if the ink sheet is slack.

Ink sheet

Do not touch

or pull on.

Preparing the Paper Cassette

Open the outer lid. Open the inner lid.

For Wide Size

paper cassette

(sold separately),

slide the inner lid

ﬁrst, then open it.

Remove the

protective sheet.

The shiny side is

faced up.

Set the paper. Close the inner lid.

Clicks.

For Postcard Size paper with a stamp ﬁeld, orient the

stamp ﬁeld on the reverse side towards the inner lid.

For Wide Size paper cassette, close the

inner lid and slide it until it clicks.

Always use the paper speciﬁc to SELPHY CP series printers included in the genuine Canon brand Color

Ink/Paper Sets. Commercially sold printing paper, regular postcards, or paper speciﬁed for use in SELPHY

ES series printers cannot be used.

Do not set 19 or more sheets in the paper cassette (13 or more for Wide Size sheets).

Mistakenly reversing the paper in the cassette may damage the printer.

Do not bend the paper at the perforations or separate it before printing.

Do not use label sheets that have begun to peel or label sheets with portions peeled back.

Do not write on a sheet before printing with the printer. It may lead to a malfunction.

Do not print on printed paper.

Never reuse a spent ink cassette.

•

Conﬁrm the

size indication.

Inner lid

COPY

Paper visible through

opening

Installing the Ink Cassette and the Paper Cassette

Open the two covers of the printer.

Ink cassette

compartment cover

Paper cassette

compartment cover

Insert the ink cassette and the paper cassette.

Paper cassette

(Insert all the way into

the slot)

Ink cassette

(Insert until it clicks)

Ink cassette lever

To remove the ink cassette, slide up the ink cassette lever.

Close the ink cassette cover.

Placing and Connecting the Printer

Set up and connect your SELPHY printer in the following manner for safe use.

Do not block the air vents.

To a power

outlet

Power cord

Compact power adapter

Do not place the printer on an unstable or tilted surface.

Keep the printer at least 1 meter (3 ft.) from devices emitting electromagnetic waves or strong magnetic

ﬁelds.

•

Conﬁrm the size indication

(Should be the same)

You can also use the battery pack sold separately (p. 20).

10 cm (4 in.)

Make sure there is free space at the front and back

of the printer of at least the length of the paper.

(During printing, the paper will pass in and out.)

Insert the power cord

to the compact power

adapter.

Plug the other end into a

power outlet.

Connect the compact

power adapter to the

printer.

COPY

Printing from Memory Cards

Print images from a memory card that is inserted into the printer.

Compatible Memory Cards

Make sure that no camera or computer is connected to the printer.

This SELPHY printer supports image data conforming to the Design rule for Camera File system (Exif

compliant) and DPOF (Ver.1.00) standard.

Use a memory card formatted in the device used for taking the images. A memory card formatted in the

computer might not be recognized.

Images that have been edited on a computer might not be displayed or printed properly.

An image that has been taken by a mobile phone might not be displayed or printed properly depending

on the size of the image when it was taken.

Movies cannot be played back on this printer.

•

Slot Memory Cards

CompactFlash Card

Microdrive

xD-Picture Card*1

SD Memory Card

miniSD Card

SDHC Memory Card

miniSDHC Card

MultiMediaCard

MMCplus Card

HC MMCplus Card

MMCmobile Card

RS-MMC Card*2

microSD Card

microSDHC Card

MMCmicro Card

Memory Stick

Memory Stick PRO

Memory Stick Duo

Memory Stick PRO Duo

Memory Stick micro

: You need to use the speciﬁc adapter for the memory card. Please purchase the speciﬁc adapter.

*1 Purchase the CompactFlash Card Adapter for xD-Picture Card.

*2 Reduced-Size MultiMediaCard

For memory cards requiring an adapter, be sure to ﬁrst insert the memory card into the adapter before

inserting the adapter into the appropriate card slot. If you insert the memory card into a card slot without

ﬁrst inserting it into an adapter, you may not be able to remove the memory card from the printer.

Please refer to the user guide included with your memory card and adapter for handling instructions.

•

COPY

Printing the Selected Image (Basic Printing)

You can select images, specify the number of copies for each, and then print them all out. If you want

to embed the date, follow the instructions on page 12 before printing.

Do not pull out the paper cassette or open the ink cassette cover just after turning on the printer or while

printing. This will lead to malfunctions.

During printing, the paper will pass in and out several times. Do not touch or pull on the paper until printing

has ﬁnished and the printed sheet collects on the print output tray (on top of the paper cassette).

Do not let 10 or more sheets of printed paper collect on the print output tray.

Do not pull out the memory card during printing.

•

Press and hold until the start-up image

appears on the LCD monitor to turn on the power.

Insert a single memory card into the

appropriate card slot.

When inserting a small memory card like miniSD Card in

the “SD/miniSD/MMC+/RS-MMC” slot, insert the card in

the lower portion of the slot.

Press or to select the image you wish to

print.

Press and hold down or : Jumps images by 5.

Number of copies of

the selected image

Label side

Press or to set the number of copies.

Press and hold down or : Increases or decreases the number

of copies by 5.

You can specify up to 99 copies (or total of 999 prints).

•

Press .

Printing starts.

To print other images together, repeat the steps and .

Pressing when the total number of prints is 0 copies will print one copy of the image displayed on the

LCD monitor.

To remove a memory card, grasp the portion of the card protruding from the card slot and pull it out.

Use a marker pen to write on the printed sheets.

•

Number of sheets

required

To change the display language, refer to page 14.

Insert all the way.

COPY

What You Can Do with Your SELPHY Printer

Enjoy a multitude of basic and advanced functions with SELPHY.

Buttons and LCD Monitor

Controls

1LCD monitor Displays images, setting screens, and

error messages.

2Turns on or off the power.

3Displays the menu screen.

DPOF Print (p. 13)

Print All Images (p. 13)

Print Settings (p. 10)

Printer Setup (p. 14)

•

4,Speciﬁes the number of prints or

changes menu items.

5Selects settings.

6Returns to the previous operation or

cancels printing.

7,Switches between images or changes

setting values.

8Starts printing.

LCD Monitor

Display when [Info Display] (p. 14) is set to [On].

The LCD monitor may be covered with a thin plastic ﬁlm for protection against scratches during shipment.

If so, remove the ﬁlm before using the printer.

1File Number

2Installed ink cassette type

(In this example, [P] stands for Postcard Size)

3Card slot being used

4Print Settings (p. 10)

Date

Correct Red-Eye

My Colors

Page Layout

Image Optimize

Borders

(Settings that are not available are grayed out)

5Number of sheets required

6Number of copies of the selected image

COPY

Print Settings

You can make print-related settings such as bordered/borderless or print layout.

Date

Prints images with the date

when they were taken.

On, Off ( )

Correct Red-Eye

Corrects red-eye in the image.

On, Off ( )

My Colors

Changes the color of the image.

Off ( ), Vivid*1,

Neutral*2, Positive Film*3,

Sepia, B/W

Page Layout

Sets the number of

images to print on a

single sheet of paper.

The number of copies

selected for an image (p. 8)

will be printed in the set

layout.

1-up ( ), 2-up,

4-up, 8-up,

Index

Image Optimize

Corrects the images for optimum

quality.

On ( ), Off

Borders

Prints bordered or

borderless.

Bordered,

Borderless ( )

*1 Contrast and color depth are enhanced.

*2 Contrast and color depth are suppressed.

*3 Produces intense, yet natural-looking colors, such as those obtained with positive ﬁlm.

The default setting is marked as .

COPY

Otros manuales para SELPHY CP770

Tabla de contenidos

Otros manuales de Impresora de Canon

Canon

Canon MultiPASS L6000 Manual de usuario

Canon

Canon Pixma Pro 9000 Mark II series Manual de usuario

Canon

Canon imagePROGRAF iPF820 Manual de usuario

Canon

Canon PIXMA G2060 Series Manual de usuario

Canon

Canon imagePROGRAF iPF6350 Guía del usuario

Canon

Canon LBP7100Cn Manual de usuario

Canon

Canon imagePROGRAF iPF825 MFP Basic Guide No.1 Manual de usuario

Canon

Canon BJ-5 Manual de instrucciones

Canon

Canon iPF750 - imagePROGRAF Color Inkjet Printer Manual de usuario

Canon

Canon Satera LBP8610 Manual de usuario

Canon

Canon ImageRUNNER ADV Manual de usuario

Canon

Canon imageprograf IPF785 Manual de usuario

Canon

Canon PIXMA TS5320 Guía de configuración

Canon

Canon Pixma Pro9500 Series Manual de usuario

Canon

Canon S520 Manual de usuario

Canon

Canon imagePROGRAF TX-4000 Manual de usuario

Canon

Canon PIXMA iP8720 Manual de usuario

Canon

Canon G4070 Series Manual de usuario

Canon

Canon iP6600D - PIXMA Color Inkjet Printer Manual de usuario

Canon

Canon iP4200 - PIXMA Photo Printer Manual de usuario

Canon

Canon PIXMA TS3120 Guía de configuración

Canon

Canon mg6400 series Manual de usuario

Canon

Canon MultiPASS C50 Manual de usuario

Canon

Canon LBP2900 series Manual de usuario

Manuales populares de Impresora de otras marcas

Lexmark

Lexmark 1400 Series Manual

Evolis

Evolis Elypso Manual de usuario

Kyocera

Kyocera FS-9530DN Manual de usuario

Samsung

Samsung BIXOLON SRP-350plusF Manual de usuario

Dell

Dell Color Laser Printer 2130cn Manual de usuario

Tektronix

Tektronix Phaser 840 Manual de usuario

Epson

Epson ET-7750 Instrucciones de funcionamiento

Eltron

Eltron P210 Guide Manual de usuario

Ricoh

Ricoh MD-P1 Manual de usuario

Epson

Epson SC-F7100 series Manual de usuario

Epson

Epson Stylus C40UX Manual de usuario

IRA3D

IRA3D POETRY4 Manual de usuario

Ricoh

Ricoh Aficio AP400 Manual de usuario

BIXOLON

BIXOLON SRP-352plusV Manual de usuario

Epson

Epson Stylus Photo PX700W Instrucciones de montaje

Ricoh

Ricoh SP204SF Manual de usuario

Star Micronics

Star Micronics futurePRNT TSP100 Manual de usuario

Epson

Epson TM-TM88V-i Manual de uso y cuidado
