PIXMA TS5020 Easy Wireless Connect setup - Mac

OS X Computers

Description

mac / Wireless Network

Solution

Wireless Setup - Mac OS X Computers

To be able to use the PIXMA TS series printer to print or scan wirelessly on a Mac computer, the printer must

first be connected to the Wireless Network and software drivers and applications installed on the computer. The

instructions / screenshots below show the setup program steps when using the "Easy Wireless Connect"

method to connect to the wireless network.

The setup process consists of 2 parts:

1. Starting Easy Wireless Connect on the printer, and

2. Downloading and running the setup file to install the drivers and software.

1. Start Easy Wireless Connect on the printer.

Prior to starting setup on the Computer, Smartphone or tablet device, start the Easy wireless connect on the

printer. Then complete the setup on the computer or device.

See the procedure below to start the Easy Wireless connect.

1. Make sure that the printer is turned on.

If the power is on, the POWER lamp (A) will be lit.

Notes on Wireless Connection (http://ugp01.c-ij.com/ij/webmanual/Tutorial/TS5000%20series/EN/TRL/trl-

a0002.html)

(Appears in a new window)

If the printer is performing cleaning, print head

alignment, or other processes

8/13/2017 Canon Knowledge Base - PIXMA TS5020 Easy Wireless Connect setup - Mac OS X Computers

https://support.usa.canon.com/kb/index?page=content&id=ART167274&pmv=print&impressions=false&viewlocale=en_US 2/17

Wait for the process to finish, before starting setup.

2. Press the HOME button (B) on the printer.

If an error screen is displayed, press OK button, then press the HOME button.

3. Use the buttons (C) to select (D).

4. Press the OK button.

5. Select LAN settings and press the OK button.

6. Select Wireless LAN and press the OK button.

7. Select Wireless LAN setup and press the OK button.

8/13/2017 Canon Knowledge Base - PIXMA TS5020 Easy Wireless Connect setup - Mac OS X Computers

https://support.usa.canon.com/kb/index?page=content&id=ART167274&pmv=print&impressions=false&viewlocale=en_US 3/17

8. Select Easy wireless connect and press the OK button.

9. Select Yes and press the OK button.

10. When the printer preparation is complete, the screen below appears.

Return to the setup application screen and proceed with the setup.

2. Download and run the setup file.

Get the Setup File (http://ugp01.c-ij.com/ij/webmanual/WebPortal/PTL/ptl-setup.html?lang=en&type=setup&area=us&model=ts50&os=m)

Read the information taking note of the information concerning warning messages that may appear during setup

then click the "Download" button.

Start setup.

8/13/2017 Canon Knowledge Base - PIXMA TS5020 Easy Wireless Connect setup - Mac OS X Computers

https://support.usa.canon.com/kb/index?page=content&id=ART167274&pmv=print&impressions=false&viewlocale=en_US 4/17

1. Start setup. Click Next on the first screen.

2. Select Start Setup

8/13/2017 Canon Knowledge Base - PIXMA TS5020 Easy Wireless Connect setup - Mac OS X Computers

https://support.usa.canon.com/kb/index?page=content&id=ART167274&pmv=print&impressions=false&viewlocale=en_US 5/17

3. Select appropriate region and click Next

8/13/2017 Canon Knowledge Base - PIXMA TS5020 Easy Wireless Connect setup - Mac OS X Computers

https://support.usa.canon.com/kb/index?page=content&id=ART167274&pmv=print&impressions=false&viewlocale=en_US 6/17

4. Select Yes on the License Agreement.

5. Select Agree or Do Not Agree to the Survey.

8/13/2017 Canon Knowledge Base - PIXMA TS5020 Easy Wireless Connect setup - Mac OS X Computers

https://support.usa.canon.com/kb/index?page=content&id=ART167274&pmv=print&impressions=false&viewlocale=en_US 7/17

6. Status check occurs

8/13/2017 Canon Knowledge Base - PIXMA TS5020 Easy Wireless Connect setup - Mac OS X Computers

https://support.usa.canon.com/kb/index?page=content&id=ART167274&pmv=print&impressions=false&viewlocale=en_US 8/17

7. Select Yes on the Connection Method. *Note : (Model #) used in

example. Actual model series number will appear in the setup program.

8. Setup continues. If the *Select wireless router screen (below) appears,

select the wireless router to connect to the printer, enter the Network Key

(password) and click Next.

* The router being used and its network settings determines whether or

not this screen appears

8/13/2017 Canon Knowledge Base - PIXMA TS5020 Easy Wireless Connect setup - Mac OS X Computers

https://support.usa.canon.com/kb/index?page=content&id=ART167274&pmv=print&impressions=false&viewlocale=en_US 9/17

9. Network Connection completed. Click Next

8/13/2017 Canon Knowledge Base - PIXMA TS5020 Easy Wireless Connect setup - Mac OS X Computers

https://support.usa.canon.com/kb/index?page=content&id=ART167274&pmv=print&impressions=false&viewlocale=en_US 10/17

10. Drivers install.

11. Click Add Printer on the Add Printer screen
