PIXMA MP110/130

SERVICE

MANUAL

REVISION 0

HY8-13A2-000

Scope

This manual has been issued by Canon Inc., to provide the service technicians of this product with the

information necessary for qualified persons to learn technical theory, installation, maintenance, and repair

of products. The manual covers information applicable in all regions where the product is sold. For this

reason, it may contain information that is not applicable to your region.

Revision

This manual could include technical inaccuracies or typographical errors due to improvements or changes

made to the product. When changes are made to the contents of the manual, Canon will release technical

information when necessary. When substantial changes are made to the contents of the manual, Canon will

issue a revised edition.

The following do not apply if they do not conform to the laws and regulations of the region where the

manual or product is used:

Trademarks

Product and brand names appearing in this manual are registered trademarks or trademarks of the

respective holders.

into another language without the written permission of Canon Inc., except in the case of internal business

use.

CANON INC.

Inkjet MFP Quality Assurance Div.

5-1 Hakusan 7-Chome, Toride-city, Ibaraki 302-8501, Japan

I. MANUAL OUTLINE

This manual consists of the following three parts to provide information necessary to service the PIXMA

MP110/MP130:

Part 1: Maintenance

Information on maintenance and troubleshooting of the PIXMA MP110/MP130

Part 2: Technical Reference

New technology and technical information such as FAQ's (Frequently Asked Questions) of the PIXMA

MP110/MP130

Part 3: Appendix

Blockdiagrams PIXMAMP110/MP130

Reference:

This manual does not provide sufficient information for disassembly and reassembly procedures. Refer

to the graphics in the separate Parts Catalog.

II. TABLE OF CONTENTS

Page Part 1: MAINTENANCE

1-1 1. MAINTENANCE

1-1 1-1. Adjustment, Periodic Maintenance, Periodic Replacement Parts, and Replacement

Consumables by Service Engineer

1-2 1-2. Customer Maintenance

1-3 1-3. Product Life

1-3 1-4. Special Tools for Service

1-4 1-5. Serial Number Location

1-5 2. LIST OF ERROR DISPLAY / INDICATION

1-5 2-1. Users Error Messeges

1-8 2-2. User Error Codes

1-8 2-3. Service Error Codes

1-8 2-4. New Error Codes and Recovery Methods

1-8 2-5. Warnings

1-9 2-6. Troubleshooting by Symptom

1-12 3. REPAIR

1-12 3-1. Notes on Service Part Replacement (and Disassembling / Reassembling)

1-14 3-2. Special Notes on Repair Servicing

(1)

Flexible cable and harness wiring, connection

(2) Notes on disassembly

1-16 3-3. Adjustment / Settings

(1) Paper feed motor adjustment

(2) Grease application

(3) Waste ink counter setting

1-19 3-4. User Data Flow

1-21 3-5. Service Switches

(1) Hardware switches

(2) Service data overview

(3) Service data registration / setting method

(4) Service data menu

(5) New service data added to this model

1-25 3-6. Test Mode

(1) User test print Functions

(2) Test mode overview

(3) Test mode Menu

1-29 3-7. Flash ROM Version Upgrade

1-30 4. CLEANING YOUR MACHINE

1-30 4-1 Exterior

1-30 4-2 Scanning Unit

1-31 5. PRINTER TRANSPORTATION

Page Part 2: TECHNICAL REFERENCE

2-1 1. NEW TECHNOLOGIES

2-1 2. CLEANING MODE AND AMOUNT OF INK PURGED

2-2 3. PRINT MODE

2-6 4. FAQ (Problems Specific to the PIXMA MP110/ MP130 and Corrective Actions)

Page Part 3: APPENDIX

3-1 1. BLOCK DIAGRAM

3-2 2. PIXMA MP110/ MP130 SPECIFICATIONS

Part 1

Maintenance

1-1

1. MAINTENANCE

1-1 Adjustment, Periodic Maintenance, Periodic Replacement Parts, and Replacement

Consumables by Service Engineer

(1) Adjustment

Item Timing Purpose Tool

Approx.

time

Country setting

(Service Mode)

- At MAIN BOARD

ASS’Y replacement

To set the country. None

(Service Mode

MARKET

MODEL-JPN)

1 min.

Registration of

waste ink

absorption

amount at the

waste ink counter

(Service Mode)

- At MAIN BOARD

ASS’Y replacement

- At INK ABSORBER

(HY7-2819/2820)

replacement

To register the waste ink

absorption amount at the

waste ink counter.

None

(Service Mode

COUNTER

ACSESS)

1 min.

Print head

alignment

- At print head

replacement

- At MAIN BOARD

ASS’Y replacement

To compensate the print

head landing-in position

error.

None

- Main body

buttons

- Computer

settings via

the printer

driver

2 min.

Paper feed motor

installation

adjustment *1

-At PAPER FEED

MOTOR UNIT

replacement

To adjust the belt tension.

(Install the paper feed

motor unit by moving in

the direction to stretch the

belt tightly with proper

tension.)

None 2 min.

Grease

application

-At CARRIAGE UNIT

replacement

-At MAIN UNIT

replacement

-To apply grease to the

carriage sliding portion

and the carriage rail

portion.

- To apply grease to the

blade.

- To apply grease to the

Eject Roller sliding

portion.

-FLOIL

KG-107A

(QY9-0057)

-MOLYKOTE

PG641

(CK-0562)

2 min.

*1: Caution for the paper feed motor installation adjustment

The screws securing the paper feed motor may be loosened only at replacement of the paper feed motor unit.

(2) Periodic maintenance

Item Timing Purpose Tool Approx.

time

None

1-2

(3) Periodic replacement parts

Item Timing Purpose Tool Approx.

time

None

(4) Replacement consumables

Item Timing Purpose Tool Approx.

time

None

1-2 Customer Maintenance

Item Timing Purpose Tool

Approx.

time

Print head

alignment

At print head

replacement.

To compensate the print

head landing-in position

error.

- Main body

buttons

- Computer

performed by

the automatic

settings via the

printer driver

3 min.

Print head cleaning When print quality is

not satisfying.

To improve nozzle

conditions.

- Main body

buttons

- Computer

settings via the

printer driver

30 sec. -

1 min.

Print head

refreshing

When print quality is

not satisfying (and not

improved by print head

cleaning).

To improve nozzle

conditions.

- Main body

buttons

- Computer

setting via the

printer driver

1 min. -

1 min.

and half

Ink tank

replacement

When an ink tank

becomes empty. (At No

Ink error)

- -

2 min.

Paper feed roller

cleaning

When paper cannot be

fed properly.

To clean the paper feed

rollers.

Main body

buttons

2 min.

1-3

1-3 Product Life

(1) Main body

At any of the following (I) to (II), whichever comes first.

(I) Print Volume: 4,000 pages

BK: 2,000 pages (in printing A4, Black 1,500 character standard document pattern)

CL: 1,200 pages (in printing A4, 7.5 % duty per color pattern)

120 pages (in printing A4, photo, borderless)

80 pages (in printing L-size, photo, borderless)

600 pages (in printing Postcard, photo, borderless)

The figures of Print Volume shown above indicate an assumed breakdown when an average user prints 4,000

pages.

(II) Years of use:

3 years of use

(2) Print head

Item Details

Structure 4 color integrated head (Detachable ink tanks)

Print head Bk: 320 nozzles, 2-column vertical array

C/M/Y: 128 nozzles/color, 2-column vertical array/color

Droplet: Bk 30pl, Col 5pl/2pl

Ink colors Bk (pigment), Col: C, M, Y (high coloration)

Ink tanks BCI-24Black, BCI-24Color

Weight Approx. 58 g (ink tanks are not included)

Form of supply Service parts (ink tanks are not included)

Service parts number: QY6-0054

Product life 4,000 pages (the same as the main body)

(3) Ink tanks

BCI-24Black: approx. 300 pages (JEIDA standard patternJ1, plain paper, standard mode)

approx. 520 pages (ISO JIS-SCID No. 5 pattern, plain paper, standard mode)

BCI-24Color: approx. 170 pages (ISO JIS-SCID No. 5 pattern, plain paper, standard mode)

1-4 Special Tools for Service

Name Tool No. Purpose Remarks

MOLYKOTE

PG641

CK-0562-000 To be applied to the lift cam base upper

gear and the lift cam shaft sliding portion.

In common with

other models.

FLOIL KG-107A QY9-0057-000 To be applied to the carriage sliding

portion, the carriage rail portion, and the

paper guide flapper’s sliding portion.

In common with

other models.

1-4

1-5 Serial Number Label Location

The middle on the rear cover
