Canon PIXMA iP1900 Manual de usuario

iP1900

Getting Started

Make sure to read this manual before using the printer. Please keep it in hand for future reference.

Symbols

■

The following symbols are used to mark important instructions.

Observe these instructions.

Instructions that must be observed for safe operation.

Instructions that, if ignored, could result in personal injury or

material damage.

Contents

Loading Paper

Install the Software

Install the FINE Cartridges

Turn the Power On

Descriptions for operations that take some time to complete.

Additional explanations.

Remove the Protective Material

After Installing the Printer

Model Number: K10328(iP1900)

Microsoft is a registered trademark of Microsoft Corporation.

Windows is a trademark or registered trademark of Microsoft Corporation in the U.S. and/or other countries.

Windows Vista is a trademark or registered trademark of Microsoft Corporation in the U.S. and/or other countries.

Macintosh and Mac are trademarks of Apple Inc., registered in the U.S. and other countries.

•

12 3 4 5

(A)

(B)

Remove the Protective Material

First, check the included items

Manuals

Setup CD-ROM (containing the drivers, applications and on-screen

manuals)

Warranty

•

Open the Cover (A), then remove the protective material (B).

Remove the protective sheets before opening the Cover.

Before turning on the printer, remove all the orange tapes.

•

Close the

Cover

(A) after removing the protective material (B).

power cordFINE cartridge

Color

Black

12 3 4 5

(1)

(2)

(A) (B)

Turn the Power On

Do NOT connect the USB cable at this stage.•

Plug in the power cord in the back of the

printer and connect the other end to

the wall outlet.

Press the ON button (A) to turn on the printer. Confirm that the POWER lamp (B) flashes

green.

1 2 34 5

(E)

(D)

(A)

Install the FINE Cartridges

Be sure to use the supplied FINE

Cartridges.

•

Open the Cover. Pull the orange protective tape (E) in the

direction of the arrow and remove it gently.

Be careful not to stain your hands or

surrounding work area with ink on the

removed protective tape.

•

The FINE Cartridge Holder (D) moves to the

left automatically. (This is where you install

the cartridge.)

Do not handle the FINE Cartridges

roughly such as applying them excessive

pressure or dropping them.

•

If the FINE Cartridge Holder returns to the

right, close the Cover and reopen it. If the

FINE Cartridge Holder does not come out

to the left, make sure that the power is

turned on.

•

Insert the Color FINE Cartridge into the right slot, and the Black one into the

left slot.

•

Insert the Color FINE Cartridge ( ) into the right slot ( ).

Insert the Black FINE Cartridge ( ) into the left slot ( ) in the same way.

Push up the cartridge until it clicks into place.

Do not knock the FINE Cartridge against the sides of the holder.•

Install the FINE Cartridges

1 2 34 5

(A)

(F)

Wait until the POWER lamp lights green (about 1 - 2 minutes) and go to the next step.•

Close the Cover (A).

Once you have installed the FINE Cartridges, do not remove them unnecessarily.•

If the alarm lamp (F) is ﬂ ashing orange, make sure that the FINE Cartridges are correctly installed.•

Install the Software

Quit all running applications before installation.

You need to log on as the administrator (or a member of the Administrators

group).

Do not switch users during the installation process.

It may be necessary to restart your computer during the installation process.

Follow the on-screen instructions and click OK, and do not remove the Setup

CD-ROM during restarting.

The installation resumes from where it left off when your computer has been

restarted.

Mac OS 9, Mac OS X Classic environments, or Mac OS X v.10.3.8 or earlier

are not supported.

•

To use the printer by connecting it to a computer, software including the

drivers needs to be copied (installed) to the computer’s hard disk.

The screens below are based on Windows Vista operating system Ultimate

Edition (hereafter referred to as “Windows Vista“) and Mac OS X v.10.5.x.

Macintosh P.15

Windows P.7

51 2 3 4

(A)

If the Found New Hardware or

Found New Hardware Wizard

screen appears:

Click Cancel to quit the screen.

Proceed from .

Remove the USB cable

connected to your computer.

Press the ON button (A) to TURN OFF

THE PRINTER.

Turn on the computer, then insert the Setup

CD-ROM into the CD-ROM drive.

The setup program should run automatically.

Operating noise continues for about

15 seconds until the power turns off.

Make sure that the POWER lamp stops

ﬂ ashing.

• If the program does not start automatically,

double-click the CD-ROM icon on the computer.

When the CD-ROM contents appear, double-

click MSETUP4.EXE.

•

Windows

Windows Vista

Windows XP/2000

Go to Step

The screen may close. In this case,

proceed from .

AutoPlay screen appears, click Run Msetup4.exe.User Account Control screen appears, click Continue.

If the same screen reappears in subsequent steps, click Continue.

Windows

Windows Vista Windows Vista
