Canon ImageCLASS LBP247dw Manual de usuario

Setup Guide

• After you finish reading this guide, store it in a safe

place for future reference.

• The information in this guide is subject to change

without notice.

https://oip.manual.canon/

1Important Safety Instructions

Be sure to read these instructions before using

the machine.

3User's Guide

This section explains all the ways this machine

can be used.

FAQ

This section describes problems that may arise

and how to resolve these problems.

2Setup Guide (this document)

See p. 7“Accessing the Online Manual” for details.

Unless otherwise stated, illustrations used in this

document are for the LBP247dw.

Checking the Items

Included

Removing the Packing

Material

1. Install the machine in the location where it

will be used.

Provide a space of 4” (100 mm) or more

around the machine when installing.

2. Remove all packing material.

Remove all tapes.

Do not remove the sticker that covers the USB port

until you actually use the USB port.

Rear

Loading Paper

A5/A4

1234567 11

Ensure that the amount

of paper loaded is not

above this line

Installing the Optional

Part

If you are not using optional part, proceed to

step .

Before Installing the Optional Part

After the machine has been installed, perform the following

before installing the optional part:

1. Turn OFF the machine and your computer.

2. Unplug the machine from the mains power outlet.

3. Disconnect all cords and cables from the machine.

Cassette Feeding Module

1. Install the cassette feeding module in the

location where it will be used.

1234567 11

Connecting the Power

Cord

Rear

Specifying the Basic

Settings

When you turn on the machine for the first time, the Setup

Guide appears on the operation panel. Perform the initial

machine setup by following the on-screen instructions.

Depending on your model, the items available for selection

and the procedure for making choices may differ from

those shown in this document. Proceed as directed in the

screens shown.

Operation panel

1. Select the language, the country or region,

and then the time zone.

2. Set the current date/time.

Specifying the Security

Settings

To prevent unauthorized access to the machine, set access

restrictions for Remote UI.

What is Remote UI?

Remote UI allows you to use your computer’s Web

browser to check the machine’s operating status

and change settings.

1. To use the Remote UI, select <Yes>.

• To continue without using the Remote UI, select

<No> and proceed to step 8.

• When <A Remote UI Access PIN must be

configured...> appears, proceed to step 5.

45678 111

2. To use System Manager mode, select <Yes>.

• Set the System Manager ID and PIN so that you

can configure the settings for extended functions

and the management of access privileges, etc.

• To continue without using System Manager mode,

select <No> and proceed to step 5.

3. Set the System Manager ID.

Enter any number and then select <Apply>.

4. Set the System Manager PIN.

• Enter any number and then select <Apply>.

• Re-enter the same PIN on the next screen as

confirmation and select <Apply>.

* Do not forget your PIN.

5. To use General User mode, select <Yes>.

• Set the PIN to be used by general users to access

the Remote UI.

• To continue without using General User mode,

select <No> and proceed to step 8.

6. Set the Remote UI Access PIN.

• Enter any number and then select <Apply>.

• Re-enter the same PIN on the next screen as

confirmation and select <Apply>.

* Do not forget your PIN.

Specifying the Network

Settings

Specify the settings for connecting the machine to a

network. Before proceeding, check that the computer and

router are correctly connected to the network.

• You cannot use a wired LAN and a wireless LAN at the

same time.

Wireless LAN

1. Check the router's "SSID" and "Network

ke y."

SSID : XXXXXXXXXXXX

Network key : XXXXXXXXXXXX

2. To configure the settings, select <Yes> on

the operation panel.

3. Select the network with a matching SSID.

4. Enter the password (network key) and select

<Apply>.

Depending on your model, a connection

confirmation screen may appear. To connect, select

<Yes>.

Wired LAN

Connect the router to the machine with a LAN cable and

then select <No> in the screen for choosing how to

connect to the network.

Rear

Setting Up the Toner

Replenishment Service

Use this procedure to set up the toner replenishment

service. To use this service, you must enter into an

agreement beforehand.

1. Check the message and select <Next>.

2. Check the conditions of use, and then

choose whether or not to use the service.

• To use the service: <Accept>.

• To not use the service or not enter into an

agreement: Select <Do Not Accept> and proceed

to step 10 .

3. When <Connection was successful.> appears,

select <OK>.

5 6 7 8 109111

Ending the Setup Guide

Check the description in the Application Library and then

select <End>.

* If your model does not support the Application Library

function, this step does not appear.

Installing the Software/

Drivers

To use the print function of the machine, you must install

the printer driver.

Downloading from the Canon website

1. Search for“(model name) download.”

Example: LBP247dw download

XXXXXXX download

If you cannot find the download site, go to

https://global.canon/en/support/

2. Download the software and drivers, and

install them on your computer.

Installing from the Bundled CD/DVD-

ROM

1. Load the CD/DVD-ROM into your computer,

and install the software and drivers.

For normal installation, select “Easy Installation.”

Selecting “Easy Installation” installs the drivers along

with the standard software and manuals.

If a problem arises during the installation, see

“Questions Related to Drivers”in “FAQ.”

Accessing the FAQ

p. 7 “Accessing the Online Manual”

5678 109111

Useful Functions and Helpful Information

Accessing the Online Manual

1. Scan the QR code to open the website to the

Canon online manual.

If the site does not open, go to

https://oip.manual.canon/

2. Select the manual.

User’s Guide

This section lists the functions of the machine,

including machine operations, settings, and

operating procedures.

FAQ

This section lists frequently asked questions and

their answers.

If a problem arises during driver installation,

see “Questions Related to Drivers.”

Questions Related to Drivers

Using this Machine from a

Mobile Device (Linking with

Mobile Devices)

This machine can be used from mobile devices such as

smartphones. This makes it easy to print documents or

photos from a mobile device.

User’s Guide

See “Linking with Mobile Devices.”

Managing the Machine from

a Computer (Remote UI)

Remote UI allows this machine to be managed using the

Web browser on a computer. You can use it to check the

machine’s operating status and change settings.

User’s Guide

See “Managing the Machine from a

Computer (Remote UI).”

• Après avoir lu ce guide, rangez-le dans un

endroit sûr pour information.

• Les informations figurant dans ce guide sont

sujettes à modifications sans préavis.

Guide de

configuration

Consignes de sécurité importantes

Veillez à lire ces instructions avant d'utiliser l'appareil.

2Guide de configuration

(ce document)

https://oip.manual.canon/

3Guide de l’utilisateur

Cette section explique toutes les façons dont

cette machine peut être utilisée.

FAQ

Cette section décrit les problèmes qui peuvent

survenir et la manière de les résoudre.

Voir p. 15 «Accès au manuel en ligne» pour plus de détails.

1234567 11

Sauf indication contraire, les illustrations utilisées

dans ce document sont pour le modèle LBP247dw.

Vérification des articles

inclus

Retrait du matériel

d'emballage

1. Installez l'appareil là où il sera utilisé.

Laissez un espace d’au moins 4” (100 mm)

autour de l’appareil lors de son installation.

2. Retirez tout le matériel d'emballage.

Retirez tous les rubans adhésifs.

Ne retirez l’autocollant qui recouvre le port USB

qui si vous avez besoin d’utiliser le port USB.

Arrière de

l’équipement

Chargement du papier

A5/A4
