Canon GX7010 Manual de usuario

Leia Informações Importantes e Sobre

Segurança (adendo) primeiro.

Para Começar

Lea primero Información de seguridad

e información importante (apéndice).

Guía de inicio

Getting Started

Read Safety and Important Information

(addendum) ﬁrst.

Segurando a impressora

As ilustrações e as capturas de tela usadas neste manual são da GX7000 series. As informações especícas do modelo são

indicadas por ícones.

Instalando a impressora......................................................................................................página 1

Conectando a um computador, smartphone ou tablet.................................página 6

Cómo sujetar la impresora

Las ilustraciones y las capturas de pantalla que se utilizan en esta publicación son de la serie GX7000. La información especíca

de un modelo se indica mediante iconos.

Instalación de la impresora ...............................................................................................página 1

Conexión con un ordenador, teléfono inteligente o tableta.......................página 6

Installing the Printer...................................................................................................................page 1

Connecting to a Computer, Smartphone or Tablet............................................... page 6

Holding the Printer

The illustrations and screenshots used in this book are from the GX7000 series. Model-specic information is indicated by icons.

ENGLISH

Setting Up the Printer

1. Box Contents

•

Ink Bottles

•

Power Cord

• Phone Cable

•

Setup CD-ROM

•

Safety and Important Information

•

Getting Started (this manual)

2. Removing Packing Materials

1 Remove and dispose of any packing materials

and orange tape.

• Using the printer with orange tape or packing

material still attached, may cause the printer to

malfunction.

2 Open the scanning unit / cover, remove and

dispose of the orange tape and protective

material inside.

a b

3 Close the scanning unit / cover.

• Open the scanning unit / cover fully and then close it.

Caution

Watch your ngers.

3. Turning on the Printer

1 Connect the power cord.

Back

For Setup, visit the URL

https://ij.start.canon

or scan the code with your mobile device

•

Follow the instructions below if you do not have an internet connection.

Setting Up the Printer

2 Open the operation panel and press the ON

button.

3 Scroll and tap to select your language, and then

tap Yes .

4 If the following screen appears, tap your

country or region to select.

5 Set the date, and then tap OK.

6 Set the time, and then tap OK.

7 Tap OK.

4. Pouring Ink

Important

This product requires careful handling of ink. Ink may splatter

when the ink tanks are lled with ink. If ink gets on your clothes or

belongings, it may not come o.

1 Open the scanning unit / cover.

ENGLISH

2 Open the ink tank cover and tank cap on the left

of the printer.

3 Hold the ink bottle upright and gently twist the

bottle cap to remove.

Check!

4 Align the nozzle of the ink bottle with the inlet.

5 Slowly stand the ink bottle upside down and

push down to pour the ink.

• If the ink does not pour, gently remove the ink bottle

and try again.

6 Gently remove the ink bottle from the inlet.

• Be careful not to spill the ink.

7 Replace the tank cap securely.

8 Close the ink tank cover securely.

9 Repeat steps 2 through 8 to pour all ink into the

corresponding ink tanks on the right.

Check!

CM Y

Setting Up the Printer

10 Close the scanning unit / cover.

• Open the scanning unit / cover fully and then close it.

Caution

Watch your ngers.

5. Loading Paper

1 Tap OK.

2 Remove the cassette from the printer.

• Pull out Cassette 1 (upper) from the printer.

3 Slide apart the paper guides.

• Slide the right paper guide to the right edge. Align

the front paper guide with the Letter or A4 mark.

4 Load Letter or A4 sized plain paper.

• Place the paper against the front paper guide, and

align the right paper guide to the width of the paper.

a b

5 Replace the cassette.

6 Pull out the paper output tray.

ENGLISH

7 Tap OK.

• The alignment process prints out one double sided

sheet. Wait without touching the paper until the

screen in step 8 appears.

8 Tap Next.

• Follow the on-screen instructions to continue setup.

This includes making selections related to sending

information.

Refer to "Sending Information To Canon" in Safety

and Important Information.

9 Check that the following screen appears.

If you will use the printer without connecting any other

devices, setup is now complete.

Select the connection method that best matches how you

will use the printer.

• To use the printer without connecting to any other

devices

Setup is now complete.

To set up a fax, see "Using Fax

Function" on page 8.

• To use the printer connecting to a computer or

smartphone

Proceed to the next page.

6-a

Setting Up the Printer

Computer Smartphone

Computer and

smartphone

Connecting to a Computer

If you are using multiple computers, perform these steps on each computer.

1 Access the Canon website from your computer.

2 Select Set Up.

3 Enter your printer's model name and click Go.

4 Click Start.

5 Click (B) Connecting to a Computer/Smartphone.

• The following steps are for Windows users.

6 Click Download.

7 Run the downloaded ﬁle.

• Follow the on-screen instructions. This may take some time.

• To connect to a smartphone as well, see "6-b. Connecting to a Smartphone" on page 7.

• To set up a fax, see "Using Fax Function" on page 8.

What device are you connecting?

6-a. Connecting to a Computer

Using the Setup CD-ROM

Double click EasySetup.exe in the CD-ROM, and then continue from step 3. If you do not have an

internet connection, open the win folder in the CD-ROM and double click SETUP.exe. This will install

the printer driver.

6-b

ENGLISH

1 Install the "Canon PRINT Inkjet/SELPHY" app on your smartphone.

• Search for "Canon PRINT" in App Store, or Google Play.

• Access the Canon website to download the app.

2 Open your smartphone's Wi-Fi settings. Check that the network name (SSID) that starts

with "Canon_ij_" appears.

(Example of iOS screen)

The network name (SSID) that starts with "Canon_ij_"

• If "Canon_ij_" appears Proceed to step

• If "Canon_ij_" does not appear Proceed to step

3 Tap the network name (SSID) that starts with "Canon_ij_".

4 Open the installed app, and follow the on-screen instructions in the app to add your

printer.

Connecting to a Smartphone

If you are using multiple smartphones, perform these steps on each smartphone.

6-b. Connecting to a Smartphone

• Once you have added your printer, you can print from your smartphone. To print photos, see

"Loading Paper" on page 8.

• To set up a fax, see "Using Fax Function" on page 8.

1 Open the rear tray cover and extend the paper

support. 2 Slide the right-hand side paper guide to the far

right.

3 Load several sheets of paper with the print side

facing up and slide the side paper guide against

the edge of the paper stack.

Transporting Your Printer

When relocating the printer, check the following. Refer to the Online Manual for details.

Check that the position of the ink valve lever is closed.

Pack the printer in a plastic bag in case ink leaks.

• Pack the printer in a sturdy box so that it is placed with its

bottom facing down, using sucient protective material

to ensure safe transport.

• Do not tilt the printer. Ink may leak.

• Please handle with care and ensure the box remains at

and NOT turned upside down or on its side, as the printer

may be damaged and ink in the printer may leak.

• When a shipping agent is handling transport of the

printer, have its box marked "THIS SIDE UP" to keep the

printer with its bottom facing down. Mark also with

"FRAGILE" or "HANDLE WITH CARE".

Loading Paper

Using Fax Function

The fax function of your printer requires setup. Refer to FAX Setup Guide.

■Access the FAX Setup Guide

1 Access the Canon website.

2 Click See Recommended Functions.

3 Click Functions/Services.

4 Click Setting Up the FAX.
