SELPHY DS700

SERVICE

MANUAL

Canon

shall be retained for reference purposes byAuthorized Service Facilities of Canon U.S.A. Its unauthorized use is prohibited.

Download Service Manual And Resetter Printer at http://printer1.blogspot.com

Scope

This manual has been issued by Canon Inc., to provide the service technicians of this product with the information necessary for

qualified persons to learn technical theory, installation, maintenance, and repair of products. The manual covers information

applicable in all regions where the product is sold. For this reason, it may contain information that is not applicable to your region.

Revision

This manual could include technical inaccuracies or typographical errors due to improvements or changes made to the product. When

changes are made to the contents of the manual, Canon will release technical information when necessary. When substantial changes

are made to the contents of the manual, Canon will issue a revised edition.

The following do not apply if they do not conform to the laws and regulations of the region where the manual or product is used:

Trademarks

Product and brand names appearing in this manual are registered trademarks or trademarks of the respective holders.

without the written permission of Canon Inc., except in the case of internal business use.

CANON INC.

Inkjet SFP Quality Assurance Div.

16-1, Shimonoge 3-chome, Takatsu-ku, Kawasaki, Kanagawa 213-8512, Japan

Download Service Manual And Resetter Printer at http://printer1.blogspot.com

I. MANUAL OUTLINE

This manual consists of the following three parts to provide information necessary to service the SELPHY DS700:

Part 1: Maintenance

Information on maintenance and troubleshooting of the SELPHY DS700

Part 2: Technical Reference

ew technology and technical information such as FAQ's (Frequently Asked Questions) of the SELPHY DS700

Part 3: Appendix

Block diagrams and pin layouts of the SELPHY DS700

Reference:

This manual does not provide sufficient information for disassembly and reassembly procedures. Refer to the graphics in the separate

Parts Catalog.

Download Service Manual And Resetter Printer at http://printer1.blogspot.com

II. TABLE OF CONTENTS

Part 1: MAINTENANCE

1. MAINTENANCE

1-1. Adjustment, Periodic Maintenance, Periodic Replacement Parts, and Replacement Consumables by Service

Engineer

(1) Adjustment

(2) Periodic maintenance

(3) Periodic replacement parts

(4) Replacement consumables

(5) Replacement of the print head

1-2. Customer Maintenance

1-3. Product Life

(1) Printer

(2) Print head

(3) Ink tank

1-4. Special Tools

1-5. Serial Number Location

2. LIST OF ERROR DISPLAY / INDICATIONS

2-1. Operator Call Errors

2-2. Service Call Errors

2-3. Warnings

2-4. Troubleshooting by Symptom

3. REPAIR

3-1. Notes on Service Part Replacement

3-2. Special Notes on Repair Servicing

(1) Flexible cable and harness wiring, connection

(2) Notes on disassembly and re-assembly

3-3. Adjustment / Settings

(1) Paper feed motor adjustment

(2) Access cover gear phase adjustment

(3) Pump unit adjustment

(4) Grease application

(5) Waste ink counter setting

(6) User mode

(7) Service mode

3-4. Verification Items

(1) Service test print

(2) EEPROM information print

4. PRINTER TRANSPORTATION

Part 2: TECHNICAL REFERENCE

1. NEW TECHNOLOGIES

(1) Robust direct printing

(2) Card direct printing

(3) PictBridge / Canon Bubble Jet Direct supporting

(4) Infrared printing

(5) New design

(6) New print head and ink tank

(7) Memory card access functionality

2. CLEANING MODE AND AMOUNT OF INK PURGED

3. PRINT MODE

3-1. Resolution during Printing via Computer

3-2. Resolution in Card Direct / Camera Direct / Infrared Printing

4. PHOTO DIRECT PRINT FUNCTION

4-1. Host PC Memory Card Access Function

(1) Supported memory cards

(2) Mounting the drive

(3) Arrangement of image files

(4) Data access

(5) Card slot attribute

4-2. Memory Card Direct Printing Function

(1) Slide show

Download Service Manual And Resetter Printer at http://printer1.blogspot.com

(2) Print mode

(3) Print quality

(4) Supported image formats

(5) Supported file names

4-3. File Search

4-4. File Sort

4-5. Date Print

4-6. Canon Bubble Jet Direct Function

(1) Print mode

(2) Media type

(3) Print layout

(4) Print quality

(5) Image correction function

(6) Maintenance

(7) Print date

(8) Copies

4-7. PictBridge Function

(1) Print mode

(2) Media type

(3) Print layout

(4) Print quality

(5) Image correction function

(6) Image adjustment

(7) Image processing

(8) Maintenance

(9) Print date

(10) Copies

(11) Digital camera's standard setting

4-8. Exclusive Processes

(1) Exclusive processes in Memory Card Direct Printing and Digital Camera Direct Printing

(2) Exclusive process control between Direct Printing and printing from the host computer

(3) Exclusive processes in host computer memory card access and Memory Card Direct Printing

(4) Exclusive processes between the memory card and memory card

4-9. Display

4-10. Card Slot-related Operations and Display

(1) Timing and precautions when removing the memory card

(2) Power supply/cut to the memory card

(3) Memory card removal command from the host computer

4-11. DPOF Settings in the Memory Card Direct Printing Function

(1) Supported DPOF functions

(2) Print specifications in DPOF print mode

4-12. Print Layout (Details)

(1) Selectable layout in Memory Card Direct Printing

(2) Selectable layout in Digital Camera Direct Printing

(3) Selectable layout in Infrared Printing (Direct Printing from a Mobile Phone via Infrared Communication)

(4) Layout in Memory Card Direct Printing

(5) Layout and image size

4-13. Date Print Specifications

(1) Date print in Memory Card Direct Printing

(2) Date print in Digital Camera Direct Printing

(3) Date print in Infrared Printing

4-14. Photo Number Printing Specifications

(1) Photo number printing in Memory Card Direct Printing

(2) Photo number printing in Digital Camera Direct Printing

(3) Photo number printing in Infrared Printing

5. FAQ (Problems Specific to the SELPHY DS700 and Corrective Actions)

Part 3: APPENDIX

1. BLOCK DIAGRAM

2. CONNECTOR LOCATION AND PIN LAYOUT

2-1. Main Board

2-2. Panel Board

2-3. Front I/F Board

2-4. Rear I/F Board

3. SPECIFICATIONS

Download Service Manual And Resetter Printer at http://printer1.blogspot.com

art 1

MAINTENANCE

Download Service Manual And Resetter Printer at http://printer1.blogspot.com

1. MAINTENANCE

1-1. Adjustment, Periodic Maintenance, Periodic Replacement Parts, and Replacement

Consumables by Service Engineer

(1) Adjustment

Note: DO NOT loosen the 2 red screws on both front sides of the main chassis, adjusting the head-to-paper distance.

The red screws securing the paper feed motor ass'y may be loosened only at replacement of the paper feed motor ass'y.

(2) Periodic maintenance

No periodic maintenance is necessary.

(3) Periodic replacement parts

There are no parts in this printer that require periodic replacement by a service engineer.

(4) Replacement consumables

There are no consumables that require replacement by a service engineer.

(5) Replacement of the print head

Procedures:

1) Press the Power button to turn on the printer.

2) Open the access cover.

=> The print head holder will move to the ink tank replacement position (to the left), and the LED blinks in green.

3) Press and hold the Resume/Cancel button for 2 seconds or longer.

=> The print head holder will move to the print head replacement position (to the right), and the LED blinks in green.

4) Raise the print head lock lever.

=> The print head can be removed from the holder.

5) Replace the print head, following the instructions in the user's guide.

Adjustment Timing Purpose Tool Approx.

time

Destination

settings

(EEPROM

settings)

At logic board ass'y replacement To set the destination. None. 1 min.

Language settings At logic board ass'y replacement To set the language to be displayed on

the TV.

TV (in the user

mode)

1 min.

Waste ink counter

resetting

(EEPROM

settings)

- At logic board ass'y replacement

- At waste ink absorber

replacement

To reset the waste ink counter. None. 1 min.

Paper feed motor

ass'y position

adjustment

- At paper feed motor ass'y

replacement

To adjust the belt tension. (Position the

paper feed motor so that the belt is

stretched tight.)

None. 2 min.

Access cover gear

phase adjustment

- At access cover unit

replacement

- At main cover unit replacement

To adjust the access cover damper. None. 1 min.

Pump unit

adjustment

- At pump unit replacement

- At purge tube replacement

- At pump drive gear replacement

To set an accurate ink absorption

function. None. 2 min.

Grease

application

- At carriage unit / carriage shaft

replacement

- At access cover unit

replacement

- At feed roller ass'y replacement

To maintain sliding properties of the:

- carriage oil pad / carriage shaft,

carriage rail.

- access cover, and

- feed roller ass'y.

- GREASE EU-1

- MOLYKOTE

PG641

- FLOIL KG-107A

1 min.

1 - 1

Download Service Manual And Resetter Printer at http://printer1.blogspot.com

1-2. Customer Maintenance

1-3. Product Life

(1) Printer

Specified print volume (I) or the years of use (II), whichever comes first.

(I) Print volume: 2,000 pages (4" x 6", borderless printing, standard photo)

(II) Years of use: 5 years

(2) Print head

Print volume: 2,000 pages (4" x 6", borderless printing, standard photo)

(3) Ink tank

BCI-16 Color: Approx. 75 pages (4" x 6", borderless printing, PP-101, standard mode printing from a computer)

Adjustment Timing Purpose Tool Approx. time

Print head cleaning When print quality

is not satisfying.

To improve nozzle

conditions.

- Remote control and connection to a

- Printer button

- Computer (settings via the printer

driver)

42 sec.

Print head deep cleaning When print quality

is not satisfying,

and not improved

by print head

cleaning.

To improve nozzle

conditions.

- Remote control and connection to a

- Computer (settings via the printer

driver)

82 sec.

Ink tank replacement When the ink tank

becomes empty.

(No ink error)

--- ---

2 min.

Print head alignment When print quality

is not satisfying.

To ensure accurate dot

placement.

- Remote control and connection to a

- Computer (settings via the printer

driver)

1 min.

Print head alignment value

printing

When confirming

the print head

alignment values set

in the printer.

To confirm the current

print head alignment

values.

- Remote control and connection to a

25 sec.

Language selection When necessary. To select the TV display

language.

- Remote control and connection to a

10 sec.

Paper feed roller cleaning When paper does

not feed properly,

or the paper feed

roller is soiled.

To clean the paper feed

roller.

- Printer button 2 min.

Bottom plate cleaning After printing is

performed on the

wrong side of

paper, or rollers

inside the printer

are extremely

soiled.

To cleaning the bottom

plate and platen ribs.

- Printer button 40 sec.

1 - 2

Download Service Manual And Resetter Printer at http://printer1.blogspot.com

1-4. Special Tools

1-5. Serial Number Location

On the bottom shield plate.

To the top

Name Tool no. Application Remarks

MOLYKOTE

PG641

CK-0562-000 To be applied to the sliding portion of the

access cover arm, and feed roller ass'y.

In common with

other models.

FLOIL KG-

107A

QY9-0057-000 To be applied to the sliding portion of the

carriage guide rail.

In common with

other models.

EU-1 QY9-0037-000 To be applied to the carriage oil pad, and the

sliding portion of the carriage shaft.

In common with

other models.

1 - 3

Download Service Manual And Resetter Printer at http://printer1.blogspot.com

2. LIST OF ERROR DISPLAY / INDICATIONS

Errors and warnings are displayed by the following ways:

1) Errors are indicated by the number of times the LED blinks.

2) Errors and warnings are displayed on the TV.

3) Errors and warnings are displayed on the printer driver's Status Monitor.

2-1. Operator Call Errors

(by LED Blinking in Orange)

2-2. Service Call Errors

(by LED Blinking in Orange and Green Alternately, or Lit in Orange)

LED

blinking

in orange

Error [Error code] Solution Remarks

2 times No paper. (ASF) [1000] Set the paper in the ASF, and press the

Resume/Cancel button.

3 times Paper jam. [1300] Remove the jammed paper, and press the

Resume/Cancel button.

4 times No ink tank. [1662] Install an ink tank, and press the

Resume/Cancel button.

5 times - The print head is not

installed, or it is not

properly installed. [1401]

- EEPROM data of the print

head is faulty. [1403 /

1405].

- Install the print head properly, and close

the access cover, or, with the print head

installed, turn the printer off and on.

- If the error is still not resolved, the print

head may be defective. Replace the print

head.

8 times Warning: The waste ink

absorber is almost full

(approx. 95% of the

maximum capacity). [1700]

Pressing the Resume/Cancel button will

exit the error, and enable printing.

In repair servicing, replace the ink

absorbers.

The service call error, indicating the

waste ink absorber is full, is likely to

occur soon.

9 times The connected digital camera

or digital video camera does

not support Camera Direct

Printing. [2001]

After removing the cable between the

camera and the printer, press the

Resume/Cancel button, and re-connect the

cable. If the error is still not resolved, a

non-supported camera may be connected.

Connect a supported camera.

Access cover open. [1200] Close the access cover.

LED alternate

blinking in orange

and green

Error [Error code] Solution

(Replacement of listed parts, which are likely to be faulty)

2 times Carriage error [5100] - Carriage unit (QM2-1974)

- Timing slit strip film (QC1-5153)

- Logic board ass'y (QM2-1961)*1

- Carriage motor ass'y (QM2-1744)

1 - 4

Download Service Manual And Resetter Printer at http://printer1.blogspot.com

Otros manuales para DS700 - Selphy Compact Photo Printer

Tabla de contenidos

Otros manuales de Impresora de Canon

Canon

Canon image Prograf iPF780 Series Guía del usuario

Canon

Canon SELPHY CP400 Manual de usuario

Canon

Canon PIXMA MX715 Manual de usuario

Canon

Canon iP6700D - PIXMA Color Inkjet Printer Manual de usuario

Canon

Canon Laser Shot LBP7200Cd Manual de usuario

Canon

Canon imageCLASS MF273dw Manual de usuario

Canon

Canon NP6251 Manual de usuario

Canon

Canon imageCLASS MF515x Manual de usuario

Canon

Canon G2010 Series Guía de configuración

Canon

Canon LBP-800 Manual de instrucciones

Canon

Canon MX470 Manual de usuario

Canon

Canon imgaePRESS 1110+ Manual técnico

Canon

Canon PIXMA MG6460 Manual de usuario

Canon

Canon iPF8400S Series Manual de usuario

Canon

Canon PIXMA G1411 Guía de configuración

Canon

Canon Oce Colr Wave 500 Manual de usuario

Canon

Canon iP2600 - PIXMA Color Inkjet Printer Manual de usuario

Canon

Canon iPF655 - imagePROGRAF Color Inkjet Printer Manual de referencia

Canon

Canon iP3300 - PIXMA Color Inkjet Printer Manual de usuario

Canon

Canon iP4000 - PIXMA Photo Printer Manual de usuario

Canon

Canon imagePROGRAF iPF6400SE Manual de usuario

Canon

Canon IMAGECLASS MF249dw Manual de usuario

Canon

Canon iPF655 - imagePROGRAF Color Inkjet Printer Manual de usuario

Canon

Canon Laser Shot LBP-1420 Manual de usuario

Manuales populares de Impresora de otras marcas

Lexmark

Lexmark 1400 Series Manual

Evolis

Evolis Elypso Manual de usuario

Kyocera

Kyocera FS-9530DN Manual de usuario

Samsung

Samsung BIXOLON SRP-350plusF Manual de usuario

Dell

Dell Color Laser Printer 2130cn Manual de usuario

Tektronix

Tektronix Phaser 840 Manual de usuario

Epson

Epson ET-7750 Instrucciones de funcionamiento

Eltron

Eltron P210 Guide Manual de usuario

Ricoh

Ricoh MD-P1 Manual de usuario

Epson

Epson SC-F7100 series Manual de usuario

Epson

Epson Stylus C40UX Manual de usuario

IRA3D

IRA3D POETRY4 Manual de usuario

Ricoh

Ricoh Aficio AP400 Manual de usuario

BIXOLON

BIXOLON SRP-352plusV Manual de usuario

Epson

Epson Stylus Photo PX700W Instrucciones de montaje

Ricoh

Ricoh SP204SF Manual de usuario

Star Micronics

Star Micronics futurePRNT TSP100 Manual de usuario

Epson

Epson TM-TM88V-i Manual de uso y cuidado
