Canon BJC-3000 Series Manual de usuario

Quick Start

Guide

IMPORTANT

Follow the steps in this Quick

Start Guide to unpack and

set up your new BJC-3000 Series

Color Bubble Jet Printer.

Color Bubble Jet™Printer

BJC-3000

Series

Quick Start

Guide

IMPORTANT

Followthe steps in this Quick

StartGuide to unpack and

setup your new BJC-3000 Series

ColorBubble Jet Printer.

ColorBubble Jet™Printer

BJC-3000

Series

Remove all shipping tape and materials

from the unit.

Open the front cover and remove the

protective material and fixing tape

from the BJ cartridge holder.

Note that tape may not be in the exact

locations shown here.

Extend the paper support, and attach

the paper output tray to the front of

the printer.

You will need to purchase a parallel

cable for Windows 95/98/2000 or

Windows NT®(must be IEEE

1284-compliant), or a USB cable for

Windows 98/2000 or Mac®OS.

(Some models in the BJC-3000 Series

may come with a USB cable.)

Unpack the Printer

Remove all items from the box.

1 2

BJC-3000 Series

Color Bubble Jet®Printer

BC-33 Color BJ®Cartridge

Ink Tanks

BCI-3C Cyan BCI-3M Magenta

BCI-3BK Black BCI-3Y Yellow

Ink Cartridge

Storage Box—

For use when you purchase

additional BJ cartridges

Documentation Kit

Power Cord

Paper Output Tray

The Canon Creative CD-ROM includes:

Microsoft®Windows®printer driver

Macintosh®printer driver

IS-32 Color Scanner Cartridge driver

Online User's Manual

Software applications

Electronic registration

Tape

Spacer

BJ Cartridge

Holder

Paper Output Tray

Paper Support

Parallel Cable Users

Connect the cable to the computer and

then to the printer.

Connect the Printer

to the Computer

Make sure your computer is turned off.

Plug in the Printer

Load Paper

USB Cable Users

Connect the cable to the computer,

then to the printer.

Parallel Interface

Cable—

IEEE 1284

compliant

USB Cable

PC Connection

Connect the cable to the computer,

then to the printer.

Macintosh Connection

Wire Clips

Screws

Connect the power cord to

the back of the printer.

POWER

Button

POWER

Light

RESUME Button

Press to resume printing after clearing a paper jam.

POWER

Button

Connect the

other end of

the power cord

to a power outlet.

Press the

POWER button

to turn the

printer on.

The POWER light

starts flashing.

Important! The socket-outlet shall be

installed near the equipment and shall be

easily accessible.

Load a stack

of paper

in the

sheet

feeder.

USB Port

Insert the Four

Ink Tanks

Install the Canon

BJ®Cartridge

Lift the

front cover.

The cartridge

holder moves

to the left.

Raise the blue cartridge lock lever

on the

cartridge

holder.

Remove the cartridge

from its package.

Remove these

protective materials:

Orange cap

Orange tape

Set the

cartridge into

the cartridge

holder.

Lower the

blue cartridge

lock lever until

it locks into

place.

Press in on the

tabs to remove

the caps.

Front Cover

Cartridge Holder

Cap

Tape

Do Not Touch

these areas

Serial

Number

Lock Lever

Remove the two orange

protective

cartridge caps.

Twist off the orange

protective cap.

To prevent spills,

do not press

the side of

the ink tank.

Insert the

yellow ink

tank into the

right slot of

the cartridge.

Press down

on the top of

the ink tank

until it locks

into place.

Install the other 3 ink tanks

as shown.

Magenta (BCI-3M)

Cyan (BCI-3C)

Black (BCI-3BK)

Important!

Before you close the front cover, write down

the serial number (located inside the printer

to the right of the cartridge holder).

Close the front cover.

When the POWER light stops flashing,

the printer is ready.

Pick up the BCI-3Y (Yellow)

Ink Tank.

Pull up the

orange tape.

Remove the

plastic wrapper

from the tank.

Serial No. Date of Purchase

9. Follow the on-screen instructions.

Setup includes:

Printer driver installation

Product registration (see What's Next—Product

Registration)

Creative software installation

Windows 98—USB Cable Users

Installation Tips

If Setup does not start automatically,

click Start on the Windows taskbar

and then click Run.

Type X:\SETUP (where X:is your

CD-ROM drive). Then click OK.

Install the Printer Driver

1. Turn on the computer. The Add New

Hardware screen appears:

If you do not see one of these screens, eject the CD-ROM

and re-insert it. Then follow the instructions on the screen.

2. Insert the Canon Creative CD-ROM into your

CD-ROM drive and click Next. The next

screen asks what you want Windows to do:

6. Click Next. The next screen shows the successful

completion of this installation. USB is now enabled

on your computer.

7. To proceed on to the printer driver installation,

click Next.

8. Eject the CD-ROM and re-insert it. Setup starts

automatically.

3. Choose "Search for the best driver for your

device," and click Next. The next screen

asks you where to look for the driver:

4. As shown above, click the "CD-ROM drive"

check box; be sure to uncheck the other

options. Click Next.

5. Once the driver is found, this screen appears:

The printer driver controls communication between the printer and your computer. Use the Canon Creative CD-ROM

and follow these simple steps and the instructions on the screen.

Windows 95/98/NT—Parallel Cable Users

Installation Tips

5. Follow the on-screen instructions.

Setup includes:

Printer driver installation

Product registration (see What's Next—Product Registration)

Creative software installation

If Setup does not start automatically, click Start on the Windows taskbar

and then click Run.

Type X:\SETUP (where X:is your CD-ROM drive). Then click OK.

1. Turn on the computer. If you see any type of "New Hardware Found" or "Update Wizard" screen, click Cancel

to return to the Windows desktop.

2. If any other applications start automatically, close them before you start the driver installation. This is very

important. Make sure NO applications are running, including any virus protection programs.

3. Make sure the Windows desktop appears on the screen.

4. Insert the Canon Creative CD-ROM into your CD-ROM drive. Setup starts automatically.

If you do not see one of these screens, eject the CD-ROM and re-insert it. Then follow the instructions on the screen.

1. Turn on the computer.

2. Insert the Canon Creative CD-ROM into your

CD-ROM drive. The following screen appears:

Macintosh—USB Cable Users

3. Click on the "Install BJC-3000 Drivers."

The License Agreement screen appears.

Read the agreement and click Agree to

continue.

4. The next screen asks you to choose the printer

you are installing:

7. After driver installation, you must reboot the

system. Click the Restart button when you see

the "Installation was successful" screen.

8. After rebooting, the opening screen appears,

allowing you to proceed with other portions of

the installation process.

9. Once installation is complete, be sure to go to

the Chooser menu (under the Apple®sign) and

select the BJC-3000 as the default printer.

5. Click on the printer name to highlight it, and

click Choose. This screen appears:

6. Click on Install to continue with Easy Install.

The next screen reports the progress of the

driver installation.

Printed in U.S.A.

CST-5303-001

40-41645-0400

ENERGY STAR®Compliant

Bubble Jet are trademarks of Canon Inc. Print Planet is a service mark

of Canon Computer Systems, Inc. All other product and brand names

are trademarks or service marks of their respective owners. As an

Energy Star®Partner, Canon U.S.A., Inc., has determined that this

product meets the Energy Star® guidelines for energy efficiency.

For e-mail technical support, the latest driver

downloads and answers to frequently asked

questions (www.ccsi.canon.com)

24-hour, 7-day-a-week automated support

for troubleshooting issues on most current

products (1-800-423-2366)

24-hour, Fax-On-Demand System for

product specifications and technical

information (1-800-526-4345)

Free technical support Monday–Saturday for

products still under warranty**

(1-757-413-2848)

Technical support 7 days a week for

products no longer under warranty for

$24.99 per call (1-800-423-2366), or for

$2.50 per minute, to a maximum of $25.00

per call (1-900-246-1200)

Canon Computer Systems, Inc. offers a full

range of customer technical support* options:

NOTE: Within Canada, call for technical support

24 hours a day, 7 days a week

(1-800-OK-CANON)

Setup installs this icon on your desktop.

When you double-click the icon, you'll

see this screen:

From here, you can:

Install or use your creative software

View your online User's Manual

By registering with Canon, you enable us

to better serve you and provide you with

important Canon product information.

Canon will respect your privacy with regards

to the information you provide us.

During product registration, you are asked for

the serial number of your printer. This number

is located inside the printer. When you open

the printer cover, the cartridge holder moves

to the center of the printer; the serial number

is located to the right of the cartridge holder.

Product Registration

Online User's Manual

What's Next Getting Help From Canon

Serial Number

* Support program specifics subject to

change without notice.

**Refer to individual product information

for warranty details.

Otros manuales para BJC-3000 Series

Tabla de contenidos

Otros manuales de Impresora de Canon

Canon

Canon imageCLASS MF5550 Guía del usuario

Canon

Canon MP560 - PIXMA Color Inkjet Manual de usuario

Canon

Canon imagePROGRAF iPF760 Manual de usuario

Canon

Canon MAXIFY MB2320 Manual de instrucciones

Canon

Canon SELPHY ES3 CDP-E063-010 Manual de usuario

Canon

Canon MF275dw Manual de usuario

Canon

Canon Selphy CP520 Guía de configuración

Canon

Canon imageRUNNER ADVANCE C7580i III Guía de instalación

Canon

Canon imagerunner advance 8205 Manual de usuario

Canon

Canon MX520 series Guía de configuración

Canon

Canon S820D Manual de usuario

Canon

Canon imageCLASS MF449dw Manual de usuario

Canon

Canon GX5000 Series Manual de usuario

Canon

Canon iPF5100 - imagePROGRAF Color Inkjet Printer Manual de usuario

Canon

Canon imageRUNNER 2320 Manual de usuario

Canon

Canon BJC-5100 Series Manual

Canon

Canon LBP-800 Manual de usuario

Canon

Canon Pixma TS7700 Series Guía de configuración

Canon

Canon DS810 - SELPHY Color Inkjet Printer Manual de usuario

Canon

Canon PIXMA MP520 Manual de usuario

Canon

Canon PIXMA MX922 Manual de usuario

Canon

Canon 8747B002 Guía de configuración

Canon

Canon CP-220 Manual de usuario

Canon

Canon iPF830 Series Manual de usuario

Manuales populares de Impresora de otras marcas

Lexmark

Lexmark 1400 Series Manual

Evolis

Evolis Elypso Manual de usuario

Kyocera

Kyocera FS-9530DN Manual de usuario

Samsung

Samsung BIXOLON SRP-350plusF Manual de usuario

Dell

Dell Color Laser Printer 2130cn Manual de usuario

Tektronix

Tektronix Phaser 840 Manual de usuario

Epson

Epson ET-7750 Instrucciones de funcionamiento

Eltron

Eltron P210 Guide Manual de usuario

Ricoh

Ricoh MD-P1 Manual de usuario

Epson

Epson SC-F7100 series Manual de usuario

Epson

Epson Stylus C40UX Manual de usuario

IRA3D

IRA3D POETRY4 Manual de usuario

Ricoh

Ricoh Aficio AP400 Manual de usuario

BIXOLON

BIXOLON SRP-352plusV Manual de usuario

Epson

Epson Stylus Photo PX700W Instrucciones de montaje

Ricoh

Ricoh SP204SF Manual de usuario

Star Micronics

Star Micronics futurePRNT TSP100 Manual de usuario

Epson

Epson TM-TM88V-i Manual de uso y cuidado
