Special Features User Guide
Special Features User GuideSpecial Features User Guide
Special Features User Guide
Page
2
HOW TO COPY
1. Press <COPY> on the iRC 3570/4570.
2. Place originals face- p in the a tomatic doc ment reader or face down on
the glass.
3. Using the key pad, enter the desired n mber of copies.
4. If other f nctions are desired press <SPECIAL FEATURES> or <FINISHER> on the
LCD panel
5. Press <START> to begin making copies.
*A to paper selection is the standard mode setting. To man ally select paper size,
press <PAPER SELECT> and choose the appropriate size.
1. 3.
4.
5.
2.
Page
3
BOOKLET
Booklet allows sers to copy a single-sided or do ble-sided original in s ch a way
that a booklet is created when a copy is folded in half.
Examples:
1. Men s, broch res, programs, invitations
2. Company newsletters, training man als, ser g ides
DIVIDED BOOKLET
Enables yo to copy a doc ment with many pages and create m ltiple s b-
booklets (with each s b-booklet sing p to 15 sheets of paper).
Since the Saddle Finisher can only fold a maxim m of 15 sheets of paper, this
mode will allow all of the o tp t for a large doc ment to be folded, which wo ld
not be possible with the booklet mode mentioned above.
Page
4
COVER SHEET/INSERTION
Cover Sheet/Insertion is sed to add covers, chapter pages, or insertion sheets
between specified pages.
Examples:
1. Cover Page
a. Specialty paper for the cover of yo r doc ment (Colored
paper, heavier paper stock, etc.)
Front Cover
Adds a front cover sheet to each set of copies. The cover sheet can also be
copied. Printed front cover selected in the Cover/Sheet Insertion mode.
Page
5
Back Cover
Adds a back cover sheet to each set of copies. The cover sheet can also be
copied.
Printed front cover selected in the Cover/Sheet Insertion mode.
2. Insertion Sheet
a. Chapter page, to indicate separate sections of a doc ment.
b. Sheet insertion, to highlight a page within a doc ment by
sing a different colored paper or heavier card stock.
Chapter Pa e
Adds chapter pages between the pages of copy sets. Since the chapter page
is always copied on one side, it is sef l when yo want to divide the copy by
chapter.
Printed sheet insertions selected in Cover/Sheet insertion mode.
Sheet Insertion
Adds sheet insertion between the pages of copy sets. It is sef l when yo want
to divide yo r copy sets into different sections with a blank sheet. The cover
sheet can also be copied.
Printed sheet insertions selected in the Cover/Sheet insertion mode.
DIFFERENT-SIZED ORIGINALS
Different-sized originals can be placed together, provided that the leading edge
of each page is the same length.
Examples:
1. Use all doc ments in the same job, rather than r nning to different
paper sizes as separate jobs.
2. Packets of information, s ch as HR new-hire doc ments may have
some legal-sized doc ments.
Page
6
FRAME ERASE
Frame Erase eliminates shadows and dark lines to create clean copies of odd-
size originals, bo nd doc ments, originals with ragged edges, hole p nches, or
notes in the margin. Fo r erase modes are accessible within Frame Erase.
Ori inal Frame Erase
Eliminates dark borders and lines that appear on the copies when the original is
smaller than the selected paper size.
Examples:
1. Pages from a book, note pad
2. Faxes images, skewed faxes
Page
7
Book Frame Erase
Erases the gray shadow that appears when copying from a book.
Bindin Erase
Erases the shadows that appear in copies from binding holes in originals.
Page
8
IMAGE COMBINATION
Image combination enables yo to a tomatically red ce two, fo r or eight
originals to fit on a single-sided or two-sided copy sheet.
Examples:
1. For presentation hando ts, create th mbnails of each image in yo r
presentation.
2. Save paper and storage space by storing p to 16 doc ments on
one page (8 on each side)
2 on 1
Red ces two 1-sided originals or one 2-sided original to fit on one side or both
sides of the sheet.
4 on 1
Red ces fo r 1-sided or two 2-sided originals to fit on one side or both sides of a
sheet.
8 on 1
Red ces eight 1-sided or fo r 2 sided originals to fit on one side or both sides of
the sheet.
Page
9
IMAGE REPEAT
Image Repeat repeatedly copies the image of an original in either a length-wise
or width-wise direction.
Examples:
1. B siness cards
2. Labels
Automatic Settin
The original image is copied so that the minimal possible n mber of copies fit on
the selected paper size.
Manual Settin
The original image is copied for the specified n mber of times
Examples:
When <3 times> is specified, images overlap when copied.
JOB BUILD
Job B ild enables yo to scan originals that are too many to set at once, by
dividing them into m ltiple batches. Yo can se the feeder and the platen
glass for scanning. The originals are copied as one doc ment after all the
b nches have been scanned.
Examples:
1. Doc ments with more pages than the feeder can hold
2. Combine images or pages from separate doc ments
Page
10
MARGIN
Margin enables yo to make copies with an entire image shifted to the left, right,
top or bottom of a sheet.
Examples:
1. Eliminate the top lines of a fax
2. When binding or sing a three hole p nch, yo r printed data will not
be c t off.
