Canon PIXMA MX860 series Manual de usuario

Obtaining Your Network Key

PIXMA MP980 / PIXMA MX860 / PIXMA MP620

Windows OS

<< Previous Next >>

Obtaining Your Network Key

PIXMA MP980 / PIXMA MX860 / PIXMA MP620

Windows OS

Introduction 3

Download the Canon PIXMA Wireless Setup Assistant 4

Using the Canon PIXMA Wireless Setup Assistant 6

Trouble Shooting 10

Introduction

If you are unable to proceed past the Access Points screen during wireless setup because the required Network Key is not known, you may be

able to retrieve the information using the Canon PIXMA Wireless Setup Assistant.

NOTE: The Wireless Setup Assistant is supported on the following operating systems only:

•Windows XP SP3 or later

•Windows XP x64 Edition SP3 or later

•Vista (32 & 64 bit)

•Windows 7 (32 & 64 bit)

<< Previous Next >>

Introduction

Step One

Go to the Canon USA Download Library

Click here to go to the Canon USA download library

Step Two

Select Multifunction Printers in the first menu dropdown,

Inkjet in the second and your model in the third. Click Go.

Download the Canon PIXMA Wireless Setup Assistant

To use the machine by connecting it to a computer, software including the drivers needs to be copied (installed) to the computer's hard disk. The

installation process takes about 20 minutes. (The installation time varies depending on the computer environment or the number of applications

to be installed.)

<< Previous Next >>

Download the Canon PIXMA

Wireless Setup Assistant

Step Four

In the Software section, click the link to download the file

CanonAPChkTool.

<< Previous Next >>

Step Five

On the next screen, read the information and instructions and

click I Agree - Begin Download

Choose to "Save" the file. Write down the file name and the

location to where the file is being saved.

Step Three

In the Drivers / Software Selection section, select

your operating system in the Select OS dropdown menu.

Download the Canon PIXMA

Wireless Setup Assistant

Using the Canon PIXMA Wireless Setup Assistant

<< Previous Next >>

Step One

Open the Access Points window.

If the Access Points window is closed:

1. If you are installing the latest driver from download, re-run the

the driver/network installation by double-clicking the driver

file you downloaded previously.

2. If you are installing from the CD-ROM, select Custom Install,

printer driver / MP Drivers, and then perform the installation.

Note:

Leave this window open on your desktop and proceed to step two.

Using the Canon PIXMA

Wireless Setup Assistant

Step Three

Read the License Agreement, and then click Yes when you accept the

agreement.

Using the Canon PIXMA

Wireless Setup Assistant << Previous Next >>

Step Two

Double-click the downloaded tool for confirming the Canon

PIXMA Wireless Setup Assistant CNMNPHLP.

Step Four

1. The "Canon PIXMA Wireless Setup Assistant" tool is

launched.

2. Confirm that the access points listed in the window are the

same as the ones in the Access Points window (Step One).

3. Select the access point name that you are connecting to,

and then click the "Copy Network Key."

<< Previous Next >>

Using the Canon PIXMA

Wireless Setup Assistant

<< Previous Next >>

Using the Canon PIXMA

Wireless Setup Assistant

Step Five

1. Click the access point name(s) in the Access Point window

(you will find the name(s) in "Detected Access Points"

there.)

2. Click the Network Key input box

3. Enter the network key by doing one of the following:

a. Right-click the mouse and select "Paste" from the

drop down menu.

b. Or, while holding the "Ctrl" key, press the "V" key

on your keyboard.

4. Click Connect. When access point names are the same, you

can select any one of them. The tool "Canon PIXMA

Wireless Setup Assistant" is launched.

Step Six

When the setup is completed, the Setup Complete dialog is displayed.

Troubleshooting

If either of the dialog boxes pictured below are displayed, the entered network key may not match with the access point you specified.

Click the OK or Back button to open the Access points window. Confirm the correct access point name and repeat Steps Four through Six.

<< Previous Next >>Troubleshooting
