Canon MultiPass C560 Manual de usuario

User's Manual

MULTIPASS™

C530/C560

COLOR BUBBLE JET™PRINTER

FAX • SCANNER • COPIER

Preface ii

Under the copyright laws, this manual may not be reproduced in any form, in whole or part,

without prior written consent of CCSI.

Disclaimer

Canon Computer Systems, Inc. has reviewed this manual thoroughly in order to make it an

easy to use guide for your Canon MultiPASS system. All statements, technical information, and

recommendations in this guide and in any guides or related documents are believed reliable, but

the accuracy and completeness thereof are not guaranteed or warranted, and they are not intended

to be, nor should they be understood to be, representations or warranties concerning the products

described.

Your MultiPASS and the software media included with your system have been sold to you

subject to the limited warranties set forth in the warranty and license agreement enclosed with the

respective products. All software is licensed AS IS, as described in the license agreement enclosed

with the software media. Further, CCSI reserves the right to make changes in the specifications of

the products described in this guide at any time without notice and without obligation to notify

any person of such changes.

Trademarks

Canon, BCI, BJ, Bubble Jet, MultiPASS, ScanGear, and UHQ are trademarks and SelectExchange is

a service mark of Canon Inc.

All other product and brand names are trademarks or service marks of their respective owners.

ENERGY STAR® COMPLIANT

As an ENERGY STAR® Partner, Canon U.S.A., Inc. has determined that this product meets the

ENERGY STAR® guidelines for energy efficiency.

Preface iii

Users in the U.S.A.

PRE-INSTALLATION REQUIREMENTS FOR CANON FACSIMILE EQUIPMENT

A. Location

Supply a suitable table, cabinet, or desk. See Appendix A for the unit’s dimensions and weight.

Appendix A,Specifications

B. Order Information

1. Only a single line, touch-tone or rotary telephone set is to be used.

2. Order an RJ11-C modular jack (USOC code), which should be installed

by the phone company. If the RJ11-C jack is not present, installation

cannot occur.

3. Order a normal business line from your telephone company’s business representative. The

line should be a regular voice grade line or the equivalent. Use one line per unit.

DDD (DIRECT DISTANCE DIAL) LINE

-or-

IDDD (INTERNATIONAL DIRECT DISTANCE DIAL) LINE IF YOU COMMUNICATE

OVERSEAS

Preface iv

nCanon recommends an individual line following industry standards, e.g. the 2500 (Touch Tone)

or 500 (Rotary/Pulse Dial) telephones. A dedicated extension off a PBX unit without “Call

Waiting” can be used with your MultiPASS. Key telephone systems are not recommended because

they send non-standard signals to individual telephones for ringing and special codes, which may

cause a fax error.

C. Power Requirements

This equipment should be connected to a standard 120 volt AC, three-wire grounded outlet

only. Do not connect this unit to an outlet or power line shared with other appliances that

cause “electrical noise”. Air conditioners, electric typewriters, copiers, and machines of this

sort generate electrical noise which often interferes with communications equipment and the

sending and receiving of documents.

CONNECTION OF THE EQUIPMENT

This equipment complies with Part 68 of the FCC rules. On the rear panel of this equipment is a

label that contains, among other information, the FCC Registration Number and Ringer

Equivalence Number (REN) for this equipment. If requested, this information must be given to

the telephone company. This equipment may not be used on coin service provided by the

telephone company. Connection to party lines is subject to state tariffs.

Preface v

An FCC compliant telephone cord and modular jack is provided with this equipment. This

equipment is designed to be connected to the telephone network or premises wiring using a

compatible modular jack which is Part 68 compliant. See Installation instructions for details.

The REN is used to determine the quantity of devices which may be connected to the telephone

line. Excessive RENs on the telephone line may result in the devices not ringing in response to an

incoming call. In most, but not all areas, the sum of the RENs should not exceed five (5.0). To be

certain of the number of devices that may be connected to the line, as determined by the total

RENs, contact the telephone company to determine the maximum REN for the calling area.

IN CASE OF EQUIPMENT MALFUNCTION

Should any malfunction occur which cannot be corrected by the procedures described in this

User’s Manual, disconnect the equipment from the telephone line or unplug the power cord. The

telephone line should not be reconnected or the power cord plugged in until the problem is

completely resolved. Users should contact Canon Authorized Service Facilities for servicing of

equipment. Information regarding Authorized Service Facility locations can be obtained by calling

the Canon Computer Systems Customer Care Center. (See page 1-14 for details.)

Preface vi

RIGHTS OF THE TELEPHONE COMPANY

Should the equipment cause harm to the telephone network, the telephone company may

temporarily disconnect service. The telephone company also retains the right to make changes in

facilities and services which may affect the operation of this equipment. When such changes are

necessary, the telephone company is required to give adequate prior notice to the user.

WARNING

Do not make any changes or modifications to the equipment unless otherwise specified in this

manual. If such changes or modifications should be made, you could be required to stop

operation of the equipment.

MultiPASS C530: Facsimile Transceiver, Model H12159

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions:

(1) This device may not cause harmful interference, and

(2) this device must accept an interference received, including interference that may cause

undesired operation.

Preface vii

nThis equipment has been tested and found to comply with the limits for a class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment

off and on, the user is encouraged to try to correct the interference by one or more of the following

measures:

■Reorient or relocate the receiving antenna.

■Increase the separation between the equipment and receiver.

■Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

■Consult the dealer or an experienced radio/TV technician for help.

Use of shielded cable is required to comply with class B limits in Subpart B of Part 15 of FCC

Rules. Do not make any changes or modifications to the equipment unless otherwise specified in

this manual. If such changes or modifications should be made, you could be required to stop

operation of the equipment.

Preface viii

The Telephone Consumer Protection Act of 1991 makes it unlawful for any person to use a

computer or other electronic device to send any message via a telephone fax machine unless such

message clearly contains in a margin at the top or bottom of each transmitted page or on the first

page of the transmission, the date and time it is sent and an identification of the business or other

entity, or other individual sending the message and the telephone number of the sending machine

or such business, other entity, or individual.

To automatically enter this information into your MultiPASS, follow the instructions in your

Quick Start Guide.

Preface ix

Users in Canada

PRE-INSTALLATION REQUIREMENTS FOR CANON FACSIMILE EQUIPMENT

A. Location

Supply a suitable table, cabinet, or desk. See Appendix A for the unit’s dimensions and weight.

Appendix A,Specifications

B. Order Information

1. Provide only a single-line to touch-tone or rotary telephone set terminated with a standard

4-pin modular phone plug. (Touch-tone is recommended if available in your area.)

2. Order an RJ11-C modular jack (USOC code), which should be installed by the phone

company. If the RJ11-C jack is not present, installation cannot occur.

3. Order a normal business line from your telephone company’s business representative. The

line should be a regular voice grade line or equivalent. Use one line per unit.

DDD (DIRECT DISTANCE DIAL) LINE

-or-

IDDD (INTERNATIONAL DIRECT DISTANCE DIAL) LINE IF YOU COMMUNICATE

OVERSEAS

Preface x
