Use and Installation Instructions

This appliance must be installed in accordance with the regulations in force and only used in

a well ventilated space.

Read these instructions before installing or using the appliance and retain them for future

reference.

Part no. 195057446.00

HARROGATE

PAGE

Introduction 3

For Your Safety 4

Oven Timer Operation 6

Hotplate 12

Grill 14

Ovens 15

Oven Cooking Charts 16

The Slow Cook Setting 18

Care and Cleaning 19

Something Wrong with your cooker? 21

Installation Instructions 23

Service Information Back Cover

CONTENTS

To help you make the best use of your cooker, PLEASE READ THIS BOOKLET

CAREFULLY.

Your new cooker is guaranteed and will give lasting service. The guarantee is only

applicable if the cooker has been installed in accordance with the Installation

Instructions.

The cooker is designed specifically for domestic use and responsibility will not be

accepted for use in any other installation.

When first using the cooker ensure that the room is well ventilated (e.g. open a

window or use an extractor fan) and that persons who may be sensitive to the odour

avoid any fumes. It is suggested that any pets be removed from the room until the

smell has ceased. This odour is due to any temporary finish and also any moisture

absorbed by the insulation.

INTRODUCTION

Our policy is one of continual improvement in design and development,

therefore strict accuracy of illustrations and descriptions cannot be

guaranteed.

This appliance conforms to the following EEC Directives:

Gas Appliances

90/396/EEC

Low Voltage Equipment

73/23/EEC

93/68/EEC

Electromagnetic Compatibility

89/336/EEC

92/31/EEC

93/68/EEC

Please read the precautions below before using your cooker.

ALWAYS . . .

ALWAYS make sure you understand the controls before using the cooker.

ALWAYS check that all controls on the cooker are turned off after use.

ALWAYS stand back when opening an oven door to allow heat to disperse.

ALWAYS use dry, good quality oven gloves when removing items from the ovens.

ALWAYS take care when removing items from the top oven/grill when the main

oven is on, as the contents may be hot.

ALWAYS keep the oven and grill doors closed when the cooker is not in use.

ALWAYS place pans centrally over the hotplate burners and position them so that

the handles cannot accidentally be caught or knocked or become heated

by other burners.

ALWAYS keep the cooker clean, as a build up of grease or fat from cooking can

cause a fire.

ALWAYS allow the cooker to cool before cleaning.

ALWAYS follow the basic principles of food handling and hygiene to prevent the

possibility of bacterial growth.

ALWAYS keep ventilation slots clear of obstructions.

ALWAYS turn off the electricity supply before cleaning or replacing an oven lamp.

ALWAYS refer servicing to CORGI registered appliance service engineers.

FOR YOUR SAFETY

NEVER . . .

NEVER leave children unsupervised where the cooker is installed as all surfaces will

get hot during and after use.

NEVER allow anyone to sit or stand on any part of the cooker.

NEVER store items that children may attempt to reach above the cooker.

NEVER heat up unopened food containers as pressure can build up causing the

container to burst.

NEVER

store chemicals, food stuffs, pressurised containers in or on the cooker,

or in

cabinets immediately above or next to the cooker.

NEVER fill a deep fat frying pan more than 1/3full of oil, and never use a lid.

DO NOT LEAVE UNATTENDED WHILE COOKING.

NEVER place flammable or plastic items on or near the hotplate.

NEVER use proprietary spillage collectors on the hotplate.

NEVER use the cooker as a room heater.

NEVER dry clothes or place other times over or near to the hotplate or oven/grill

doors.

NEVER wear garments with long flowing sleeves whilst cooking.

NOTE: The use of a gas cooking appliance results in the production of heat and

moisture in the room in which it is installed. Always ensure that the kitchen is well

ventilated; keep natural ventilation holes open or install a mechanical ventilation

device (mechanical extractor hood).

In particular when using more than one hotplate burner, open a window if a mechanical

ventilation device is not operating.

FOR YOUR SAFETY

OVEN TIMER OPERATION

The oven timer offers you the following features:

1. Time of Day

2. Automatic Cooking

3. Minute Minder

AUTOMATIC COOKING

The main oven can be controlled automatically.

GUIDANCE ON AUTOMATIC COOKING

1. Select foods which will take the same time to cook.

2. Set the oven timer so that the food has just finished or is just about to finish

cooking on your return to the oven. This will ensure the food has not cooled down

and does not require reheating before serving.

3. Food should be as cold as possible when it goes into the oven, ideally straight

from the refrigerator. Frozen meat and poultry should be thawed thoroughly

before it is put in the oven.

4. Warm food should never be placed in the oven if there is to be a delay period. Stews

prepared by frying the meat and vegetables should be cooked as soon as possible.

5. Dishes containing left-over cooked poultry or meat, for example Shepherds Pie,

should not be cooked automatically if there is to be a delay period.

6. Stews and joints should be cooked by the long slow method, so that the delay

period is kept to a minimum.

7. On warm days, to prevent harmful bacterial growth in certain foods (ie poultry,

joints, etc) the delayed start should be kept to a minimum.

8. Wine or beer may ferment and cream may curdle during the delay period, so it is

best to add these ingredients just before serving.

9. Foods which discolour should be protected by coating in fat or tossing in water to

which lemon juice has been added, prior to placing food in the oven.

10. Dishes containing liquid should not be filled too full to prevent boiling over.

11. Food should be well sealed (but not airtight) in a container to prevent the loss of

liquid during cooking. Aluminium foil gives a good seal.

12. Ensure food is cooked thoroughly before serving.

OVEN TIMER OPERATION

CLOCKFACE

The timer incorporates a 24 hour clock.

Ensure the correct time of day is always set, before using your cooker.

SYMBOLS

A ‘bell’ symbol will light up when you select a Minute Minder Period and will

remain lit for the period set.

At the end of the Minute Minder Period, the timer will emit an audible tone and

the ‘bell’ symbol will disappear.

The ‘cookpot’ symbol will light up either:–

– When the timer is in manual mode, or

– During the actual Cook Period.

‘AUTO’ will light up:–

– When the timer is first turned on it will flash. It will go out when a time of day

is set or when the timer is set to manual.

The ‘AUTO’ symbol will flash at the end of an Auto Cooking programme to indi-

cate that the programme has finished.

(When the ‘AUTO’ symbol is flashing, to return the oven to Manual operation,

turn the oven controls off, ensure that the correct time of day is set, and press

the “Manual” button – The ‘AUTO’ symbol will go out).

Here you can set a time period of up to 23 hours 59 minutes, that will count down.

When it reaches zero, the timer will emit an audible tone.

For Example: If you set 20 minutes, the audible tone will occur 20 minutes later.

Cook Period is the actual length of time for which, the timer will switch the oven(s)

on as part of an “Auto Cooking” programme.

(e.g. If you set 2 hours, the food will be cooked for 2 hours).

The time of day at which you want an “Auto Cooking” programme to end.

For Example: If you set a “Cook Period” for 2 hours, and “End Time” of 11:00. The

timer will switch the oven(s) on at 9:00 and turn the oven(s) off at 11:00. You will hear

a audible tone at 11:00, to indicate that the Auto Cooking Programme has finished.

Notes:

- When setting an Auto Cooking programme you will need to set the oven

control(s) to the required temperature(s) when you set the timer.

- If an Auto Cooking programme has been set the oven(s) will only operate during

the pre-programmed time.

Needs to be pressed to cancel an Auto Cooking programme and return the oven(s) to

Manual operation.

Used to adjust the various timer function settings.

Minute Minder

Button

Cook Period Button

End Time Button

Manual Button

“+” and “–” Buttons

TIMER FUNCTION BUTTONS

AUTO COOKING PROGRAMME

OVEN TIMER OPERATION

SETTING THE TIME OF DAY

Step 1 Make sure all oven controls are turned Off.

Step 2 Check the electricity supply to the cooker is turned on.

Step 3 When switched on the display will show 0.00 and the Auto symbol,

flashing intermittently.

Step 4 Press & hold in both the Cook Period & End Time buttons together.

Step 5 With the Cook Period & End Time buttons still held in, press either the “+”

or “–” buttons to set the correct time of day.

Step 6 Release all the buttons simultaneously.

THE TIME OF DAY IS NOW SET.

To change the time of day repeat Steps 4, 5 & 6 above.

Note: You cannot adjust the time of day if the timer has been set for an

Auto Cooking Programme.

SETTING THE MINUTE MINDER

Step 1 Ensure the time of day is set correctly.

Step 2 Press and hold the Minute Minder button.

Step 3 With the Minute Minder button held in, set the required Minute Minder

period using the “+” and “–” buttons. A ‘bell’ symbol will light up.

Release all buttons and the timer display will revert back to the time of day.

The ‘bell’ symbol will remain lit to signify that a Minute Minder period has been

set.

At the end of the set time an audible tone will be heard, and the ‘bell’ symbol will

disappear.

Step 4 To cancel the audible tone press the Minute Minder button.

Note 1 When the Minute Minder has been set, the time remaining can be checked at any

time by simply pressing the Minute Minder button.

Note 2 If necessary the Minute Minder can be cancelled before the tone sounds by

pressing and holding the Minute Minder button and then at the same time

pressing the “–” button until 0.00 appears in the display window.

OVEN TIMER OPERATION

Step 3 Press and hold in the Cook Period button.

The display will read 0.00 with the ‘cookpot’ symbol lit.

Step 4 With the Cook Period button still held in, set the required Cook Period

using the “+” and “–” buttons.

Release the buttons and the timer display will revert to the time of day with the

‘Auto’ symbol and ‘cookpot’ symbol lit.

Step 5 Press and hold in the End Time button.

The display will read the earliest possible end time for the Cook Period

that you have set above.

The ‘Auto’ symbol and ‘cookpot’ symbol will be lit.

Step 6 With the End Time button still held in, use the “+” and “–” buttons to set

the ‘End Time’ (i.e. The time you require the oven to switch off).

Release all the buttons and the timer will revert back to the time of day.

The ‘Auto’ symbol will remain lit to signify that an Auto Cooking Programme has

been set. The ‘cookpot’ symbol will go out.

Step 7 Turn the oven control(s) to the required temperature, and if necessary

select the appropriate oven function.

At the end of the Automatic Cook Period the Auto Symbol will flash and an

intermittent bleeping sound will be heard.

The audible tone will continue unless cancelled.

The ‘Auto’ symbol will continue to flash until the timer is returned to Manual

operation (see below).

Step 8 Press the Manual button, the audible tone will be cancelled and the

oven(s) will be returned to Manual.

Step 9 Turn the oven control(s) to the OFF position.

AUTO COOKING PROGRAMMES

There are two Auto Cooking programmes that can be selected using your timer:–

(a) To set the timer to switch the oven(s) On and Off Automatically

(b) To set timer to switch on immediately and OFF automatically after a set cook period.

a) TO SET THE TIMER TO SWITCH THE OVEN(S) ON AND OFF AUTOMATICALLY

This allows you to cook at a specified time for a chosen period before the oven switches

off Automatically.

Step 1 Check that the correct time of day is set, if not follow instructions for setting the time of day.

Step 2 Place food onto the correct shelf position in the oven and close the oven door(s).

OVEN TIMER OPERATION

Step 4 Press & hold in the Cook Period button, the display will read 0.00 and the

‘cookpot’ symbol will light up.

With the Cook Period button still held in set the required Cook Period using the

“+” and “–” buttons. Example: 1hr 30 minutes (as shown).

Note: Cook Period is the length of time the food requires to cook.

Step 5 Release all buttons.

The timer display will revert to the time of day with the ‘Auto’ symbol lit &

‘cookpot‘ symbol remaining lit.

At the end of the Cook Period the ‘Auto’ symbol will flash and an intermittent

audible tone will be heard.

The audible tone will continue until cancelled. The ‘Auto’ symbol will continue to

flash until the timer is returned to Manual operation (see below).

Step 6 Press the Manual button. The audible tone will be cancelled and the

oven(s) will be returned to Manual.

Step 7 Turn the oven control(s) to the OFF position.

b) TO SET TIMER TO SWITCH ON IMMEDIATELY AND OFF AUTOMATICALLY AFTER A SET COOK

PERIOD

Step 1 Check that the correct time of day is set, if not follow instructions for setting the time of day.

Step 2 Place food onto the correct shelf position in the oven and close the oven door(s).

Step 3 Turn the oven control(s) to the required temperature, and if necessary select the appropriate oven

function.

Note 1 When cooking automatically the Cook Period can be checked at any time by simply

pressing the Cook Period button.

Note 2 When cooking automatically the End Time can be checked at any time by simply

pressing the End Time button.

NOTE: The Cookpot symbol disappears

Tabla de contenidos

Otros manuales de Estufa de Cannon

Cannon

Cannon 50cm Free Standing Electric Cooker C50ECK Manual de usuario

Cannon

Cannon WORCESTER 10525G Manual técnico

Cannon

Cannon 90cm Free Standing Gas Cooker C90DPX Manual de usuario

Cannon

Cannon TRADITIONAL 60 Manual de usuario

Cannon

Cannon Chesterfield Traditional 60 C60GC Manual técnico

Cannon

Cannon CARRICK Manual técnico

Cannon

Cannon harrogate Manual técnico

Cannon

Cannon CHESTER 10540G Manual técnico

Cannon

Cannon Langdale C50GLK Manual de usuario

Cannon

Cannon WINCHESTER Mk2 Manual de usuario

Cannon

Cannon CHESTERIELD C60GCB Manual técnico

Cannon

Cannon 50cm Free Standing Electric Cooker C50ELB Manual de usuario

Cannon

Cannon CAMBERLEY Mk3 Manual técnico

Cannon

Cannon Professional 60 Manual técnico

Cannon

Cannon Winchster Manual técnico

Cannon

Cannon 110cm Free Standing Gas Cooker C110DPX Manual de usuario

Cannon

Cannon HENLEY 10582G Manual técnico

Cannon

Cannon Professional 60 Manual de usuario

Cannon

Cannon 50cm Free Standing Gas Cooker C50GKB Manual de usuario

Cannon

Cannon C50HNB Manual de usuario

Cannon

Cannon LICHFIELD Manual técnico

Cannon

Cannon ICON 1000 Manual técnico

Cannon

Cannon 10450G Manual de usuario

Cannon

Cannon 50cm Free Standing Gas Cooker C50GCIK Manual de usuario

Manuales populares de Estufa de otras marcas

Modena

Modena FC 7645 SGM Manual del propietario

Electrolux

Electrolux Insight EKG6049 Manual de usuario

Stanley

Stanley Donard 60 Manual de usuario

Bartscher

Bartscher 201TC Manual de usuario

Parkinson Cowan

Parkinson Cowan 50 GR/BU Manual de usuario

Siemens

Siemens HK9P00020U Manual de usuario

Creda

Creda S150E Guía

Creda

Creda HB48309 Manual de usuario

Bosch

Bosch HCE743220F Manual de usuario

Tricity Bendix

Tricity Bendix SE545P Manual de usuario

NEFF

NEFF E1461A2/01 Manual de usuario

Zanussi

Zanussi ZCM 700 X Manual de usuario

Smeg

Smeg SNL61MA9 Manual de usuario

RiverGrille

RiverGrille TF2002501-RG Manual de usuario

Vollrath

Vollrath 69504F Manual de usuario

Tricity Bendix

Tricity Bendix CSIE500 Manual de usuario

AEG

AEG Competence 5731 V Manual de usuario

Euromaid

Euromaid ES60 Manual de usuario
