CanMore TW-353 Manual de usuario
TW-353 Golf Watch
User Guide
WARNING
Use only USB chargers with 5V output that comply with the CE/FCC
standard. Using non-standard USB chargers will void the warranty.
82-353U-01010
[GPS Locating Tips]:
• Receive a GPS signal in an open space, and refer to
the following instructions.
▪ GPS receiver is located in the middle of the watch. Do
NOT cover the receiver and face it towards the sky.
▪ The first positioning will take 2~5 minutes.
Subsequent positioning will take 1~2 minutes.
• If you are unable to complete GPS positioning, press ➀
to exit. Move to an open space and try again.
Open
Space
Correct
Building Nearby
Cover GPS Receiver
In car
In houseUnder eaves
Avoid
1.
1. Starting with the Watch
2. Device Overview
At first time use, or after factory reset, or after software update,
please choose language and set time. You can set the time by
manual or by GPS. If you choose to set time by GPS, please
refer to [GPS Locating Tips] on Page 1.
Note: 1. At first time use, please charge the device more
than 2 hours in advance.
2. If the watch battery runs out, time will need to be reset.
➀Power/Backlight/Return
Hold to turn the device on/off.
Press to turn the backlight on/off.
Press to return to previous page or step.
➁Up
Press to scroll up the menu.
➂OK/Enter
Press to accept an entry or to move
forward on a menu.
➃Down
Press to scroll down the menu.
➀
➂
➃
➁
11
08
SUN
OCT
11
2.
3. Watch Menus
1. Press ➂to enter main menu.
2. Press ➁/➃to scroll up/down the menu.
3. Choose a selected function and press ③to enter.
4. Watch Settings
Press ➂to enter main menu. Use ➁/➃to scroll to [SETTINGS].
Once in [SETTINGS], you will find following options :
•Language - Select your preferred language.
•Clock - Set time, alarm, toggle between 12-hour and 24-hour
mode, summer time <1>, and sun rise/set time.
•Backlight - Set the duration for the backlight to remain on.
•Alert - Select either Sound or Light for your alert mode.
•Unit - Toggle between imperial/metric units.
•GPS - Search for GPS signal.
•Factory Reset - Reset the watch to factory settings.
•About Watch - Watch version number.
12
28
FRI
JAN
10
PLAY GOLF
SCORE CARD
SETTINGS
<1> When summer time is on, the time will be adjusted one
hour head.
3.
5. Golf Mode
1. Press ➂to enter main menu.
2. Select [PLAY GOLF], and press ➂to enter.
3. Satellites will be located automatically<2> and a list of golf
courses will be shown by proximity.
4. Press ➁/➃to scroll up/down, and press ➂to enter a
selected golf course.
<2> Refer to [GPS Lacating Tips]on Page1.
5-1 Play Golf
This product is your digital golf caddy and contains
thousands of golf course maps. The watch can locate
where you are, detect your distance to the hole, show
hazards and track your score.
GPS Searching…
Course
ragon Hill Admi
(C)Nine Dragon
(B)Nine Dragon
(New Course)Ti
12
28
FRI
JAN
10
PLAY GOLF
4.
• Press ➁/➃to go to next/previous hole.
• If the course has dual greens, hold ➂for three seconds to switch
right / left green distance.
(The default unit is Yard. To switch the display unit, please refer to
4. Watch settings)
When playing golf, you will notice that there are five metrics
displayed on the screen. The list below explains what each of
those pieces of information represents.
5-2 On The Course
Press ➂to enter Score Card, and use ➁/➃to
record your score of each hole. To save and exit,
press➂.
3
-1
PAR 4#18
While in GOLF mode, follow below instruction to access Scorecard,
Shot Distance, Hazard or Save this record.
SCORE 3
#1 320
258
227
Par4
Current hole number.
PAR for the hole.
Distance to the back of green.
Distance to the center of green.
Distance to the front of green.
5.
Hold ➃for 3 seconds to access the Hazard
screen. To return, press ➀.
320
227
258
To finish the round, press ➀, and then press ➂
to exit golf mode, or press ➀to continue playing
golf.
Quit?
YESNO
Hold ➁ for 3 seconds to access Shot Distance.
Travel to your ball, and the distance will be
calculated. To return, press ➀.
SHOT
120
1. Press ➂to enter main menu.
2. Select [SCORE CARD], and press ➂to enter.
3. Press ➁/➃to scroll up/down to check the history record.
4. To exit, press ➀.
Score
1-9
H
1
2
3
4
5
1
P
5
4
3
4
3
S
-1
0
1
0
1
Score
1 - 9
Total
PAR
Score
7
7
7
10 - 18
Score
2018.01.20
2018.01.18
2018.01.17
2018.01.15
6. Score History
6.
7. Charge the Watch
1. Attach the magnetic charger on the charging contacts
located on the side of the watch. Be sure the pins are
aligned. Keep the watch on a stable surface while
charging.
2. Insert the USB end of the charging cord into a computer
USB port or CE/FCC certified 5V output USB charger.
(exceeding 5V will void the warranty).
Battery/ Charging Information
Battery Specifications: 3.7V / 400mAh
Charging Specifications: 5V / 500mA
CHARGING PINS CHARGING PORT
AVOID touching the magnetic end of the charging cable with
metallic objects to prevent short circuits and damage to the cable.
For safety reasons, after the watch is fully charged, disconnect
the charging cable from USB power source.
CAUTION
7.
9. Limited Warranty
The products are warranted to be free from defects
in materials or workmanship for 12 Months from the
date of purchase. Within the period, the manufac-
ture will, as its sole option, repair or replace any
components that fail in normal use. Such repairs or
replacement will be made at no charge to the
customer for parts or labor. The customer shall be
responsible for any transportation cost.
If any errors or malfunction occur,
use factory reset at [SETTINGS
→ Factory Reset]. If that does not
work, try hardware reset by
pressing ➂+➃ together, and
then press ➀. Release all three buttons at the same
time.
8. Troubleshooting
➀
➂
➃
11
08
SUN
OCT
11
8.
The limited warranty does not apply to
1. Cosmetic damage, such as scratches, nicks and
dents.
2. Consumable parts, such as batteries, unless
product damage has occurred due to the defect
in materials or workmanship.
3. Damage to a product that has been modified or
altered without written permission of manufature.
4. Damage to a product that has been connected to
a non-CE/FCC certified 5V power supply.
The manufacture reserves the right to refuse
warranty claims against products or services that
are obtained or used in contravention of the laws of
any country. The device is intended to be used only
as a sport or leisure aid and must not be used for
any purpose requiring precise measurement of
direction, distance, and location. The manufacture
makes no warranty to the accuracy or completeness
of the course data.
To obtain warranty service, an original or copy of the
sales receipt from the original retailer is required.
9.
