Candy GO W 485 D ALISE Instrucciones de instalación

User instructions

EN GO W 485 D

OUR COMPLIMENTS

With the purchase of this Candy household appliance, you

have shown that you will not accept compromises: you want

only the best.

Candy is happy to present their new washing machine, the

result of years of research and market experience through

direct contact with Consumers.You have chosen the quality,

durability and high performance that this washing machine

offers.

Candy is also able to offer a vast range of other household

appliances: washing machines, dishwashers, washer-dryers,

cookers, microwave ovens. Traditional ovens and hobs,

refrigerators and freezers.

Ask your local retailer for the complete catalogue of Candy

products.

Please read this booklet carefully as it provides important

guide lines for safe installation, use and maintenance and

some useful advise for best results when using your washing

machine.

Keep this booklet in a safe place for further consultation.

When contacting Candy

or a Customer Services Centre always refer to the Model,

No., and G number (if applicable of the appliance see

panel).

CHAPTER

INDEX

Introduction

General points on delivery

Guarantee

Safety Measures

Technical Data

Setting up and Installation

Control Description

Table of Programmes

Selection

Detergent drawer

The Product

Washing

Drying cycle

Automatic washing/Drying cycle

Cleaning and routine maintenance

Faults Search

CHAPTER 2

GUARANTEE

The appliance is supplied with a guarantee certificate

which allows free use of the Technical Assistance Service.

CHAPTER 1

GENERAL POINTS ON DELIVERY

On delivery, check that the following are included with the

machine:

A) INSTRUCTION MANUAL

B) CUSTOMER SERVICE ADDRESSES

C) GUARANTEE CERTIFICATES

D) CAPS

E) BEND FOR OUTLET TUBE

KEEP THEM IN A SAFE PLACE

Check that the machine has not incurred damage during

transport. If this is the case, contact your nearest Candy

Centre.

CHAPTER 3

SAFETY MEASURES

IMPORTANT:

FOR ALL CLEANING AND MAINTENANCE WORK

●Remove the plug

●Turn off the water inlet tap.

●All Candy appliances are earthed. Ensure that the main

electricity circuit is earthed. Contact a qualified electrician

if this is not the case.

Appliance complies with European Directives

73/23/EEC and 89/336/EEC, replaced by 2006/95/EC and

2004/108/EC, and subsequent amendments.

●Do not touch the appliance with wet or damp hands or

feet.

●Do not use the appliance when bare-footed.

●Extreme care should be taken if extension leads are used

in bathrooms or shower rooms. Avoid this where possible.

WARNING:

DURING THE WASHING CYCLE, THE WATER CAN

REACH A TEMPERATURE OF 90°C.

●Before opening the washing machine door, ensure that

there is no water in the drum.

● Do not use adaptors or multiple plugs.

● This appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental

capabilities, or lack of experience and knowledge, unless

they have been given supervision or instruction concerning

use of the appliance by a person responsible for their safety.

Children should be supervised to ensure that they do not

play with the appliance.

● Do not pull the mains lead or the appliance itself to

remove the plug from the socket.

● Do not leave the appliance exposed to atmospheric

agents (rain, sun etc.)

● In the case of removal, never lift the appliance by the

knobs or detersive drawer.

● During transportation

do not lean the door against the trolley.

Important!

When the appliance location is on carpet floors, attention

must be paid so as to ensure that there is no obstruction to

the bottom vents.

● Lift the appliance in pairs as illustrated in the diagram.

● In the case of failure

and/or incorrect operation,turn the washing machine off,

close the water inlet tap and do not tamper with the

appliance. Contact a Candy Technical Assistance Centre for

any repairs and ask for original Candy spare parts.

Avoidance of these norms may compromise the safety of the

appliance.

● Should the supply cord (mains cable) be demaged, this is

to be replaced by a specific cable available from the after

sales service centre.

CHAPTER 4

MAXIMUM WASH

LOAD DRY

NORMAL WATER LEVEL

POWER INPUT

ENERGY CONSUMPTION

(PROG. 90°C)

POWER CURRENT FUSE

AMP

SPIN

r.p.m.

WATER PRESSURE

SUPPLY VOLTAGE

TECHNICAL DATA

kg 5

6÷15

2150

1,8

min. 0,05

max. 0,8

220 - 240

kWh

SSEEEERRAATTIINNGGPPLLAATTEE

MPa

Washing Drying

54 cm

60 cm

CHAPTER 5

SETTING UP INSTALLATION

Move the machine near its permanent position without the

packaging base.

Carefully cut the securing strap that holds the main cord and

the drain hose.

Remove the 3 fixing screws marked (A) and remove the 3

spacers marked (B)

Remove the screw (C).

A spacer will fall inside the machine.

By tilting the machine, remove the above mentioned spacer.

Cover the 4 holes using the caps provided in the instruction

booklet pack.

WARNING:

DO NOT LEAVE THE PACKAGING IN THE REACH OF

CHILDREN AS IT IS A POTENTIAL SOURCE OF DANGER.

min 50 cm

max 85 cm

+2,6 mt max

max 100 cm

min 4 cm

Fix the sheet of corrugated material on the bottom as shown

in picture.

Connect the fill hose

to the tap.

The appliance must be connected to the water mains using

new hose-sets.The old hose-sets should not be reused.

IMPORTANT:

DO NOT TURN THE TAP ON AT THIS TIME.

Position the washing machine next to the wall. Hook the

outlet tube to the edge of the bath tub, paying attention

that there are no bends or contractions along the tube.

It is better to connect the discharge hose to a fixed outlet of

a diameter greater than that of the outlet tube and at a

height of min. 50 cm. If is necessary to use the plastic sleeve

supplied.

The appliance must not be installed behind a lockable door,

a sliding door or a door with a hinge on the opposite side to

that of the washer dryer.

Use the 4 feet to level the machine with the floor:

a) Turn the nut clockwise to release the screw adjuster of

the foot.

b) Rotate foot to raise or lower it until it stands firmly on the

ground.

c) Lock the foot in position by turning the nut anti-clockwise

until it comes up against the bottom of the machine.

Ensure that the knob is on the “OFF” position and the load

door is closed

Insert the plug.

ATTENTION:

should it be necessary to replace the supply cord, connect

the wire in accordance with the following colours/codes:

BLUE - NEUTRAL (N)

BROWN - LIVE (L)

YELLOW-GREEN - EARTH ( )

After installation, the appliance must be positioned so that

the plug is accessible.
