Candy CTAS 127 Manual de usuario

This Instruction Manual

contains everything you need

to know about the everyday

running of your machine.

Keep it for future reference.

An Installation and

Maintenance Manual is also

provided which you should

consult during the installation

and routine maintenance of

your washing machine. The

manual also contains

information about possible

working problems, advice

about the wash load, an

explanation of label symbols

and hints about how to remove

stubborn stains.

INTRODUCTION

Read this manual carefully as it offers practical advice to help you get the most from your

washing machine.

1.- CONTROL PANEL

2.- LID

3.- DRUM

4.- DETERGENT COMPARTMENT

5.- FILTER DOOR

6.- FILTER

7.- WHEEL TROLLEY

When contacting a CANDY or one of its Technical Assistance Cen-

tre always refer to the model (see control panel) and the registration

and series numbers which are indicated at the bottom of the machine

under the lower panel or on the warranty certificate. That is to say,

everything that appears in the box.

Providing this information will ensure a faster and more efficient service.

INDEX

GUARANTEE..............................................................................

TECHNICAL DATA .......................................................................

OPENING THE LID – LOADING ................................................

DETERGENT DISPENSER ........................................................

AUTOMATIC VARIABLE CAPACITY - FUZZY LOGIC

ELECTRONICS ...........................................................................

PROGRAMME SELECTION .......................................................

CONTROL DESCRIPTION ..........................................................

TABLE OF PROGRAMMES .......................................................

page

Place the attached «program label»

in the corresponding language in the

rear slot of the panel window.

SERVICE

GUARANTEE

The appliance comes with a guarantee certificate.

Complete part Aand keep it in a safe place. It should

be presented to the Technical Assistance Centre in

the event of a repair being necessary along with the

legal receipt issued by the dealer on purchase.

230

125

400

1.950

2.200

0,05 min.

0,8 max.

1200

0,95

CTAS 127

TECHNICAL DATA

Load capacity ........................................................................

kg.

Voltage .....................................................................................

Wash motor power rating ........................................................

Spin motor power rating ..........................................................

Electropump power rating .......................................................

Heating element power rating .................................................

Max. power input .....................................................................

Fuse ........................................................................................

Water pressure ...................................................................

MPa

Spin speed ..............................................................

r.p.m./min

Water consumption (60º C programme) ................................

lit.

Energy consumption (60º C programme)/5 kg...................

kWh

Energy efficiency rating ..............................................................

OPENING THE DRUM

Lift the lid (

) and open it completely. Next, open the drum

door following these instructions:

Place your hand on the rear door (

Hold the catch (

) down.

Press the front door (

) to unlock the two doors (

and

Open the rear door (

). Open the front door (

Place the washing in the drum.

Close the front door (

Close the rear door (

) so that the front door (

)

fasteners fit perfectly into the slots.

Ensure that the doors fit together perfectly and are

properly closed.

ATTENTION:

CLOSE THE DRUM CAREFULLY. OTHERWISE, THE

MACHINE OR THE LAUNDRY COULD GET

DAMAGED.

WASHING

MACHINE LID

FRONT OF THE

WASHING MACHINE

2 min. ATTENTION:

A special safety device

prevents the lid from

being opened immediately

after the wash has

finished. Once the spin

cycle has finished, wait for

2 minutes before trying to

open the lid.

FRONT OF THE

WASHING MACHINE

FRONT OF THE

WASHING MACHINE

FRONT OF THE

WASHING MACHINE

Note: WE RECOMMEND USING DETERGENT IN POWDER FORM WHENEVER

A PRE-WASH IS PROGRAMMED.

DETERGENT DISPENSER

The detergent dispenser is divided into 4 compartments:

• Compartment I, is for prewash powder detergent. The recommended quantity is

60 gm of detergent (for 5 kg of laundry).

• Compartment II, is for wash powder detergent. The recommended quantity is 120

gm of detergent (for 5 kg of laundry).

• The compartment is for bleach. The recommended quantity is 7 cl.

• The compartment is for fabric conditioners, scenting agents and special

additives. The recommended quantity is 5 cl.

The detergent compartment has two guidance lines:

• RECOMMENDED (lower line).This indicates the recommended level for the prewash

and wash compartments.

• MAX. This indicates the maximum level which should never be exceeded.

MAXIMUM

(wash)

MAXIMUM

(bleach and scenting agent)

MAXIMUM

(prewash)

RECOMMENDED

AUTOMATIC VARIABLE CAPACITY – FUZZY LOGIC ELECTRONICS

This machine has electronics that automatically process all stages of the wash to

ensure exceptional results and at the same time save you time and money.

Once a programme has been selected, the machine optimises the following elements

depending on the wash load and type of fabric:

-quantity of water and power consumption

-wash time

-drum rotation rate

-rinse efficiency

The washing machine also:

-detects suds and increases the amount of rinse water if necessary

-adjusts spin speed according to load distribution, thus forestalling any imbalance in

the mechanism.

HALF LOAD

APPROX.

20%

EXAMPLE: COTTONS PROGRAMME AT 60º

LOAD

POWER KWH

TIME MIN.

WATER LITRES

FULL LOAD

(5 KG)*

0,95

135

SMALL LOAD

APPROX.

30%

50%

The programme duration indicated is APPROXIMATE.

GAIN WITH REGARD TO

5 kg CYCLE

GAIN WITH REGARD TO

5 kg CYCLE

PROGRAMME SELECTION

Select as follows:

• Check the programme table and set the desired programme using selector

(A)

• Select the options as permitted: the options available via the keys depend on

which programme is selected. If a key flashes when pressed, the options it offers are

not available. If it remains lit, they are. Options can be seen on the display (V).

• Press the Start/ Pause button. The door lock lamp will light up and the display will

show three dashes (- - -) and then the average duration of the programme selected.

After 10-15 minutes, during which time the water temperature, amount of washing,

etc. are determined, the display will show the time remaining to the end of the wash

cycle.

• Because the machine is electronic, the programme may take up to one minute to

commence. Its fuzzy logic programming technology gives this machine smart

monitoring capabilities, enabling it to adapt water levels, washing rates and spin

speeds with no further intervention by the user.

NOTE: A special memory unit stores the programme choice in case of power failure, so that

the machine will resume washing at the point where it left off when power is restored.

END OF CYCLE: At the end of the cycle the lights go out and the display reads (0 0 0). After

2 minutes, the display begins to flash. This means that the washing can be removed.

Press Start/ Pause and set the control to OFF.

PROGRAMME/ TEMPERATURE SELECTOR ...........................

DISPLAY: Delayed start, Spin-speed, Temperature,

Time remaining ...........................................................................

SPIN REGULATION button ........................................................

SUPER FAST button...................................................................

ACTIVA RINSE button ................................................................

EASY IRON button .....................................................................

DELAYED START button ............................................................

Door secure ................................................................................

START/ PAUSE button ................................................................

Reference indicator .....................................................................

CONTROLS

CTAS 127

. PROGRAMME/ TEMPERATURE SELECTOR

THIS CONTROL TURNS BOTH WAY

Use this control to select the desired wash programme/

temperature. Turn the control to bring the marker dot (p)

into line with the number or symbol of the desired

programme. Temperature selection depends on the

programme selected. The display shows the temperature

or the relevant readings for special programmes.

For programme selection, follow the programme table.

To change settings or programmes when a programme

is under way, proceed as follows:

-Press Start/ Pause. The display will read (0 0 0).

-Select the new programme with the selector.The temperature of the programme selected

or the relevant indication for special programmes will appear.

-Press Start/ Pause again.

-The machine will run the new programme.

To add more washing when the programme is under way, proceed as follows:

- Hold down Start/ Pause until the display shows three dashes (- - -).

-When the Door Secure lamp goes off, open the door and add more washing.

-Close the doors of the drum and the outer cover.

-Press Start/ Pause.

.DISPLAY: Delayed start, Spin speed,Temperature, Time remaining.

Display as per function indicated.

NOTE: Only lit buttons are enabled: if a button flashes the options it offers are not available

in the programme selected.

To change options when a programme is under way, proceed as follows:

-Press Start/ Pause until the display shows three dashes (---), then flashes the

temperature of the programme selected.

-Make the change desired (e.g. reduction of spin speed).

-Press Start/ Pause.The time remaining to the end of the programme will appear on the

display.

-The machine will resume the programme with the new setting.

USE OF THE SELECTION CONTROLS
