Campbell 4WPB100 Manual de usuario
4WPB100, 4WPB1K PRT Bridge
Terminal Input Modules
Revision: 12/06
Copyright © 1996-2006
Campbell Scientific, Inc.
H
L
AG
H
L
AG
H
L
G
Warranty and Assistance
The 4WPB100, 4WPB1K PRT BRIDGE TERMINAL INPUT MOUDLES
are warranted by CAMPBELL SCIENTIFIC, INC. to be free from defects in
materials and workmanship under normal use and service for twelve (12)
months from date of shipment unless specified otherwise. Batteries have no
warranty. CAMPBELL SCIENTIFIC, INC.'s obligation under this warranty is
limited to repairing or replacing (at CAMPBELL SCIENTIFIC, INC.'s option)
defective products. The customer shall assume all costs of removing,
reinstalling, and shipping defective products to CAMPBELL SCIENTIFIC,
INC. CAMPBELL SCIENTIFIC, INC. will return such products by surface
carrier prepaid. This warranty shall not apply to any CAMPBELL
SCIENTIFIC, INC. products which have been subjected to modification,
misuse, neglect, accidents of nature, or shipping damage. This warranty is in
lieu of all other warranties, expressed or implied, including warranties of
merchantability or fitness for a particular purpose. CAMPBELL SCIENTIFIC,
INC. is not liable for special, indirect, incidental, or consequential damages.
Products may not be returned without prior authorization. The following
contact information is for US and International customers residing in countries
served by Campbell Scientific, Inc. directly. Affiliate companies handle
repairs for customers within their territories. Please visit
www.campbellsci.com to determine which Campbell Scientific company
serves your country. To obtain a Returned Materials Authorization (RMA),
contact CAMPBELL SCIENTIFIC, INC., phone (435) 753-2342. After an
applications engineer determines the nature of the problem, an RMA number
will be issued. Please write this number clearly on the outside of the shipping
container. CAMPBELL SCIENTIFIC's shipping address is:
CAMPBELL SCIENTIFIC, INC.
RMA#_____
815 West 1800 North
Logan, Utah 84321-1784
CAMPBELL SCIENTIFIC, INC. does not accept collect calls.
i
4WPB100, 4WPB1K Table of Contents
PDF viewers note: These page numbers refer to the printed version of this document. Use
the Adobe Acrobat® bookmarks tab for links to specific sections.
1. Function........................................................................1
2. Specifications ..............................................................1
3. Wiring............................................................................2
4. Programming Examples..............................................3
4.1 CR10(X) ...................................................................................................5
4.2 21X ...........................................................................................................5
4.3 CR7...........................................................................................................6
4.4 CR9000X..................................................................................................6
4.5 CR1000.....................................................................................................7
5. PRT in 4 Wire Half Bridge ...........................................7
5.1 Excitation Voltage ....................................................................................8
5.2 Calibrating a PRT .....................................................................................8
Figures
1-1. Terminal Input Module ...........................................................................1
2-1. Circuit Schematic ....................................................................................2
3-1. Wiring for Example Programs ................................................................2
Tables
3-1. 4WPB100/4WPB1K Connections to Campbell Scientific Dataloggers..3
4-1. Excitation Voltage for 100 Ohm PRT in 4WPB100 Based on
Maximum Temperature and Input Voltage Range...............................3
4-2. Excitation Voltage for 1000 Ohm PRT in 4WPB1000 Based on
Maximum Temperature and Input Voltage Range...............................4
This is a blank page.
1
4WPB100, 4WPB1K PRT Bridge
Terminal Input Modules
1. Function
Terminal input modules connect directly to the datalogger's input terminals to
provide completion resistors for resistive bridge measurements, voltage
dividers, and precision current shunts. The 4WPB100 and 4WPB1K are used
to provide completion resistors for 4 wire half bridge measurements of 100
Ohm and 1 killohm Platinum Resistance Thermometer (PRT), respectively.
H
L
AG
H
L
AG
H
L
G
FIGURE 1-1. Terminal Input Module
2. Specifications
Current limiting 10 kOhm Resistor
Tolerance @ 25 °C ±5%
Power rating 0.25 W
Completion Resistor
Tolerance @ 25 °C ±0.01%
Temperature coefficient
0-60 °C
-55-125 °C
4 ppm/°C
8 ppm/°C
Power rating 0.25 W
4WPB100, 4WPB1K PRT Bridge Terminal Input Modules
2
GND
HI
LO
Rf
GND
H
L
Rf = 100 , 1k
Vx
10k
5%
Rs
HI
LO
0.01%
FIGURE 2-1. Circuit Schematic
3. Wiring
The Terminal input module is connected to the appropriate channel. The
dashed lines in Figure 2-1 indicate the sensor wiring. When making 4 wire
half bridge measurements, the 4WPB is connected to a differential channel and
the sense leads from the PRT to the next differential channel. The black
excitation wire is connected to the excitation channel. In the following
examples the 4WPB is connected to differential channel 1 and the PRT to
differential channel 2; the excitation wire is connected to excitation channel 1
(Figure 3-1).
Ex1
1H
1L
AG or
2H
2L
PRT
4WPB100
L
G
Datalogger
FIGURE 3-1. Wiring for Example Programs
4WPB100, 4WPB1K PRT Bridge Terminal Input Modules
3
TABLE 3-1. 4WPB100/4WPB1K Connections to
Campbell Scientific Dataloggers
Function
Label/Lead
CR10X,
CR510
CR23X, CR1000,
CR800, CR850,
CR3000
21X, CR7,
CR9000X
Excitation Black Wire E1 EX1 Excitation 1
V1 High H 1H 1H 1H
V1 Low L 1L 1L 1L
Ground G AG
4. Programming Examples
The following examples simply show the two instructions necessary to 1)
make the measurement and 2) calculate the temperature. The result of the 4
wire half bridge measurement as shown is Rs/Ro, the input required for the
PRT algorithm to calculate temperature. Note that “Full Bridge” is shown as
the name for measurement Instruction 9 (used with CR10(X), 21X, and CR7).
When Instruction 9 is used with the first measurement range not set to the
maximum input range, it becomes a four wire half bridge measurement.
All the examples are for a 100 Ohm PRT in the 4WPB100. The excitation
voltages used were chosen with the assumption that the temperature would not
exceed 50 °C. Tables 4-1 and 4-2 list excitation voltage as a function of
maximum temperature and the input voltage ranges used with the different
dataloggers. Calculation of optimum excitation voltage is discussed in Section
5.1.
TABLE 4-1. Excitation Voltage for 100 Ohm PRT in
4WPB100 Based on Maximum Temperature and Input
Voltage Range
Excitation Voltage, mV
Max.
Temp
°C
PRT
Resistance
Ohms
±25 mV Input
Range, CR10(X),
CR800, CR850,
CR1000
±50 mV
Range, 21X,
CR7, CR3000,
CR9000X
50 119.4 2035 4070
100 138.5 1758 3516
150 157.31 1551 3101
200 175.84 1390 2780
250 194.07 1262 2523
300 212.02 1157 2314
350 229.67 1070 2140
400 247.04 997 1993
450 264.11 934 1867
500 280.9 879 1759
550 297.39 832 1664
600 313.59 790 1581
4WPB100, 4WPB1K PRT Bridge Terminal Input Modules
4
650 329.51 753 1507
700 345.13 720 1441
750 360.47 691 1382
800 375.51 664 1328
850 390.26 640 1280
TABLE 4-2. Excitation Voltage for 1000 Ohm PRT in
4WPB1000 Based on Maximum Temperature and Input Volta
g
e
Range
Excitation Voltage, mV
Max.
Temp.
°C
PRT
Resist.
Ohms
±200 mV Input
Range
CR9000X
±250 mV Input
Range CR10(X),
CR1000, CR800,
CR850
±500 mV Input
Range 21X,
CR7, CR3000
50 1194. 1959 2448 4897
100 1385. 1716 2145 4291
150 1573.1 1535 1919 3837
200 1758.4 1394 1743 3486
250 1940.7 1282 1603 3205
300 2120.2 1190 1488 2976
350 2296.7 1114 1393 2786
400 2470.4 1050 1313 2625
450 2641.1 995 1244 2488
500 2809. 948 1184 2369
550 2973.9 906 1133 2265
600 3135.9 870 1087 2174
650 3295.1 837 1047 2093
700 3451.3 808 1011 2021
750 3604.7 783 978 1956
800 3755.1 759 949 1898
850 3902.6 738 923 1845
4WPB100, 4WPB1K PRT Bridge Terminal Input Modules
5
4.1 CR10(X)
01: Full Bridge w/mv Excit (P9)
1: 1 Reps
2: 23 ±25 mV 60 Hz Rejection Ex Range
3: 23 ±25 mV 60 Hz Rejection Br Range
4: 1 DIFF Channel
5: 1 Excite all reps w/Exchan 1
6: 2035 mV Excitation
7: 1 Loc [ Rs_Ro ]
8: 1.0 Mult
9: 0 Offset
02: Temperature RTD (P16)
1: 1 Reps
2: 1 R/Ro Loc [ Rs_Ro ]
3: 2 Loc [ Temp_C ]
4: 1 Mult
5: 0 Offset
4.2 21X
1: Full Bridge w/mv Excit (P9)
1: 1 Reps
2: 3 ± 50 mV Slow Ex Range
3: 3 ± 50 mV Slow Br Range
4: 1 DIFF Channel
5: 1 Excite all reps w/Exchan 1
6: 4070 mV Excitation
7: 1 Loc [ Rs_Ro ]
8: 1.0 Mult
9: 0.0 Offset
2: Temperature RTD (P16)
1: 1 Reps
2: 1 R/RO Loc [ Rs_Ro ]
3: 2 Loc [ Temp_C ]
4: 1.0 Mult
5: 0.0 Offset
4WPB100, 4WPB1K PRT Bridge Terminal Input Modules
6
4.3 CR7
1: Full Bridge w/mv Excit (P9)
1: 1 Reps
2: 3 ± 15 mV Slow Range
3: 3 ± 15 mV Slow Range
4: 1 In Card
5: 1 DIFF Channel
6: 1 Ex Card
7: 1 Ex Channel
8: 1 Meas/Ex
9: 4070 mV Excitation
10: 1 Loc [ Rs_Ro ]
11: 1.0 Mult
12: 0.0 Offset
2: Temperature RTD (P16)
1: 1 Reps
2: 1 R/RO Loc [ Rs_Ro ]
3: 2 Loc [ Temp_C ]
4: 1.0 Mult
5: 0.0 Offset
4.4 CR9000X
'CR9000X Datalogger
Public Rs_Ro, Temp_F
DataTable (Temp_F,1,-1)
DataInterval (0,0,0,10)
Sample (1,Temp_F,FP2)
EndTable
BeginProg
Scan (1,mSec,0,0)
BrHalf4W (Rs_Ro,1,mV50,mV50,4,1,5,7,1,4070,True,True,30,40,1.0,0)
PRT (Temp_F,1,Rs_Ro,1.8,32)
CallTable Temp_F
NextScan
EndProg
