CamFive FM Series Manual de usuario
Fiber Laser Marking Machine
Quick Start Guide “FM series”
Fiber Laser Marking Machine
FM30/fm50 Quick Start Guide
First of all, thanks for choosing and buying our CAMFive
Fiber series laser marking machine. Your trust is the bi-
ggest support for us. In the following, the general ins-
truction and basic application of the fiber laser marking
machine will be introduced to you in several aspects.
We hope these can help you.
We aim to improve and perfect our products cons-
tantly so slight differences may exist between this
manual and the machine you are using. If any chan-
ges are made, we will inform users by attachments. If
there is any question, please contact the after-sales
service department for your inquiries
Preface
FM30/fm50 Quick Start Guide
As the input/output terminals, laser
power supply, sound and light
power supply, and control power
supply, etc. may be charged, you
must be careful while in use to
avoid electrical shock. Please pay
attention to personal safety!
This manual is protected by copyright law, international copyright treaties, and the relevant law.
Do not copy or reproduce the content in any context without permission. By following the princi-
ples of sustainable development, changes can be made in this manual when necessary with no
notice needed beforehand.
Optical fiber laser marking machine
belongs to the fourth-class laser
products, therefore, please wear
protective glasses while using it.
The technical workers without trai-
ning are also strictly forbidden to
operate and use the equipment!
NOTES
- This manual contains essential information and instructions that provide help with your personal
safety, economy, and an important notice of the operation. By following these tips, you will not
only avoid dangerous accidents, reduce maintenance costs, and lower downtime of examination
and repair, but also improve the credibility and the working life of the machine.
- This manual includes industrial injury prevention and environmental protection. Users can adjust
accordingly regarding their specific conditions.
- Instructions shall be stored with the machines for reference.
- The operator should have relevant technical training or be guided
Rights Declaration
FM30/fm50 Quick Start Guide
Improper use of the machine can lead to personal injury. Therefore, it is important to read the manual and acknowledge how to
use the laser safely in order to avoid any injury and damage to the product or other connected items. In order to avoid the possi-
bility of danger, this product can only be used within the prescribed scope.
1) Do not direct the laser to your or others’ eyes even when the condition of the laser is listed as turned off since errors may occur.
2) Any items that contain irrelevant reflection and diffuse objects are prohibited to be placed near the equipment in case the laser
directly reflects to the human body or flammable items.
3) Lasers should not be given to children, mental incompetence, or anyone who are not educated with the characteristic of laser
under any circumstances as they are vulnerable to danger and damage the machine can cost.
4) As the light produced by this laser is invisible, inflammable and explosive items are strictly prohibited to be placed near the laser
in case of causing fire incidents.
5) For invisible laser, we suggest wearing protection glasses when using the machine.
6) The top cover plate must be covered when in use in case the laser deviating and causing damage to people.
7) When the voltage is unstable, it is prohibited to start up the CAMFive Laser Machine FM30/FM50. Otherwise, a voltage stabilizer
must be used.
8) The filter screen of the fan from fiber optic equipment should be cleaned regularly.
We suggest not to use it for long when the amperemeter is in the maximum state as it will break down laser power and shorten the
life of the laser.
9) Cut off the power immediately if there is a malfunction or an outbreak of fire.
Safety Requirement
Do not operate or continue to operate the machine if you suspect there is any damage. Contact us for an inspection immediately.
Do not operate the machine in a wet environment.
Do not operate the machine in an explosive environment.
Keep the surface clean and dry.
Suggest all related workers read this manual.
FM30/fm50 Quick Start Guide
Chapter One: Brief Introduction 6
1.1 Summary 6
1.2 Main Specifications 7
Chapter Two: Working principle and structure
2.1 Marking Principle 8
2.2 Structure Description 8
2.3 Fiber Laser 10
2.4 Control Section 11
2.5 Back Panel of the Control system 12
2.6 Other Parts of the Marking Machine 13
Chapter Three: Installation Requirements & Operating Instructions 14
3.1 Equipment Installation Requirements 14
3.2 Operation Process Instructions 15
3.2.1 Start Up Order 15
3.2.2 Sequence of Shutting the Equipment Down 17
Chapter Four: Precautions for Use 17
4.1 Caution for Daily Operation 17
4.2 Maintenance 19
Content
FM30/fm50 Quick Start Guide
06
Optical fiber laser marking machine is a kind of professional laser marking equipment,
which integrated light, machine, electricity, independent research and development, and
production. The key components are imported. Our machine is with the advantage of novel
style, unique structure, convenient operation, high-frequency modulation, high marking
speed and precision, and stable performance. It is widely used in all kinds of metallic and
nonmetallic surfaces for permanent markers.
Chapter One: Brief Introduction
1.1 Summary
07
1.2 Main Specifications
FM30/fm50 Quick Start Guide
Laser wavelength: 1064nm
Laser power: 30W / 50W
Modulation frequency: 20KHz-80KHz
Scanning speed: ≤2000 to 7000mm/s
Repeatability precision: 0.001mm
Engraving range:100mmX100mm (optional 300x300mm)
Marking depth: 0.01- 0.2 mm (Depending on the material)
Marking line width: 0.01-0.2 mm (Depending on the material)
Power supply: AC220V ±10%, 60 Hz, ≤0.8KW
Safety: overcurrent protection, over-temperature protection, over-voltage protection
Continuous Working hours: >23 Hours
08
Chapter Two: Working principle and structure
2.1 Marking Principle
FM30/fm50 Quick Start Guide
* The laser light energy evaporates the material in the surface and shows lower
material;
* The laser light energy causes the surface chemical to change physically and
"engrave" the needed text pattern
* The laser light energy burns part of the material before showing the design and
text of etching.
2.2 Structure Description
The optical fiber laser marking machine is mainly made up of the control cabinet,
optical fiber laser, marking head, working table, and computers, etc.
FM30/fm50 Quick Start Guide
09
10
FM30/fm50 Quick Start Guide
2.3 Fiber Laser：
