CAMBRIONIX ModIT Manual de usuario

User Manual

ModIT-سﻮﺑ

سسس/ش

ModIT-سﻮﺑﺔﺤﻔﺻ2ﻦﻣ21

1.Table of Contents

1.Table of Contents2

2.Safety3

2.1.Signal word panel3

2.2.Safety alert symbol4

2.3.Pictograms4

2.4.Product modification4

2.5.Power supply5

2.6.Storage and Installation6

3.Getting Started7

3.1.Opening your product7

3.2.What's Included7

3.3.Connecting to the mains7

3.4.Registration8

3.5.Cleaning your ModIT-سﻮﺑ9

4.Installing Host System10

5.Product Specifications13

5.1.تﺎﺒﻠﻄﺘﻣﺔﻗﺎﻃلﺎﺧدﻹا13

5.2.تﺎﻔﺻاﻮﻤﻟاﺔﻳدﺎﻤﻟا13

5.3.تﺎﻣﻮﻠﻌﻤﻟاةﺄﺒﻌﻤﻟا13

5.4.داﻮﻤﻟاﺔﻴﻛﻼﻬﺘﺳﻻاﻊﺿووﺮﻣاوﻷا13

6.Disposal16

7.Returns and Damaged Products17

7.1.What do I do if my order arrives and something the product is faulty

or is physically damaged?17

7.2.What happens after I have requested a Return?17

8.Compliance and Standards19

ModIT-سﻮﺑﺔﺤﻔﺻ3ﻦﻣ21

2.Safety

This user manual is for informational purposes only, it contains information for start-up and

operation of this product. Note: the contents and the product described are subject to change

without notice. To avoid injuries and damage observe the safety instructions of the user

manual.

This manual has been arranged to follow IEC/ICEE 82079-1 standards. This is to facilitate the

easier understanding and location of information relating to the ModIT-سﻮﺑ.Any errors or

omissions can be reported back using our support ticket system (see"Help and Support") this

way any issues can be collected and fixed.

Understanding and observing the instructions in this user manual are prerequisites for

hazard-free use and safety during operation. This user manual cannot cover all conceivable

applications. If you would like additional information or if problems arise that are not

sufficiently addressed in this manual please ask your distributor or contact us directly using the

means preferred which are located on the back cover of this manual.

رﺬﺤﻟا

Personal Injury and Damage to the product

lObserve the safety instructions in this user manual

2.1.Signal word panel

Depending on the probability of serious consequences, potential dangers are identified with a

signal word, the corresponding safety colour, and if appropriate, the safety alert symbol.

رﺬﺤﻟا

Indicates a potentially hazardous situation which, if not avoided, may result in moderate or

minor (reversible) injury.

رﺬﺤﻟا

Indicates a potentially hazardous situation which, if not avoided, may result in damage to the

product and/ or its functions or of a property in its proximity.

ModIT-سﻮﺑﺔﺤﻔﺻ4ﻦﻣ21

2.2.Safety alert symbol

Use of the safety alert symbol indicates a risk of injury.

Observe all measures that are marked with the safety alert symbol in order to

avoid injury

2.3.Pictograms

Warning Signs

Electrical hazardFire Hazard

Mandatory action signs

Read operating instructionsMandatory regulation

2.4.Product modification

Cambrionix products are designed and manufactured to meet the requirements of UK and

International safety regulations. Modifications to the product could affect safety and render the

product non-compliant to relevant safety standards, which could result in injury or damage to

the product.

رﺬﺤﻟا

Electric shock or personal injury may occur

lDo not modify the product in any way

ModIT-سﻮﺑﺔﺤﻔﺻ5ﻦﻣ21

رﺬﺤﻟا

lDo not dismantle the product

رﺬﺤﻟا

Fire or personal injury may occur

lDo not obstruct air vents on the product

lDo not cover the product in combustible material

رﺬﺤﻟا

Damage to your product may occur

lDo not bend or compress any part of the product

2.5.Power supply

This section describes safety precautions you must follow when using the power supply.

رﺬﺤﻟا

Electric shock or personal injury may occur

lDo not use a damaged power cord or plug, or a loose power socket

lDo not touch the power plug with wet hands

lDo not allow liquids to come into contact with the unit or power supply

رﺬﺤﻟا

Damage to your product may occur

lDo not short circuit the Power Supply Unit (PSU) supplied with your

product

lDo not disconnect the power cord while the product is being used

ModIT-سﻮﺑﺔﺤﻔﺻ6ﻦﻣ21

رﺬﺤﻟا

lDo not bend or pull the power cord with excessive force

2.6.Storage and Installation

This section describes safety precautions you must follow when installing and storing your

ModIT-سﻮﺑ.

رﺬﺤﻟا

Electric shock or personal injury may occur

lDo not place the power cord near heat sources

lConnect the plug to an earthed socket

رﺬﺤﻟا

Damage to your Cambrionix product may occur

lOperate the product only in an environment where the ambient

temperature is inside the operating temperature range

lOperate the product only in an environment where the relative humidity is

inside the operating range

lBe careful not to leave the power cord underneath a heavy object

رﺬﺤﻟا

Overheated power sockets may cause a fire

lDo not overload the power socket that your hub is connected to

lInsert the power plug all the way into the socket so that it is not loose

ModIT-سﻮﺑﺔﺤﻔﺻ7ﻦﻣ21

3.Getting Started

This manual provides a reference for end-users who are installing for the first time and using

their hub thereafter. As well as a guide for product safety-related information.

The ModIT-سﻮﺑis intended to be used in an indoor static environment in which the

environment falls within the tested specifications to provide charge, sync and management

functionality. For information on the environment specifications please see the physical

specifications section of this manual.

3.1.Opening your product

When you have received your product please check the packing slip to ensure all products and

quantities of them are correct before opening. This is to avoid retesting and repackaging any

items which are not required.

When opening the packaging use a suitable method to open the box i.e. do not use a knife. This

is to ensure the product is not damaged.

3.2.What's Included

ModIT-سﻮﺑHub

2m Mains power cable (Country specified on order including fuse for UKplugs(

ءﺰﺟﻒﺻﻮﻟاﻢﻗرﺔﻌﻄﻘﻟا

ﻞﺑﺎﻛءﺎﺑﺮﻬﻜﻟاﻲﻧﺎﻄﻳﺮﺒﻟا200144

ﻞﺑﺎﻛﺔﻗﺎﻄﻟاﻲﻜﻳﺮﻣﻷا200327

ﻞﺑﺎﻛﺔﻗﺎﻃدﺎﺤﺗﻻاﻲﺑوروﻷا200329

ﻞﺑﺎﻛﺔﻗﺎﻄﻟاAUS200337

ﻞﺑﺎﻛءﺎﺑﺮﻬﻜﻟاIND200341

3.3.Connecting to the mains

ﺪﻛﺄﺗﻦﻣماﺰﺘﻟﻻاﺢﺋاﻮﻠﺑﺔﻣﻼﺴﻟاﺔﻴﻠﺤﻤﻟا،ﻢﻗوﻞﻴﺻﻮﺘﺑﻞﺒﻛﺔﻗﺎﻄﻟاﺲﺒﻘﻤﻟﺎﺑﻞﻴﻐﺸﺗورﺪﺼﻣ.ﺔﻗﺎﻄﻟارﻮﺤﻤﻟاﺰﻫﺎﺟنﻵا

ﻦﺤﺸﻟةﺰﻬﺟﻷا.ﺔﻠﺼﺘﻤﻟا

Periodic inspection should be made to power supply cables and any USB cables for any signs of

damage. If any damage is found then replace damaged cord before further use.

ModIT-سﻮﺑﺔﺤﻔﺻ8ﻦﻣ21

Please note that USB specifications require a minimum 100 mA charge current to be delivered

during data transfer. As indicated in above, if the attached device has a BC1.2 compliant CDP

port, the device can draw up to while transferring data.

3.4.Registration

You may register your product at www.cambrionix.com/product-registration

ModIT-سﻮﺑﺔﺤﻔﺻ9ﻦﻣ21

3.5.Cleaning your ModIT-سﻮﺑ

Cleaning the product is generally not required, although in some instances it may be necessary

if excess dirt/ dust/ hair has accumulated, or if minor liquid spillages have occurred on the

module during operation or storage.

رﺬﺤﻟا

Electric shock or personal injury may occur

lIf there is a dirt/ spillage over a ventilation slot, external data/ power

connector or product aperture, please remove power from the unit without

touching the liquid and contact Cambrionix immediately

ﺪﻛﺄﺗﻦﻣفﺎﻘﻳإﻞﻴﻐﺸﺗﺞﺘﻨﻤﻟاﺔﻟازإوﻚﻠﺳﺔﻗﺎﻄﻟاﻦﻣ.ﺞﺘﻨﻤﻟاﻚﺴﻣأﻞﺒﻛﺔﻗﺎﻄﻟاﻦﻣﺲﺑﺎﻘﻟاﻻوﺲﻤﻠﺗﺲﺑﺎﻘﻟاوأ

ﻚﻠﺳﺔﻗﺎﻄﻟايﺪﻳﺄﺑﺔﻠﻠﺒﻣوأﺔﺒﻃر،ﺪﻘﻓﺞﺘﻨﻳﻦﻋﻚﻟذﺔﻣﺪﺻﺔﻴﺋﺎﺑﺮﻬﻛ

ﺢﺴﻣاﺞﺘﻨﻤﻟاﺔﻌﻄﻘﺑشﺎﻤﻗﺔﻔﻴﻈﻧﺔﻓﺎﺟو.ﺔﻤﻋﺎﻧوﻻمﺪﺨﺘﺴﺗتﺎﻔﻈﻨﻤﻟاﻲﺘﻟايﻮﺘﺤﺗﻰﻠﻋلﻮﺤﻜﻟاوأتﺎﺒﻳﺬﻤﻟا

وأﻞﻣاﻮﻋﺔﻄﺸﻧ.ﺢﻄﺴﻟاﻻشﺮﺗءﺎﻤﻟاوأتﺎﻔﻈﻨﻤﻟاةﺮﺷﺎﺒﻣﻰﻠﻋﺞﺘﻨﻤﻟا

ﻞﻠﺑﺔﻌﻄﻗشﺎﻤﻗﺔﻤﻋﺎﻧﺔﻓﺎﺟوﻲﻓءﺎﻤﻟاﺎﻫﺮﺼﻋاواًﺪﻴﺟﻒﻴﻈﻨﺘﻟﺞﺘﻨﻤﻟاﺎﻤﻛﻮﻫبﻮﻠﻄﻣ

ﻒﻔﺟﺞﺘﻨﻤﻟااًﺪﻴﺟدﺮﺠﻤﺑءﺎﻬﺘﻧاﻒﻴﻈﻨﺘﻟا

ﺪﻋأﻞﻴﺻﻮﺗﻚﻠﺳﺔﻗﺎﻄﻟامﺪﺨﺘﺳاوﺞﺘﻨﻤﻟاﺎﻤﻛﻮﻫﻰﺻﻮﻣﻪﺑدﺮﺠﻤﺑلﺎﻤﺘﻛاﻒﻴﻈﻨﺘﻟاﻒﻴﻔﺠﺘﻟاو

تﺎﻓﺎﻀﻣتادﺎﻀﻣتﺎﺑوﺮﻜﻴﻤﻟا

ﻞﻤﻌﺗﺎﻨﺘﻴﻨﻘﺗﺔﻠﻣﺎﻜﺘﻤﻟاةدﺎﻀﻤﻟاتﺎﺑوﺮﻜﻴﻤﻠﻟﻞﺧادModITﻲﺘﻟا)ﺎﻬﻌﻨﺼﺗClariant(ﻰﻠﻋﻞﻴﻠﻘﺗدﻮﺟوتﺎﺑوﺮﻜﻴﻤﻟا

راﺮﻤﺘﺳﺎﺑﺎﻤﺑ)ﻲﻓ.ﻚﻟذﺎﻳﺮﻴﺘﻜﺒﻟاﺐﻟﺎﺤﻄﻟاو(تﺎﻳﺮﻄﻔﻟاولاﻮﻃةرودةﺎﻴﺣﺞﺘﻨﻤﻟا.ﺎﻬﻠﻤﻛﺄﺑﻞﻤﻌﻳاﺬﻫﻦﻣلﻼﺧدﻮﺟو

ﺢﻄﺳﻻﻦﻜﻤﻳنأﻮﻤﻨﺗﻪﻴﻓتﺎﺑوﺮﻜﻴﻤﻟاﺎﻤﻣﻞﻠﻘﻳهروﺪﺑﻦﻣرﺎﺸﺘﻧاتﺎﺑوﺮﻜﻴﻤﻟا،اﺬﻫوﺪﻋﺎﺴﻴﺳﻲﻓﻞﻴﻠﻘﺗطﺎﻘﻧ

لﺎﺼﺗﻻاﻞﻴﻠﻘﺗوﺮﻃﺎﺨﻣلﺎﻘﺘﻧاىوﺪﻌﻟا/ضاﺮﻣﻷاﻲﻓﻊﻴﻤﺟءﺎﺤﻧأﺔﺌﻴﺑ.ﻚﻠﻤﻋ

ModIT-سﻮﺑﺔﺤﻔﺻ10ﻦﻣ21

4.Installing Host System

One of the features of the Boss Module is the ability to install a Mac mini inside. This provides

different levels of sophistication to the ability of your device.

There are 8 screws on the underside of the case and 7 on the rear that need to be removed

there are also two pins on each side of the boss unit that will need to be removed.

Remove these using a screwdriver and slide the top of the Boss Module 4 inches, as

demonstrated in the in the graphic below.

The graphic below demonstrates how the product should look at this stage. Notice the

highlighted yellow screws, which should all have been removed at this point
