Calyenty RBH 125 Guía de referencia

Customer Manual

RBH125s. RBH185s - sms ready version 3.0s

October 2009

Warranty information.

Please note your arranty may be invalidated if you do not properly maintain the ater

in your pool and all ancillary pool equipment, see the full arranty at the base of this

document. Also your arranty ill be invalidated if the heat pump is not installed

follo ing the procedures in THIS manual exactly.

Quick Reference.

Appearance of control panel screen and time clock under normal operating conditions:

Version 3.0s

Your heat pump ill operate normally in Pool mode. This controller has various timer

functions that you ill not need. You can set the date and time, apart from this, all you

need to set is your desired temperature ith the arro buttons. You can select Pool

mode by pressing mode until it appears. Above is ho the screen should look under

normal orking conditions.

Setting the Time Clock (Guidelines only):

Time clock above illustrates auto mode ith 12 daytime hours (bet een 9.00am and

9.00pm), n.b if the top slider s itch is in the I position the filter pump ill run

continuously, and in O ill be off. There are many types and makes of timer, ho ever

they all have this basic functionality. It is far better if you have or get fitted a timer ith

a memory so that the settings do not shift after po er interruptions.

It is recommended that for optimum filtration of a 8m x 4m or 10m x 5m pool ith a

0.75 - 1.2 kW circulation/filter pump, the pump runs for 6 - 8 hours a day during the day,

i.e. from 10.00am until 6.00pm. This coincides ith the optimum time settings for the

running of the heat pump too. As the ambient air temperature drops into the colder

months you may find that you need to increase the time that the circulation/filter pump

runs up to t elve hours to maintain the pool ater temperature that you require.

Please note that in colder climates you may find that it becomes uneconomical to

maintain a high pool ater temperature during the colder months, or that the

temperature loss is greater than the temperature gain provided by the heat pump. In

such cases you may decide that it is prudent to cease using your heater. Remember

during months here the outside ambient temperature drops to zero you must use the

by-pass and drain do n your heat pump. Al ays use a Calyenty heat pump cover hen

your heater is not in use.

To Install your Calyenty heat pump, you will need:

• 3 x 50mm ball valves for the bye-pass.

• 2 x 50 mm pressure 90°elbo fittings.

• 2 x 50 mm pressure T fittings.

• Adequate 50mm pressure tubing (rigid or flexible).

• uPVC solvent and cement.

• Adequate 2.5mm x 3 core flexible electrical cable.

You may find that you need some more pressure fittings or 45°elbo s depending on

here you position the heat pump in relation to your existing installation.

Tools:

Tape measure, hacksa , Philips scre driver, Drill + m8 masonry bit, strap rench.

Do not over tighten any ater fittings, hand tight should be sufficient to ensure a good

atertight seal.

1. This unit should be installed by a competent person.

2. All electrical ork should be carried out by a qualified electrician / lampista.

3. Check packaging for obvious signs of damage, before installation begins. Report

any damage to Calyenty before installation if you have concerns.

4. Please read the Installation & Operation Manuals carefully before you install or

operate the unit.

5. The company ill not be responsible should someone be injured in the event of

the proper installation procedures have not having been adhered to.

6. Choose a suitable location for your heat pump. Remember this must satisfy your

aesthetic requirements, should be close to the filter pump, be on flat ground

(unless positioned on a custom bracket), be in a sunny position if possible and

comply ith the space requirements as illustrated in 3.3 in the main customer

manual.

7. Secure the Stainless Steel fixing base to the ground. First position the base and

mark here the fixing bolt ill go. Next drill a hole ith an m8 masonry bit. Fix

the base permanently using a m8 fixing bolt, ensuring that the anti-vibration

pads are in place (bet een the ground and the underside of the base). If you are

positioning the unit on softer ground, i.e. a grassed area or la n, you can make a

concrete core under here the central fixing point ill be and fix the base to this

core.

8. Lift the heat pump into place onto the base. The lifting points are under the

outside edge of the fan housing. Once the pump has been lo ered onto base,

make sure the scre holes line up and scre in the retaining scre s, this fixes

the main heat pump body securely to the base plate. Also make sure that the

anti-vibration pads are positioned bet een the base and the bottom of the heat

pump. DO NOT ATTEMPT TO LIFT THE HEAT PUMP FROM THE BOTTOM AND

DROP ONTO BASE AS THIS MAY DAMAGE THE UNIT.

9. The ater is fed through the heat pump using the circulation/filter pump. You

ill need to identify the return pipe from the filter to the pool (this is often

marked RETURN). You ill no need to cut into this return plumbing / pipe ork

of the pool system. Before you make this cut, make sure that if there are shut off

valves/taps in this pipe- ork, that they are in the closed position. USEFUL TIP: If

there are not any taps, it is possible to do this ork ithout draining the pool by

inserting ine bottle corks into the return jets. IMPORTANT - Make sure that the

connection from the filter goes to the pipe connector on the heat pump marked

WATER INLET. Connect the pipe connector on the heat pump marked WATER

OUTLET to the return pipe that continues to the pool jets. See diagram on page

belo to ensure that the pipe ork is connected correctly as sho n. When

making uPVC connections, it is very important that the surfaces of both the pipe

and the fitting are clean and dry. It is also very important to thoroughly ipe the

surfaces ith the solvent cleaner, as this starts the chemical reaction to ensure a

good bond hen the adhesive is applied. Make sure that the adhesive covers

100% of both surfaces that are to come in contact ith each other.

10. It is possible to connect a drain tube from the base tray to control the discharge

of any collected ater from the condensation produced, (under normal

operation the heat pump ill create considerable condensation). Please ensure

that this exit is al ays kept clear to avoid ater collecting in the tray. This tube

can be taken to any convenient point for discharge of the ater.

11. IMPORTANT: Po er supply to the filter pump, and the heat pump, and the

s itching on and off of both devices must be the same and simultaneous. Using

the electrical entry marked "Po er Supply" connect the heat pump to the dead

side of the filter pump timer clock electricity supply. Please ensure this is carried

out be a qualified Electrician or Lampista. It is important to give the heat pump

po er supply its o n RCD circuit breaker. N.B. Please check that hen the

po er to the filter pump is cut or times out from the timer , the po er to the

heat pump is also cut and the back lit LCD controller s itches off.

12. Connect the supplied control panel to the snap connecters to complete the

installation. The control panel can be mounted in a convenient dry place.

13. We recommend that the heat pump is fitted ithin 8 meters (25 feet) of the

existing circulation pump for maximum performance. This is not critical but could

slightly reduce the efficiency of the unit if positioned further than this distance.

14. If the ater in the heat pump is allo ed to freeze it ill damage the unit. It is

essential for the guarantee to remain valid to drain the heat pump during

months here the outside ambient air temperature can drop to 0°C. Simply

close the ball valve / shutoffs and open the bye-pass. Then remove the drain

plug at the base of the unit to remove all the ater.

Main Customer Manual.

This manual includes the information about specifications, installation, debugging,

operation and maintenance. Please read this manual carefully before you install, start,

repair or service the unit. Professional technicians must carry out the installation of the

unit. The manufacturer shall not be held legally responsible for any damage of the unit

or physical injury or death caused by improper installation, debugging, operation,

maintenance or disregarding the manual.

1. General Information

This s imming pool heat pump is produced to strict standards. The unit runs safely;

giving excellent performance, lo noise and lasting durability.

1.1 Features

Titanium heat exchanger-- Most manufacturers adopt copper for heat exchanger

production. The chemicals (chlorine, bromine and acid) in pool ater are extremely

corrosive to cooper heat exchangers. Calyenty adopts a titanium heat exchanger, hich

is completely anticorrosive to the chemicals in pool ater. NO LEAKAGE, NO

POLLUTION, MORE DURABLE.

Brand-name compressor-- The compressors in Calyenty s imming pool heats pump are

HITACHI, This orld kno n brand stands for excellent performance, lasting durability

and lo noise.

Extra- ide heat exchanging area-- Except the electrical iring and ater connection

area, the surface of Calyenty s imming pool heat pump is for heat exchange bet een

the air and refrigerant in the evaporator. Extra- ide heat exchanging area gets more

heat from the air and helps the unit heat the pool more quickly.

Large impeller & po erful fan motor-- The large impeller and po erful fan motor

accelerate the circulation of air. The faster the air circulates, the more HEAT the unit

gets from the air.

Easy operation-- The temperature of your pool and running time of the unit can be

easily set on the small digital control panel, hich is designed ith a clear and operator-

friendly style.

Compact size-- Calyenty s imming pool heat pump is much smaller than the other

products of the same heating capacity. It saves space and is aesthetically pleasing.

1.2 Note

• We recommend 27C (80F) as the optimum ater temperature for s imming.

Overheated ater may cause tiredness and reduce comfort of s imming.

• Children should be supervised at all times: both in the pool and in close

proximity.

• Don't use the pool after drinking alcohol. The hot pool ater can quicken the

circulation of alcohol in the body and cause unconsciousness even dro ning.

• Special notice for pregnant omen: ater above 38C (100F) may result in brain-

damage to the fetus.

• Al ays use an accurate thermometer to monitor the ater temperature.

• People ith medical history of heart disease, diabetes, circulatory system or

blood pressure problem should consult their physicians before using a hot pool.

• Don't use a hot pool after taking medicines hich may cause dro siness.

• Soaking in the hot pool too long may result in hypothermia.

• It is necessary to maintain a chemical balance ithin the pool ater to ensure

longevity of the heat pump.

1. Energy Saving Tips

• A pool heat pump cannot heat your pool as quickly as a gas or electric pool

heater does. It ill take a fe days for a heat pump to heat your pool ater to

your desired temperature.

• We suggest you to use a pool cover to reduce energy loss hen you don't use

the pool.

• For eekend use, it's more economical to maintain the pool ater at your

expected temperature or a little lo er.

• If you don't use the pool for a long period, turn the unit off.

• Please turn the unit off during the inter and drain out all the ater by

removing the drain plug. We recommend that you cover the machine ith a

Calyenty inter cover.

• Use an accurate thermometer to measure the ater temperature. A slight

temperature difference may cause a considerable difference in energy

consumption.

• Set the ater temperature according to the temperature of the air. For example,

you can set the temperature lo er hen the eather is armer. During the

summer, if the eather is very hot, you can turn the unit off.

2.1 Model Data:

Oct-07 Calyenty Eco Heat Pump Specifications

Item/Type Unit RBH 125 RBH 185

Pool Capacity Cu. Mtrs. 50 70

Fan Location Top Top

Heating F BTU/H 42650 59368

Capacity W 12500 17400

E* BTU/H 32414 54592

W 9500 16000

Po er F W 1900 2750

Input E* W 1800 2600

C O P F 6.58 6.33

E* 5.27 6.15

Current F A 8.6 14.3

E* A 8.2 13.6

Po er Supply V/Ph/Hz 220-240/1/50 220-240/1/50

Compessor Rotary Rotary

Heat Exchanger Titanium heat exchanger in PVC housing

Refridgerant R407C R407C

Fans 1 1

Po er

Input W 175 175

of Fan

Rotation Speed 650 650

Noise Level dB(A) 47 51

Calyenty Eco Heat Pump Specifications

Item/Type Unit RBH 125 RBH 174

Connections 50mm 50mm

Min. Water Flo Cu.Mtr/hr 3 6

Water Pressure Kpa 10 10

Dimensions mm 575x575x680 575x575x780

Packaged mm 710x710x820 710x710x920

Sizes

Net Weight Kg 58 75

Gross Weight Kg 72 90

Surrounding tempreture 24c db/19c b

Note The above data is for your reference. There ill be no prior notice for technical improvement.

2.2 Illustrations:

Otros manuales para RBH 125

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Bomba de calor de Calyenty

Calyenty

Calyenty RBH 125 Guía de referencia

Manuales populares de Bomba de calor de otras marcas

MICROWELL

MICROWELL HP 1000 GREEN Manual de usuario

Sanyo

Sanyo SAP120FCH Manual de usuario

Daikin

Daikin EHYHBH05AA Manual de usuario

Panasonic

Panasonic WH-SDF03E3E5 Guía

Bryant

Bryant 544B Manual de usuario

Airxcel

Airxcel 45000 Series Manual

Mitsubishi Electric

Mitsubishi Electric PUZ-SWM60VAA Manual de usuario

Dimplex

Dimplex LI 16I-TUR Guía del usuario

Carrier

Carrier WSHP Open v3 Guía de configuración rápida

TGM

TGM CTV14CN018A Manual de usuario

Carrier

Carrier 38MGQ Series Manual de usuario

Kokido

Kokido K2O K880BX/EU Guía de solución de problemas

Viessmann

Viessmann VITOCAL 300-G PRO Type BW 2150 Guía rápida

Carrier

Carrier 48EZN Manual de usuario

Viessmann

Viessmann KWT Vitocal 350-G Pro Series Instrucciones de funcionamiento

Ariston

Ariston NIMBUS Manual de usuario

Weishaupt

Weishaupt WWP L 7 Guía del usuario

GE Zoneline AZ85H09EAC Manual de usuario
