Cake Makka Manual de usuario
Makka
Manual
Makka
Manual
Welcome
to CAKE!
We are extremely flattered that you have chosen to ride a CAKE electric
motorbike. It’s our obligation to do the best we can to serve you with the
product, information, service and spare parts for an eortless experience.
Our ambition is to develop uncompromising high-performance motorbikes.
CAKE´s mission is to inspire people, contributing to speeding up the journey
towards a zero-emission society, combining excitement with responsibility.
To optimize the performance and benefits for a lightweight electric motorbike.
Established with an electric drivetrain, establishing a new category, we
needed to start from scratch. Every little detail, hard, and software has
been engineered, designed, and chiseled for perfection while considering
the perspectives of sustainability.
Explore with Respect.
Stefan Ytterborn, Founder & CEO
Table of contents
Contents
1. Symbols used
2. Safety
2.1 Owner’s manual
2.2 Risk symbols
2.3 Intended use
2.4 Misuse
2.5 Safety labels and marks on the product
2.6 Safety advice
2.7 Customer service
3. Warranty
4. Getting started
4.1 Unboxing the vehicle
4.2 Preparing for use
4.3 Powering on
4.4 Downloading the Ride CAKE app
4.5 Riding
5. Description
5.1 General description
5.2 Battery
5.3 Display
5.4 Ride modes
5.5 Brake modes
6. Operating
6.1 Handling the battery
6.2 Before every ride
6.3 Starting
6.4 Accelerating
6
7
7
7
7
8
8
9
13
13
13
13
14
15
17
18
20
20
22
22
23
23
24
24
28
28
29
Contents
6.5 Changing brake mode
6.6 Changing ride mode (R1) (R2)
6.7 Braking
6.8 Powering o/locking
6.9 Activating steering lock
6.10 Storing the vehicle
7. Service schedule
8. Work on the vehicle and its accessories
8.1 Tools, materials, and substances used
8.2 Brake system
8.3 Chassis
8.4 Cleaning the vehicle
8.5 Electrical system
8.6 Suspension, fork, rear
8.7 Handlebar
8.8 Key card
8.9 Lights
8.10 Saddle
8.11 Wheels, tires
9. Troubleshooting
10. Spare parts and accessories
11. Technical data
11.1 Makka Range and Makka Range :work
11.2 Makka Flex and Makka Flex :work
11.3 Battery charger
12. Contact and Support
6
7
7
7
7
8
8
9
13
13
13
13
14
15
17
18
20
20
22
22
23
23
24
24
28
28
29
29
29
29
30
30
30
31
32
32
33
38
40
40
41
43
44
46
47
48
53
57
57
57
59
61
62
1. Symbols used
Indicates mandatory safety information.
Indicates required maintenance according to the service schedule.
Indicates environmental measures.
Indicates a reference to the CAKE app.
6
2. Safety
2.1 Owner’s manual
Before riding the vehicle for the first time, read through this entire manual and
make sure you fully understand it. Contact
if any questions.
The manual contains useful and important information on how to operate,
service, and customize the vehicle, and protect yourself from injury.
This manual is being updated continuously. Make sure you have the latest
version; visit
ridecake.com/manuals
.
If the owner sells the vehicle, the manual is part of the purchase.
2.2 Risk symbols
Safety instructions are emphasized in the text. Read them carefully to avoid
hazardous situations and to operate the vehicle safely.
Danger A hazard that will immediately lead to death or serious
permanent injury.
Warning A hazard that may lead to death or serious permanent injury.
Caution A hazard that may lead to minor injuries.
Notice A hazard that may lead to machine, material, or
environmental damage.
2.3 Intended use
This vehicle is designed and built for use on public roads. The lithium battery
is designed and built for the Makka vehicle. The charger is designed and built
for the lithium battery.
7
2.4 Misuse
Only use the vehicle and its accessories, battery, and charger as intended.
Ensure to use the stated fluids and tools when servicing.
Misuse may lead to danger for people, property, or the environment.
2.5 Safety labels and marks on the product
Information labels and warning labels are attached to the product. Do not remove
any labels, as you or others may then not recognize danger.
Placement of safety labels and marks on the vehicle
Fig. 1
8
D, E
H
C, D, E
G
A
B, E, F
AType label
BElectric battery
CElectric motor
DHot parts
ENo high-pressure cleaning
FFire hazard
GTire pressure
HVehicle Identification Number (VIN)
2.6 Safety advice
Tampering warning
Tampering with the vehicle is prohibited, or safe operation cannot be guaranteed,
and the warranty coverage will become void.
Examples of prohibited tampering:
• Modifying any part of the vehicle.
• Opening the battery.
• Opening the charger.
• Misusing the vehicle.
Cake 0 Emission AB
L1e-B
YW2XXXXXXXXXXXXXX
--dB(A) - --min
4,0 kW 45 km/h max 245 KG
-1
CAKE 0 EMISSION AB
HAMMARBY FABRIKSV. 43
120 30 Stockholm
Sweden
F: GAWR/PNBE TDB KG (TDB LB) --- 3.00x14 TIRE/PNEU --- 1,85x14 RIM/JANTE --- 225 KPA (32 PSI) COLD/FROID
R: GAWR/PNBE TDB KG (TDB LB) --- 3.00x14 TIRE/PNEU --- 1,85x14 RIM/JANTE --- 225 KPA (32 PSI) COLD/FROID
YWXXXXXXXXXXXXXXX
9
Safe operation
Each of the below safety instructions is repeated where relevant.
WARNING! Risk of personal injury.
Do not use the vehicle if you are not fit to ride due to alcohol, drugs,
or medicine.
Do not use the vehicle if you are physically or mentally impaired.
Do not ride with a passenger unless you have installed a proper CAKE
passenger seat, see
ridecake.com/en/products/spare-parts/
.
The vehicle is completely silent when it has been powered on but is at
a standstill. Anyone not realizing the vehicle is powered on may get
hurt if the throttle is accidentally twisted. Do not forget to power o.
There is no foot brake. Remember that you control both the rear and
front brakes from the handlebar.
When slowing down using the motor brake, other road users are not
notified of your slowing down. Use the motor brake with caution.
Always use the mechanical brakes to bring the vehicle to a standstill.
When charging, always first connect the charger to the battery.
Thereafter, connect the charger to the mains supply.
Safe charging cannot be guaranteed if another charger or battery
than the intended is used. Only use the intended charger. Only use
the intended battery.
Regularly examine the charger for any damages, especially the cord,
plug, and enclosure. Do not use a damaged charger. Contact
CAKE
Service & support
.
During charging, place the battery in a well-ventilated area.
WARNING! Risk of burns. Stay clear of vehicle parts that are hot
after usage.
10
CAUTION! Do not leave the battery unattended during charging.
Never ride the vehicle above your comfort level. Always ride according
to your riding skills.
• Make sure you have the correct driving license to ride the vehicle.
• Follow the local trac laws and regulations.
• Adhere to the vehicle warning labels.
• Only operate the vehicle for its intended use.
• Always operate the vehicle in a safe manner for people, animals,
and the environment.
• Only operate the vehicle when it is in perfect technical condition.
• Always wear a helmet and appropriate clothing.
Accident/damaged vehicle
WARNING! Fire hazard. Do not use a damaged battery, as it is
highly flammable. A damaged battery may self-ignite. If the vehicle
should catch fire, inform the fire brigade that it is an electrical vehicle
with a lithium battery.
After an accident or fall, check the vehicle for any damages. Do not ride the
vehicle if it requires service. If in doubt, do not ride the vehicle but contact
CAKE Service & support
.
Service and work on the vehicle
DANGER! Risk of electric shock.
Do not open the battery. Do not open the charger.
Work on the battery and charger must only be performed by an authorized
CAKE workshop.
Remove the battery before starting any work on the vehicle.
11
