CUSTOMER CONVENIENCE/PERSONALIZATION GUIDE

SRX

DRIVER INFORMATION

Instrument Panel . . . . . . . . . . . .1

Instrument Panel Cluster . . . . . . .2

Driver Information Center . . . . . .3

SEATS, LIGHTS & WIPERS

Manual Seat Adjustments . . . . . .5

Power Seat Adjustments . . . . . .5

Power Lumbar . . . . . . . . . . . . . .6

Heated Front Seats . . . . . . . . . . .6

Second-Row Seat . . . . . . . . . . .6

Third-Row Access . . . . . . . . . . . .6

Power Third-Row Seat . . . . . . . .7

Child Restraints (LATCH) . . . . . .7

Memory Seat and Mirrors . . . . . .8

Instrument Panel and

Courtesy Lights . . . . . . . . . . . . .8

Rear Washer/Wiper . . . . . . . . . . .8

ENTERTAINMENT SYSTEMS

Standard Audio System . . . . . . .9

Bose®Audio System . . . . . . . . . .9

Navigation System . . . . . . . . . . .9

Rear Seat Entertainment (RSE) . .11

CONVENIENCE FEATURES

OnStar®...................12

XM Satellite Radio . . . . . . . . . .12

Universal Home Remote . . . . .12

Ultrasonic Rear Parking Assist

(URPA) . . . . . . . . . . . . . . . . . . .13

UltraView/UltraView Plus

Sunroof . . . . . . . . . . . . . . . . . .13

Power Adjustable Pedals . . . . .13

Cruise Control . . . . . . . . . . . . . .14

Dual Climate Control . . . . . . . .14

Rear Air Conditioning . . . . . . . .14

POWERTRAIN & CHASSIS

Engine Fuel . . . . . . . . . . . . . . . .15

Transmission . . . . . . . . . . . . . . .15

Traction & Stability . . . . . . . . . .15

OWNER PRIVILEGES™

Roadside Service . . . . . . . . . . .16

Customer Assistance . . . . . . . .16

Cadillac Online . . . . . . . . . . . . .16

TABLE OF CONTENTS

Refer to your Owner Manual for more information.

Driver

Information

Seats, Lights

&Wipers

Entertainment

Systems

Convenience

Features

Powertrain

&Chassis

Owner

Privileges™

Driver Information

1. Air Outlets

2. Turn Signal/Multifunction Lever

3. Instrument Panel Cluster

4. Windshield Wiper Lever

5. Hazard Warning Flasher Button

6. Audio System/

Navigation System (if equipped)

7. Glove Box

8. Dual Climate Control

Automatic Transmission Shift

Lever

10. CD Player

11. Steering Wheel Controls

INSTRUMENT PANEL

12 3 4 5 6

10 87

11 1

INSTRUMENT PANEL CLUSTER

1. Oil Pressure Light

2. Tire Pressure Light

3. Fog Lamp Light

4. Tachometer

5. Cruise Control Light

6. High Beam On Light

7. Speedometer

8. Malfunction Indicator Lamp

(Check Engine Light)

9. Air Bag Readiness Light

10. Fuel Gauge

11. Safety Belt Reminder Light

12. Charging System Light

13. Odometer/Driver Shift Control

(DSC) Display

14. Antilock Brake System (ABS)

Warning Light

15. Traction Control System (TCS)

Warning Light

16. Brake System Warning Light

17. Security Light

18. Engine Coolant Temperature

Warning Light

19. Engine Coolant Temperature

Gauge

Note: Some of the gauges and indicators may differ from the illustration presented. The

instrument panel cluster is designed to let you know about many important aspects of your

vehicle’s operation.

It is important for you to read your Owner Manual and become familiar with the information

that is being relayed to you by the lights, gauges and indicators, particularly the message center,

as well as what action can be taken to ensure your safety and to prevent damage.

123456789

19 15

SRX

❏Reviewed with Customer (Please Check Box)

Refer to your Owner Manual for more information.

Driver

Information

Seats, Lights

&Wipers

Entertainment

Systems

Convenience

Features

Powertrain

&Chassis

Owner

Privileges™

The DIC displays vehicle system

status, warning messages,

personalization features and the

clock.

All information will appear on the

audio display or, if the vehicle is

equipped with the optional

navigation system, it will appear on

the navigation display.

The following procedures are

provided only to acquaint you with

the DIC. It is strongly recommended

that you review your Owner Manual

to become familiar with the various

messages and how to access and/or

reset them.

Vehicle System Status

The vehicle system menu provides

the following information:

•OUTSIDE TEMPERATURE

•TRIP ODOMETER A

•TRIP ODOMETER B

•FUEL RANGE

•AVERAGE FUEL ECONOMY

•INSTANTANEOUS FUEL ECONOMY

•FUEL USED

•AVERAGE VEHICLE SPEED

•TIMER

•BATTERY VOLTAGE

•TIRE PRESSURES (Requires optional

Tire Pressure Monitor)

•ENGINE OIL LIFE

•TRANSMISSION FLUID LIFE

You can view the above information

at any time, but only one item at a

time. Refer to your Owner Manual for

detailed descriptions of the menu

items and how to reset them.

Display Status without Navigation

To display the vehicle system status

menu in vehicles without navigation,

the vehicle must be in RUN.

Use the following controls to access

the vehicle system status menu:

1. Push the arrows on the INFO

button located to the lower right

of the audio display to scroll

through the

vehicle system

information.

2. Press the CLR

button to clear

and/or reset DIC

items to zero.

Refer to your

Owner Manual

for detailed

description.

DRIVER INFORMATION CENTER (DIC)

Display Status with Navigation

(if equipped)

To display the vehicle system status

menu in vehicles with navigation, the

vehicle must be keyed On. Push the

hard key to display the main

system menu.

1. The vehicle system status

information is displayed on the

upper-right corner of the display.

Touch this soft button to cycle

through the vehicle system status

menu.

2. To view the complete vehicle

system status menu, touch and hold

this rectangular soft button or touch

the soft button on the lower

part of the display.

3. Cycle through the menu items with

the 



soft buttons.

4. The RESET soft button can be

pushed to reset.

Warning Messages

Messages will appear on the audio or

navigation/audio display if there is a

problem sensed in one of your vehicle’s

systems. You must acknowledge

a message to clear it from the

screen for further use.

For vehicles without navigation,

press the CLR button next to

the audio display to clear a

message.

To clear a message in vehicles

with navigation, press the OK

soft button.

Note: Removing the message does not

remove the sensed problem or

condition. Refer to your Owner Manual

for a list of messages and

accompanying icons, a description of

the condition and the recommended

action. Be sure to regard seriously any

message that appears and take the

appropriate action.

Check Warning Lights with OnStar

(if equipped)

If your vehicle is equipped with OnStar

and your Malfunction Indicator Lamp

(Check Engine Light) illuminates, or any

other warning message appears, you

can press the blue OnStar button and

speak to an OnStar Advisor. In many

vehicles, OnStar Advisors can access

certain diagnostic information and tell

you how serious the condition is and

what you should do about it.

SRX

❏Reviewed with Customer (Please Check Box)

Refer to your Owner Manual for more information.

Driver

Information

Seats, Lights

& Wipers

Entertainment

Systems

Convenience

Features

Powertrain

& Chassis

Owner

Privileges™

Personalization

Your vehicle is equipped with

personalization capability that allows

you to program certain features to a

preferred setting for up to two

drivers. To personalize programmable

features, please refer to the

Personalization Instructional CD and

booklet or the Owner Manual

provided with your vehicle.

Setting the Time

If your vehicle is not equipped with

the Navigation System:

1. Press the TUNE/SEL knob to enter

the main menu.

2. Turn the TUNE/SEL knob until “SET

CLOCK” is displayed.

3. Press the TUNE/SEL knob to select

SET CLOCK.

4. Turn the TUNE/SEL knob to adjust

the time.

5. Press the TUNE/SEL knob to

update the time. “VEHICLE TIME

UPDATED” will be displayed.

If your vehicle is equipped with

navigation, refer to the Entertainment

and Navigation Supplement.

Seats, Lights & Wipers

MANUAL SEAT ADJUSTMENTS

(passenger side only)

Use the bar at the front of the seat to

adjust seat position. Use the lever at

the side of the seat to recline the

seat or return it to upright.

POWER SEAT ADJUSTMENTS

If your vehicle has this feature, the

power seat controls are located on

the outboard sides of the front seats.

1. The front or rear part of the lever

will raise or lower the front or

rear of the seat cushion.

Move the entire lever up or

down to raise or lower the entire

seat.

Slide the entire lever forward or

rearward to move the seat in that

direction.

2. Move the vertical lever rearward

to recline, and forward to return,

the seatback.

POWER LUMBAR (if equipped)

If your vehicle has this feature, a

two-way switch is located beneath

the power seat switch controls. Hold

the control forward or rearward to

increase or decrease support.

HEATED FRONT SEATS (if equipped)

The buttons to heat the driver and

front passenger seats are located on

the Climate Control panel. The

ignition must be on to heat the seats

and the heated

seats must be

turned on again

(if desired) after

the vehicle has

been turned off.

1. Press the button twice for the seat

you wish to heat to set the

heat to LO (approximately normal

body temperature).

2. Press the button once to set the

heat at HI (slightly higher than

LO setting).

3. Press the button a third time

to turn the heat OFF.

The selected setting will appear on

the display panel.

SECOND-ROW SEAT

Adjusting the Seat

An adjustment lever to move the

seat forward or rearward is located

under each side of the 60/40 seat.

After adjustment, move the seat back

and forth to make sure it locks into

place.

THIRD-ROW ACCESS

The right side of the second-row

60/40 seat has an easy entry feature

to make it easier to get into and out

of the third-row seat, if equipped.

To operate the easy entry seat:

• Pull the release lever located on

the top of the seat upward.

• Tilt the seatback forward by

pulling the top of the seat

forward.

• Pull upward on the release lever

located on the back of the seat

and rock forward until it stops.

SRX

❏Reviewed with Customer (Please Check Box)

Refer to your Owner Manual for more information.

Driver

Information

Seats, Lights

& Wipers

Entertainment

Systems

Convenience

Features

Powertrain

& Chassis

Owner

Privileges™

POWER THIRD-ROW SEAT

(if equipped)

If your vehicle has a third-row seat,

it includes a power-folding feature

to provide additional cargo space.

Before the seat can be folded, the

headrests must be removed and

stored.

Removing Headrests

1. Press the button on top of the

seatback below the headrest and

pull up on the headrest.

2. Open the storage compartment

cover behind the seat and insert

the headrest posts through the

slats in the carpet.

3. Position and snap the headrests in

the storage tray provided.

The seatback will not fold all the way

down if the headrests are not

removed.

Folding/Unfolding Seat

Before folding or unfolding the third-

row seat,

all

of the following

conditions must be met:

• The vehicle must be in Park and

not have a low battery.

• The liftgate or right-side rear

door must be open.

• The carpet seatback panel must be

folded and attached to itself.

• The ignition must be in ON or

ACCESSORY. If not, pressing the

unlock button on the key fob or

door

three

times will enable

power folding or unfolding for two

minutes.

Two buttons are located on the right-

side panel behind the third-row seat.

One folds and raises the seat and the

other changes the seatback angle.

The other button

for folding the seat

is located on the

right-side trim

panel behind the

second-row seat.

Press and hold either folding button

to fold or unfold the seat.

After the seat is folded, the panel on

the back of the seat must be flipped

forward to create a flat floor space.

Before returning the seat to its

upright position, the panel must be

returned to its folded position.

CHILD RESTRAINTS (LATCH)

Your vehicle is equipped with LATCH

anchors, and may have top tethers

for use with a LATCH compatible

child restraint. If your child restraint

is not compatible with the LATCH

system, you may still use it by

installing the child restraint with the

seat belt system.

Choose a child restraint that is

appropriate for the child’s age and

size (weight and height).

See Section 1 of your Owner Manual.

MEMORY SEAT AND MIRRORS

(if equipped)

The buttons to set the seat and mirror

memory are located on the driver’s

armrest. To set the memory, first adjust

the driver’s seat, including the seatback

recliner, both outside mirrors, the

throttle and brake pedals, audio settings

and HVAC settings.

1. Press and hold button 1 until two

beeps are heard to confirm memory

setting.

2. Repeat the procedure using button 2

to store memory for a second driver.

Setting Exit Position

1. Press button 1 or the unlock symbol

on the keyless entry fob with number

1 on the back. Adjust the driver’s

seat to the desired exit position.

2. Press and hold the exit button,

located above buttons 1 and 2 on the

driver door armrest, until two beeps

are heard to confirm exit memory

setting. Repeat the procedure for a

second driver using button 2 and the

key fob with 2 on the back.

To recall stored exit positions, press and

release the exit button. A beep will

sound and the seat will move to the

memory exit position for the identified

driver. If no exit position is stored, the

seat will move all the way back.

Note: The vehicle must be in Park to

recall the exit position.

For further programming instructions for

seat and mirror memory, refer to your

Owner Manual or Personalization

Instructional CD and Booklet.

INSTRUMENT PANEL AND COURTESY

LIGHTS

Slide the lever in the overhead console

forward to brighten the panel lights and

past the resistance point to turn the

courtesy lights on. Slide the lever in the

opposite direction to turn off the

courtesy lights or dim the panel lights.

REAR WASHER/WIPER

The rear washer/wiper

control is located in the

overhead console. Press

the center of the switch to

wash the rear window.

Press the forward part of

the switch for delayed

wipes. Press the rear part

of the switch for steady wipes.

SRX

Tabla de contenidos

Otros manuales de Automóvil de Cadillac

Cadillac

Cadillac 2015 SRX Manual de usuario

Cadillac

Cadillac CTS 2017 Manual de usuario

Cadillac

Cadillac Escalade 2016 Manual de usuario

Cadillac

Cadillac CTS SEDAN - BROCHURE 2010 Manual de usuario

Cadillac

Cadillac SRX 2010 Manual de usuario

Cadillac

Cadillac 2011 SRX CROSSOVER Manual de usuario

Cadillac

Cadillac ESCALADE EXT 2005 Guía de referencia

Cadillac

Cadillac ESCALADE - BROCHURE 2009 Manual de usuario

Cadillac

Cadillac CAR SUPERCHARGED 4.4L NORTHSTAR V8 Manual de usuario

Cadillac

Cadillac 2011 Escalade ESC Manual de usuario

Cadillac

Cadillac CTS COUPE - SPECIFICATIONS 2011 Manual de usuario

Cadillac

Cadillac CT5 2022 Manual de usuario

Cadillac

Cadillac 2014 Cadillac SRX Manual de usuario

Cadillac

Cadillac 1995 sedan deville Manual de usuario

Cadillac

Cadillac 2011 SRX CROSSOVER Manual de usuario

Cadillac

Cadillac 2011 CTS COUPE Manual de usuario

Cadillac

Cadillac 2010 Escalade Manual de usuario

Cadillac

Cadillac CTS-V 2019 Manual de usuario

Cadillac

Cadillac 2003 CTS Manual de usuario

Cadillac

Cadillac CTS 2015 Manual de usuario

Cadillac

Cadillac 2010 DTS Manual de usuario

Cadillac

Cadillac 2004 CTS Manual de usuario

Cadillac

Cadillac 2014 ELR Manual de lista de piezas

Cadillac

Cadillac CTC 2005 Manual de usuario

Manuales populares de Automóvil de otras marcas

Toyota

Toyota 2000 Tundra Manual de usuario

CITROËN

CITROËN DS4 DSign Manual de usuario

Lexus

Lexus 2015 CT 200h Manual de usuario

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Manual de usuario

Porsche

Porsche Boxster S Manual de usuario

GMC

GMC 2010 Savana 1500 Cargo Manual de usuario

KIAM

KIAM SPORTAGE 2014 Manual de lista de piezas

GMC

GMC 2013 Terrain Instrucciones de montaje

GMC

GMC T-Series 1999 Manual de usuario

Mercury

Mercury 1998 Mystique Manual de usuario

Mercury

Mercury 2007 Mariner Manual de usuario

Mazda

Mazda 2007 Mazdaspeed 3 Guía

Mazda

Mazda 2014 CX-5 Manual de usuario

GMC

GMC Chevrolet Express 2022 Manual de usuario

GMC

GMC 1997 Jimmy Manual de usuario

Chevrolet

Chevrolet 2012 Malibu Manual de usuario

Skoda

Skoda FABIA RS - ANNEXE 118 Manual de usuario

Seat

Seat toledo Manual de usuario
