CUSTOMER CONVENIENCE/PERSONALIZATION GUIDE

D E V I L L E

DRIVER INFORMATION

•Instrument Panel

(DeVille and DHS)

•Instrument Panel (DTS)

•Digital Cluster

•Analog Cluster (DHS/DTS)

•Driver Information Center

Controls

AUDIO SYSTEMS

•Audio System Control

Designations and Functions

•Preset Stations

•Setting the Time

•Loading CD Changer

COMFORT/CONVENIENCE

•Tri-zone Climate Control System

•Rainsense™ Wipers (if equipped)

•OnStar®

•Driver Memory Settings

•Heated Seats, Heated and

Cooled Seats

•Ultrasonic Rear Parking Assist

(URPA)

•Night Vision

PERSONALIZATION GUIDE

MAINTENANCE/OWNER

PRIVILEGES

TABLE OF CONTENTS

Refer to your Owner Manual for further information.

20 19

18 17 16 1513 13

4 5 6 7 9 8

14 11

1 1 1

INSTRUMENT PANEL DeVille and DHS

1. Air Outlets

2. Driver Information Center

Controls

3. Digital Instrument Cluster

(available on DHS)

Analog Instrument Cluster (DHS)

4. Driver Information Center Display

5. Shift Lever

6. Hazard Warning Flasher Button

7. Electronic Climate Controls

8. Glove Box

9. Passenger-Side Air Bag

10. Audio System

11. Ashtray/Lighter

12. Steering Wheel Audio System

Controls

13. Cruise Control

14. Driver-Side Air Bag/Horn

15. Tilt Wheel Lever (DeVille)

Power Tilt/Telescope Wheel

Control (DHS)

16. Parking Brake Pedal

17. Hood Release

18. Steering Wheel Climate System

Controls or optional Phone

Controls

19. Turn Signal/Multifunction Lever

20. Lighting Controls

21. 12V Power Outlet

(On front of passenger seat, near

umbrella tray)

Driver

Information

Audio Systems Comfort/

Convenience Personalization

Guide

Maintenance/

Owner Privileges™

Driver

Information

D E V I L L E

Driver

Information

1. Air Outlets

2. Driver Information Center Controls

3. Digital Instrument Cluster

4. Driver Information Center Display

5. Hazard Warning Flasher Button

6. Electronic Climate Controls

7. Audio System

8. Glove Box

9. Passenger-Side Air Bag

10. Ashtray/Lighter

11. Console Shift Lever

12. Steering Wheel Audio System

Controls

13. Driver-Side Air Bag/Horn

14. Cruise Control

15. Tilt Wheel Lever

(Power Tilt/Telescope Wheel Control

if equipped)

16. Parking Brake Pedal

17. Hood Release

18. Steering Wheel Climate System

Controls or optional Phone Controls

19. Turn Signal/Multifunctional Lever

20. Lighting Controls

21. 12V Power Outlet

(On front of passenger seat, near

umbrella tray)

INSTRUMENT PANEL DTS

20 19 18 17 16 1514 13 10

14 11 21

1345679

21 1 1

❏Reviewed with Customer (Please Check Box)

Refer to your Owner Manual for further information.

21 4 5 6 7 9

3 8

DIGITAL CLUSTER DeVille (available on DHS)

1. Odometer

2. Trip Odometer

3. Engine Coolant Temperature Gauge

4. PRND321 Indicator

5. Speedometer

6. High Beam Indicator Light

7. Turn Signal Indicator

8. Fuel Data Center

9. Traction Control System

Warning Light

10. Air Bag Ready Light

11. Brake System Warning Light

12. Seat Belt Reminder Light

13. Service Engine Soon Light

14. Antilock Brake System

Warning Light

15. Cruise Control Light

16. The Driver Information Center (DIC)

shows the status of many of your

vehicle’s systems; the DIC also

displays driver personalization

features and warning/status

messages

17. Charging System Light

18. Security Light

19. Oil Pressure Light

20. Engine Coolant Temperature

Warning Light

21. Exterior Lamps Indicator Light

20 19 18 17 16 15 14 13 10

Driver

Information

Audio Systems Comfort/

Convenience Personalization

Guide

Maintenance/

Owner Privileges™

Driver

Information

D E V I L L E

ANALOG CLUSTER DHS/DTS

1. Engine Coolant Temperature

2. Tachometer

3. PRND321 Indicator

4. Digital Speed Display

5. Turn Signal Indicator

6. Speedometer

7. Fuel Gauge

8. Traction Control System Warning

Light

9. Air Bag Ready Light

10. Parking Brake Indicator Light

11. Safety Belt Reminder Light

12. Antilock Brake System

Warning Light

13. Service Engine Soon Light

14. Cruise Control Light

15. Odometer

16. The Driver Information Center (DIC)

shows the status of many of your

vehicle’s systems; the DIC also

displays driver personalization

features and warning/status

messages

17. High Beam Indicator Light

18. Trip Odometer

19. Charging System Light

20. Security Light

21. Oil Pressure Light

22. Engine Coolant Temperature

Warning Light

23. Fog Lamp Indicator Light

(if equipped)

24. Exterior Lamps Indicator Light

134567 8

17 16 15 14 13 9

20 19 18

22 2124 23

❏Reviewed with Customer (Please Check Box)

Refer to your Owner Manual for further information.

Driver

Information

Audio Systems Comfort/

Convenience Personalization

Guide

Maintenance/

Owner Privileges™

DRIVER INFORMATION

CENTER CONTROLS

1. ENG/MET

Press this button to display

instrument cluster and climate

control information in English or

Metric.

2. DSPL MODE

Turns digital/analog display feature

on or off (analog only). Turns all

but speedometer off on digital

model.

3. RESET TRIP A/B

There are two trip odometers

Press the A/B portion of the

button to select and view the trip

odometers.

Press the reset portion of the button

to reset the displayed trip odometer.

4. INFO

Press this button’s up or down

arrow to display information such

as battery volts, oil life, average

miles per gallon, and outside air

temperature.

5. INFO RESET

Press this button to reset average

fuel economy, fuel used, average

speed, timer, oil life left, and

transmission fluid life.

To Use the Timer Functions:

•Press the INFO button (4) until the

timer function is displayed.

•Press the ON/OFF button (6) to

begin timing. Press button again to

stop timing.

•Press INFO/RESET (5) to return to

zero.

•Press the INFO button (4) until

display is off to exit.

356

D E V I L L E

Navigation/Radio System

AM/FM Stereo with Cassette and

Compact Disc Player

AM/FM Stereo with Cassette and

Compact Disc Player/RDS/DSP

(DHS & DTS if equipped)

AM/FM Stereo with Compact

Disc Player (Base System)

Audio Systems

Note: If your

vehicle is

equipped with the

Radio/Navigation

System, please

see your

NAVIGATION

SYSTEM

SUPPLEMENT for

operating

instructions.

❏Reviewed with Customer (Please Check Box)

Refer to your Owner Manual for further information.

Driver

Information

Audio Systems Comfort/

Convenience Personalization

Guide

Maintenance/

Owner Privileges™

AUDIO SYSTEM CONTROL

DESIGNATIONS AND

FUNCTIONS

PWR – Press to turn system

on or off.

VOL – Turn to control

volume.

RDS – Press to activate an

RDS function.

TA – Press to seek traffic

announcement.

MSG – Press to see

message when MSG is

displayed.

TUNE/SEEK – Press up

arrow to seek next station,

tape selection or disc track.

Press down arrow to seek

previous station, tape

selection or CD track.

SCAN – Press to scan

stations, tape selections or

CD tracks.

SOURCE – Press to select

tape or disc source.

BAND – Press to select

AM, FM or XM band.

– Press to eject tape

or disc.

SIDE – Press to play other

side of tape.

TONE – Up-level system:

Press and release to display

BALANCE, FADE, BASS,

TREBLE or MIDRANGE.

TONE ( ) – Base system:

Press TONE to select BASS,

TREBLE, or MIDRANGE.

Press speaker symbol to

select BALANCE or FADE.

- LEVEL + — Press to

select tone or speaker

level.

DSP – Press to turn DSP on

and continue to press and

release until desired

listening experience

appears in display. To turn

DSP off, press and hold

button until DSP OFF is

displayed.

1-6 – Base system: Press

to select discs loaded in

changer.

PTY – Press to select RDS

or XM listening category.

See Owner Manual for

complete instructions.

RDM – Press to listen to

CD tracks in random order.

DISC – Press to select next

disc if equipped with

changer.

RW (<< >>) – Press to

rewind tape or reverse

through track.

FF (<< >>) – Press to fast-

forward tape or advance

through track.

NEXT – Press to select next

tape selection or CD track.

PREV – Press to select

previous tape selection or

CD track.

D E V I L L E

PRESET STATIONS

• Turn radio on.

• Select band.

• Tune to desired station.

• Press one of six numbered buttons

for two seconds.

SETTING THE TIME

All radios:

• Press and hold HR button until

correct hour appears in display.

• Press and hold MN button until

correct minute appears in display.

• Display time when ignition is off

by pressing either HR or MN

button.

RDS radio only: To synchronize time

with RDS broadcast information:

• Press and hold HR and MN

buttons at same time until TIME

UPDATED is displayed. If time is

not available from station, NO

STATION TIME will be displayed.

LOADING CD CHANGER

• Slide the door of the changer

open. The magazine will eject only

when the door is completely open.

• Press the EJECT button to remove

the magazine. (The EJECT button is

on the upper left after the door is

opened. In this view, the button is

hidden by the closed door.)

• Load the trays into the magazine

from the bottom to the top,

placing the label side of the

CD up.

• To remove a tray, press the button

on the back of the magazine.

• Push the magazine into the

changer, following the direction of

the arrow marked on top of

the magazine.

Audio Systems

Otros manuales para 2005 DeVille

Tabla de contenidos

Otros manuales de Automóvil de Cadillac

Cadillac

Cadillac ESCALADE - BROCHURE 2009 Manual de usuario

Cadillac

Cadillac 1997 Catera Manual de lista de piezas

Cadillac

Cadillac 2004 ESCALADE Guía de referencia

Cadillac

Cadillac 2010 Escalade EXT Manual de usuario

Cadillac

Cadillac Escalade ESV 2012 Manual de usuario

Cadillac

Cadillac CTS-V SEDAN 2014 Manual de usuario

Cadillac

Cadillac ATS 2017 Manual de usuario

Cadillac

Cadillac 2014 Cadillac SRX Manual de usuario

Cadillac

Cadillac ESCALADE EXT 2005 Manual de usuario

Cadillac

Cadillac XT5 2017 Manual de usuario

Cadillac

Cadillac 2010 Escalade Manual de usuario

Cadillac

Cadillac ATS 2014 Manual de usuario

Cadillac

Cadillac Escalade EXT Manual de usuario

Cadillac

Cadillac 2010 Escalade Manual de usuario

Cadillac

Cadillac Escalade EXT 2006 Guía de referencia

Cadillac

Cadillac 2011 CTS-V Sports Sedan Manual de usuario

Cadillac

Cadillac 2007 STS-V Manual de usuario

Cadillac

Cadillac 2010 Escalade EXT Manual de usuario

Cadillac

Cadillac 2006 XLR Manual de usuario

Cadillac

Cadillac XLR 2006 Hoja de especificaciones

Cadillac

Cadillac 2015 XTS Manual de usuario

Cadillac

Cadillac Escalade 2016 Manual de usuario

Cadillac

Cadillac XT4 2020 Manual de usuario

Cadillac

Cadillac LYRIQ 2023 Manual de usuario

Manuales populares de Automóvil de otras marcas

Toyota

Toyota 2000 Tundra Manual de usuario

CITROËN

CITROËN DS4 DSign Manual de usuario

Lexus

Lexus 2015 CT 200h Manual de usuario

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Manual de usuario

Porsche

Porsche Boxster S Manual de usuario

GMC

GMC 2010 Savana 1500 Cargo Manual de usuario

KIAM

KIAM SPORTAGE 2014 Manual de lista de piezas

GMC

GMC 2013 Terrain Instrucciones de montaje

GMC

GMC T-Series 1999 Manual de usuario

Mercury

Mercury 1998 Mystique Manual de usuario

Mercury

Mercury 2007 Mariner Manual de usuario

Mazda

Mazda 2007 Mazdaspeed 3 Guía

Mazda

Mazda 2014 CX-5 Manual de usuario

GMC

GMC Chevrolet Express 2022 Manual de usuario

GMC

GMC 1997 Jimmy Manual de usuario

Chevrolet

Chevrolet 2012 Malibu Manual de usuario

Skoda

Skoda FABIA RS - ANNEXE 118 Manual de usuario

Seat

Seat toledo Manual de usuario
