Cable Electronics DVP14 Manual de usuario
DVP14
Video Wall Processor
LAUNAMNOITCURTSNI
DVI Output
Cascadable
4 Output Displays
Dual-View
THIS PAGE IS LEFT
INTENTIONALLY BLANK
1
Safety and Notice
The DVP14 DVI output Cascadable Video Wall Processor,
4-Display Dual-View has been tested for conformance to
safety regulations and requirements, and has been certi ed
for international use. However, like all electronic equipment,
the DVP14 should be used with care.
Please read and follow the safety instructions to protect your-
self from possible injury and to minimize the risk of damage to
the unit.
● Follow all instructions and warnings marked on this unit.
● Do not attempt to service this unit yourself, except where
explained in this manual.
● Provide proper ventilation and air circulation and do not
use near water.
● Keep objects that might damage the device and assure
that the placement of this unit is on a stable surface.
● Use only the power adapter and power cords and
connection cables designed for this unit.
● Do not use liquid or aerosol cleaners to clean this unit.
Always unplug the power to the device before cleaning.
2
Table of Contents
INTRODUCTION.............................................................3
FEATURES.......................................................................4
SPECIFICATIONS...........................................................5
PACKAGE CONTENTS..................................................6
INPUTS AND OUTPUTS...................................................6
SUPPORTED RESOLUTION.............................................7
HARDWARE INSTALLATION..........................................9
Installation Procedures ................................10
Connection Diagram ..................................11
OPERATION SOFTWARE.............................................12
System Requirement and Precautions ......12
Instruction of Software Connection ..........12
Instruction of Software Operation .............13
USING THE TV WALL CALCULATOR………………….17
TROUBLESHOOTING...................................................21
WARRANTY.................................................................22
3
INTRODUCTION
The DVP14 Cascadable Video Wall Processor, 4-Display Dual-
View DVI Output is a powerful most cost effective, and fully
real time data/video processor for multiple at panel displays
or projectors. With high-denition real-time DVI output, the
quality of the video wall is guaranteed. The output display
is scalable up to 255 by 255 squares.
Virtually any setup for the display layout may be possible by
the provided software. The DVP14 allows you to manipulate
two input videos, in any position and whatever sizes you want
for viewing. The embedded scaler converts signals from the
two input sources to match the native resolution of monitors,
at panel displays, and/or projectors.
Also, there are user-selectable output settings up to WUXGA
(1920x1200). The DVP14 sends the resulting mixed video thru
DVI interface to the connected monitors/projectors based on
the display layout. The layout can be readily modied to t
your applications and optimize visual effects. Typical applica-
tions include digital signage, Sport Bars, and broadcasting /
education / surveillance systems, etc.
This is a Video only processor and does not receive or output
any kind of audio.
4
Features
● Four DVI outputs from 640x480 to 1920x1200
● Local DVI loop output for monitoring the DVI input only
● Supports HDMI, DVI, S-Video, CVBS, Component, and VGA
input, from 640x480 to 1920x1200, interlaced or progressive
● Advanced video de-interlacing for improving 480i and 576i
SD video input
● PIP (picture-in-picture), PAP or PBP (Picture by Picture), Full
screen modes and adjustable size & position through
software
● Resize, position, ip, zoom output video
● Perfect as a video screen splitter, a video converter and
a video switcher
● Each DVI output has an independent controllable
display area
● User-selectable output settings, up to 1920x1200
● Can be cascaded to obtain larger display walls
● Image parameters and layouts are automatically saved
in ash memory of the device and can be recalled for
later use
● Several image parameters and layouts can be saved in the
controlling computer and can be loaded for later use
● Software control through RS-232
● Firmware upgradable for support of new features and
technology enhancements
● Built-in factory reset switch
● 2RU size for compact rack installations
DVP14
5
Model Name
Technical
Typical usage Video-wall processor
Output displays
Input Format
Support
Output Support
Video loop-out
HDCP compliance
Video bandwidth
Video support
Audio support
Control
PIP/PAP
Cascadable
Input TMDS signal
ESD protection
PCB stack-up
Input
Output
DVI connector
4
HDMI / DVI / VGA / YPbPr / S-Video / CVBS
[One digital and one analog can be used in PIP or PAP mode]
DVI (HDMI by adapter)
Yes, DVI
No
HDMI / DVI [Single-link 4.95Gbps] VGA [165MHz]
Up to 1920x1200@60 / 1600x1200@60
No
RS-232
Yes
Yes
1.2 Volts [peak-to-peak]
Human body model — ± 19kV [air-gap discharge]
& ±12kV [contact discharge]
6-layer board [impedance control — differential 100Ω; single 50Ω]
1x DVI + 1x VGA + 1x RS-232 1XS-Video, 1XCVBS
4x DVI
DVI-I [29-pin female, digital only]
VGA connector HD-15 [15-pin D-sub female]
RS-232 connector DE-9 [9-pin D-sub female]
RCA connector 75Ωfemale
RJ-45 connector WE/SS 8P8C with 2 LED indicators (Not in use)
Mechanical
Housing Metal enclosure
Dimensions
[L x W x H]
1'10" x 1'5" x 3. 5" [550 x 440 x 88mm]
Fixedness
1'11" x 1'8" x 9.1" [592 x 500 x 230mm]
Power supply
1'11" x 1'8" x 9.1" [592 x 500 x 230mm]
Power consumption
17.4 lbs [7900g]
Model
Package
Carton
20.9 lbs [9500g]
Model
Package
Weight
Operation temprature
Relative humidity
2RU rack-mount with ears
AC Power 100-240V
30 Watts [max]
32~95°F [0~35°C]
-4~140wF [-20~60°C]
20~90% RH [no condensation]
Specications
Storage temprature
6
Package Contents
Inputs and Outputs
● 1x DVP14
● 1x UL AC C13 power cord
● 1x VGA to component breakout cable
● 1x Composite, S-video breakout cable
● 1x DVI/VGA breakout cable
The DVP14 can use up to two inputs at one time and supports multiple in-
put interfaces (HDMI, DVI, composite, S-Video, component, VGA (adapters
needed)) and accepts both graphics and video signals, which come from
computers and NTSC / PAL video sources respectively. There is a concept
of main channel and sub channel for this device. You can select one of the
digital inputs and one of the analog inputs, and then the DVP14 will display
the mixed video on the connected 4 displays. With an advanced de-interlace
function built in, low resolution but popular video formats such as NTSC / PAL
will be improved.
The drawing below shows the rear panel connectors for the video inputs of a
DVP14. Please see the Connection Diagram later in this manual to see how
you can connect video devices and displays to the DVP14.
Rear Panel
1. Factory Reset switch:
Default: Turn on the DVP14 then switch both switches simultaneously up and down
to factory default mode.
2. Firmware Update Switch:
Normal operation: OFF, OFF
Firmware update mode: DOWN, DOWN
This Input, Outputs ports support a variety of resolutions from 640x480 up
to 1920x1200, for more information on the supported resolutions,
see "Supported Resolution".
● 1x Rack-mounting ear set
● 1x Installation software CD
● 1x User Manual
● 1x USB to RS-232 cable
● 1x DVI to VGA adapter
SEE NOTE: 1
SEE NOTE: 2
7
Supported Resolution
Supported Mode Resolution Supported Mode Resolution
480p / 525p 720x483 @60Hz MAC 832x624 @75Hz
480p (16:9) 960x483 @60Hz VESA 1024x768 @60Hz
576p / 625p 720x756 @50Hz MAC 1024x768 @60Hz
(HDTV) 720p 1280x720 @50Hz VESA 1024x768 @70Hz
(HDTV) 720p 1280x720 @60Hz IBM 1024x768 @72Hz
(HDTV) 1080p 1920x1080
@30Hz VESA 1024x768 @75Hz
VESA 720x400 @85Hz MAC 1024x768 @75Hz
VESA 640x350 @85Hz VESA 1024x768 @85Hz
VESA 640x400 @85Hz VESA 1152x864 @75Hz
IBM 720x400 @70Hz MAC 1152x870 @75Hz
IBM 720x350 @70Hz SUN 1152x900 @66Hz
IBM 640x350 @70Hz SUN 1152x900 @76Hz
IBM 640x400 @70Hz VESA 1280x960 @60Hz
VESA 640x480 @60Hz VESA 1280x960 @85Hz
MAC 640x480 @67Hz VESA 1280x1024 @60Hz
VESA 640x480 @72Hz HP 1280x1024 @60Hz
VESA 640x480 @75Hz IBM 1280x1024 @67Hz
VESA 640x480 @85Hz HP 1280x1024 @72Hz
VESA 800x600 @56Hz VESA 1280x1024 @75Hz
VESA 800x600 @60Hz SUN 1280x1024 @76Hz
VESA 800x600 @72Hz VESA 1600x1200 @60Hz
VESA 800x600 @75Hz VESA 1920x1200 @60Hz
VESA 800x600 @85Hz
[DVI-I digital only IN] Socket
Supported
Mode Resolution
(HDTV) 720p 1280x720 @50Hz
(HDTV) 720p 1280x720 @60Hz
(HDTV) 1080p 1920x1080 @60Hz
VESA 640x480 @60Hz
VESA 800x600 @60Hz
VESA 1024x768 @60Hz
VESA 1152x864 @75Hz
VESA 1280x1024 @60Hz
VESA 1280x1024 @50Hz
Supported
Mode Resolution
VESA 1280x768 @60Hz
VESA 1366x768 @60Hz
VESA 1400x1050 @60Hz
VESA 1400x1050 @50Hz
VESA 1152x864 @75Hz
VESA 1600x1200 @60Hz
VESA 1920x1200 @50Hz
VESA 1920x1200 @60Hz
[DVI-I digital only Out] Socket
8
Digital Visual Interface (DVI) to HDMI Female
The unit has DVI-I Female connectors for Input and Outputs:
Recommended Adapter Connector you can use from DVI to HDMI Female
DVI-I [29-pin Female, digital only]
DVI-I (Dal Link) to HDMI Female
DVI-D (Dual Link) to HDMI Female
