Bush BEUCL6082 Manual de usuario

Customer service manual

Built Under Larder

Contents

Precautions

Page 2

Door

Page 4

Thermostat Setting

Page 6

Replacement Lamp

Page 7

Replacement Door Switch

Page 8

Additional Support

Page 9

Precautions:

Always follow safety advice.

Always switch off and unplug the appliance before attempting to remove any part.

Always wear appropriate protective equipment when carrying out any work.

Always use the correct tools for carrying out any work.

Some repairs may not be suitable for unqualified users to carry out. If in doubt seek the advice of

a profession repairer.

SAFETY PRECAUTIONS

REPLACEMENT PROCEDURE

Applicable models

General

Part name

Door

A- Changing The Door Swing Direction to Right Hand

1- Unscrew the two screws fixing the top hinges (Fig-1) and bottom hinges. (Fig-2) Remove the doors. (Fig-1)

Figure 1

Figure 2

2. Remove the top hinge screw caps (big) on the left side (Fig-3) and insert them to the right side. (Fig-4)

Figure 3

Figure 4

3. Remove the bottom hinge screw caps (big) on the

left side and insert them to the right side. (Fig-5)

4. Unscrew the two screws fixing the top hinge and

bottom hinges. Remove the hinges. (Fig-6)

Figure 5

Figure 6

5. Assemble the top hinge to the bottom of the door (Fig-7) and assemble the door and then assemble the

bottom hinge to the top of the door. (Fig-8)

Figure 7

Figure 8

REPLACEMENT PROCEDURE

Applicable models

General

Part name

Door

B- Changing The Freezer Door Swing Direction

1- Unscrew the screw fixing the freezer door hinge (Fig-1) and remove the freezer door (Fig-2)

Figure 1

Figure 2

2- Unscrew the screw fixing the freezer door holder

and remove it. (Fig-3)

3- Screw the freezer door holder to the right side. (Fig-

Figure 3

Figure 4

4- Assemble the freezer door and fix the freezer door

hinge by tightening the screw. (Fig-5)

Figure 5

REPLACEMENT PROCEDURE

Applicable models

General

Part name

Thermostat

Setting

REPLACEMENT PROCEDURE

Applicable models

General

Part name

Replacement Lamp

Unscrew the screws which are fixing the lamp cover and change lamp.

REPLACEMENT PROCEDURE

Applicable models

General

Part name

Replacement the Door

Switch

Stick a tape to protect the body plastic. Flex it with the

help of a tool like a slotted screwdriver

Also flex the top-side of the switch and then displace

by pulling.

Put the switch connector cable in the housing. First place the top-side of the switch and then push the bottom

side.

After the switch is placed, complete the assembly by pushing.

ADDITIONAL SUPPORT

Applicable models

General

The following parts are available for the customer to undertake repairs at their own risk.

Please carefully follow the guidance given in this manual including all safety measures.

•Door Handles

•Door Hinges

•Trays

•Baskets

•Door Gaskets

Parts can be obtained by calling the support service listed in this section.

All repairs in this manual can be achieved using commonly available tools.

If you are in any doubt of your ability to carry out a repair, please use a professional repairer, also

available through the support service.

Damage sustained to the appliance or future faults arising from poorly carried out repairs will not be

covered under warranty.
