Instruction Manual Supplement

R5 Aqua version

Oil-Lubricated Rotary Vane Vacuum Pumps

RA 0165 D, RA 0205 D, RA 0255 D, RA 0305 D

RA 0400 C, RA 0502 C, RA 0630 C, RA 1000 B, RA 1600 B

0870524638/A0003_en / Original instructions / Modifications reserved 17/02/2021

Ateliers Busch S.A.

Zone industrielle, 2906 Chevenez

Switzerland

Table of Contents

2 / 12 0870524638_RA_Aqua_A0003_IMS_en

Table of Contents

1 Safety .......................................................................................................................................3

2 Introduction..............................................................................................................................4

3 Product Description ..................................................................................................................5

3.1 Application....................................................................................................................... 6

3.2 Standard Accessories ........................................................................................................ 6

3.2.1 Gas Ballast Valve ................................................................................................... 6

3.2.2 Thermostatic Valve................................................................................................ 6

3.2.3 Temperature Switch "Oil"..................................................................................... 6

3.3 Optional Accessories ........................................................................................................ 6

3.3.1 Inlet Filter ..............................................................................................................6

3.3.2 Water Separator ....................................................................................................6

4 Installation................................................................................................................................7

4.1 Connecting Lines / Pipes .................................................................................................. 7

4.1.1 Suction Connection ............................................................................................... 7

4.1.2 Discharge Connection ........................................................................................... 7

4.2 Electrical Connection of the Monitoring Devices............................................................... 7

4.2.1 Wiring Diagram Temperature Switch "Oil" ........................................................... 7

5 Technical Data..........................................................................................................................8

6 Oil ............................................................................................................................................8

Safety | 1

0870524638_RA_Aqua_A0003_IMS_en 3 / 12

1 Safety

Prior to handling the machine, this instruction manual should be read and understood. If

anything needs to be clarified, please contact your Busch representative.

Read this manual carefully before use and keep for future reference.

This instruction manual remains valid as long as the customer does not change anything

on the product.

The machine is intended for industrial use. It must be handled only by technically trained

personnel.

Always wear appropriate personal protective equipment in accordance with the local

regulations.

The machine has been designed and manufactured according to state-of-the-art meth-

ods. Nevertheless, residual risks may remain. This instruction manual highlights potential

hazards where appropriate. Safety notes and warning messages are tagged with one of

the keywords DANGER, WARNING, CAUTION, NOTICE and NOTE as follows:

DANGER

... indicates an imminent dangerous situation that will result in death or serious injuries if

not prevented.

WARNING

... indicates a potentially dangerous situation that could result in death or serious injuries.

CAUTION

... indicates a potentially dangerous situation that could result in minor injuries.

NOTICE

... indicates a potentially dangerous situation that could result in damage to property.

NOTE

... indicates helpful tips and recommendations, as well as information for efficient and

trouble-free operation.

2 | Introduction

4 / 12 0870524638_RA_Aqua_A0003_IMS_en

2 Introduction

NOTE

Instruction manual supplement.

This document is a supplement to the R5 instruction manuals which contents remain

valid.

It contains additional information in the following chapters: Product Description

[►5], Installation [►7] and Technical Data [►8].

Product Description | 3

0870524638_RA_Aqua_A0003_IMS_en 5 / 12

3 Product Description

INIF GB1 GB2

OUTTS

INIF GB

OUT

RA 0165-0305 D Aqua

RA 0400-0630 C Aqua

IF GB1

WS1

OUT1GB2WS2OUT2

RA 1000-1600 B Aqua

CD2

CD1

IN Suction connection IF Inlet filter

OUT Discharge connection CD Condensate drain

TS Temperature switch WS Water separator

NOTE

Illustrations

In this instruction manual the illustrations may differ from the machine appearance.

3 | Product Description

6 / 12 0870524638_RA_Aqua_A0003_IMS_en

3.1 Application

The machine is intended for the suction of gases which contain a high percentage of wa-

ter vapour.

Other agents should not be transported. In case of doubt, please contact your Busch

representative.

3.2 Standard Accessories

3.2.1 Gas Ballast Valve

The gas ballast valve mixes the process gas with a limited quantity of ambient air to

counteract the condensation of vapour inside the machine.

The gas ballast of the Aqua version has a larger air volume flow than a standard R5.

The gas ballast valve has an influence on the ultimate pressure of the machine, see Tech-

nical Data [►8].

3.2.2 Thermostatic Valve

It allows to fix a higher operating temperature than a standard R5.

3.2.3 Temperature Switch "Oil"

The temperature switch monitors the oil temperature of the machine.

It has two switch points.

Depending on the oil type, the machine must be stopped when the oil reaches a certain

temperature, see Oil [►8].

3.3 Optional Accessories

3.3.1 Inlet Filter

The inlet filter protects the machine against dust and other solids in the process gas. The

inlet filter is available with a polyester cartridge.

3.3.2 Water Separator

It allows to retrieve a certain amount of condensate at the machine exhaust. It is

equipped with a drain plug at its bottom.

Installation | 4

0870524638_RA_Aqua_A0003_IMS_en 7 / 12

4 Installation

4.1 Connecting Lines / Pipes

• Remove all protective covers before installation.

• Make sure that the connection lines cause no stress on the machine‘s connection; if

necessary use flexible joints.

• Make sure that the line size of the connection lines over the entire length is at least as

large as the connections of the machine.

In case of very long connection lines it is advisable to use larger line sizes in order to

avoid a loss of efficiency. Seek advice from your Busch representative.

4.1.1 Suction Connection

Connection size(s):

– Ø60 mm hose for RA 0165-0305 D

– Ø90 mm hose for RA 0400-0630 C

– DN150 PN16, EN 1092-1 for RA 1000-1600 B

The inlet connection may be equipped with a ball valve.

Depending on the specific order, other connection dimensions may apply.

4.1.2 Discharge Connection

Connection size(s):

– G2 for RA 0165-0305 D

– G3 for RA 0400-0630 C

– 2x DN125 PN16, EN 1092-1 for RA 1000-1600 B

Depending on the specific order, other connection dimensions may apply.

4.2 Electrical Connection of the Monitoring Devices

4.2.1 Wiring Diagram Temperature Switch "Oil"

Part no.: 0651563747

Connector: M12x1, 4-pin

Electrical data:

U = ≤ 250 V AC/DC (50/60 Hz) ; I = ≤ 1 A

Switch point:

T1 pin 1 + 2 = 110 °C*

T2 pin 3 + 4 = 130 °C*

1 2

4 3

1 = Brown ; 2 = White ;

3 = Blue ; 4 = Black

* The switch point value depends on the oil type, see Oil [►8].

5 | Technical Data

8 / 12 0870524638_RA_Aqua_A0003_IMS_en

5 Technical Data

RA 0165 D RA 0205 D RA 0255 D RA 0305 D

Nominal pumping speed

(50Hz / 60Hz)

m³/h 160 / 190 200 / 240 250 / 300 300 / 360

Ultimate pressure hPa (mbar) abs. < 5

Water vapour tolerance max. hPa (mbar) 200

Water vapour capacity

(DIN 28426-1)

(50Hz / 60Hz)

kg / h 23 / 27 26 / 31 35 / 41 39 / 47

RA 0400 C RA 0502 C

Nominal pumping speed

(50Hz / 60Hz)

m³/h 410 / 480 510 / 590

Ultimate pressure hPa (mbar) abs. < 5

Water vapour tolerance max. hPa (mbar) 200

Water vapour capacity

(DIN 28426-1)

(50Hz / 60Hz)

kg / h 60 / 70 75 / 90

RA 0630 C RA 1000 B RA 1600 B

Nominal pumping speed

(50Hz / 60Hz)

m³/h 630 / 760 1000 / 1200 1600 / 1800

Ultimate pressure hPa (mbar) abs. < 5

Water vapour tolerance max. hPa (mbar) 100

Water vapour capacity

(DIN 28426-1)

(50Hz / 60Hz)

kg / h 50 / 60 89 / 160 99 / 160

6 Oil

VSC 100 VSB 100

ISO-VG 100 100

Oil type Synthetic oil Synthetic oil

Part number 1L packaging 0831 168 356 0831 168 351

Part number 5L packaging 0831 168 357 0831 168 352

Part number 10L packaging 0831 210 162 -

Part number 20L packaging 0831 168 359 0831 168 353

Warning signal

Oil temperature [°C]

110 110

Switch point / Trip signal

Oil temperature [°C]

130 130

In case of unfavourable ambient temperature, other oil viscosities may be used. Please consult your Busch repre-

sentative for more details.

To know which oil has been filled in the machine, please refer to the nameplate (NP).
