Burg M.options sPinLock 200 Manual de usuario

sPinLock 200

www.burg.de

Operating manualGB

sPinLock 200

sPinLock 200 |March 2018 01- AN/DSW English ǀ 2

sPinLock 200

Indicator

Close position

Open position

Guide-Line

Contents

Default settings ...................................................... 2

Technical specifications ........................................... 2

Configuration ...................................................... 2-3

Finding the code by masterkey................................. 3

Installation ............................................................ 3

configuration

Default Settings

Out of the packaging, the resettable combination lock can

be opened using the number combination 0-0-0-0, even

though the number dials may be in other positions.

Number combination 0-0-0-0

Number dials

Rotary knob

1. Putting the lock in the disengaged state

The lock has to be in the disengaged state. To do so, the

dials must be turned to the current code (default setting 0-

0-0-0). Then turn the knob 90° clockwise until the open

position is reached.

Technical specifications

Dimensions Ø 5,96 cm x 5,22 cm

Material Casing: plastic

Color black

Mounting hole 16 mm x 19 mm

Number of dials 4

Number of possible codes 9.999

Default settings 0-0-0-0

Locking direction L, R, LAD

Lock attachement M19 Nut

Latch Zinc (nickel-plated)

2. Setting the number combination

The desired number combination can be set by turning the

number dials while the lock is in the disengaged state.

sPinLock 200 |March 2018 01- AN/DSW English ǀ 3

Important: A new code can be set any time the lock is in

the disengaged state. Only the code used to engage the lock

can be used to disengage it again. This makes the lock sui-

table for use by several persons.

Turning the knob 90° counterclockwise to the close

position will end the configuration process. Turning the

number dials while the knob is in the close position will

engage the lock.

Finding the code by masterkey

1. Inserting the master key

Insert the master key an turn it 90° clockwise to align it

with the open position.

2. Turning the number dials

Turn the number dials carefully until they stop. It is

important to turn the dials bottom-up one by one, starting

from the leftmost dial and working your way toward the

right.

3. Removing the masterkey

Turn the masterkey 90° counterclockwise and pull it out. In

this state, you will be able to read out the current code and

open the lock.

Installation

Mounting hole: 16 x 19 mm

BURG F.W. Lüling KG

Hegestraße 6

58300 Wetter (Germany)

Fon + 49 (0) 2335 / 63 08-0

Fax + 49 (0) 2335 / 63 08-999

[email protected]

www.burg.de
