Bunn H5E Manual de usuario
Features
Related Products
Item#
Project
Dat e
For current specification sheets and other information, go to www.bunn.com.
Patents Apply 09/07 E2
5 Gallon Hot Water Machine
• Dispensesupto18gallons(68.14liters)ofboilingwater(H5X)perhourfor
foodprepandcleaning.
• Precisetemperature(72º–212ºF)(22.2ºC-100ºC)ensuresconsistent,high
qualityresults.
• Locatehotwateratpreparationsitetoincreasespeed,safetyandefciency
ofkitchenstaff.
• Preparelargeamountsofmashedpotatoes,gravy,cheesesauce,gelatin,
oatmeal,&manymorefoods.
• Internationalelectricalcongurationsavailable.
• Availablewith3”and8”faucetextensions.
Model H5E/H5X*
Dimensions:28.5”Hx7.1”Wx17.5”D
(72.4cm H x 18.03cm W x 44.5cm D)
* International models may vary in appearance.
Model Agency Listing
H5E
H5X
5 Gallon Hot Water Machine
Easy Clear®EQ-11-TL
ProductNo.:30344.1001
Dimensions:
15
7
⁄
8
"Hx
3
5
⁄
8
"Wx
4
17
⁄
32
"D
40.3cmHx9.2cmWx11.5cmD
Easy Clear®ED-11-TL
ProductNo.:30244.1001
Dimensions:
14
3
⁄
16
"Hx
5
1
⁄
16
"Wx
5
1
⁄
16
"D
36cmHx12.9cmWx12.9cmD
1. Wall Mount Bracket (side)
ProductNo.:12542.0000
Dimensions:30"Hx131⁄2"Wx41⁄2"D
76.2cmHx34.29cmWx11.43cmD
2. Wall Mount Bracket (front)
ProductNo.:13125.0001
Dimensions:301⁄2"Hx81⁄2"Wx151⁄4"D
77.47cmHx21.59cmWx38.74cmD
3. Container Holding Shelf
ProductNo.:12599.0000
Dimensions:63⁄4"Wx21"D
17.15cmWx53.34cmD
4. Drip Tray
ProductNo.:02597.7998
E9006.7001B
BUNN®practicescontinuousproductresearchandimprovement.Wereservetherighttochangespecicationsandproductdesignwithoutnotice.Such
revisionsdonotentitlethebuyertocorrespondingchanges,improvements,additionsorreplacementsforpreviouslypurchasedequipment.
Alldimensionsshownininches. Bunn Corporation owns all copyrights relating to materials in this publication. Please contact Bunn Corporation to request permission to reproduce any portion of this publication.
Dimensions & Specifications
Bunn-O-MaticCorporationofCanada-280IndustrialPkwy.S.Aurora,OntarioL4G3T9•905-841-2866•Fax905-841-2775•www.bunn.com
CANADA
Model Product # Volts Amps Tank Total ˚F/˚C Capacity/Hr. Capacity/Hr. Cubic Weight Cord
Heater Watts Settings cold water hot water ft
3
/m
3
lbs/kgAttached
Watts input 35˚F/1.7˚C input 140˚F/60˚C
H5E-15-120 12500.6031 120 12.5 1500 1500 155-200/68.3-93.3Varies with application 4.1/.116 34/15.4 Yes*
H5E-15-120 12500.6000 120 12.5 1500 1500 85-115/29.4-46.1Varies with application 4.1/.116 34/15.4 Yes*
H5E-40-208 12500.6008 208 19.2 4000 4000 200/93.3Varies with application 4.1/.116 34/15.4 No
H5X-40-240 12500.6004 240 16.7 4000 4000 212/100 7.3gal/27.6liter 14.7gal/55.7liter 4.1/.116 34/15.4 No
H5X-40-208 12500.6002 208 19.2 4000 4000 212/100 7.3gal/27.6liter 14.7gal/55.7liter 4.1/.116 34/15.4 No
H5X-15-120 12500.6001 120 12.5 1500 1500 212/100 3.7gal/14.0liter 8.1gal/30.7liter 4.1/.116 34/15.4 Yes*
H5X-60-240 12500.6005 240 25.0 6000 6000 212/100 9.9gal/37.5liter 18.6gal/70.5liter 4.1/.116 34/15.4 No
H5X-60-208 12500.6003 208 28.8 6000 6000 212/100 9.9gal/37.5liter 18.6gal/70.5liter 4.1/.116 34/15.4 No
*Power cord (NEMA 5-15P) 15 Amp-120V machine only.
Electrical: Models-15Modelshaveattachedcordsetandrequire2-wiregroundedservicerated120V,singlephase,60Hz.
Othermodelsrequire2-wiresplusgroundservice,single-phase.Suppliedstrainreliefonrearsideofmachine.
Plumbing: 20-90psi(138-621kPa).Machinesuppliedwith1⁄4"(6.3mm)ODmalearetting.
7!4%23500,9
#/..%#4)/./$
45"%8&,!2%
342!).%2&,/7
#/.42/,-/5.4%$
).4%2.!,,9
0/7%23500,9
#/..%#4)/.
