Buick Enclave Instrucciones de montaje

Review this Quick Reference Guide for an overview of some important features in your Buick Enclave.

More detailed information can be found in your Owner Manual. Some optional equipment described in

this guide may not be included in your vehicle.

If you have additional questions about the features and controls in your vehicle, press the blue OnStar

button to speak with a customer assistance representative who can provide more information.

www.buick.com

Ambient Light

Control

Exterior Lamps

Control

Instrument Panel

Tilt/Telescope

Steering Wheel

Lever

Instrument Panel

Illumination Control/

Dome Lamp Off Button

Symbols

Low Fuel

Traction Control Off

Engine Coolant

Temperature

Brake System

Cruise Control Set

Low Tire Pressure

StabiliTrak Active

StabiliTrak Off

Security

Check Engine

Oil Pressure

Charging System

Safety Belt Reminder

Airbag Readiness

Antilock Brake

System

Side Blind Zone Alert

Cruise Control

Buttons

Driver

Information

Center

Audio Steering

Wheel ControlsF

Turn Signal

Lever/Windshield

Wipers Lever

Refer to your Owner Manual to learn about the information being relayed by the lights, gauges and

indicators on the instrument cluster.

See In Brief in your Owner Manual.

F Optional equipment

Driver

Information

Center

ButtonsF

Audio System/

Navigation

SystemF

Climate

Controls

Hazard Warning

Flashers Button

USB Port

(inside storage

compartment)

Accessory

Power Outlet

Driver’s Heated/

Cooled Seat

ButtonsF

Rear Wiper Switch/

Traction Control Off Button/

Tow/Haul Mode ButtonF/

Power Liftgate SwitchF

Passenger’s

Heated/Cooled

Seat ButtonsF

Front Seats

A. Seat Adjustment

Move the horizontal control to move the

seat forward or rearward and to raise,

lower or tilt the seat.

B. Seatback Recline Adjustment

Move the vertical control to recline or

raise the seatback.

C. Lumbar AdjustmentF

Press the switch to adjust the amount of

lumbar support.

D. Lumbar Adjustment

Pull up/push down the lever on the

inboard side of the seatback to adjust

the amount of lumbar support.

Power Seats

Head Restraint

Manual Lumbar

A B C

FOptional equipment

The driver and front passenger head

restraints are adjustable.

Press the button on the left side of the

head restraint and then raise or lower

the head restraint, or slide it forward or

rearward.

See Seats and Restraints in your Owner Manual.

2nd-Row Seats

Slide the Seat

1. Make sure nothing is on the 2nd-row

seat or the oor in front of or behind

the seat.

2. Fold up the armrest(s).

3. Rotate the release lever (A) on the

upper-outboard side of the seatback

forward.

4. Push the top of the seatback forward.

The seat cushion will fold and the entire

seat will slide forward.

5. After entering/exiting, push the top of

the seatback rearward until the seatback

and oor tracks lock.

6. Push down at the rear of the seat cush-

ion to lock it in place.

1. Make sure nothing is on the oor in front

of or behind the 2nd-row seat.

2. Pull outward on the handle (B) on the

outboard side of the seat cushion and

slide the seat forward or rearward.

3. Release the handle.

1. Make sure the seat is all the way rear-

ward (when folding the seat) and the

armrest(s) are upright.

2. Pull forward on the strap (C) on the

outboard side of the seatback.

3. Fold down or recline the seatback.

Fold/Recline the Seatback

See Seats and Restraints in your Owner Manual.

Enter or Exit the 3rd-Row Seats

Lighting

Off/On

AUTO Automatic Headlamp System

Activates the Daytime Running Lamps (DRLs) in the

daytime and the headlamps and other exterior lamps at

night or when necessary.

Parking Lamps

Headlamps

Ambient Off

The ambient lighting illuminates across the instrument

panel. Press the button to turn the ambient lighting on or

off. Turn the instrument panel brightness knob to adjust the

lighting. The headlamps must be on for the ambient lighting

to operate.

Note: Only the instrument panel ambient lighting, not the door

panel ambient lighting, can be turned off.

Instrument Panel Brightness

Press the small knob to extend it. Turn the knob to adjust

the instrument panel lighting. Turn the knob fully to turn on

the dome lamps when all doors are closed.

Dome Off

Press the button to turn off the dome lamps. The button

indicator will illuminate when the dome lamps are turned off.

With the button depressed, the dome lamps will not turn on

when a door is open.

Press the button again to have the dome lamps turn on

when a door is open.

See Lighting in your Owner Manual.

Exterior Lamps

Rotate the knob to operate

the exterior lamps.

Ambient Lighting

Interior Lighting

Dome Lamps

Audio Steering Wheel Controls

Cruise Control

F Optional equipment

Volume

Pull up the +or –button to adjust the

volume.

SRCE Source

Press to select an audio source.

Next/Previous

Press the up or down arrow to go to the

next or previous favorite radio station,

track, or le.

Seek

Press to go to the next radio station on the

same band or CD track.

Push to Talk

Press to start voice recognition to

interact with the audio, OnStar®, Bluetooth

or navigationFsystem.

Press and hold to mute the speakers.

End Call/Mute

Press to end or reject an OnStar or a

Bluetooth call.

Setting Cruise Control

1. Press the On/Off button. The

Cruise Control symbol will illuminate in

white on the instrument cluster.

2. When traveling at the desired speed,

press the SET/– button to set the speed.

The symbol will illuminate in green

on the instrument cluster.

Adjusting Cruise Control

RES/+ Resume/Accelerate

Press to resume a set speed.

When the system is active, press to

increase speed.

SET/– Set/Coast

When the system is active, press to

decrease speed.

Cancel

Press to cancel the cruise control but retain

the set speed in memory.

Pressing the brake pedal also will cancel

the cruise control.

The cruise control set speed is erased

when cruise control or the vehicle ignition

is turned off.

See Driving and Operating in your Owner Manual.

Infotainment System

VOL

Volume/ Power

Eject disc

TUNE/MENU:

Tune radio stations/

Open and select

menus

FAV:

Display pages

of favorite radio

stations

HOME

Home page

BACK:

Move back

one level in the

menus

SEEK:

Previous/Next

radio station,

track or le

SRCE:

Select the

audio or media

source

Auxiliary input

jack

The infotainment system is controlled using the faceplate buttons, touch screen, voice

recognition and audio steering wheel controls.

See Infotainment System in your Owner Manual.

Infotainment System

F Optional equipment

Refer to your Owner Manual for important safety information about using the infotainment system

while driving.

Setting the Time

1. Touch the Time Display on the touch screen.

2. Touch the desired down or up screen button to adjust the time.

3. Touch the OK screen button to conrm the setting.

Storing Favorite Stations

Radio stations from all bands (AM, FM or XMF) can be stored, in any order, on up to six

pages of favorites.

1. Tune in the desired radio station.

2. Press and hold one of the six preset screen buttons until a beep is heard.

3. Repeat the steps for each desired station.

Home Page

Adding Home Page Screen Buttons

1. Press the

HOME

Home button.

2. Touch the Menu screen button.

3. Touch Customize.

4. Touch a button to add or remove. Up to

eight screen buttons can be displayed.

5. Touch Done.

Moving Home Page Screen Buttons

1. Press the

HOME

Home button.

2. Touch the Menu screen button.

3. Touch Sort.

4. Touch the screen button to be moved

and the screen button for the new

location.

5. Touch Done.

A USB portFis located in the upper

instrument panel storage compartment.

• An iPod™, iPhone™, MP3 Player, a

USB ash drive or a USB mass storage

device can be connected to the USB

port. Compatible devices connected to

the USB port can be controlled by the

audio system. Not all devices may be

supported. Use the audio controls and

audio steering wheel controls to access

various functions.

Portable Audio Devices

Note: Connect an iPod/iPhone USB cord after

starting the vehicle for optimum performance.

See Infotainment System in your Owner Manual.

Bluetooth® System

Before using a Bluetooth-enabled device in the vehicle, it must be paired with the

in-vehicle Bluetooth system. Not all devices will support all functions. Bluetooth

streaming audio is available with the IntelliLink system.FFor more information, visit

www.gm.com/bluetooth.

Pair a Phone

1. To use voice recognition, press the Push to Talk button; after the beep, say

“Pair phone.”

To use the screen buttons, press the Settings screen button and then touch Bluetooth

Device List > New Device.

2. Start the pairing process on the phone.

Locate your vehicle name on the phone.

3. Enter the four-digit code that appears

on the touch screen into the phone or

conrm the six-digit code on the phone.

4. If your phone prompts you to accept the

connection or phone book download,

click “yes” and always allow.

Streaming Audio

With a paired device connected via Bluetooth, select Bluetooth Audio on the home screen

to stream audio from the device. Control audio operation using the device controls.

See Infotainment System in your Owner Manual.

IntelliLink uses a Bluetooth or USB connection to link a smartphone, cell phone, USB ash

drive or portable audio player/iPod™ to the touch screen infotainment display. It offers

a variety of entertainment options, including streaming audio from the Internet through a

smartphone, and features enhanced hands-free voice control, music information and the

ability to play music les from a USB ash drive.

For assistance with Bluetooth pairing, application downloading and installation, mobile

device compatibility, and operation of the IntelliLink system, contact Customer Assistance

at 1-855-4-SUPPORT (855-478-7767) or visit www.buick.com/intellilink.

See Infotainment System in your Owner Manual.

Buick IntelliLink

FOptional equipment

Otros manuales para Enclave

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Automóvil de Buick

Buick

Buick 2012 LaCrosse Manual de usuario

Buick

Buick 2005 Rendezvous Manual de usuario

Buick

Buick 2004 LeSabre Manual de usuario

Buick

Buick 2006 Lucerne Manual de usuario

Buick

Buick 2004 Park Avenue Manual de usuario

Buick

Buick ENCLAVE - 2011 Manual de usuario

Buick

Buick Encore GX 2023 Manual de usuario

Buick

Buick 2016 LaCrosse Instrucciones de montaje

Buick

Buick 1994 LeSabre Manual de usuario

Buick

Buick 2018 REGAL SPORTBACK Manual de usuario

Buick

Buick Enclave 2015 Manual de usuario

Buick

Buick 1998 Riviera Manual de usuario

Buick

Buick Lacrosse2018 Instrucciones de montaje

Buick

Buick 2002 LeSabre Manual de usuario

Buick

Buick 2004 Rendezvous Manual de usuario

Buick

Buick VERANO 2014 Manual de usuario

Buick

Buick LaCrosse Manual de usuario

Buick

Buick 1993 Roadmaster Manual de usuario

Buick

Buick 2003 Rendezvous Manual de usuario

Buick

Buick 2011 Regal Manual de usuario

Buick

Buick ENVISION 2019 Instrucciones de montaje

Buick

Buick 2016 Envision Manual de usuario

Buick

Buick 40 Series 1948 Guía de instalación

Buick

Buick 2011 Regal Manual de usuario

Manuales populares de Automóvil de otras marcas

Toyota

Toyota 2000 Tundra Manual de usuario

CITROËN

CITROËN DS4 DSign Manual de usuario

Lexus

Lexus 2015 CT 200h Manual de usuario

Cadillac

Cadillac CTS 2008 Manual de usuario

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Manual de usuario

Porsche

Porsche Boxster S Manual de usuario

GMC

GMC 2010 Savana 1500 Cargo Manual de usuario

KIAM

KIAM SPORTAGE 2014 Manual de lista de piezas

GMC

GMC 2013 Terrain Instrucciones de montaje

GMC

GMC T-Series 1999 Manual de usuario

Mercury

Mercury 1998 Mystique Manual de usuario

Mercury

Mercury 2007 Mariner Manual de usuario

Mazda

Mazda 2007 Mazdaspeed 3 Guía

Mazda

Mazda 2014 CX-5 Manual de usuario

GMC

GMC Chevrolet Express 2022 Manual de usuario

GMC

GMC 1997 Jimmy Manual de usuario

Chevrolet

Chevrolet 2012 Malibu Manual de usuario

Cadillac

Cadillac 2010 Escalade Manual de usuario
